ADC ADCP-90-216 Manuel utilisateur

ADCP-90-216

Issue 2, January 1998

1017825 Page 1

7-Inch Fiber Distribution

System Splice Module

User Manual

Content Page

INTRODUCTION...........................................................................1

Revision History.......................................................................1

List of Changes.......................................................................2

Trademark Information..................................................................2

Related Publications...................................................................2

Admonishments.......................................................................2

1.GENERAL............................................................................3

2.FIBER DISTRIBUTION SYSTEM SPLICE MODULE.............................................3

3.FDS ACCESSORIES....................................................................3

4.DESCRIPTION.........................................................................5

A. Chassis..........................................................................6

B. Front and Rear Covers..............................................................6

C. Splice Drawers.....................................................................7

5.INSTALLATION........................................................................7

A. Unpack...........................................................................7

B. Chassis Installation.................................................................7

C. Cable Routing.....................................................................9

D. Fiber Storage.....................................................................12

E. Pigtails..........................................................................12

6.SPLICING...........................................................................13

7.SYSTEM INTEGRATION SERVICES.......................................................14

8.CUSTOMER SUPPORT SERVICES........................................................15

INTRODUCTION

This manual describes the ADC 7-Inch Fiber Distribution System (FDS) Splice Module. The

Splice Module provides splicing and storage capabilities for the 7-Inch FDS. It contains physical

and functional descriptions, installation, and operation information, and is intended for persons

involved in installing and maintaining the fiber distribution system. The user of this manual must

have a basic understanding of fiber optic terminology and concepts.

Revision History

ISSUE DATE REASON FOR CHANGE

Issue 1 02/94 Original

Issue 2 01/98 Update to reflect product changes and reformat to current standards.

ADCP-90-216

Issue 2, January 1998

Page 2

1998, ADC Telecommunications, Inc.

List of Changes

PAGE IDENTIFIER DESCRIPTION OF CHANGE

All pages – Reformat to current standards with editorial and technical changes.

Trademark Information

The following trademarks are documented in this manual:

FibrLok is a trademark of 3M

Lucent is a registered trademark of Lucent Technologies, Inc.

Related Publications

Listed below are related manuals and their publication numbers. Copies of these publications can

be ordered by contacting the ADC Technical Assistance Center at 1-800-366-3891 (in U.S.A. or

Canada) or 612-946-3000, extension 3475 (outside U.S.A. and Canada).

Title ADCP Number

7-Inch Fiber Distribution System Application Guide and User Manual ADCP-90-198

7-Inch Fiber Distribution System Equipment Rack Installation Instructions ADCP-90-193

Admonishments

Important safety admonishments are used throughout this manual to warn of possible hazards to

persons or equipment. An admonishment identifies a possible hazard and then explains what may

happen if the hazard is not avoided. The admonishments — in the form of Dangers, Warnings,

and Cautions — must be followed at all times. These warnings are flagged by use of the

triangular alert icon (seen below), and are listed in descending order of severity of injury or

damage and likelihood of occurrence.

Danger: Danger is used to indicate the presence of a hazard that will cause severe

personal injury, death, or substantial property damage if the hazard is not avoided.

Warning: Warning is used to indicate the presence of a hazard that can cause severe

personal injury, death, or substantial property damage if the hazard is not avoided.

Caution: Caution is used to indicate the presence of a hazard that will or can cause

minor personal injury or property damage if the hazard is not avoided.

ADCP-90-216

Issue 2, January 1998

Page 3

1998, ADC Telecommunications, Inc.

1. GENERAL

1.01 The ADC 7-Inch Fiber Distribution System (FDS) (Figure 1) provides the termination,

splicing, and storage requirements of a large fiber optic cable system. The splice module is compatible

with the 7-Inch FDS or it can be used with or as a replacement for the Lucent LGX splice modules.

1.02 The FDS is modular in design so that additional capacity and functions can be added as

the system requirements change. A 7-Inch FDS consists of these major components.

•FDS Frame

•FDS Splice Module

•FDS Connector Module (72 terminations)

•Accessories including vertical cable guides

2. FIBER DISTRIBUTION SYSTEM SPLICE MODULE

2.01 The splice module permits splicing outside plant (OSP) or intrafacility fiber cable (IFC)

fibers to each other or to pigtail assemblies. The module provides a protective enclosure for

mounting splices and for coiling the service loop required in the splicing process.

