Advidia B-31 Manuel utilisateur

B-31 User’s Manual

3.6x

Zoom

H.264

4-Megapixel

D/N

Vandal-

Proof

PoE

Rugged Dome with

P-Iris &

ExDR

B-31 User’s Guide

Table of Contents

Precautions 3

Introduction 4

Package Contents............................................................................. 4

FeaturesandBenefits.......................................................................5

SafetyInstructions............................................................................ 7

Physical description................................................................................

Product Specification ...........................................................................

InstallationProcedure 14

Connecting the IP Outdoor Rugged Dome .................................14

1) Remove the cover................................................................. 14

2) Insert the cable..................................................................... 14

3) Connect cables to connectors.............................................14

How to Do the Waterproof Installation......................................... 15

AccessingCamera 18

If you have DHCP server / router in your network ........................ 18

If you do NOT have DHCP server / router in your network:.......... 18

B-31 User’s Guide

Precautions

Read these instructions

You should read all the safety and operating instructions before using this product.

Heed all warnings

You must adhere to all the warnings on the product and in the instruction manual. Failure to

follow the safety instruction given may directly endanger people, cause damage to the system

or to other equipment.

Servicing

Do not attempt to service this video device yourself as opening or removing covers may

expose you to dangerous voltage or other hazards.Refer all servicing to qualified service

personnel.

Trademarks

All names used in this manual are probably registered trademarks of respective companies.

Liability

Every reasonable care has been taken during the writing of this manual.Please inform your

local office if you find any inaccuracies or omissions.Wecannot be held responsible for any

typographical or technical errors and reserve the right to make changes to the product and

manuals without prior notice.

FCC/CERegulation

NOTE:This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment.This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual, maycause harmful

interference to radio communications.Operation of this equipment in a residential area is likely

to cause harmful interference in which case the users will be required to correct the

interference at their own expense.

B-31 User’s Guide

Introduction

Package Contents

3.6x Zoom H.264 4-Megapixel IP D/N

Vandal Proof PoE Rugged Dome QIG

Product CD Terminal Blocks for Power DI/O and Audio

Accessories

DrillTemplate

B-31 User’s Guide

FeaturesandBenefits

This is a cutting edge network video surveillance camera.It can capture, compress and

transmit real time video in excellent quality (8 FPS 4Megapixel, 2032 x 1920).This camera is

your best choice to build an intelligent IP surveillance system.

Adaptive Profile

With the innovative embedded Image Signal Processor (ISP), this camera responds to

changing lighting condition with customized algorithm.This allows for clear image with very

little noise at night.

H.264/MPEG-4/MJPEG Triple Codec Dual Streaming

This device supports 3 compression formats, H.264, MPEG-4 and MJPEG.It brings superior

image quality at 8 frames per second up to resolution of 2032 x 1920 pixels, and offers up to 15

frames per second in Full HD 1080p (!920 x 1080).In 720p (1280 x 720) and VGA resolution

(640 x 480) the device reaches 30 frames per second.

Rugged Vandal-Proof Construction withstands all kinds of abuse.

Special engineer polymer clear dome shell protects against brute force impact.It is extremely

durable against any tampering intruder.IP66 construction isolates electronics against the

elements.Rain, sleet or snow, nothing goes through.Temperature control ensures cold-start

capability for use in the worst of weathers.

ExDR (Extreme Dynamic Range)

Extreme Dynamic Range technology is the most advanced approach of improving the dynamic

range of the camera.While many other WDR technologies enhance the dynamic range while

producing noise, blur edges of objects and untrue colors, ExDR is designed to improve the

dynamic range while keeping the true colors, sharp edges of objects and free from noise.

P Iris Control

With optional P Iris Lens, this camera automatically adjusts incoming light levels to achieve the

best video performance.Wildly fluctuating outdoor lighting condition is no longer an issue with

your video quality.

B-31 User’s Guide

Powerful Bundled Surveillance Software

To extend the capabilities of the IP Dome Camera series, a powerful surveillance program is

included in the package for free.Users can easily use an existing PC as a digital video recorder.

Scheduled recording and manual recording keep every important video recorded in the local

hard disk.Reliable and accurate motion detection with instant warning enables immediate

response in everycondition. Quick and simple search and playback function lets you easily find

the images and video you want.

B-31 User’s Guide

Safety Instructions

Don’t use the power supply with other voltages

This device is likely to be damaged or damage other equipment / personnel, if you use a

power supply with different voltage than the one included with this device. All warranty of this

product will be voided in the situations above.

Don’t open the housing of the product

Cleaning

Disconnect this video product from the power supply before cleaning.

Attachments

Do not use attachments not recommended by the video product manufacturer as they may

causehazards.

Water and Moisture

Do not use this video product near water, for example, near a bathtub, washbowl, kitchen sink,

or laundry tub, in a wet basement, or near a swimming pool and the like.

Don’t use accessories not recommended by the manufacturer

Only install this device and the power supply in a dry place protected from weather

Servicing

Do not attempt to service this video product yourself as opening or removing covers may

expose you to dangerous voltage or other hazards. Refer all servicing to qualified service

personnel.

Damage Requiring service

Disconnect this video product from the power supply immediately and refer servicing to

qualified service personnel under the following conditions.

When the power-supply cord or plug is damaged

If liquid has been spilled, or objects have fallen into the video product.

If the video product has been directly exposed to rain or water.

If the video product does not operate normally by following the operating Instructions in

B-31 User’s Guide

this manual.Adjust only those controls that are covered by the instruction manual, as an

improper adjustment of other controls may result in damage, and will often require

extensive work by a qualified technician to restore the video product to its normal

operation.

Safety Check

Upon completion of any service or repairs to this video product, ask the service technician to

perform safety checks to determine if the video product is in proper operating condition.

B-31 User’s Guide

Physical Description

Power Button

Press the Power Button and then camera will reboot automatically.

Ethernet Port

The IP device connects to the Ethernet via a standard RJ45 connector.Supporting NWAY,this

IP device can auto detect the speed of local network segment (10Base-T/100Base-TX

Ethernet).

Reset Button

Step 1: Switch off IP device by disconnecting the power cable

Step 2: Press and continue to hold the Reset Button (with a sharp tipped object, like a pen.)

Step 3: Reconnect the power cable while continuing to hold the reset button. The red

Power LED light will flash on for 3 second first, turn off for about 15 seconds, flash on for

another second and turn off again. By this time the reset to default operation is already

completed.This will take around 20 seconds from power up. You may then release the

reset button.This length of time fluctuates slightly with the environment.The Power LED light

will come back on and stay on after a few more seconds.The unit will start up with factory

defaultsettings automatically.

B-31 User’s Guide

Power On

Restore to Default

Complete

On (3s)

Off (about 15s)

Off (10~15s)

About 20 Seconds

Micro SD / Micro SDHC Card Slot*

Insert your Micro SD card here for local recording on camera

Audio Input / Output

The IP device supports audio input and output via terminal block

DC 12V Power Input

Connect DC power source to the terminal block.The wire with white dashed lines is the live

wire, which should connect to the 12V pin.

Digital Input / Output

Used in applications like motion detection, event triggering, time lapse recording, alarm

notifications, etc., the I/O terminal connector provides the interface to:

2 transistor output - For connecting external devices such as relays and LEDs.

Connected devices can be activated by Output buttons on the LiveView page or through

video management software.Connect Pin 2 with 4 or 6 with 8.

2 Digital Input - An alarm input for connecting devices that can toggle between an open

and closed circuit, for example:PIRs, door/window contacts, glass break detectors, etc.

The device will detect the change in digital input and transmit the signal to video

surveillanceservers.

NAME

DESCRIPTION

AC Power Input

GND

E-Ground of power

Stay On
