ACTi D92 Manuel utilisateur

Indoor Mini Dome &

Indoor Mini Fisheye Dome

Hardware Manual

D91, D92, E91, E92, E93, E94, E95, E96,

E97, E98, E913

Ver. 2015/01/08

www.acti.com

Hardware Manual

Table of Contents

Precautions 4

Safety Instructions ...........................................................................6

Introduction 7

List of Models....................................................................................7

Package Contents.............................................................................9

Physical Description ......................................................................10

Installation Procedures 12

Installing the Camera on a Surface...............................................13

Installing the Camera on a Gang Box ...........................................16

Step 1: Install the Gang Box ........................................................17

Step 2: Install the Gang Box Converter........................................18

Step 3: Connect the Cable...........................................................19

Step 4: Install the Camera............................................................19

Step 5: Connect to Network .........................................................20

Step 6: Access the Camera Live View .........................................20

Step 7: Adjust the Viewing Angle and Focus................................20

Step 8: Close the Dome Cover ....................................................20

Basic Connections .........................................................................21

Other Adjustments and Accessories 22

How to Adjust the Viewing Angle and Focus ...............................22

How to Rotate the Viewing Orientation (E96 / E98)......................24

How to Replace the Dome Cover...................................................25

How to Replace the Lens (D91 / D92 only).................................... 27

Accessing the Camera 30

Configure the IP Addresses...........................................................30

www.acti.com

Hardware Manual

Using DHCP Server to Assign IP Addresses................................30

Using the Default Camera IPAddress..........................................32

Access the Camera.........................................................................34

www.acti.com

Hardware Manual

Precautions

Read these instructions

You should read all the safety and operating instructions before using this product.

Heed all warnings

You must adhere to all the warnings on the product and in the instruction manual. Failure to

follow the safety instruction given may directly endanger people, cause damage to the system

or to other equipment.

Servicing

Do not attempt to service this video device yourself as opening or removing covers may

expose you to dangerous voltage or other hazards. Refer all servicing to qualified service

personnel.

Trademarks

All names used in this manual are probably registered trademarks of respective companies.

Liability

Every reasonable care has been taken during the writing of this manual. Please inform your

local office if you find any inaccuracies or omissions. We cannot be held responsible for any

typographical or technical errors and reserve the right to make changes to the product and

manuals without prior notice.

www.acti.com

Hardware Manual

Federal Communications Commission Statement

This equipment has been tested and found to comply with the limits for a

class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Warning: Changes or modifications to the equipment that are not expressly approved by the

responsible party for compliance could void the user’s authority to operate the equipment.

European Community Compliance Statement

This product has been tested and found to comply with the limits for Class B

Information Technology Equipment according to European Standard EN 55022

and EN 55024. In a domestic environment, this product may cause radio interference in which

cause the user may be required to take adequate measures.

www.acti.com

Hardware Manual

Safety Instructions

Cleaning

Disconnect this video product from the power supply before cleaning.

Attachments

Do not use attachments not recommended by the video product manufacturer as they may

cause hazards.

Water and Moisture

Do not use this video product near water, for example, near a bathtub, washbowl, kitchen sink,

or laundry tub, in a wet basement, or near a swimming pool and the like.

Don’t use accessories not recommended by the manufacturer

Only install this device in a dry place protected from weather

Servicing

Do not attempt to service this video product yourself as opening or removing covers may

expose you to dangerous voltage or other hazards. Refer all servicing to qualified service

personnel.

Damage Requiring service

Disconnect this video product from the power supply immediately and refer servicing to

qualified service personnel under the following conditions.

1) When the power-supply cord or plug is damaged

2) If liquid has been spilled, or objects have fallen into the video product.

3) If the video product has been directly exposed to rain or water.

4) If the video product does not operate normally by following the operating Instructions in

this manual. Adjust only those controls that are covered by the instruction manual, as an

improper adjustment of other controls may result in damage, and will often require

extensive work by a qualified technician to restore the video product to its normal

operation.

Safety Check

Upon completion of any service or repairs to this video product, ask the service technician to

perform safety checks to determine if the video product is in proper operating condition.

www.acti.com

Hardware Manual

Introduction

List of Models

This hardware manual contains the following models:

D91

1MP Indoor Mini Dome with Fixed lens

D92

3MP Indoor Mini Dome with Fixed lens

E91

1MP Indoor Mini Dome with Basic WDR, Fixed lens

E92

3MP Indoor Mini Dome with Basic WDR, Fixed lens

E93

5MP Indoor Mini Dome with Basic WDR, Fixed lens

E94

1.3MP Indoor Mini Dome with Basic WDR, SLLS, Fixed lens

E95

2MP Indoor Mini Dome with Basic WDR, SLLS, Fixed lens

E96

5MP Indoor Mini Fisheye Dome with Basic WDR, Fixed lens

E97

10MP Indoor Mini Dome with Basic WDR, Fixed lens

E98

10MP Indoor Mini Fisheye Dome with Basic WDR, Fixed lens

www.acti.com

Hardware Manual

E913

3MP Indoor Mini Dome with Superior WDR, Fixed lens

www.acti.com

Hardware Manual

Package Contents

Camera

(Mini Dome)

Camera

(Mini Fisheye Dome)

Screw Kit

Drill Template

Hexagon Screwdriver

Lens Focus Tuner

(Not available in E93, E96, and E97 models)

Quick Installation Guide

Warranty Card

Drill Template

www.acti.com

Hardware Manual

Physical Description

Mini Dome

Mini Fisheye Dome