2.02 The splice module can be used as a direct replacement for the LGX splice module and

can be installed in the same frame.

3. FDS ACCESSORIES

3.01 Optional Interbay Management Panels (IMPs) are available for installation between

frames. The panels provide storage for patch cords between frames. Other accessories such as

connector adapters, connector retainers, blank panels, and outside plant and intrafacility fiber

cable clamp kits are available to complete the installation.

3.02 Optional vertical cable guides can be attached at each side of the chassis (see Figure 2),

unless the splice module is installed in an ADC equipment frame which includes guides. The

cable guides form a vertical pathway and provide protection and organization for patch cords.

Four vertical cable guide styles are available. Their use is determined by frame spacing and

whether they are used with the 7-Inch FDS or LGX frames. Choose one of the vertical cable

guides that match what is installed on the other FDS equipment in the rack:

•2-inch/2-finger design - Used with LGX modules only, when no rack spacing is used and

a retrofit IMP panel is installed.

•2-inch/2-finger design – Used with 7-Inch FDS modules when no rack spacing is used

and a retrofit IMP is installed.

•4-inch/7-finger design –Used with 7-inch FDS modules when no rack spacing is used and

an IMP is not installed, or when racks are spaced five inches apart and an IMP is used.

•Rear vertical cable guide – Used in a cross-connect application, to organize and route

fiber optic terminal (FOT) equipment patch cords to the rear of the module.

ADCP-90-216

Issue 2, January 1998

Page 4

1998, ADC Telecommunications, Inc.

3.03 Splice trays are available in nine configurations which provide splice chips to support

individual splices. See Table 1 for catalog numbers.

4117-A

OSP

CABLE

SPLICE

MODULE

CONNECTOR

MODULE

= TERMINATION

= SPLICE

IFC

CABLE

PIGTAILS

CABLE

GUIDES

INTERBAY

MANAGEMENT

PANEL

Figure 1. 7-Inch FDS

1200-A

2- OR 4-INCH

(7-FINGERS) 7 FANNING

FINGERS

4-INCH

(7 FINGERS) 7 FANNING

FINGERS

2-INCH

(RETROFIT) 2 FANNING

FINGERS 2 FANNING

FINGERS

REAR VERTICAL

CABLE GUIDE

Figure 2. Optional Vertical Cable Guides

ADCP-90-216

Issue 2, January 1998

Page 5

1998, ADC Telecommunications, Inc.

4. DESCRIPTION

4.01 The splice module requires a 7-inch (17.8 cm) mounting space within the frame. Major

components of the splice module are shown in Figure 3 and are described in the following

paragraphs. Specifications for the module are listed in Table 1.

PIGTAIL

CABLE ACCESS

OSP/IFC

CABLE ACCESS

7.0 IN.

11.0 IN.

4118-A

17.0 IN.

Figure 3. 7-Inch FDS Splice Module Components and Dimensions

ADCP-90-216

Issue 2, January 1998

Page 6

1998, ADC Telecommunications, Inc.

Table 1. Splice Module Specifications

FEATURE SPECIFICATION

Dimensions

Height 7 in. (17.78 cm)

Width 17 in. (43.18 cm)

Depth 11 in. (27.94 cm)

Mounting 19-inch or 23-inch rack

Splice Details

Splice Drawers 6

Splice Trays 12 (One or two splice trays per drawer)

Catalog Number: Splice Chip Type:

FST-F3DF-FT Bare Fusion

FST-F3DF-HS Heat Shrink Fusion

FST-F3DF-MT Mechanical (Elastomeric)

FST-F3DF-RT Rotary

FST-F3DF-3M FibrLok

FST-F3DF-NT Qpak

FST-F3DF-RC Raychem

FST-F3DF-HS18 Heat Shrink Fusion (18 splices)

FST-F3DF-HSAC AOFR Clip

Splice Capacity 144 splices (12 splices per splice tray)*

Cable Clamp Kits

IFC/OSP Cable Clamp FL2-ACC007 Outside diameter 0.5-0.8 in. (13-20 mm)

* Except where otherwise noted.

A. Chassis

4.02 The splice module chassis is constructed of heavy gauge aluminum and has a baked

powder paint finish. The module is compatible with the 7-inch FDS connector module. Cable

access holes at the left and right side of both modules provide IFC or OSP cable fiber access.

