ACTi KCM-5511 Instructions d'utilisation

KCM-5511

26x Zoom H.264 2-Megapixel IP IR D/N

PoE Outdoor Box Camera with Advanced

WDR

Hardware User’s Manual

(DC 12V / PoE)

Ver. 2012/8/9

www.acti.com

KCM-5511 Hardware User’s Manual

Table of Contents

0. Precautions 3

1. Introduction 4

Package Contents ........................................................................... 4

Features and Benefits ..................................................................... 5

Safety Instructions .......................................................................... 6

Physical description ........................................................................ 8

Preparing for Installation ............................................................. 11

How to Do the Waterproof Installation ....................................... 11

Basic Connections ......................................................................... 15

Product Specification.................................................................... 16

2. Accessing Camera 18

If you have DHCP server / router in your network: ...................... 18

If you do

NOT

have DHCP server / router in your network: ......... 18

www.acti.com

KCM-5511 Hardware User’s Manual

0. Precautions

Read these instructions

You should read all the safety and operating instructions before using this product.

Heed all warnings

You must adhere to all the warnings on the product and in the instruction manual. Failure to

follow the safety instruction given may directly endanger people, cause damage to the system

or to other equipment.

Servicing

Do not attempt to service this video device yourself as opening or removing covers may

expose you to dangerous voltage or other hazards. Refer all servicing to qualified service

personnel.

Trademarks

All names used in this manual are probably registered trademarks of respective companies.

Liability

Every reasonable care has been taken during the writing of this manual. Please inform your

local office if you find any inaccuracies or omissions.We cannot be held responsible for any

typographical or technical errors and reserve the right to make changes to the product and

manuals without prior notice.

FCC/CE Regulation

NOTE:This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment.This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference in which case the users will be required to correct the

interference at their own expense.

www.acti.com

KCM-5511 Hardware User’s Manual

1. Introduction

Package Contents

KCM-5511 QIG

Terminal Blocks for Power, DI/O and

Serial Port Warranty Card

www.acti.com

KCM-5511 Hardware User’s Manual

Features and Benefits

This is a cutting edge network video surveillance camera. It can capture, compress and

transmit real time video in excellent quality (15 FPS 2 Megapixel, 1920 x 1080).This camera is

your best choice to build an intelligent IP surveillance system.

26x Zoom Lens with Auto Focus

The powerful 26x Zoom Lens with ISP enabled Auto Focus brings precision video quality not

available with manual adjustments.Focus is no longer an issue during installation, saving time

while enhancing quality.

Adaptive Profile

With the innovative embedded Image Signal Processor (ISP), this camera responds to

changing lighting condition with customized algorithm.This allows for clear image with very

little noise at night.

H.264/MPEG-4/MJPEG Triple Codec Dual Streaming

This device supports 3 compression formats, H.264, MPEG-4 and MJPEG.It brings superior

image quality at 15 frames per second in Full HD 1080p (1920 x 1080). In 720p (1280 x 720)

and VGA resolution (640 x 480) the device reaches 30 frames per second.

Advanced WDR

Advanced WDR technology is the most advanced approach of improving the dynamic range of

the camera.While many other WDR technologies enhance the dynamic range while producing

noise, blur edges of objects and untrue colors, Advanced WDR is designed to improve the

dynamic range while keeping the true colors, sharp edges of objects and free from noise

DC Iris Control

With DC Iris Lens, this camera automatically adjusts incoming light levels to achieve the best

video performance.Wildly fluctuating outdoor lighting condition is no longer an issue with your

video quality.

www.acti.com

KCM-5511 Hardware User’s Manual

Powerful Bundled Surveillance Software

To extend the capabilities of the IP Box Camera series, a powerful surveillance program is

included in the package for free.Users can easily use an existing PC as a digital video recorder.

Scheduled recording and manual recording keep every important video recorded in the local

hard disk. Reliable and accurate motion detection with instant warning enables immediate

response in every condition.Quick and simple search and playback function lets you easily find

the images and video you want.

Software Development Kit Support

This IP Box Camera can be integrated or controlled by applications from third party software

developers. Software developers can save considerable efforts by using our Streaming Library

or ActiveX control.

