MP8740 Projecteur multimédia Guide de l'opérateur

MP8740 Multimedia-Projektor Benutzerhandbuch

Proyector de Multimedia MP8740 Manual del Usuario

MP8740 Proiettore Multimediale Manuale dell'operatore

MP8740 Bruksanvisning for multimediaprojektor

MP8740 Multimedia Projector Gebruiksaanwijzing

MP8740 Multimedia Projector

Operator's Guide

EPS-36A

Downloaded from Projector.com

ENGLISH

Table of Contents

Safeguards .................................................................................................................1

Warranty .................................................................................................................2

Section 1: Unpack .......................................................................................................3

1.1 Contents of Shipping Box............................................................................................ 3

1.2 Optional Accessories ................................................................................................... 3

1.3 Keep Your Packing Materials ...................................................................................... 3

1.4 What's Next? ................................................................................................................ 3

Section 2: Product Description ..................................................................................4

2.1 Machine Characteristics............................................................................................... 4

2.2 Part Identification List ................................................................................................. 4

2.3 System Setup................................................................................................................ 5

2.4 Remote Control Transmitter Identification ................................................................. 6

Section 3: Basic Operations........................................................................................7

3.1 Projector Startup .......................................................................................................... 7

3.2 Projector Shutdown ..................................................................................................... 7

Section 4: Adjustments and Functions......................................................................8

4.1 Menu Navigation ......................................................................................................... 8

4.2 How To Use Height Adjustment Feet .......................................................................... 9

4.3 SETUP ......................................................................................................................... 10

4.4 INPUT.......................................................................................................................... 11

4.5 IMAGE ........................................................................................................................12

4.6 OPT .............................................................................................................................. 13

Section 5: Maintenance...............................................................................................14

5.1 Cleaning the Air Filter ................................................................................................. 14

Section 6: Lamp...........................................................................................................15

6.1 Lamp ............................................................................................................................ 15

6.2 Display Lamp Operation Hours................................................................................... 15

6.3 Replacing the Lamp ..................................................................................................... 15

Section 7: Troubleshooting .........................................................................................17

7.1 Sympton/Solution Table .............................................................................................. 17

7.2 Message/Solution Table ............................................................................................... 17

Section 8: Accessories .................................................................................................18

8.1 Service Information ..................................................................................................... 18

Appendix: Technical Information...............................................................................A.1

Downloaded from Projector.com

3M™Multimedia Projector MP8740 © 3M 1999

ENGLISH

Downloaded from Projector.com

ENGLISH

Safeguards

WARNING - Indicates a potentially hazardous situation which, if not avoided, could result in

death or serious injury.

Caution - Indicates a potentially hazardous situation which, if not avoided, could result in

minor or moderate injury. It may also be used to alert against unsafe practices.

2. Close supervision is necessary when any appliance is used by or near children. Do not leave

appliance unattended while in use.

3. Never look directly into the projector lens when the lamp is on. The metal halide lamp produces

a strong light which could damage your eyesight.

4. Care must be taken as burns can occur from touching hot parts.

5. Do not operate appliance with a damaged cord or if the appliance has been dropped or

damaged – until it has been examined by a qualified service technician.

6. Position the cord so that it will not be tripped over, pulled, or contact hot surfaces.

7. If any extension cord is necessary, a cord with a current rating at least equal to that of the

appliance should be used. Cords rated for less amperage than the appliance may overheat.

8. Always unplug appliance from electrical outlet before cleaning and servicing and when not in

use. Grasp plug and pull to disconnect.

9. To reduce the risk of electric shock, do not immerse this appliance in water or other liquids.

10. To reduce the risk of electric shock, do not disassemble this appliance, but take it to a qualified

technician when service or repair work is required. Incorrect assembly can cause electric shock

when the appliance is subsequently used.

11. Connect this appliance to a grounded outlet.

12. Do not expose this projector to direct sunlight, or use it outside.

13. Keep all ventilation openings free of any obstructions.

14. Always open the lens shutter when the projection lamp is on.

15. Do not look directly into light beam of laser pointer.The pointer produces a strong light which

could damage your eyesight.

16. The projection lamp contains mercury. Always dispose of it in a proper manner according to local

regulations.

SAVE THESE INSTRUCTIONS

The information contained in this manual will help you operate and maintain your 3M MP8740

Multimedia Projector.

IMPORTANT SAFEGUARDS

1. Read and understand all instructions before using.

Pay particular attention to areas where this symbol is shown.

INTENDED USE

Before operating the machine, please read the entire manual thoroughly. The 3M™Multimedia

Projector 8740 was designed, built and tested for use indoors, using 3M™brand lamps and nominal

local voltages. The use of other replacement lamps, outdoor operation or different voltages has not

been tested and could damage the projector or peripheral equipment and/or create a potentially

unsafe operating condition.