Fiber access holes in the top and bottom of both modules permit protected routing of pigtails to a

connector module mounted either above or below the splice module.

B. Front and Rear Covers

4.03 A transparent front cover, hinged at the bottom, protects the fibers and pigtails from

normal activity near the module. The circuit designation labels provided are to be attached to the

front of each splice drawer. Circuit identification can be written on labels and attached to the

designation cards. The front cover can be removed for convenience and protection during

installation or other activity. The metal rear cover is hinged at the bottom and is removable. The

removable cover provides access to the interior of the chassis for fiber activity.

ADCP-90-216

Issue 2, January 1998

Page 7

1998, ADC Telecommunications, Inc.

C. Splice Drawers

4.04 The splice module contains up to six splice drawers. Each splice drawer can handle two

ADC splice trays. Each ADC splice tray can handle 12 Fusion, heat shrink, mechanical

(elastomeric), rotary, FibrLok, Qpak, AOFR clip, or Raychem splices using the appropriate splice

chips. The FST-F3DF-HS18 splice tray can handle 18 heat shrink splices. Individual catalog

numbers are shown in Table 1.

5. INSTALLATION

5.01 This section describes how to install the splice module in the 7-Inch FDS or LGX frame.

The sequence of procedures is as follows:

•Unpack and inspect

•Chassis installation

•Cable routing and termination

•Fiber storage and splicing

A. Unpack

5.02 Unpack and inspect the various components as follows:

1. Inspect the exterior of the shipping container(s) for evidence of rough handling that may

have damaged the components in the container.

2. Unpack each container while carefully checking the contents for damage.

3. If damage is detected or if parts are missing, file a claim with the commercial carrier and

notify ADC Customer Service. Save damaged cartons for inspection by the carrier.

4. Refer to the Customer Service section at the back of this instruction sheet for repair,

replacement, and warranty information.

5. Save all shipping containers for use if the equipment requires shipment at a future date.

B. Chassis Installation

5.03 This procedure describes how to install the standard 7-inch FDS splice module in either

an ADC supplied frame or an LGX frame.

1. Release the latch on the front cover and open it about 2 inches (5 cm).

2. Lift the front cover from the hinges and place it where it will not be scratched or damaged.

3. The splice module brackets are installed for a 19-inch equipment rack. If a 23-inch

equipment rack is being used, remove the brackets and install them with the short

bracket side against the splice module side as shown in Figure 4.

Note: If a vertical cable guide is installed on the frame, it must be removed before

installing the splice module.

ADCP-90-216

Issue 2, January 1998

Page 8

1998, ADC Telecommunications, Inc.

4. If applicable, remove the vertical cable guide from each side of the frame position in

which the splice module is being installed.

5. Place the splice module in its assigned position in the frame.

6. Insert two #12-24 screws supplied through the mounting bracket at each side of the

chassis and in the frame as shown in Figure 4.

7. Install optional vertical cable guides or reinstall the removed guides (see Figure 5).

8. Re-attach the front cover.

1216-A

FRAME

INTERBAY

MANAGEMENT

PANEL

MOUNTING

BRACKET

#12-24 SCREW

(2 PLACES - BOTH SIDES)

Figure 4. Splice Module Installation in an Equipment Rack

ADCP-90-216

Issue 2, January 1998

Page 9

1998, ADC Telecommunications, Inc.

#12-24 SCREW

(2 PLACES EACH SIDE)

INTERBAY

MANAGEMENT

PANEL

1217-A

VERTICAL CABLE

GUIDE MOUNTING

HOLES

VERTICAL CABLE

GUIDE MOUNTING

HOLES

VERTICAL

CABLE GUIDE

Figure 5. Vertical Cable Guide Installation in an Equipment Rack

C. Cable Routing

5.04 Cable installation is performed from the rear side of the splice module. The OSP or IFC

cables are routed to the back of the module chassis from either above or below the module. The

pigtails are routed to the connector module through the fiber access holes in the top and bottom

of the chassis.

5.05 Prior to splicing, all cables (OSP and IFC) are routed to and secured to the side of the splice

module using a cable clamp kit. A total of eight cable clamp positions are available at both sides of

the chassis. To avoid congestion, OSP and IFC cables should be installed on opposite sides of the

module. Cables should be clamped as close as possible to the splice module to which the fibers will

be routed to reduce the length of cable sheath that needs to be stripped and cleaned.

