ACTi I71 Manuel utilisateur

Outdoor Hemispheric

Dome

Hardware Manual

I71, I73

2015/07/09

www.acti.com

Hardware Manual

Table of Contents

Precautions 4

Safety Instructions ...........................................................................6

Introduction 7

The List of Models ............................................................................7

Package Contents.............................................................................8

Physical Description ........................................................................9

Mounting Solutions ........................................................................10

Installing the Camera on a Surface 11

Step 1: Drill the Holes..................................................................... 11

Step 2: Open the Camera Cover....................................................13

Step 3: Prepare to Waterproof and Connect the Cable ...............14

Waterproof Solution with Naked Cable ........................................15

Waterproof Solution with Conduit.................................................17

Step 4: Install the Camera to the Surface.....................................20

Step 5: Connect Camera to Network.............................................20

Step 6: Access the Camera Live View...........................................21

Step 7: Close the Cover ................................................................. 21

Other Connections 22

Connecting a Power Adapter (Optional).......................................22

Connecting DI/DO Devices (Optional)........................................... 24

Connecting Audio In / Out Devices (Optional) .............................27

Other Adjustments and Accessories 28

How to Rotate the Viewing Orientation.........................................28

How to Install / Remove the Memory Card ................................... 29

How to Insert the Memory Card...................................................29

How to Remove the Memory Card............................................... 29

www.acti.com

Hardware Manual

How to Replace the Dome Cover................................................... 30

Accessing the Camera 32

Configure the IP Addresses........................................................... 32

Access the Camera.........................................................................36

www.acti.com

Hardware Manual

Precautions

Read these instructions

Read all the safety and operating instructions before using this product.

Heed all warnings

Adhere to all the warnings on the product and in the instruction manual. Failure to follow the

safety instructions given may directly endanger people, cause damage to the system or to

other equipment.

Servicing

Do not attempt to service this product yourself as opening or removing covers may expose you

to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

Trademarks

ACTi and ACTi logo are registered trademarks of ACTi Corporation. All other names and

products used in this manual are registered trademarks of their respective companies.

Liability

Every reasonable care has been taken during the writing of this manual. Please inform your

local office if you find any inaccuracies or omissions. ACTi will not be held responsible for any

typographical or technical errors and reserves the right to make changes to the product and

manuals without prior notice.

www.acti.com

Hardware Manual

Federal Communications Commission Statement

This equipment has been tested and found to comply with the limits for a

class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Warning: Changes or modifications to the equipment that are not expressly approved by the

responsible party for compliance could void the user’s authority to operate the equipment.

European Community Compliance Statement

This product has been tested and found to comply with the limits for Class B

Information Technology Equipment according to European Standard EN 55022

and EN 55024. In a domestic environment, this product may cause radio interference in which

cause the user may be required to take adequate measures.

www.acti.com

Hardware Manual

Safety Instructions

Cleaning

Disconnect this product from the power supply before cleaning.

Accessories and Repair Parts

Use only the accessories and repair parts recommended by the manufacturer. Using other

attachments not recommended by the manufacturer may cause hazards.

Installation

Install other devices (such as PoE injector, alarm, etc.) that will be used with the camera in a

dry place protected from weather.

Servicing

Do not attempt to service this product yourself. Refer all servicing to qualified service

personnel.

Damage Requiring service

Disconnect this product from the power supply immediately and refer servicing to qualified

service personnel under the following conditions.

1) When the power-supply cord or plug is damaged

2) If liquid has been spilled, or objects have fallen into the product.

3) If the inner parts of product have been directly exposed to rain or water.

4) If the product does not operate normally even by following the operating instructions in this

manual. Adjust only those controls that are covered by the instruction manual, as improper

adjustment of other controls may result in damage, and will often require extensive work

by a qualified technician to restore the product to its normal operation.

Safety Check

Upon completion of any service or repairs to this product, ask the service technician to perform

safety checks to determine if the product is in proper operating condition.

www.acti.com

Hardware Manual

Introduction

The List of Models

This hardware manual contains the following models:

I71

5MP Outdoor Hemispheric Dome with D/N, Advanced WDR, SLLS,

Fixed lens

I73

6MP Outdoor Hemispheric Dome with D/N, Advanced WDR, ELLS,

Fixed lens

www.acti.com

Hardware Manual

Package Contents

Check if the camera package comes with the following items.

Camera

Cable Gland

Conduit Gland

Hexagon Screwdriver

Screw Plugs

Screws for Surface Mount

Terminal Block

(for Power)

Terminal Block

(for DI/DO)

Terminal Block

(for Audio In/Out)

Warranty Card

Quick Installation Guide

Drill Template

IMPORTANT: When the camera is taken out from the box, the lens cover is covered by a thin

film. DO NOT remove this film. It is used to protect the lens from scratches or fingerprint marks

which may happen during installation. Remove this film only after the camera is securely

installed and all connections are complete.

Drill Template

www.acti.com

Hardware Manual

Physical Description

Item

Description

Reset Button

Restores the factory default settings of the camera. To reset the

camera, while the power is on, press and hold the Reset Button for

at least 5 seconds or until the Power LED lights up.

Audio Input / Output

Connects to audio input and output devices, such as microphones

and speakers. See Connecting Audio In / Out Devices

(Optional) on page 27.

Ethernet Port

Connects to a network using an Ethernet cable.

DC 12V Power Input

In case the camera is connected to a non-PoE (Power over

Ethernet) switch, use this connector to connect the camera to an

external power adapter. See Connecting a Power Adapter

(Optional) on page 22 for information.

Memory Card Slot

Insert a memory card (not included) into the slot for local recording

purposes. See How to Install / Remove the Memory Card on

page 29.

NOTE: Supports only microSDHC and microSDXC cards.

Digital Input / Output

Connects to digital input or output devices, such as an alarm

trigger, panic button, etc. Digital Input (DI) and Digital Output (DO)

devices are used in applications like motion detection, event

triggering, alarm notifications, etc. See Connecting DI/DO

Devices (Optional) on page 24 for information.

www.acti.com

Hardware Manual

Mounting Solutions

There are several mounting options that you can use to install the camera. Select the most

suitable solution for your installation environment.

Mount Types

Accessories

Surface Mount

Suitable when mounting the camera on flat and smooth surface, like ceilings

or walls. This solution directly installs the camera to the surface without

additional accessories. See Error! Reference source not found. on page

Error! Bookmark not defined. for more information.

Tilted Wall

Mount

Suitable when mounting the camera on high walls. The camera can be tilted

10 to capture a larger viewing angle below the camera and less on the

ceiling.

Pendant Mount

Suitable when mounting the camera on hard and high cielings.

Horizontal Pole

Mount

Suitable when mounting the camera on a horizontal pole.

Vertical Pole

Mount

Suitable when mounting the camera on a vertical pole.

Corner Mount

Suitable when mounting the camera on a corner area. The camera can also

be tilted 10 to capture a larger viewing angle below the camera and less

above.

NOTE:

For more information about the mounting solutions and accessories, please check the

Mounting Accessory Selector in our website (http://www.acti.com/mountingselector).

The mounting accessories are not included in the package. Contact your sales agents

to purchase.
