Advantech ASMB-588 Manuel d'installation et d'exploitation

ASMB-588 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

• 1 × Startup manual

• 2 × Serial ATA HDD data cables

• 2 × Serial ATA HDD power cables

• 1 × COM cable (for connection to rear panel)

• 1 × I/O port bracket

• 1 × Warranty card

• 1 × Screw for M.2 devices

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note: Acrobat Reader is required to view any PDF

le.AcrobatReadercanbedownloadedat:

http://www.adobe.com/downloads/ (Acrobat is a

trademark of Adobe)

LGA 1700 12th Gen Intel®Core™ MicroATX

Server Board with 4 x DDR5, 3 x PCIe, 6 x USB

3.2, 5 x SATA 3, Quad/Dual LAN, & IPMI

Startup Manual

Standard Functions

• CPU: LGA 1700 12th Gen Intel®Core™ i9/i7/i5/i3 proces-

sor

• BIOS: AMI 256 Mb SPI BIOS

• Chipset: Intel W680

• System memory: Dual Channel DDR5 ECC/Non-ECC

4400/4000/3600MHzunbu󰀨eredDIMM,Max.128GB

Note: Due to the inherent limitations of PC architecture,

the system may not fully detect 128 GB RAM

when 128 GB RAM is installed.

• SATA3 interface: 5xSATA36Gb/sportstosupportIntel

Rapid Storage Technology with software RAID 0, 1, 10, &

5 (for Windows only)

• Serial ports: Three serial ports onboard, only support

RS-232(1xinsertedinrearI/OviaCOMcableconnec-

tion)

• Watchdog timer: 255 level timer intervals (sec/min)

• USB 3.2: Supportsupto6xUSB3.2ports,4xGen2

portsinrearI/Oand2xGen1portsfromon-boardpin

header

• USB 2.0: Supportsupto5xUSB2.0ports(1xType-A)

Display Interface

• Chipset: CPUintegratedIntelHDgraphicscontroller

• Display memory: 1GBmaximumsharedmemorywith

2 GB and above system memory installed (BIOS default

is 256 MB)

• Resolution:

-SupportsVGAupto1920x1200resolution@60Hz

refresh rate

-SupportsDVIupto1920x1200resolution@60Hz

refresh rate

-SupportsHDMI2.0upto2K/4Kresolution@60Hz

refresh rate

Ethernet Interface

• Interface: 10/100/1000 Mbps

• Controller: LAN1: Intel

I219LM; LAN2 ~ LAN4: Intel

I210AT

(LAN2isBMCsharedNIC;LAN3/4isforG4SKUonly)

Mechanical and Environmental

• Dimensions (L x W): 244x244mm(9.6x9.6in)

• Power supply voltage: +3.3V, +5V, ±12V, 5V

• Power consumption: Max.load:+3.3V@0.76A,+5V@

0.92A,+12V@0.03A,+12V(8P)@4.82A,+5V

@0.15A

• Operating temperature: 0 ~ 60 °C; 32 ~ 140 °F(depends on

CPUspeedandcoolersolution)

• Weight: 0.5 kg; 1.1 lb (weight of board)

For more information on this and other Advantech products,

please visit our website at:

http://www.advantech.com

For technical support and service, please visit our support

website for ASMB-588 at:

https://advt.ch/asmb588

extrawarrantyforFREEat:

http://www.register.advantech.com

This manual is for the ASMB-588 series Rev. A1.

Part No. 2042058800 1st Edition

Printed in China September 2022

Packing List Specications

2 ASMB-588 Startup Manual

Connector list

PCIEX16_SLOT6 PCIex16slot(Gen5x16link)

PMBUS1 PMBUSconnectortocommunicate

with power supply

SATA0~4 SATA III (6 Gb/s)

SMBUS1 SMBus connector

SPDIF_OUT1 SPDIF audio output pin header

SPI_CN1 SPIashcardpinheader

SPI_TPM1

SPI connector to support Advantech

TPM 2.0 module (P/N: PCA-TPMSPI-

00A1)

SYSFAN0,SYSFAN1,

SYSFAN2,SYSFAN3 System FAN connector

SYS_LED1 System information LED connector

USB2A1 USB2.0port(USBTypeA)

USB2H1,USB2H2 USB2.0port(header)

USB3H1 USB3.2Gen1port(header)

