PG-FLEXPLUS

TECHNICAL PRACTICE

MANAGEMENT UNIT

SECTION SCP-PMU712-020-08H

Model List CLEI Code

PMU-712 2S9C3CCDA~~

SCP-PMU712-020-08H

March 1, 2004 PMU-712 List 2

Revision History of This Practice

ADC and PG-FlexPlus are registered trademark s of ADC Telecommunications, Inc. No right, license, or interest to such trademarks

is granted hereunder, and you agree that you shall assert no such right, license, or interest with respect to such trademarks. Other

product names mentioned in this document are used for identification purposes only and may be trademarks or registered

trademarks of their respective companies.

Information contained in this document is company private to ADC Telecommunications, Inc., and shall not be modified, used,

copied, reproduced or disclosed in whole or in part without the written consent of ADC.

Contents herein are current as of the date of publication. ADC reserves the right to change specifications at any time without notice.

Information furnished by ADC is believed to be accurate and reliable. In no event shall ADC be liable for any damages resulting

from the loss of data, loss of use, or loss of profits and ADC further disclaims any and all liability for indirect, incidental, special,

consequential or other similar damages. This disclaimer of liability applies to all products, publications and services during and

after the warranty period.

Revision Release Date Revisions Made

01 July 11, 2001 Initial Release

02 July 31, 2001 Release to:

1correct all custom defaults for Power A Missing and Power B Missing in Table 20, “Alarm

Types,” on page 61.

2correct table captions for Table 21, “Service Loss Alarm Types,” on page 62 and Table 22

on page 64.

3correct custom default for Environmental Alarm n(where n= 1 to 4), List 3 in Table 24,

“Environmental Alarm Types,” on page 65.

03 August 17, 2001 Release to:

1make corrections in “Specifications” on page 10. Height was changed to 5.50 in. (14.0 cm)

and Length was changed to 10.25 in (26.0 cm).

2correct Figure 6, “Front Panel Craft Port to Terminal Connections,” on page 15

3delete second and third sentences in second paragraph after Figure 13 on page 20.

4make corrections in “Logging On” on page 25 reference to the establishment of a password.

The third bullet, third sentence was revised.

5correct first line of second bullet on page 22.

6correct second line of first paragraph in the Download Retry section on page 70.

7correct other non-service affecting changes on pages 6, 7 and 52.

04 December 20, 2001 Release to rebrand document to comply with ADC standards

05 July 8, 2002 Eliminate references to the PMU-712 List 3

06 January 6, 2003 Updated Product Support Information

07 August 6, 2003 Updated external alarms

08 March 1, 2004 Updated DB-25 alarm information

SCP-PMU712-020-08H Using This Practice

PMU-712 List 2 March 1, 2004

USING THIS PRACTICE

Three types of messages, identified by icons, appear in the text.

INSPECTING YOUR SHIPMENT

Upon receipt of the equipment:

•Unpack each container and visually inspect the contents for signs of damage. If the equipment has been

damaged in transit, immediately report the extent of damage to the transportation company and to ADC.

Order replacement equipment, if necessary.

•Check the packing list to ensure complete and accurate shipment of each listed item. If the shipment is short

or irregular, contact ADC as described in “Returns” on page 77. If you must store the equipment for a

prolonged period, store the equipment in its original container.

Notes indicate information about special circumstances.

Cautions indicate the possibility of equipment damage or the possibility of personal injury.

Electrostatic Discharge (ESD) susceptibility symbols indicate that a device or assembly is

susceptible to damage from electrostatic discharge.You must wear an antistatic wrist strap

connected to the appropriate ground connection prior to performing installation procedures.

You must also observe normal ESD precautions when handling electronic equipment. Do not

hold electronic plugs by their edges. Do not touch components or circuitry.

Inspecting Your Shipment SCP-PMU712-020-08H