ADCP-90-216

Issue 2, January 1998

Page 10

1998, ADC Telecommunications, Inc.

Danger: Infrared radiation is invisible and can seriously damage the retina of the eye.

Do not look into the optical bulkhead of an operational transmitter, or into the launching

(output) end of an active fiber. A clean, protective cap or hood MUST be immediately

placed over any radiating bulkhead receptacle or optical fiber connector to avoid

exposure to potentially dangerous amounts of radiation. This practice also helps

prevent contamination of connectors and adapters.

5.06 Strip the outer sheath of the cable to expose the inner fiber bundles. Clean the cable core

as necessary per local practice. The cable sheath must extend about 0.75 inches (1.9 cm) beyond

the cable clamp. The service loop length shown in Figure 6 includes approximately 30 inches

(76.2 cm) of fiber within the splice tray for splicing. If buffer tubes or fiber protector sleeves are

needed add them at this time.

CABLE CLAMP

CABLE SHEATH

FIBERS

SPLICES

0.75 IN.

(1.9 CM)

13 FT. (4.0 M)

RECOMMENDED

4135-A

Figure 6. Sheath Opening for OSP/IFC Cables

Table des matières

Autres manuels ADC Matériel réseau

ADC

ADC FlexWave MMX 7000 Manuel utilisateur

ADC

ADC FPL Series Manuel utilisateur

ADC

ADC OmniReach MDU Rapid Fiber System Manuel utilisateur

ADC

ADC HiGain HDU-404 LIST 2 Instructions d'utilisation d'origine

ADC

ADC Active Digital Signal Cross-Connect ASX Manuel utilisateur

ADC

ADC High Density Position Panel LSX 288 Manuel utilisateur

ADC

ADC HiGain HLU-C-388 List 5F Instructions d'utilisation d'origine

ADC

ADC HiGain HLU-200 Manuel utilisateur

ADC

ADC H2TU-C-388 HiGain Manuel utilisateur

ADC

ADC HiGain H2TU-C-231 Instructions d'utilisation d'origine

ADC

ADC Campus RS Destop Unit Manuel utilisateur

ADC

ADC HiGain H2TU-C-319 List 4E Manuel utilisateur

ADC

ADC OmniReach OFDT-24 Manuel utilisateur

ADC

ADC H2TU-C-202 Manuel utilisateur

ADC

ADC HiGain HDSL2 Manuel utilisateur

ADC

ADC HiGain H2TU-C-319 List 4E Instructions d'utilisation d'origine

ADC

ADC WiMAX Single-sector Base Station WMX 3000 Manuel utilisateur

ADC

ADC HiGain H2TU-C-319 List 4E Manuel utilisateur

ADC

ADC PG-FLEXPLUS PLL-735 Manuel utilisateur

ADC

ADC HiGain HXU-358 Manuel utilisateur

ADC

ADC ETP-64 Manuel utilisateur

ADC

ADC HiGain HLU-200 Manuel utilisateur

ADC

ADC HRE-425 List 1 Instructions d'utilisation d'origine

ADC

ADC TrueNet Intelligent Patching Manuel utilisateur

Manuels Matériel réseau populaires d'autres marques

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuel utilisateur

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuel utilisateur

Yudor

Yudor YDS-16 Manuel utilisateur

D-Link

D-Link ShareCenter DNS-320L Manuel utilisateur

Samsung

Samsung ES1642dc Instructions d'utilisation

Honeywell Home

Honeywell Home LTEM-PV Instructions de montage

evertz

evertz 7700 Series Manuel utilisateur

D-Link

D-Link ShareCenter DNS-343 Manuel utilisateur

Asante

Asante AsanteBridge 1012 Manuel utilisateur

FireBrick

FireBrick FB2700 Manuel utilisateur

Audiovox Electronics

Audiovox Electronics ARWH2T Manuel utilisateur

NetComm

NetComm NF2 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 5620 Manuel utilisateur

Dell EMC

Dell EMC XC6420 Series Manuel utilisateur

Lanner

Lanner NCA-1020A Manuel utilisateur

Allied Telesis

Allied Telesis AT-TN121-A Manuel utilisateur

Arista

Arista CCA-ETM-Q12 Manuel utilisateur

Lanner

Lanner NCA-1525 Manuel utilisateur