Jumper list

Label Function

JCMOS1 CMOS clear

JFV1 VGA is forced on

JME1 Intel ME disable jumper for ME/

BIOS update

JPEG1 x16orx8x8forslot-6

JPSMB1, JPSMB2 PCIESLOTSMBUSconnector:to

PCH (1-2)/ to BMC (2-3)

JSMB1 For RD debugging

JTHR_SEL1 Selectsonboardorexternal

thermistor

JUSB_1

RearwindowUSB3.2Gen2port

power source switch between +5

VSB and +5 V

JUSB_2

OnboardUSB2.0/3.2Gen1port

power source switch between +5

VSB and +5 V

JWDT1 Watchdog reset

PSON1 AT(1-2)/ATX(2-3)

The board has a number of jumpers that allow you to con-

gureyoursystemtosuityourapplication.Thetablebelow

lists the function of each jumper and connector.

Connector list

Label Function

ATXPWR1 ATX 24-pin main power connector

(for System)

ATX12V1 8-pinpowerconnector(forCPU)

AUDIO2 Audio connector

BAT1 For RTC battery

BAT2 For optional battery kits

BIOS_SKT1 BIOS SPI ROM

BMC2 BMC connector to support Advantech

IPMI module (P/N: IPMI-2000-00A1)

COM1, COM2_3 Serial port: RS-232

CPUFAN0 CPUFANconnector

DIMMA0, DIMMA1,

DIMMB0, DIMMB1 DDR5 288-pin slot

DVI1 DVI connector

ESPI1 For RD debugging

EX_THR1 Forexternalthermistorcablekit

FPAUD1 Front panel audio header

GPIO1 8-bit GPIO header

HDMI1_VGA1 HDMI + VGA connector

JCASE1 Case open

JFP1

Tosupport1Uchassis(cableP/N:

1700031926-11)

Power Switch/Power Reset/Power

LED/LAN1LED/LAN2LED/HDD LED

Power LED Behavior:

• Suspend:Fastash(ATX/AT)

• System On: ON (ATX/AT)

• SystemO󰀨:OFF(ATX/AT)

JFP1+JFP2

PowerSwitch/PowerReset/External

Speaker/ HDD LED/ SMBus con-

nector

JFP3

Keyboard lock and power LED

• Suspend:Fastash(ATX/AT)

• System On: ON (ATX/AT)

• SystemO󰀨:OFF(ATX/AT)

LAN1_USB3C1,

LAN2_USB3C2

LAN1/USB3.2Gen2port1,2stack

connector

LAN2/USB3.2Gen2port3,4stack

connector

LAN3_LAN4 LAN3 & LAN4 connector

LANLED1 LANLEDextensionconnector

M2_2280_1 M.2 2280 (PCIe)

PCIEX4_SLOT4,

PCIEX4_SLOT7 PCIex4slot(Gen4x4link)

Jumpers and Connectors

Jumpers and Connectors (Cont.)

ASMB-588 Startup Manual 3

PCIEX16_Slot6conguration(JPEG1)

Closed pins Result

1-2 Slot6PCIex16*

2-3 Slot6PCIex8+x8

*:Default

Slot6PCIex16Slot6PCIex8+x8

JCMOS1/JME1: CMOS clear/ME update function

Closed pins Result

1-2

KeepCMOSdata/DisableMEupdate*

2-3 Clear CMOS data/Enable ME update

*:Default

Keep CMOS data/ Clear CMOS data/

Disable ME update Enable ME update

JWDT1: Watchdog timer output option

Closed Pins

Result

1-2 Systemreset*

2-3 Disabled

*:Default

PSON1: ATX, AT mode selector

Closed Pins

Result

1-2 AT Mode

2-3 ATXMode*

*:Default

1 2 3

System Reset 1-2 Closed Disabled 2-3 Closed

1 2 3

AT Mode 1-2 closed ATX Mode 2-3 closed

1 2 3

JFP1+JFP2

Closed pins Result

Pin.3

#PWR_SW

Pin.6 GND

Pin.9 #RST_SW

Pin.12 GND

*PowerbuttonpinislocatedinPin3&6offrontpanelcon-

nector

3 6 9 12

PWRSW RESET

HDDLED

SNMP

JFP1

1 4 7 10

HDDLED

SM_BUS

SPEAKER

JFP2

PWRLED & KEYLOCK

1 2 3 4 5JFP3

2(+) 5(-) 8 11

(+) (-)

