ABB 2CSYD0201B Manuel utilisateur

2CSYD0201B

Outdoor dual IR detector

Installation manual

2CSYD0201B

1 GENERAL INFORMATION

1.1 Disclaimer

All information in this document has been carefully selected and checked however

ABB S.p.A. is not liable for any printing errors or technical inaccuracy.

ABB S.p.A. reserves the right to improve or change the products described in this

user manual at any time and without any advanced notice.

Moreover, it is possible that this user manual encompasses references or information

about products and services not sold yet. Such references or information do not

mean in any way that ABB S.p.A. intends to sell such products or services.

WARNING! Installation must be carried out only by a qualified electrician.

1.2 EC Declaration of Conformity

ABB S.p.A., with registered office in Milan - via Vittor Pisani 16, declares under its own

responsibility that the device with product code 2CSYD0201B meets the essential

electromagnetic compatibility and security requirements contained in the Directive

R&TTE 1999/5/EC and in the EC Low Voltage Directive 2006/95/EC, as it was

designed and manufactured in compliance with the following harmonized standards:

EN 300 220, EN 50131-1, EN 50131-2-2, EN 50131-5-3.

1.3 Package contents

no. 1 Outdoor dual IR detector

no. 1 Lithium battery 3 V – 1.4 Ah (not connected)

no. 2 Wall fixing brackets

no. 2 Self-tapping cross-recessed screws 2.9 x 27 mm

no. 2 Screw anchors Ø 5 mm

no. 1 Manual

1.4 Trademarks and copyright

DomusTech Free is a trademark of ABB S.p.A.

All trademarks in the document belong to the relevant owners.

2CSYD0201B

2 GENERAL DESCRIPTION

The outdoor dual IR detector enables to control buildings and areas from outside,

and it can be installed both on a wall and on a pole.

Thanks to two IR sensors, of which one can be adjusted, it is possible to detect

people and to avoid false alarms caused by little animals or cars passing by.

The detector is equipped with the anti-masking function.

2CSYD0201B

3 INSTALLATION

The installation procedure encompasses the following steps:

1) Device fixing.

2) Programming

3) Adjustment.

4) Completion and test.

3.1 Device fixing

INSTRUCTIONS RELEVANT TO POSITIONING

The device can be installed on a wall or on a pole, far from electromagnetic sources

(e.g. electricity meters, electric engines).

The detector shall be installed:

1) between 80 and 120 cm above the ground level (standard height 1 meter);

2) in a vertical position, otherwise its reliability will be lower;

3) in a way that the access is crosswise and not radial to the detector itself;

4) by avoiding to direct IR sensors towards moving objects (e.g. swaying

trees, bushes, flags, clothes hanging, etc.);

5) by avoiding to direct IR sensors towards reflecting objects (e.g. puddles,

windows, etc.).

6) Figure 1 graphically summarizes the above-mentioned indications.

Figure 1

2CSYD0201B

The detection of an intrusion attempt occurs only when both IR sensors are

stimulated. Figure 2 graphically summarizes how the detector operates.

Figure 2

Sensors can be horizontally adjusted from 45 to 135 degrees. The detection area is

set to 90 degrees and it can be masked. The coverage area of the lower sensor can

be vertically adjusted.

Figure 3 shows the coverage diagram (side view) for the 5 sensor inclination

positions when the detector is positioned at 1 meter height.

WARNING!The coverage distance of the detector is defined by the

coverage provided by the lower IR sensor.

Detection distance (detection height: 1 m)

IR position

Standard

(m)

Actual, according to the thermal conditions of the

environment

(m)

12,0

10,0 … 17,0

8,5

7,0 … 12,0

6,0

5,0 … 8,5

3,5,0

3,0 … 6,0

2,5

2,0 … 3,5

2CSYD0201B

Figure 3

Figure 4 shows the horizontal coverage diagrams according to the detector angular

position (A … G, D is a factory setting) of the sensor.

Figure 4

2CSYD0201B

To fix the detector (figure 5):

1) Remove the upper cover.

2) Loosen the screw and remove the front cover. WARNING: do not touch

mirrors or IR sensors!

3) Loosen the two front screws and remove the sensors-electronic unit.

WARNING: do not touch IR sensors.

4) Loosen the two screws and remove the rear cover.

5) Fix the rear cover of the detector with screws and screw anchors.

6) If you want to fix the detector on a supporting pole, insert two metal bands

(not provided) in the prearranged slots to block the detector to the pole.

Figure 5

3.2 Programming

The device programming is carried out through the DIP switch and the detector

acquisition by the control unit.

To program the detector:

1) Power the detector with the provided battery. The LED flashes.

2) Prepare the control unit to acquire the detector and select the required

area and memory location.

3) Stimulate the detector by passing the hand in front of the sensors (the LED

will flash). The detector will transmit its code that will be acquired by the

2CSYD0201B

control unit (for further information, refer to the control unit installation

manual).

3.3 Adjustment

It is possible to adjust the detection direction horizontally, the detection distance, the

masking of the detection area (to avoid possible obstacles) and the detection

sensitivity.

WARNING!Never touch mirrors or IR sensors with fingers!

To execute the adjustments (figure 6):

1) Refit the upper cover as well as the sensors-electronic unit

2) Rotate the mirrors-sensors set in order to direct the coverage area. Figure

4 shows the different coverages. In the positions A and G the detection

areas become 16.

3) Adjust the detection area by letting the lower sensor slide to the required

position 1, 2, 3, 4 or 5 (for the detection diagrams, refer to figure 3).

Figure 6

It is also possible to mask the detection area in order to change its range. To do that

(figure 7):

1) Remove the lens holder frame.

2) Remove the lens and apply the provided adhesive masking strips as

required.

3) Moreover, 5 adhesive sheets are provided for special masking ranges (the

coverage diagrams are printed on the adhesive sheets) by rotating the

mirrors-sensors set to the position A or G. In this case, it is necessary to

cut a piece of lens holder frame and to set the lower sensor to position 1.

2CSYD0201B

Figure 7

3.4 Completion and test

Complete the installation and test the detector (figure 8):

2CSYD0201B

Figure 8

1) Set the detector sensitivity (L = low, M = medium, H = high) with the proper

selector.

2) Set the DIP switch of the detector (see the following table).

3) Set the DIP switch 1 of the detector to ON (test mode).

4) Lay the front cover back on the device and walk in the area to be protected

to check if the detector signals possible intrusion attempts (the front LED

turns on). If there are no signals, try to adjust the detection area again or to

increase the sensitivity. Check if it works with the DomusLink3 control unit

(please read the installation and user manuals related to the control unit for

details about the detector test procedure).

5) Remove the front cover of the detector, set the DIP switch 1 to OFF

(standard operation), lay the cover back on the device and fix it with the

screw.

Switch

Function

Test mode.

OFF *

Standard operation.

2 ON

Suppression: only one alarm every 5 seconds is

generated even if multiple detections occurred (the

battery duration is reduced).

OFF *

Idem, but every 120 seconds.

ON *

N.O. Contact (do not change)

OFF

N.C. Contact (do not change)

4 ON

Active LED (it turns on for each detection during the

standard operation).

OFF *

Inactive LED.

5 ON *

Anti-masking activated. The detector issues an hazard

signal after having detected a masking condition for

more than 3 minutes.

OFF

Antimasking deactivated.

* Factory configuration

IMPORTANT: if the anti-masking function is activated, when you refit the front cover,

the detector starts the self-recognition phase that lasts 1 minute.