Safety Instructions

Don’t use the power supply with other voltages

This device is likely to be damaged or damage other equipments / personnel, if you use a

power supply with different voltage than the one included with this device.All warranty of this

product will be voided in the situations above.

Don’t open the housing of the product

Cleaning

Disconnect this video product from the power supply before cleaning.

Attachments

Do not use attachments not recommended by the video product manufacturer as they may

cause hazards.

Water and Moisture

Do not use this video product near water, for example, near a bathtub, washbowl, kitchen sink,

or laundry tub, in a wet basement, or near a swimming pool and the like.

Don’t use accessories not recommended by the manufacturer

Only install this device and the power supply in a dry place protected from weather

www.acti.com

KCM-5511 Hardware User’s Manual

Servicing

Do not attempt to service this video product yourself as opening or removing covers may

expose you to dangerous voltage or other hazards. Refer all servicing to qualified service

personnel.

Damage Requiring service

Disconnect this video product from the power supply immediately and refer servicing to

qualified service personnel under the following conditions.

1) When the power-supply cord or plug is damaged

2) If liquid has been spilled, or objects have fallen into the video product.

3) If the video product has been directly exposed to rain or water.

4) If the video product does not operate normally by following the operating Instructions in

this manual. Adjust only those controls that are covered by the instruction manual, as an

improper adjustment of other controls may result in damage, and will often require

extensive work by a qualified technician to restore the video product to its normal

operation.

Safety Check

Upon completion of any service or repairs to this video product, ask the service technician to

perform safety checks to determine if the video product is in proper operating condition.

www.acti.com

KCM-5511 Hardware User’s Manual

Physical description

1) Micro SD / Micro SDHC Card Slot*

Insert your Micro SD card here for local recording on camera

2) Power LED

This LED light will indicate current camera status.

3) Audio Input / Output

The IP device supports audio input and output with earphone jack

4) Power Input

If you use Power Adaptor to run the device, please connect the power adaptor to the terminal

block in the way shown below.

5) Serial Port

This port connects to serial devices via RS-485 or RS-232 protocols.

www.acti.com

KCM-5511 Hardware User’s Manual

Pin Number

RS422

RS485

TX+

D+

TX-

D-

RX+

N.C.

RX-

N.C,

6) Reset Button

Step 1: Switch off IP device by disconnecting the power cable

Step 2: Press and continue to hold the Reset Button (with a sharp tipped object, like a pen.)

Step 3: Reconnect the power cable while continuing to hold the reset button. The red

Power LED light will flash on for 3 second first, turn off for about 15 seconds, flash on for

another second and turn off again. By this time the reset to default operation is already

completed. This will take around 20 seconds from power up. You may then release the

reset button.This length of time fluctuates slightly with the environment.The Power LED light

will come back on and stay on after a few more seconds.The unit will start up with factory

default settings automatically.

On (3s) On

Power On

About 20 Seconds

Stay On

Off (about 15s) Off (10~15s)

Restore to Default

Complete

7) Ethernet Port

The IP device connects to the Ethernet via a standard RJ45 connector. Supporting NWAY, this

IP device can auto detect the speed of local network segment (10Base-T/100Base-TX

Ethernet).

8) Digital Input / Output

Used in applications like motion detection, event triggering, time lapse recording, alarm

notifications, etc., the I/O terminal connector provides the interface to:

www.acti.com

KCM-5511 Hardware User’s Manual

•1 Transistor Outputs- For connecting external devices such as relays and LEDs.

Connected devices can be activated by Output buttons on the Live View page or through video

management software. Connect DO1 and DO2 to their closest 12V pin to activate.

•2 Digital Inputs- An alarm input for connecting devices that can toggle between an open

and closed circuit, for example: PIRs, door/window contacts, glass break detectors, etc.The

device will detect the change in digital input and transmit the signal to video surveillance

servers. The I/O terminal pins are numbered right to left,

Connect input/output devices to the camera as follows:

1. Attach the cables for the device securely to the supplied green connector block. Connect DI

pins to GND pins, and DO pins to 12V pins. Link pins 1/3, 2/4, 5/7,6/8.

2. Once cables are connected, push connector block into the terminal connector on camera.

FUSE 1A

NPN

DC TO DC

3.3V

DC POWER

GND 1

CONVERTER

EARTH GND

RELAY

DIODE

DEVICE

POWER INPUT

CAMERA