2.0 mm JFP1 connector on board

Description

Pin Number Description

RST BTN

1PWR BTN

RST GND

43PWR GND

LAN1_LED+

LAN2_LED+

LAN1_LED -

LAN2_LED-

10 9SYS_LED+ (Reserved)

GND

12 11 SYS_LED- (Reserved)

PWR LED+

HDD_LED+

PWR LED-

HDD_LED-

▼

CRPS Detect (Reserved)

2.0 mm JFP1 connector to 2.54 mm Pitch Header

Description

Pin Number

Description

(Red) PWR BTN

▼12RST BTN (White)

(Black) PWR GND

RST GND (Black)

(Blue) LAN1_LED+

56LAN2_LED+ (Brown)

(Red) LAN1_LED -

78LAN2_LED - (Black)

Key

(Orang) HDD_LED+

PWR LED+ (Red)

(Black) HDD_LED -

Key 16 PWR LED - (Black)

Jumpers and Connectors (Cont.)

Installation Note

1 2 3

4 ASMB-588 Startup Manual

Declaration of Conformity

Caution! The computer is supplied with a battery-powered real-timeclockcircuit.Thereisadangerofexplosionifthebattery

is incorrectly replaced. Replace only with same or equivalent type recommended by the manufacturer. Discard

used batteries according to manufacturer’s instructions.

This device complies with the requirements in Part 15 of the FCC rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

Board Layout: Jumper and Connector Locations

For Internal Use Only

JFV1

JUSB_1

DVI1

LAN1_USB3C1

PCIEX4_SLOT4

Intel LGA1700 Socket

USB3H1

USB2A1

M2_2280_1

Intel W680 PCH PMBUS1

BAT1

DIMMA0

LAN2_USB3C2

AUDIO2

COM2_3

JSMB1

ATXPWR1

DIMMA1

DIMMB0

DIMMB1

FPAUD1

JUSB_2

SATA0~4

JFP1+JFP2 SYSFAN2

JWDT1

JFP1

JFP3

SMBUS1

JPEG1

BIOS_SKT1

JPSMB1~2

USB2H1

JCASE1

SYSFAN0~1

SPDIF_OUT1

ATX12V1

USB2H2

EX_THR1

JCMOS1

SPI_TPM1

CPUFAN0

BAT2

COM1

SYSFAN3

PCIEX16_SLOT6

PCIEX4_SLOT7

JME1

SYS_LED1

ESPI1

JTHR_SEL1

LANLED1

SPI_CN1 BMC2

PSON1

GPIO1

LAN3_LAN4

HDMI1_VGA1

Board Layout

Autres manuels Advantech Matériel informatique

Advantech

Advantech ASMB-785 Manuel d'installation et d'exploitation

Advantech

Advantech PCA-6654 Manuel utilisateur

Advantech

Advantech PCE-7214 Manuel d'installation et d'exploitation

Advantech

Advantech TREK-550-A00E Manuel utilisateur

Advantech

Advantech SOM-6883 Manuel utilisateur

Advantech

Advantech AIMB-786 Manuel d'installation et d'exploitation

Advantech

Advantech MIC-75M20 Manuel d'installation et d'exploitation

Advantech

Advantech PCL-746+ Manuel utilisateur

Advantech

Advantech MIO-5377 Manuel d'installation et d'exploitation

Advantech

Advantech PPC-IPS Manuel utilisateur

Advantech

Advantech PCLD-8751 Manuel utilisateur

Advantech

Advantech PCA-6753 Manuel d'installation et d'exploitation

Advantech

Advantech SOM-E780 Manuel utilisateur

Advantech

Advantech ECU-P1528PE Manuel d'installation et d'exploitation

Advantech

Advantech ECU-150 Series Manuel utilisateur

Advantech

Advantech ASMB-831 Series Manuel d'installation et d'exploitation

Advantech

Advantech MIO-5377 Manuel utilisateur

Advantech

Advantech PCI-1710 Manuel utilisateur

Advantech

Advantech SOM-9590 Manuel utilisateur

Advantech

Advantech MIO-5376 Manuel utilisateur

Advantech

Advantech UNO-2484G V2 Manuel utilisateur

Advantech

Advantech ADAM-3956 Manuel d'installation et d'exploitation

Advantech

Advantech MIC-7 Series Manuel d'installation et d'exploitation

Advantech

Advantech FWA-1211 Manuel d'installation et d'exploitation

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
