Advantech PCL-734 Manuel utilisateur
PCL-734
32-channel Isolated
Digital Output Card
Copyright
This documentation is copyrighted 1996 by Advantech Co., Ltd. All
rights are reserved. Advantech Co., Ltd. reserves the right to make
improvements in the products described in this manual at any time
without notice.
No part of this manual may be reproduced, copied, translated or
transmitted in any form or by any means without the prior written
permission of Advantech Co., Ltd. Information provided in this
manual is intended to be accurate and reliable. However, Advantech
Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties which may result from its use.
Acknowledgments
PC-LabCard is a trademark of Advantech Co., Ltd. IBM and PC are
trademarks of International Business Machines Corporation. MS-
DOS, Microsoft C and Quick BASIC are trademarks of Microsoft
Corporation. BASIC is a trademark of Dartmouth College. Intel is a
trademark of Intel Corporation. TURBO C is a trademark of Borland
International.
Part No. 2003734000 1st Edition
Printed in Taiwan April 1996
Contents
Chapter 1 General information ............................................. 1
Introduction........................................................................... 2
Features .................................................................................. 2
Applications ........................................................................... 2
Specifications......................................................................... 3
Digital output .................................................................................3
Register format ..............................................................................3
Dimensions ....................................................................................3
Connectors .....................................................................................3
Power consumption ........................................................................3
Daughterboards .................................................................... 3
Chapter 2 Installation............................................................... 5
Initial inspection.................................................................... 6
Switch and jumper settings .................................................. 6
Base address selection (SW1).......................................................6
Hardwareinstallation ........................................................... 9
Installing the card in your computer..............................................9
Chapter 3 Signal connections.............................................. 1 1
Connector pin assignments ................................................ 12
Isolated Output ................................................................... 13
Chapter 4 Register format ................................................... 1 5
Appendix A PC I/O port address map ................................ 1 7
Chapter 1 General information 1
1
General information
CHAPTER
2PCL-734 User's Manual
Introduction
The PCL-734 offers 32 isolated digital output channels on a PC add-
on card. Its isolated output channels provide 1,000 V of protection.
Each I/O channel corresponds to a bit in a PC I/O port. This makes the
PCL-734 very easy to program.
Features
• 32 isolated digital output channels
• High output driving capacity
• High-voltage isolation on isolated output channels (1,000 VDC)
• Open collector outputs (up to 40 VDC)
• D-type connectors for isolated output channels
• High sink current on isolated output channels (200 mA/channel)
• Suppression diode for inductive loads
Applications
• Industrial ON/OFF control
• Contact closure monitoring
• Switch status sensing
• BCD interfacing
• Digital I/O control
• Industrial and lab automation
Chapter 1 General information 3
Specifications
Digital output
32 optically-isolated outputs
• Output voltage: Open collector 5 to 40 VDC
• Sink current: 200 mA max.
• Isolation voltage: 1,000 VDC
Register format
BASE+0 Isolated DO0~DO7
BASE+1 Isolated DO8~DO15
BASE+2 Isolated DO16~DO23
BASE+3 Isolated DO24~DO31
Dimensions
185 mm x 100 mm
Connectors
DB-37 connector for isolated Digital Output
Power consumption
+5 V: 330 mA typical, 500 mA maximum
Daughterboards
PCLD-880
The PCLD-880 is a universal screw terminal board for industrial
wiring. It can be used with the analog or digital ports of various PC-
LabCards via 20-pin flat cables or shielded round cables with DB-37
connectors.
4PCL-734 User's Manual
Chapter 2 Installation 5
CHAPTER
2
Installation
6 PCL-734 User's Manual
Initial inspection
We carefully inspected the PCL-734 both mechanically and electrical-
ly before shipment. It should be free of marks and in perfect order on
receipt.
As you unpack the PCL-734, check it for signs of shipping damage
(damaged box, scratches, dents, etc.). If it is damaged or fails to meet
specifications, notify our service department or your local sales
representative immediately. Also, call the carrier immediately and
retain the shipping carton and packing material for inspection by the
carrier. We will then make arrangements to repair or replace the unit.
Discharge any static electricity on your body before you touch the
board by touching the back of the system unit (grounded metal).
Remove the PCL-734 card from its protective packaging by grasping
the rear metal panel. Handle the card only by its edges to avoid static
electric discharge which could damage its integrated circuits. Keep the
antistatic package. Whenever you remove the card from the PC, please
store the card in this package for protection.
You should also avoid contact with materials that hold static electricity
such as plastic, vinyl and styrofoam.
Switch and jumper settings
The PCL-734 card has one function switch and three jumper settings.
The following sections tell how to configure the card. You may want
to refer to the opposite page for help identifying card components.
Base address selection (SW1)
You control the PCL-734's operation by writing data to the PC's I/O
(input/output) port addresses. The PCL-734 requires four consecutive
address locations. Switch SW1 sets the card's base (beginning)
address. Valid base addresses range from Hex 200 to Hex 3F0.
However, other devices in your system may be using some of these
addresses.
