ADT Fall Detection Pendant Manuel utilisateur

ADT MEDICAL ALERT

Fall Detection

Pendant

User guide

Thank you for choosing the

ADT Fall Detection pendant

We welcome you to the ADT family.

If you have any questions please call

our support team.They are available

24/7/365.

The Fall Detection pendant*enables

you to send an alarm to the

emergency response center when you

need it by pressing the blue emergency

help button. It also provides extra

protection by automatically sending

an alarm if you fall and are unable to

push your button.

For assistance call

(800)568-1216 and select option 1

*Fall Detection pendant does not detect 100% of falls.

Complete user guide

This user guide includes information covering:

The Fall Detection pendant

Note: The Fall Detection pendant is compatible with both the

Medical Alert Plus and On-The-Go emergency response systems.

Fall Detection pendant features

Technical support

use only

Multicolor

indicator

Emergency help

(blue) button

How to wear your Fall Detection pendant

Putting on the Fall Detection pendant

ƼPlace the Fall Detection pendant around your neck and

adjust the lanyard so that it rests at chest level.Make

sure the pendant is facing away from your body so that

it is easier for you to press.

ƼWear the Fall Detection pendant outside your shirt, as

wearing it inside your shirt can reduce the percentage

of falls being detected.

ƼPlease handle your Fall Detection pendant with care

when putting it on or taking it o, as the device may

interpret this movement as a fall and activate.

If an actual fall has occurred,the Fall Detection

pendant takes 20 to 30 seconds to interpret the

movement and determines that a fall has occurred:

ƼThe Fall Detection pendant sounds a series of beeps and

the light ashes red for 20 seconds.

ƼThe medical alert system states,“fall detected, press

and hold button to cancel.”

ƼIf you do not cancel the fall detection alarm during the

rst 20 seconds after a fall was detected, the device

states, “fall detected, contacting emergency response

center” and then “please stand by for operator.”

ƼCommunicate with the operator that you are in need of

help and emergency response will be sent.

How the Fall Detection pendant works

Medical Alert Plus base

station

Fall Detection

pendant On-The-Go mobile device

How to test your Fall Detection pendant

Please follow these simple steps.

Please have your complete medical alert

system near you at the time of testing. It

is important that you test your system at

least once a month.

OPTION 1

1. Firmly press the blue button on the Fall

Detection pendant one time.

ƼIf you have a mobile device, it will sound three (3) double

beeps and the red ring around the gray emergency button

lights up for several seconds,and then fades out.

ƼAn emergency operator will speak with you through the base

station or mobile device.

2. Tell the operator that this is not an emergency and

that you are testing the system.

ƼIf you do not respond or speak to the operator and explain that

you are testing your unit, emergency help will be dispatched.

Test your Fall Detection pendant

by pressing the help button

ƼThe medical alert system states, “call in progress.”

ƼAfter the fall detection alarm is received,the base

station states, “please stand by for operator.”

Note: The mobile device nor the base station will not

transmit an emergency call if one was activated

within the last two minutes.

How to test your Fall Detection pendant

Please follow these simple steps.

Please have your complete medical alert

system near you at the time of testing. It

is important that you test your system at

least once a month.

OPTION 2

1. Drop the Fall Detection pendant from a

height of approximately18 inches.The

pendant takes 20 to 30 seconds to interpret

the movement and determine if an actual

fall has occurred.

ƼIf you have a mobile device, it will sound three (3) double beeps

and the red ring around the gray emergency button lights up for

several seconds, and then fades out.

2. Do not pick up the Fall Detection pendant before the

test is completed,as it may interpret this as normal

movement and cancel the test call.

Drop testing your Fall

Detection pendant

ƼThe Fall Detection pendant sounds a series of beeps and

the light ashes red for 20 seconds.

ƼThe base station states,“fall detected, press and hold

button to cancel."

ƼAfter 20 seconds, from when a fall was detected,the device states,

“fall detected, contacting emergency response center” and then

“please stand by for operator.”

ƼAn emergency operator will speak with you through the base

station or mobile device.

3. Tell the operator that this is not an emergency and

that you are testing the system.

ƼIf you do not respond or speak to the operator and explain that

you are testing your unit, emergency help will be dispatched.

ƼPress and hold the blue emergency help

button on the Fall Detection pendant for ve

seconds until it ashes green once and you

hear a series of beeps.

ƼFor Medical Alert Plus users: You can also

cancel the fall detection alarm by pressing

the blue RESET button on the base station.

ƼFor On-the-Go users: You cannot cancel the

fall detection alarm with the mobile device.

You must press the blue button on the Fall

Detection pendant to cancel the alarm.

ƼIf you cancel the fall detection alarm, your

base station states,“alarm cancelled.”

To cancel a false alarm

ƼWait for the emergency operator to speak

to you through the Medical Alert device.

ƼTell the operator that this is not an

emergency and that you do not need help.

If the help button was pressed on the Fall

Detection pendant, you cannot manually

cancel the alarm...

To cancel the Fall Detection alarm during the

rst 20 seconds after a fall was detected:

For no alarm to be sent to the emergency response center.

Fall Detection pendant light indicator

Color Pattern Meaning

None O No alarm detected

Red Flashes once Button has been pressed

Red Flashes repeatedly Fall is detected

Green Flashes once Alarm has been cancelled

Amber One ash every two minutes Pendant battery is low

The multicolor indicator at the top of the Fall Detection

pendant ashes in dierent colors to advise you of various

conditions.The following table describes the colors that the

indicator may ash and what it means.

Multicolor indicator
