Aaeon PER-C102 Manuel utilisateur
Ethernet Daughterboard PER-C102
PER-C102
Marvell 88E8036/52/53,
Dual PCI Express 10/100/1000
Ethernet DaughterBoard
PER-C102 Rev. A Manual 2nd Ed.
Oct. 2005
Ethernet Daughterboard PER-C102
i
Copyright Notice
This document is copyrighted, 2005. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.
Ethernet Daughterboard PER-C102
ii
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
• 1 PCI Express Cable
• 1 Gift Box
• 1 Conductive Bubble Bag
• 1 Accessory for jumpers
• 1 Flat Cable (with COM port version only)
• 1 PER-C102 DaughterBoard
• 1 Quick Installation Guide
• 1 CD-ROM for manual (in PDF format) and drivers
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.
Ethernet Daughterboard PER-C102
iii
Contents
Chapter 1 General Information
1.1 Introduction................................................................1-2
1.2 Features....................................................................1-3
1.3 Specifications............................................................1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions....................................................2-2
2.2 Location of Connectors and Jumpers .......................2-3
2.3 Mechanical Drawing..................................................2-4
2.4 List of Jumpers..........................................................2-5
2.5 List of Connectors .....................................................2-5
2.6 Setting Jumpers ........................................................2-6
2.7 LAN1, LAN2 Enable/Disable (JP1, JP2)...................2-7
2.8 RS-232 Serial Port Connector (CN4)........................2-7
2.9 LAN 1, LAN 2 Active LED Connector (CN1, CN6)....2-7
2.10 LAN 1, LAN 2 Speed LED Connector (CN2, CN5).2-7
2.11 PCI Express Connector (CN3)................................2-8
Chapter 3 Driver Installation
3.1 Installation.................................................................3-3
3.2 Wake-On-LAN Installation.........................................3-4
Ethernet Daughterboard PER-C102
Chapter 1 General Information 1 - 1
General
Chapter
1
Information
Ethernet Daughterboard PER-C102
Chapter 1 General Information 1 - 2
1.1 Introduction
The PER-C102 comes with two onboard Marvell
10/100/1000Base-T Gigabit Ethernet Controllers making this
add-on module suitable for high-performance network applications
such as Firewall PC, Entry PC, Hub PC and so on.
This Ethernet Daughterboard extends the PCI-Express interface
and is a new solution in industrial applications. It not only enhances
speed and performance of communications in any compatible
AAEON SBC (Single Board Computer), but also provides lifetime
support. In addition, the PER-C102 can work with other AAEON
full-size SBC, half-size SBC and firewall systems. You do not have
to adopt another solution to fulfill your expansion requirements, and
it allows you to keep a consistent solution.
The PER-C102 features dual LAN ports onboard which support
Gigabit LAN speed and reduces the cost of installation and
expansion. It is really a good choice for anyone serious about
industrial PC communications.
Ethernet Daughterboard PER-C102
Chapter1GeneralInformation1 - 3
1.2 Features
1. Dual PCI Express Host Interface
2. Dual 10/100 or 10/100/1000Base-T Triple-speed Ethernet
Controller
3. Supports Wake-On-LAN
Ethernet Daughterboard PER-C102
Chapter 1 General Information 1 - 4
1.3 Specifications
System
Chipset: PCI Express 10/100 or
10/100/1000Mb LAN optional
RJ-45 x 2, Marvell
88E8036/88E8052/88E8053
Expansion Interface: Dual PCI Express x 1 (DF-13,
30-pin)
Serial Port: One COM port: internal 5x2 Box
Header x 1; External D-sub x 1
Power Supply Request: From PCI Express connector
(DF-13 30-pin)
EMC: CE/FCC Class A
Operating Temperature: 32°F~140°F (0°C~60°C)
Ethernet Daughterboard PER-C102
Chapter2QuickInstallationGuide2-1
Quick
Installation
Chapter
2
Guide
Notice:
The Quick Installation Guide is derive
d
f
rom Chapter 2 of the user manual. Fo
r
other chapters and further installation
instructions, please refer to the use
r
manual CD-ROM that came with th
e
p
roduct.
Part No. 2007C10210 Printed in Taiwan September 2005
Ethernet Daughterboard PER-C102
Chapter 2 Quick Installation Guide 2-2
2.1 Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis
