2000 OverheadProjector

IllustratedPartsBreakdown

2000 OverheadProjectorIllustratedPartsBreakdown

E3MIPC2000

RevisionHistory

Revision bars( ) arenotusedinthisupdate.

Theoriginal issueofthismanualand subsequentrevisionsareidentifiedasfollows:

Issuedate:3/92

Revision DatePage(s)ChangedChange

OriginalMarch 1992 All pages

November1995 All pages

March 1997 All pagesGloballyintroducekit formatting on all pages.

M2000 HardwareRepairKit(78-8062-1150-0)

appearsin all illustrations.

2000 Cover, footers,page 7--17 Changed partnumberon page 7--17,item1.

2000 OverheadProjectorIllustratedPartsBreakdown

E3MIPC2000

Thispageintentionallyleft blank

2000SeriesOverheadProjectorsIPB--TableofContents

E3MIPC2000

Introductioniii..................................................................

PartNumbersiii................................................................

LocatingandIdentifyingaPartiii.................................................

MachineIdentificationPlate1....................................................

Section0OVERVIEW2.......................................................

Section1MIRRORHOUSINGASSEMBLYSPAREPARTKIT3.....................

Section2BASEANDBASETOPASSEMBLYSPAREPARTKIT4...................

Section3LAMPASSEMBLY--EVWSPAREPARTKIT5...........................

Section4LAMPMODULEASSEMBLY--FSYSPAREPARTKIT6...................

Section5LAMPMODULEASSEMBLY--FSXSPAREPARTKIT7...................

Section6TOPSHROUDASSEMBLY--EVWSPAREPARTKIT8....................

Section7TOPSHROUDASSEMBLY--FSX/FSYSPAREPARTKIT9.................

Section8PROJECTIONLENSASSEMBLY--SINGLETSPAREPARTKIT10............

Section9PROJECTIONLENSASSEMBLY--TRIPLETSPAREPARTKIT11............

Section10FOCUSMECHANISMASSEMBLYSPAREPARTKIT12..................

Section11POSTANDPIVOTASSEMBLY--DOMESTICSPAREPARTKIT13..........

Section12POSTANDPIVOTASSEMBLY--INTERNATIONALSPAREPARTKIT14....

Section13RESISTORKIT16...................................................

Section14STAGECOVERASSEMBLY--DOMESTICSPAREPARTKIT17.............

Section15WIREJUMPERS18..................................................

AppendixASPECIFICATIONS21...............................................

2000 OverheadProjectorIllustratedPartsBreakdown

iii

E3MIPC2000

Introduction

ThisIllustratedPartsBreakdown(IPB)containsthe

information necessarytolocate and identifyspecific

partsofthe2000 OverheadProjector.

PartNumbers

All componentsavailableon areplacementbasisare

listedwiththeir3Midentification number.Theparts

identification listopposite eachillustration provides

thedescription adequatetoidentifycomponents.

Locating and Identifying a Part

If physicalappearance and general location ofanitem

areknown:

1. UsetheOverviewillustration to determinewhich

section includestheitem.

2. Refertothesection and locatetheitemon the

exploded viewillustration.

SDashedlinebox definesassembled kits.

SCommon fastenersareonlyavailableby

ordering thehardwarekit.

SItemsoutsidethedashedlinebox are

availableseparately.

Thepart identification numbersprovidedinthis

manualarefrom themostcurrentdata available.

Makesurepart identification numbersforyour

componenthavenotbeenamended by changesand

updatesmadeto your2000 OverheadProjector.

MachineIdentificationPlate

TheMachineIdentification Plateislocated on the

insidewall ofeach projectorand lists specific

information that isneededwhencalling fortechnical

assistance orordering parts.

3M2000 OVERHEADPROJECTOR

MODEL 2000AG

812856

250

Figure 1-1. MachineIdentificationPlate

When ordering parts,includepart identification

number, description, quantityand thefollowing

information:

1. ProductName:Thespecificversion numberof

theprojector.

2. ModelNumber/AlphaCode:Theseriesnumberof

theprojector followed by athree or fourcharacter

alpha codeidentifier.TheAlphaCodeindicates

thedesign level,specificproductcharacteristics,

powercord ordistribution specifictoa country.

3. MFGCode:TheMFGCodeindicatestheyear

and quartertheprojectorwasbuilt.See example

below:

MFGCode

LetterDigit

L 1992 1 Jan -- Mar

M1993 2 Apr -- Jun

A1994 3 Jul-- Sep

C1995 4 Oct-- Dec

D1996 1 Jan -- Mar

E1997 2 Apr -- Jun

4. Lamp:The electricalrating ofthelamp.

5. S/N:Theserialnumberassignedtothisprojector.

Forpartorderscontact:

Dealers:RefertoDealersGuide

3MSubsidiaries:ContactExportOperations

Retail Customers:

FAX:1-800-852-3917

Telephone:1-800-328-2883

3MtOverheadProjector2000 IllustratedPartsBreakdown

E3MIPC2000

QuickReference Parts Index

SectionItem

DescriptionPartNumber No. No.

FRESNEL LENS,Reflective, 10.5 S, 187.1mm,FL78-8014-7442-6 14 2A...................... ... ...

FRESNEL LENS,Reflective, 10.5 T, 187.1mm,FL78-8014-6798-2 14 2B...................... ... ...

FRESNEL LENS,Reflective,A4S, 187.1mm,FL(ForJapanesemodelsalso)78-8014-7443-4 14 2C. ... ...

FRESNEL LENS,Reflective,A4T, 187.1mm,FL78-8014-6799-0 14 2D....................... ... ...

FRESNEL LENS,Reflective,A4, 187.1mm,FL,Japan 78-8065-8588-7 14 2F................... ... ...

FUSE, 5 Amp, 5 X20mm,Slow Acting (All exceptABJand ABJT)26-1005-9599-5 2 6A......... ... ....

FUSE, 5 Amp, Japan(ABJ,ABJT)JJ-9960-0007-8 2 6B.................................... ... ....

LAMP,Projection, EVW, 82V78-8014-6796-6 3 2........................................ ... .....

LAMP,Projection, FSY, 400W, 240V78-8057-4163-0 4 2.................................. ... .....

LAMP,Projection, FSX, 400W, 230V78-8057-4162-2 5 2................................. ... .....

POWER CORD,Australia78-8057-4196-0 12 4A........................................... ... ...

POWER CORD,Europe78-8057-4170-5 12 4H............................................ ... ...

POWER CORD,Italy 78-8062-1368-8 12 4D.............................................. ... ...

POWER CORD,JapanJY-2000-0001-8 12 4B............................................. ... ...

POWER CORD,SouthAfrica 78-8057-4204-2 12 4E........................................ ... ...

POWER CORD,Switzerland 78-8057-4199-4 12 4G........................................ ... ...

POWER CORD,UnitedKingdom78-8057-4191-1 12 4I.................................... ... ...

POWER CORD,UnitedStates, 10’78-8064-1536-6 11 4A................................... ... ...

POWER CORD, 3MLogo, 2 Blade WithGround, 10’78-8062-1378-7 11 4B.................... ... ...

3MtOverheadProjector2000 IllustratedPartsBreakdown

E3MIPC2000

Section0

OVERVIEW

Base and BaseTop Assembly

(See Section 2 )

Top Shroud Assembly

(See Sections6 and 7 )

LampAssemblies

(See Sections3,4 and 5 )

PostPivotAssembly

(See Sections11 and 12 )

MirrorHousing Assembly

Projection Lensand Focus

Mechanism

(See Sections8,9 and 10 )

Stage CoverAssembly

(See Section 14 )

ToSection One

3MtOverheadProjector2000 IllustratedPartsBreakdown

E3MIPC2000

Section1

MIRRORHOUSINGASSEMBLYSPAREPARTKIT

NOTE:Screws,Nuts,Bolts,Clips,and etc.arecontained inHardwareKit78-8062-1150-0.

Section1

MIRRORHOUSINGASSEMBLYSPAREPARTKIT

ItemNo. PartNumber DescriptionQty

1 78-8057-4230-7MIRRORHOUSING ASSEMBLYSparePartKit 1......... ... ............................

2JV-1890-0234-6LABEL,Caution,Mirror,Japan 1......... ... ...........................................

3M Overhead Projector 2000 IllustratedParts Breakdown

E3M IPC2001

Section 2

BASE AND BASE TOP ASSEMBLY SPARE PART KIT

NOTE: Screws, Nuts, Bolts, Clips, and etc. are contained in Hardware Kit 78-8062-1150-0.

9, 10

11 12

Section 2

BASE AND BASE TOP ASSEMBLY SPARE PART KIT

Item No. Part Number Description Qty

1 78-8062-1114-6 BASE AND BASE TOP ASSEMBLY Spare Part Kit 1......... ... ..........................

2 26-1002-4730-8 PLUG, Hole, Black 1......... ... .....................................................

3 78-8044-6919-1 TRANSFORMER, Japan (ABJ, ABJT) 1......... ... .....................................

4 26-1005-7653-2 HANDLE, Plastic, Molded 1......... ... ...............................................

5A 78-8057-4158-0 SWITCH, ON/OFF (S/N 860256 and below) 1

........ ... ................................

5B 78-8057-0959-5 SWITCH, ON/OFF (S/N 860257 and above) 1

........ ... ................................

6A 26-1005-9599-5 FUSE, 5 Amp, 5 X 20mm, Slow Acting (All except ABJ and ABJT) 1........ ... .............

6B JJ-9960-0007-8 FUSE, 5 Amp, Japan (ABJ, ABJT) 1........ ... ........................................

7A 26-1001-6189-7 FUSEHOLDER, Panel Mounted (All except ABJ and ABJT) 1........ ... ...................

7B 26-1001-6190-5 FUSEHOLDER, Panel Mounted (ABJ, ABJT) 1........ ... ...............................

8 78-8057-4166-3 FUSEHOLDER ASSEMBLY 1......... ... .............................................

9 78-8062-1362-1 LABEL, M2000T, Japan 1......... ... ................................................

10 78-8062-1361-3 LABEL, M2000S, Japan 1........ ... ................................................

11 78-8057-4186-1 LABEL, General Instructions 1........ ... .............................................

12 JV-0890-0183-6 LABEL, Caution, Japan 1........ ... .................................................

13 78-8057-4184-6 LABEL, Fuse Replacement, 5 Amp 1........ ... .......................................

3MtOverheadProjector2000 IllustratedPartsBreakdown

E3MIPC2000

Section3

LAMPASSEMBLY--EVWSPAREPARTKIT

NOTE:Screws,Nuts,Bolts,Clips,and etc.arecontained inHardwareKit78-8062-1150-0.

Section3

LAMPASSEMBLY--EVWSPAREPARTKIT

ItemNo. PartNumber DescriptionQty

1 78-8062-1090-8LAMPASSEMBLY--EVWSparePartKit 1......... ... ..................................

2 78-8014-6796-6LAMP,Projection,EVW,82V1......... ... ............................................
