ADLINK Technology PCIe-ACC100 Manuel utilisateur

PCIe-ACC100

(a.k.a. PCIe-A100)

FEC Accelerator Based On

Intel® vRAN Dedicated Accelerator ACC100

User’s Manual

Manual Rev.: Rev. 1.2

Revision Date: October 20, 2022

Part No.: 50M-00045-1020

PCIe-ACC100

Preface

This document contains proprietary information protected by copyright.All rights are

reserved. No part of this manual may be reproduced by any mechanical, electronic, or other

means in any form without prior written permission of the manufacturer.

Disclaimer

The information in this document is subject to change without prior notice in order to improve

reliability, design, and function and does not represent a commitment on the part of the

manufacturer.

In no event will the manufacturer be liable for direct, indirect, special, incidental, or

consequential damages arising out of the use or inability to use the product or

documentation, even if advised of the possibility of such damages.

Environmental Responsibility

ADLINK is committed to fulfill its social responsibility to global

environmental preservation through compliance with the European

Union's Restriction of Hazardous Substances (RoHS) directive and

Waste Electrical and Electronic Equipment (WEEE) directive.

Environmental protection is a top priority for ADLINK. We have enforced

measures to ensure that our products, manufacturing processes,

components, and raw materials have as little impact on the environment

as possible. When products are at their end of life, our customers are

encouraged to dispose of them in accordance with the product disposal and/or recovery

programs prescribed by their nation or company.

Trademarks

Product names mentioned herein are used for identification purposes only and may be

trademarks and/or registered trademarks of their respective companies.

Revision History

Revision Release Date Description of Change(s)

1.0 2021-09-23 Initial release

1.1 2022-04-27 Update product name from PCIe-A100 to

PCIe-ACC100; memory spec

1.2 2022-10-21 Update Ch. 3 Testing the Module

PCIe-ACC100

Conventions

Information to prevent serious physical injury, component damage, data

loss, and/or program corruption when trying to complete a specific task.

Informations destinées à prévenir les blessures corporelles graves, les

dommages aux composants, la perte de données et/ou la corruption de

programme lors de l'exécution d'une tâche spécifique.

VERTISSEMENT

Information to prevent minor physical injury, component damage, data

loss, and/or program corruption when trying to complete a task.

Informations destinées à prévenir les blessures corporelles mineures,

les dommages aux composants, la perte de données et/ou la corruption

de programme lors de l'exécution d'une tâche.

mise en garde

PCIe-ACC100

Table of Contents

Preface .................................................................................................................................. 2

1Overview .......................................................................................................................... 5

1.1 Introduction..............................................................................................................................5

1.1 Block Diagram..........................................................................................................................6

1.2 Mechanical Overview...............................................................................................................7

1.2.1 PCIe-ACC100 - Half Height...............................................................................................................7

1.2.2 PCIe-ACC100 - Full Height ...............................................................................................................8

2Specifications.................................................................................................................. 9

2.1 PCIe-ACC100 Specifications...................................................................................................9

3Testing the Module........................................................................................................ 10

Important Safety Instructions............................................................................................ 12

Consignes de Sécurité Importantes ................................................................................. 14

Getting Service................................................................................................................... 16

PCIe-ACC100

1 Overview

1.1 Introduction

The ADLINK PCIe-ACC100 (also knows as PCIe-A100) is a single-slot eASIC FEC

accelerator server adapter based on the Intel® vRAN Accelerator ACC100 adapter. The

PCIe-ACC100 can be deployed in various Xeon-based COTS servers ranging from dual-

socket Xeon-SP rackmount implementations, single socket Xeon-SP edge servers through to

low-core-count (LCC) based Xeon-D servers.

The main features of the PCIe-ACC100 are summarized as follows:

•Integrates Intel® vRAN Dedicated Accelerator ACC100

oLDPC FEC processing (3GPP 5G): LDPC encode/decode, CRC, rate matching,

HARQ

oLTE FEC processing (3GPP 4G): Turbo encode/decode, CRC, rate matching

oSupports virtualization, scalable to desired system configuration; separate engines for

UL/DL

oLoad balancing supported by Queue Mgr.

•Low profile PCIe card for low-cost design

oPower envelope of low-profile slot

oFor Intel Xeon Scalable Processor & Xeon D Processor based COTS servers

oNo PCIe card auxiliary power required

oNo front-panel I/O for maximum air-flow

oFull and Half-height bracket options

•Onboard DDR4 for HARQ processing

•High-speed host interface: PCIe x16 Gen3

•Operation temperature: -5°C to +55°C

•Passive cooling

•NEBS compliance ready

PCIe-ACC100

1.1 Block Diagram

Intel® vRAN

Accelerator

ACC100 Adapter

(Mount Bryce)

JTAG

DDR4

DDR4 DDR4 1GB x8

DDR4 4GB x64 x72

x8 (ECC)

x64

DDR HARQ Buffer + ECC 2667 Mb/s D

I2C Master

PCIe x16

Gen3

PCIe x16

Edge Connector

x16

I2C Master

*Default

Temp & Fan

Controller

AD7475

0X2E

Sequencer

UCD90160A

0x36

FRU

CAT24C02YI

0x53

VDD

PWR Controller

0x08

Buffer

TCA9406

x16

OSC

540BAA333M330CBGR

333.33MHz DDR4_REFCLK

LED

PWROK GREEN

PCIe-ACC100

1.2 Mechanical Overview

1.2.1 PCIe-ACC100 - Half Height

Dimensions: mm

(169.3)

(80.0)

(22.0)

PCIe-ACC100

1.2.2 PCIe-ACC100 - Full Height

Dimensions: mm

(169.4)

(120.9)

(21.6)

PCIe-ACC100

2 Specifications

2.1 PCIe-ACC100 Specifications

Performance 5G throughput: 21Gbps encode, 8Gbps decode

4G throughput: 8.4Gbps encode, 2.1Gbps decode

Software and

Cloud Support Interface via DPDK BBDev

Clould native, VM and bare metal, SRIOV/Vt-d

Interface PCIe x16 Gen3 interface to host

Memory DDR4-2666 4GB ECC

Operating

Temperature -5°C to +55°C

Dimensions Refer to 1.2 Mechanical Overview

PCIe-ACC100

3 Testing the Module

1. OS:

Install an operating system such as Ubuntu 20.04. Login and switch to user “root”

(su root). Make sure this server is connected to Internet.

2. Copy files:

Copy the file test-bbdev.tar.gz to /home and unpack it.

3. Update the grub:

Update the grub to improve the performance.

1. Execute the command "vi /etc/default/grub"

2. Paste the following text:

GRUB_CMDLINE_LINUX="default_hugepagesz=1G hugepagesz=1G

hugepages=8 nmi_watchdog=0 selinux=0 isolcpus=1-7,9-15 nohz_full=1-7,9-15

rcu_nocbs=1-7,9-15 intel_pstate=disable nosoftlockup"

3. Execute the command "update-grub"

4. Execute the command "reboot"

4. Configure the test-bbdev environment:

./test-bbdev_env_setup.sh

The configuration is successful when you see the following.
