Aaeon SBC-860 Manuel utilisateur
CD-ROM Part No. 2087860010
Mar 2003 printed in Taiwan
S
SBC-860
Full Size CPU Card
Socket 478 based Intel® Pentium® 4
processor with integrated Intel®
82845GV chipset, DDR, 4 USBs, Dual
Ethernet, & CompactFlash.
Full-size CPU Card SBC-860
i
Copyright Notice
This document is copyrighted, 2003. All rights are reserved. The original
manufacturer reserves the right to make improvements to the products
described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for any in-
fringements upon the rights of third parties that may result from its use.
The material inthis document is for product information only and is
subject to change without notice. While reasonable efforts have been
made in the preparation of this document to assure its accuracy,
AAEON assumes no liabilities resulting from errors or omissions in this
document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.
Full-size CPU Card SBC-860
ii
Acknowledgments
All other products’name or trademarks are properties of their respective
owners.
lAward is a trademark of Award Software International, Inc.
lCompactFlash ™is a trademark of the Compact Flash Association.
lIntel®,Pentium® 4, and Celeron® are trademarks of Intel®
Corporation.
lMicrosoft Windows®is a registered trademark of Microsoft Corp.
lITE is a trademark of Integrated Technology Express, Inc.
lIBM, PC/AT, PS/2, and VGA are trademarks of International Business
Machines Corporation.
lSoundBlaster is a trademark of Creative Labs, Inc.
Full-size CPU Card SBC-860
iii
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
•1 SBC-860 Full-Size CPU Card
•1 Quick Installation Guide
•1 CD-ROM for manual (in PDF format), BIOS, and drivers
•1 HDD Cable
•1 FDD Cable
•1 Audio and COM Port Cable with bracket
•1 LPT and COM Port Cable with bracket
•1 Y-Cable (Keyboard and Mouse)
•1 USB Cable with bracket
If any of these itemsshould bemissing or damaged, please contact your
distributor or sales representative immediately.
Full-size CPU Card SBC-860
iv
Contents
Chapter 1 General Information
1.1Introduction .................................................................................1-2
1.2Features.........................................................................................1-3
1.3Specifications................................................................................1-4
Chapter 2 Quick Installation Guide
2.1 Locating Jumpers & Connectors ...............................................2-2
2.2 Mechanical Drawing....................................................................2-4
2.3 Jumpers & Connectors................................................................2-6
2.4 Setting Jumpers............................................................................2-8
2.5 Front Panel (JP1) .........................................................................2-9
2.6 COM2 RS-232/422/485 Selection –1 (JP2).............................2-9
2.7 COM2 RI/+5V/+12V Selection (JP3).....................................2-9
2.8 COM2 RS-232/422/485 Selection -2 (JP4).............................2-10
2.9 CPU FSB Setting (JP5)................................................................2-10
2.10 Clear CMOS (JP6) .....................................................................2-10
2.11 Watch Dog Timer (JP7)............................................................2-10
2.12 ATX Power Connector (CN1).................................................2-11
2.13 System Fan Connector (CN2)..................................................2-11
2.14 Floppy Drive Connector (CN3)...............................................2-12
2.15 Parallel Port 1 Connector (CN4) .............................................2-13
2.16 ATX PWM 4P Power Connector (CN5)................................2-14
2.17 Primary IDE Hard Drive Connector (CN6) ..........................2-14
Full-size CPU Card SBC-860
v
2.18 Serial Port COM 2 (CN7).........................................................2-15
2.19 Serial Port COM 1 (CN8).........................................................2-16
2.20 Secondary IDE Hard Drive Connector (CN9)......................2-17
2.21 Wake on LAN Connector (CN10) ..........................................2-17
2.22 IrDA Connector (CN11) ..........................................................2-18
2.23 USB 2.0 Port 2 Connector (CN12)..........................................2-18
2.24 USB 2.0 Port 1 Connector (CN13)..........................................2-18
2.25 CRT Display Connector (CN14) .............................................2-19
2.26 Ethernet 10/100/1000 BaseT RJ-45 Phone Jack (CN15) ....2-19
2.27 Ethernet 10/100 BaseT RJ-45 Phone Jack (CN17)...............2-20
2.28 Audio Input/Output Connector (CN18) ...............................2-20
2.29 Mini-DIN PS/2 Connector (CN19)........................................2-20
2.30 CPU Fan Connector (CN20)....................................................2-21
2.31Internal Keyboard Connector (CN21)....................................2-21
2.32Internal Mouse Connector (CN22).........................................2-21
2.33Compact Flash Disk Connector (CN23) ................................2-22
2.34External 5V SB/PWRGD Connector (CN24).......................2-23
Chapter 3 Award BIOS Setup
3.1 System Test and Initialization.....................................................3-2
3.2 Award BIOSSetup......................................................................3-3
3.2.1 Main Setup............................................................................3-6
3.2.2 Advanced Features Setup.....................................................3-10
3.2.3 Default Setup.......................................................................3-32
3.2.4 Security Setup......................................................................3-33
3.2.5 PC Health Setup..................................................................3-34
Full-size CPU Card SBC-860
vi
3.2.6 Clk/Voltage Setup...............................................................3-36
3.2.7 Exit Setup............................................................................3-37
Chapter 4 Driver Installation
4.1 Installation 1.................................................................................4-2
4.2 Installation 2.................................................................................4-3
4.3Installation 3.................................................................................4-4
Appendix A Programming the WatchDog Timer
A.1 How to program the watchdog timer...................................A-2
Full-size CPU Card SBC-860
Chapter 1 General Information 1-1
General
Information
Chapter
1
Full-size CPU Card SBC-860
Chapter 1 General Information
1 -2
1.1 Introduction
Introducing AAEON’s new SBC-860, powered by Intel Pentium®4
processor, full size form factor single board computer (SBC) with an
onboard CompactFlash Type II and four USB 2.0!
SBC-860 successfully deployed Intelmost advanced 82845GV chipset,
which supports high CPU frequencyup to 3.06 GHz with front side bus
running at 400MHz /533MHz. SBC-860 supports Intel Hyper-Threading
Technology gives you the best overall Pentium 4 processor performance
available. SBC-860 also provides high memory capacityup to 2 GB DDR
DRAM (DDR 200/266).
In addition to its powerful computing engine, the full functionaldesign of
the board includes features such as chipset integrated 2D/3D graphics
engine with AGP 4x bandwidth, built-in USB2.0 and on board
CompactFlash Type II socket. SBC-860 delivers super graphic
performance without additional cost on integrated Intel 82845GV chipset,
and provides unique IntelExtreme Graphics architecture to maximize
VGA performance capability.
Four USB 2.0ports provide an expandable, Plug and Play serial interface
that ensures a standard low-cost connection for peripheral devices.
Industrial applications will benefit from the four USB2.0 by two
pin-headers, offering 480Mbps high-speed efficiency and value without
compromising performance.
Full-size CPU Card SBC-860
Chapter 1 General Information
1 -3
Moreover, SBC-860 is also equipped with Dual Intel Ethernet controllers.
One of these providessuperior 1Giga Mbps networking access ability for
high speed networking applications such as gateway, VPN, Mini server.
In short, this product is a versatile P4 level compact board with the best
cost-performance for CTI, networking, mini-server markets.
1.2Features
nSupports Intel® Pentium® 4mSocket 478 CPU
nIntegrated AC-97 2.1 codec PCI 3D Audio
nSupports type II CompactFlash
n4 USB ports onboard
nHigh Drive design to enhance the ISA driving capacity
nSupports H/W status monitoring
nSupport 1 IrDA
nOnboard 2 IDE connectors (Support 4 devices)
nSupports Ultra DMA 100
nDual Ethernet (1 Intel® 82562 phy , 1 82551QM/ER or 82540EM)
for option
