Acnodes MKD6220D Manuel utilisateur
Rack Consoles
All rights reserved. Product description and product specifications are subject to change without notice.
For latest product information, please visit Acnodes’ website at www.acnodes.com.
14628 Central Ave. Chino, CA 91710 Tel: 909.597.7588
Fax: 909.597.1939
© Copyright 2021 Acnodes Corp.
20.1" 1600 x 1200 LCD Keyboard Drawer
104-Key Keyboard with Touchpad
8-Port VGA DB-15 KVM Switch
MKD6220D
User Manual
Legal Information
First English printing, July 2020
Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness
of the contents. The information in this document is subject to change without notice. We are not liable for any injury or
loss that results from the use of this equipment.
Safety Instructions
Please read all of these instructions carefully before you use the device. Save this manual for
future reference.
■Unplug equipment before cleaning. Don’t use liquid or spray detergent; use a moist cloth.
■Keep equipment away from excessive humidity and heat. Preferably, keep it in an air-conditioned environment with
temperatures not exceeding 40º Celsius (104º Fahrenheit).
■When installing, place the equipment on a sturdy, level surface to prevent it from accidentally falling and causing
damage to other equipment or injury to persons nearby.
■When the equipment is in an open position, do not cover, block or in any way obstruct the gap between it and the
power supply. Proper air convection is necessary to keep it from overheating.
■Arrange the equipment’s power cord in such a way that others won’t trip or fall over it.
■If you are using a power cord that didn’t ship with the equipment, ensure that it is rated for the voltage and current
labeled on the equipment’s electrical ratings label. The voltage rating on the cord should be higher than the one listed
on the equipment’s ratings label.
■Observe all precautions and warnings attached to the equipment.
■If you don’t intend on using the equipment for a long time, disconnect it from the power outlet to prevent being
damaged by transient over-voltage.
■Keep all liquids away from the equipment to minimize the risk of accidental spillage. Liquid spilled on to the power
supply or on other hardware may cause damage, fire or electrical shock.
■Only qualified service personnel should open the chassis. Opening it yourself could damage the equipment and
invalidate its warranty.
■If any part of the equipment becomes damaged or stops functioning, have it checked by qualified service personnel.
What the warranty does not cover
■Any product, on which the serial number has been defaced, modified or removed.
■Damage, deterioration or malfunction resulting from:
□Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification, or
failure to follow instructions supplied with the product.
□Repair or attempted repair by anyone not authorized by us.
□Any damage of the product due to shipment.
□Removal or installation of the product.
□Causes external to the product, such as electric power fluctuation or failure.
□Use of supplies or parts not meeting our specifications.
□Normal wear and tear.
□Any other causes which does not relate to a product defect.
■Removal, installation, and set-up service charges.
Regulatory Notices Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
Any changes or modifications made to this equipment may void the user’s authority to operate this equipment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment offand on, the
user is encouraged to try to correct the interference by one or more of the following measures:
■Re-position or relocate the receiving antenna.
■Increase the separation between the equipment and receiver.
■Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Contents
< Part. 1 > MKD6220D
1.1 P.1
1.2 P.1-2
1.3 P.3-4
Package Content
Structure Diagram & Dimension
Installation
< Part. 2 > Specifications / OSD
2.1 Product Specifications P.5-6
2.2 Keyboard / Mouse Specifications P.7
< Part. 3 > Options
3.1 P.8DC Power : 12V / 24V / 48V / 125V
< Part. 4 > KVM Integration
4.1 P.9
VGA DB-15 KVM Switch
■It is very important to mount the equipment in a suitable cabinet or on a stable surface.
■Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive
dust, dirt, heat, water, moisture and vibration.
The equipment comes with the standard parts shown in package content. Check and make sure they are
included and in good condition. If anything is missing, or damaged, contact the supplier immediately.
Unpacking
Before Installation
How To Clean Your LCD Monitor
Caution :
■To avoid the risk of electric shock, make sure your hands are dry before unplugging your monitor from or
plugging your monitor into an electrical outlet.
■When you clean your monitor, do not press down on the LCD screen. Pressing down on the screen can
scratch or damage your display. Pressure damage is not covered under warranty.
■Use only cleansers made specifically for cleaning monitors and monitor screens. Cleansers not made to
clean monitors and monitor screens can scratch the LCD display or strip offthe finish.
■Do not spray any kind of liquid directly onto the screen or case of your monitor. Spraying liquids directly
onto the screen or case can cause damage which is not covered under warranty.
■Do not use paper towels or abrasive pads to clean your monitor. Using an abrasive pad or any wood based
paper product such as paper towels can scratch your LCD screen.
Cleaning Your Monitor
To clean your LCD safely, please follow these steps :
Disconnect the power cord.
Gently wipe the surface using a clean, dry microfiber cloth. Use as little pressure as possible.
1
2
Cleaning Tough Marks and Smudges
To remove tough marks and smudges, please follow these steps :
Disconnect the power cord.
Spray a small amount of non-abrasive cleanser on a microfiber cloth.
Gently wipe the surface. Use as little pressure as possible.
Wait until your monitor is completely dry before plugging it in and powering it up.
1
2
Caution : Do not spray or apply any liquids directly onto the monitor. Always apply the solution to your
microfiber cloth first, not directly on the parts you are cleaning.
3
4
P.1
MKD6220D unit X 1
- 6ft VGA console cable X 1
- Power cord X 1
- M6 screw, cage nut & cup washer X 8
1
3
Carry handle to release the 2-pt lock
LCD interchangeable module kit
Installation Slides
LCD membrane
1
2
3
5
6
7
7
Membrane switch ( KVM option )
Keyboard interchangeable module kit
Mouse interchangeable module kit
4
4
6
5
< 1.1 > Package Content
< Part 1 >
< 1.2 > Structure Diagram
2
P.2
Side View
Model Product Dimension
(W x D x H)
Packing Dimension
(W x D x H) Net Weight Gross
Weight
MKD6220D 439.6 x 650 x 44 mm
17.3 x 25.6 x 1.73 inch
595 x 860 x 140 mm
23.4 x 33.9 x 5.5 inch
15.5 kg
34.1 lb
23.4 kg
51.5 lb
< 1.2 > Dimension
Front View
UNIT : mm
1mm = 0.03937 inch
Top View
P.3
■Tighten all 8 pcs of M6 screw to complete the
installation.
Complete the installation
Step 4
< 1.3 > Installation - How to install 1U 20" LCD Tray
Left bracket
■Attach the left and right mounting bracket to
rack 19" mounting rails.
■Adjust the mounting bracket to fit your rack.
■M6 screw x 8 pcs included.
Step 1
Right bracket
Front side
Rear side
Leave all M6 screws slightly loose, until
you complete the installation in step 3
Step 2
■Pick up the LCD tray.
■Insert the LCD tray into the mounting bracket.
■Pull and hold the left & right black arrow buttons
on the rails.
■Return the LCD tray to park position.
Mounting bracket
Black arrow button
■Fix the rear kit to the mounting bracket with M3.2
screw x 4 pcs included.
Step 3
This step is necessary. Failure to complete this
will cause damage.
Front side
Rear kit
M3.2 screw
M6 screw
P.4
■Operate the LCD console drawer.
■Flip up the LCD to a suitable angle.
■Press the handle button and slide out the
drawer.
< 1.3 > Installation- How to use the drawer
P.5
Power Power Supply Range Auto-sensing 100 to 240VAC,
50 / 60Hz
Power Consumption
with KVM integration Screen ON Max. 78W
Power saving mode Max. 34W
Video
Connectivity
Analog VGA Analog 0.7Vp-p
LCD
Panel
Manufacturer
Panel Size ( diagonal ) 20-inch TFT color LCD
Display pixel ( dots x lines ) 1600 x 1200
Brightness ( typ. ) 300
Contrast Ratio ( typ. ) 800:1
Color 16.7 M
Viewing Angle ( L/R/U/D ) 89/89/89/89
Response Time ( ms ) 16
Dot pitch ( mm ) 0.255
Display Area ( mm ) 408.00H x 306.00V
Surface treatment Anti-glare, Hard-coating
Surface hardness 3H
Backlight Type CCFL
MTBF ( hrs ) 45,000
< Part 2 >
< 2.1 > Product Specifications
Regulatory Safety FCC & CE certified
Environmental RoHS2 & REACH compliant
Environmental
Conditions
Operating Temperature 0 to 55°C degree
Humidity 20~90%, non-condensing
Altitude 16,000 ft
Storage / Non-operating Temperature -20 to 60°C degree
Humidity 5~90%, non-condensing
Altitude 40,000 ft
Shock 10G acceleration (11ms duration)
Vibration 10~300Hz 0.5G RMS random
P.6
Applicable
Format
VGA Input PC Signal 1600 x 1200 x 60Hz
1400 x 1050 x 60Hz
1440 x 900 x 60Hz
1360 x 768 x 60Hz
1280 x 1024 x 60 / 75Hz
1280 x 960 x 60Hz
1280 x 768 x 60 / 75Hz
1152 x 864 x 75Hz
1024 x 768 x 60 / 70 / 75Hz
848 x 480 x 60Hz
800 x 600 x 60 / 72 / 75Hz
720 x 400 x 70Hz
640 x 480 x 60 / 72 / 75Hz
640 x 400 x 70Hz
640 x 350 x 70Hz
Physical
Specification
Product ( W x D x H ) 439.6 x 650 x 44 mm
17.3 x 25.6 x 1.73 inch
Packing ( W x D x H ) 595 x 860 x 140 mm
23.4 x 33.9 x 5.5 inch
Net Weight 15.5 kg / 34.1 lb
Gross Weight 23.4 kg / 51.5 lb
