ACTi PCDK Camera Demo Kit Manuel utilisateur

PCDK Camera Demo Kit

Product Manual

Ver. 2013/07/03

www.acti.com

User Manual

Table of Contents

Precautions............................................................................. 3

Safety Instructions ...........................................................................4

What is the Camera Demo Kit? ............................................. 5

What’s in the Box? ................................................................. 6

How to Prepare for a Demo? ................................................. 8

Must Have’s .......................................................................................8

Optional Items...................................................................................8

How to Use the Demo Kit?..................................................... 9

Step 1: Open the Demo Kit...............................................................9

Step 2: Mount the Accessories......................................................10

Step 3: Attach the Mount................................................................13

Step 4: Install the Camera..............................................................15

Using PMAX-0110........................................................................15

Using PMAX-0101 .......................................................................16

Step 5: Connect the PoE Injector ..................................................18

Step 6: Configure the Notebook for Demo ...................................19

Step 7: Do the Demo....................................................................... 20

Step 8: Repack the Demo Kit.........................................................22

www.acti.com

User Manual

Precautions

Read these instructions

You should read all the safety and operating instructions before using this product.

Heed all warnings

You must adhere to all the warnings on the product and in the instruction manual. Failure to

follow the safety instruction given may directly endanger people, cause damage to the system

or to other equipment.

Servicing

Do not attempt to service this product yourself. Refer all servicing to qualified service

personnel.

Trademarks

All names used in this manual are probably registered trademarks of respective companies.

Liability

Every reasonable care has been taken during the writing of this manual. Please inform your

local office if you find any inaccuracies or omissions. We cannot be held responsible for any

typographical or technical errors and reserve the right to make changes to the product and

manuals without prior notice.

On Warranty

All mounting accessories and the PoE injector in the demo kit have a warranty of one (1) year.

The travel suitcase is not covered under warranty.

www.acti.com

User Manual

Safety Instructions

Cleaning

Disconnect the built-in power injector in this product from the power supply before cleaning.

Attachments

Do not use attachments not recommended by the manufacturer.

Water and Moisture

Do not store this product near water, for example, near a bathtub, washbowl, kitchen sink, or

laundry tub, in a wet basement, or near a swimming pool and the like.

Servicing

Do not attempt to service this product yourself. Refer all servicing to qualified service

personnel.

Damage Requiring service

Disconnect the built-in power injector from the power supply and the camera immediately and

refer servicing to qualified service personnel under the following conditions.

1) When the power-supply cord or plug is damaged.

2) If liquid has been spilled, or objects have fallen into the built-in power injector.

3) If the product has been directly exposed to rain or water.

www.acti.com

User Manual

What is the Camera Demo Kit?

The Camera Demo Kit is a portable heavy duty travel suitcase with built-in demo stand and

related accessories for the purpose of doing a quick and convenient demonstration of the best

features of PTZ, hemispheric or dome cameras.

The Camera Demo Kit makes it possible to simulate both ceiling and wall installations right on

the desk.

Ceiling Mount Installation

Wall Mount Installation

www.acti.com

User Manual

What’s in the Box?

Travel Suitcase

Gooseneck Mount

Extension Tube

PMAX-0101 Mount Kit

PMAX-0110 Mount Kit

Universal Plug Converter

Ethernet Cable

(Male-to-Male) x 2

Ethernet Cable “Pigtail”

(Male-to-Female) x 3

Key x 6

* (1) cable pre-installed on

the PoE injector

* (1) cable pre-installed on

the Gooseneck

* (1) cable pre-installed on

the PoE injector

Mount Base

PoE Injector

Power Cord

* Comes built-in in the demo

kit base

* Comes built-in in with the

mount base

* Comes pre-installed on the

PoE injector

www.acti.com

User Manual

Screw Pack x 6

For Mount Kit

For Extension Tube

For Use with PMAX-0110

For Use with PMAX-0101

www.acti.com

User Manual

How to Prepare for a Demo?

The Camera Demo Kit contains the mounting accessories that you need to simulate a ceiling

and wall installation. However, you also need to prepare other equipment and tools to make

your demo more efficient.

Must Have’s

Below is a list of the equipment and tools that you need to bring or install when doing a demo:

Demo Camera (can be stored inside the demo kit)

Notebook computer

Screwdriver

Projector or Big-screen Monitor (if necessary)

Camera Demo Tool (must be downloaded and installed on your notebook)

The Camera Demo Tool is a Window based program to help you demo new products

more quickly and easily. Download Camera Demo Tool v1.5.04.13 from our website:

http://www.acti.com/product/detail/Video_Management_System/ACTi_Utility_Suite.

NOTE: The Camera Demo Tool uses the ActiveX control components that are

different from the ACTi NVR v2.x versions, hence, make sure the notebook does not

have any ACTi NVR software installed.

Optional Items

Camera placement is very important to project the best video output quality. That is why you

need to consider the distance between the demo site and the notebook placement or the

power outlet. For example, if the camera will be installed overlooking a window or outdoors on

the balcony and the notebook will be operated inside the building meeting room. It will be

practical to have the following tools on hand:

Long-length Ethernet cable

Power Extension Cord

www.acti.com

User Manual

How to Use the Demo Kit?

Step 1: Open the Demo Kit

1. Place the demo kit on an even surface.

2. Release the six (6) latches surrounding the demo kit.

3. Lift to remove the cover.

NOTE: Use the space for camera to place your camera inside the demo kit for easy

transport. The camera is not included upon purchase of the demo kit.

Space for Camera

www.acti.com

User Manual

Step 2: Mount the Accessories

1. Insert the pre-installed Ethernet cable through the extension tube.

2. Align the tab inside the extension tube to the base slot and install the tube to the base.

3. Twist the extension tube to secure it to the base.