Downloaded from Projector.com

3M™Multimedia Projector MP8740 © 3M 1999

ENGLISH

Warranty

THANK YOU FOR CHOOSING 3M

Thank you for choosing 3MMultimedia Projector equipment. This product has been produced in accordance

with 3M's highest quality and safety standards to ensure smooth and trouble free use in the years to come.

For optimum performance, please follow the operating instructions carefully. We hope you will enjoy using this

high performance product in your meetings, presentations and training sessions.

LIMITED WARRANTY

3M warrants this product against any defects in material and workmanship, under normal usage and storage, for a

period of two years from date of purchase. Proof of purchase date will be required with any warranty claim. In

the event this product is found to be defective within the warranty period, 3M's only obligation and your

exclusive remedy shall be replacement of any defective parts (labor included).

To obtain warranty service, immediately notify the dealer from which you purchased the product of any defects.

In the USA call 1-800-328-1371 for warranty or repair service.

LIMITATION OF LIABILITY

THE FOREGOING WARRANTY IS MADE IN LIEU OFALL OTHER WARRANTIES, EXPRESSED OR IMPLIED,AND 3M

SPECIFICALLY DISCLAIMSANY IMPLIED WARRANTYOF MERCHANTIBILITYAND FITNESS. 3M SHALLNOT BE

LIABLE FORANY DAMAGES, DIRECT, CONSEQUENTIAL, OR INCIDENTAL, ARISING OUT OFTHE USE OR INABILITY

TO USE THIS PRODUCT.

Important: The above warranty shall be void if the customer fails to operate product in accordance with 3M's

written instructions. This warranty gives you specific legal rights and you may have other rights which vary from

state to state.

FCC STATEMENT - CLASSA: This equipment generates, uses and can radiate radio frequency energy, and if

not installed and used in accordance with the instruction manual may cause interference to radio communications.

It has been tested and found to comply with the limits for a Class "A" computing device pursuant to Subpart B of

Part 15 of the FCC Rules, which are designed to provide reasonable protection against such interference when

operated in a commercial environment. Operation of this equipment in a residential area is likely to cause

interference in which case the user at his/her own expense will be required to take whatever measures may be

required to correct the interference.

EEC STATEMENT: This machine was tested against the 89/336/EEC (European Economic Community) for

EMC (Electro Magnetic Compatibility) and fulfills these requirements.

Video signal cables: Double shielded coaxial cables (FCC shield cable) must be used and the outer shield must

be connected to the ground. If normal coaxial cables are used, the cable must be enclosed in metal pipes or in a

similar way to reduce the interference noise radiation.

Video inputs: The input signal amplitude must not exceed the specified level.

IBM is a registered trademark of International Business Machines Corporation. Apple Macintosh and Apple

Powerbook are registered trademarks of Apple©Computer, Inc. Microsoft and Windows 95 are registered

trademarks, and Windows and Windows for Work Groups are trademarks of the Microsoft Corporation.

Toshiba is a registered trademark of Toshiba Corporation. Kensington is a trademark of Kensington

Corporation. All other products are trademarks or registered trademarks of their respective companies.

Downloaded from Projector.com

ENGLISH

Section 1: Unpack

1.1 Contents of Shipping Box

The 3M™ MP8740 Multimedia Projector is shipped with the necessary cables required for standard VCR, PC,

MAC™II or laptop computer connections. Carefully unpack and verify that you have all of the items shown

below in Figure 1.1.

1.4 What Next?

After you have unpacked the MP8740 system and identified all the parts, you are ready to set up the projector.

Figure 1.1 Inventory of Shipping Box

The shipping carton contains the items illustrated in Figure 1.1. In addition, the following items are also

included, but not shown here. If any of these items are missing, please contact your place of purchase.

• PS/2 mouse cable .............. (1)

• ADB mouse cable ............. (1)

• Serial mouse cable ............ (1)

• Stereo mini-jack ................ (1)

1.2 OptionalAccessories

• RS-232 control cable ........ (1)

1.3 Keep Your Packaging Materials

✔Important

Save the shipping box and packing materials in the event the MP8740 should require shipping to a 3M

Service Center for repair.

INPUT

RGB1/2 VIDEO1/2

BLANK TIMER

MENU ON MOUSE ON

RIGHT

LASER

VOLUME

MUTESTANDBY/ON

ZOOMFOCUS

POSITION ON

RESET

EPS-37A

Power Cord

110V - US

220 - UK, Europe

3-Conductor

Video/Audio Cable

MP8740 Multimedia Projector Remote ControlTransmitter

(batteries included)

VGA Cable

(15-15 pin M/M) Adapter

with dip switch Video Cable

(S-Video mini DIN4-pin)

Downloaded from Projector.com

3M™Multimedia Projector MP8740 © 3M 1999

ENGLISH

Section 2: Product Description

2.1 Machine Characteristics

The

MP8740 Multimedia Projector integrates metal halide lamp and polysilicon LCD display technology into a single unit. It

accepts input from two different computer sources and two video/audio sources and projects a bright, super crisp image.

Switching your presentation from a computer input to a video input, and then back to a computer input simply requires the

push of a button on the remote control keypad or control panel keypad.

The MP8740 Multimedia Projector offers the following features:

• Metal halide projection lamp

• XGA resolution (3 separate 1024 x 768 LCD

panels are used for the R, G and B signals)

• Advanced SXGA scaling (60 Hz and 75 Hz)

• Advanced VGA and SVGA scaling

• Compact size, light weight for portability

• RGB (computer video) output terminal

• Serial, PS/2 andApple© Desktop Bus (ADB)

mouse emulation

• Power zoom and power focus functions

• Easy to set up and use

• Ability to display 16.7 million colors

• Two computer input connections

• Two video input connections

(composite and S-video compatible)

✔Note

The MP8740 is one of the brightest projectors in the marketplace. The brightness of your machine will

vary depending on the ambient room conditions and contrast/brightness settings.

• Full function remote control

• Two built-in stereo speakers (2 watts each)

• Horizontal and vertical image inverting function

• Horizontal and vertical image position control

• Fixed keystone correction

• On screen menu with seven languages

• Universal power supply

• IR sensor in front and rear for maximum remote

control range

• RS-232 control capability

• Optional ceiling mount kit

• Laser pointer (remote control)

• Color balance control for data/video

• Kensington™ lock

2.2 Part Identification List

Figure 2.1 Identifying MP8740 Parts

1. Remote control transmitter

2. Stereo speakers

3. Control Panel Keypad

a) STAND BY/ON button

b) ON, LAMP, TEMP, Indicator

c) INPUT, MUTE, RESET buttons

d) ZOOM, FOCUS, MENU buttons

4. Remote Control Sensors (front/back)

5. Terminal Connection Panel

a) S-Video, Vidoe, Audio inputs

b) RGB1 and RGB2 inputs

c) RGB output

d) Audio L/R input, Audio output

(stereo mini jack)

e) RS-232 Control

f) AC input-power cord connection

g) Main power switch

h) Kensington™ lock

6. Height Adjustment Feet

7. Lens shutter (open/closed)

8. Projection lens

9. Cooling fan exhaust

10. Carry handle

INPUT

RGB1/2 VIDEO1/2

BLANK TIMER

MENU ON MOUSE ON

RIGHT

LASER

VOLUME

MUTESTANDBY/ON

ZOOMFOCUS

POSITION ON

RESET

Downloaded from Projector.com

ENGLISH

S-VIDEO VIDEO AUDIOLR

RGB IN

RGB OUT

CONTROL

AUDIO

OUT

AUDIO

S-VIDEO VIDEO AUDIOLR RGB IN

RGB OUT

CONTROL

AUDIO

OUT

AUDIO

EPS-39A

CRT

Display

MAC

or PC

MP8740

Laser Disc

VCR

Audio L/R

Video Power

Laptop

MAC

OUT

RGB IN

MONITOR

PORT

MONITOR

PORT

PS/2 or

SERIAL

PORT

INININ

IN IN IN

OUT

OUTOUTOUT

REDWHTYEL

OUT

REDWHT

OUT

Audio Right

Audio Left

S-VHS

RGB IN

CONTROL

RGB OUT

2.3 System Set Up - connecting various equipment

Turn power off to all devices before making connections. Never plug anything into the projector or

computer while any device is in operation.

The MP8730 must be powered down when making connections. The mouse emulation may not work if

the unit is not powered down before the mouse cable connections are made.

2.3.1 Apple™Desktop Mouse - The Macintosh operating system should recognize the MP8740 as a mouse

without any drivers being loaded.

VirtualMouse for PC Computer - For IBM™ compatible computers, the operating systems will need to

be set to "Serial Mouse" or "PS/2 Mouse" to recognize the projector as a mouse pointer device

Change mouse driver information to "Serial Mouse" or "PS/2 Mouse."

a) Windows™95 - Click "Start"; select "Settings"; select "Control Panel". Click on "Mouse"; select the

"General" tab; (see what driver is currently loaded and make note of it); select "Change"; select

"Show all devices"; (make note of the current Manufacturer and Model); select "Standard Mouse

Type" for Manufacturer; then select "Standard Serial Mouse" or "Standard PS/2 Mouse." Click OK

to change and apply the new driver. Restart Windows when prompted.

b) Windows™3.1 - From "Program Manager" click "Main"; then click "Windows Setup", (make note of

what the current mouse driver is); Click "Options"; then "Change Systems Settings". Choose

"Mouse". It should be listed as "Microsoft or IBM PS/2".

✔Note

For proper mouse operation, always turn the projector power on first and then power up the computer.

For some laptop computers you may need to disable the internal pointing device (IPD). This is done through

the BIOS level set up of the particular machine, or it could be listed in a "Utilities" program group, i.e., "Toshiba

Utilities™," or "Thinkpad Features™."

Caution

Figure 2.2 Cable Connections

Downloaded from Projector.com

3M™Multimedia Projector MP8740 © 3M 1999

ENGLISH

INPUT

RGB1/2 VIDEO1/2

BLANK TIMER

MENU ON MOUSE ON

RIGHT

LASER

VOLUME

MUTESTANDBY/ON

ZOOMFOCUS

POSITION ON

RESET

STANDBY / ON button

Set main power switch to ON.

Press and hold STANDBY/ON button for

projector mode (lamp on) or standby

mode (lamp off).

ZOOM button

Press +/- to adjust image size.

Note: If needed, move projector

closer/further from screen.

FOCUS button

Press +/- to adjust image sharpness.

POSITION button

Press and light POSITION button.

Move DISK PAD to adjust horizontal/

vertical image position.

DISK PAD

Select mode, then move DISK PAD to

position image, navigate menus or control

mouse functions. To select the mode:

• Press and light POSITION button for

position mode.

• Press and light MENU ON button for

menu mode.

MENU ON button

Press and light MENU ON button to

display the Main Menu. Move DISK PAD

to select menu and/or adjust screen

values.

BLANK ON button

Press BLANK to display a blank

background with no image. Press again to

return the image to the screen.

INPUT buttons

RGB 1/2: Select computer video input

(RGB1 ➔RGB2 ➔RGB1).

VIDEO 1/2: Select video inputs

(VIDEO1 ➔VIDEO2 ➔VIDEO1).

MUTE button

Press MUTE to switch the audio

sound ON or OFF

VOLUME button

Press +/- to adjust internal/external speaker

volume.

LASER POINTER

Press and hold down button to project laser

pointer.

CAUTION

To prevent injury to eyesight, do not point

laser beam at other persons or look directly

into laser beam.

RESET / RIGHT MOUSE button

RESET: When a menu is being displayed,

press RESET to return menu value to factory

setting.

RIGHT MOUSE: When computer image is

being displayed, press for right mouse button

function.

MOUSE ON button

Press MOUSE ON button to activate mouse

mode. Move DISK PAD to control mouse

functions.

TIMER ON / OFF button

Press TIMER to display and start the timer as

set in OPT menu setting. Note: Timer will not

display on a blank screen. To remove TIMER

display press again.

2.4 Remote Control Transmitter Identification

Backside

of Remote

Figure 2.3 Remote Control Buttons

LEFT MOUSE

button

C A U T I O N

LASER RADIATION

DO NOT STARE INTO BEAM

WAVE LENGTH: 670 nm

MAX. OUTPUT: 1mW

CLASS II LASER PRODUCT

Battery Cover

(Use AA or LR6 batteries)

Laser Aperture

AVIOD EXPOSURE-LASER

RADIATION IS EMITTED

FROM THIS APERTURE

LASER APERTURE

Table des matières

Autres manuels 3M Projecteur

3M Multimedia Projector X62w Manuel d'utilisation

3M MPro120 - VGA LCOS Projector Manuel d'installation et d'exploitation

3M X26i Manuel utilisateur

3M Multimedia Projector S10 Manuel utilisateur

3M X64W - Digital Projector XGA LCD Manuel

3M X56 Manuel utilisateur

3M Digital Projector X20 Manuel

3M Multimedia Projector S15 Manuel d'utilisation

3M X95I - Digital Projector XGA LCD Manuel

3M Multimedia Projector X62 Manuel

3M Multimedia Projector MP8760 Manuel

3M DX70i Manuel utilisateur

3M 1860 - Plus Overhead Projector Manuel d'exploitation et d'entretien

3M Multimedia Projector X68 Manuel

3M Multimedia Projector S15 Manuel

3M PX5 Series Manuel d'installation et d'exploitation

3M Multimedia Projector X80 Manuel utilisateur

3M MPro120 - VGA LCOS Projector Manuel utilisateur

3M Digital Projector X30 Manuel d'installation et d'exploitation

3M Digital Projector X30 Manuel utilisateur

3M X95I - Digital Projector XGA LCD Manuel d'installation et d'exploitation

3M SCP740 Manuel utilisateur

3M Personal Projector MP7720 Manuel utilisateur

3M Multimedia Projector X70 Manuel d'utilisation

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur
