3D Systems Viper Pro SLA iPro 8000 Manuel utilisateur

Viper Pro

quick start

guide

Thank you forpurchasing theViperPro

system .

Before using this equipm ent,please read this guide

carefullytoenjoyoptimum performanceand longer

service life.

Docum ent23XXX-M XX-00 Revision 1X DRAFT Decem ber2005

3D System s,the3D System slogo,and ViperPro are registered tradem arksof3D System s,Inc.

Othertradem arksare theproperty oftheirrespective ow ners.

To prepare and build a part, see Quick System Overview on page 11.

The Viper Pro system runs on 200-240 VAC / 50-60Hz, single phase power 30A for the single

resin delivery module and 50A for the dual and extra large resin delivery module.

iSee “Facility Requirements Guide: Viper Pro SLA System” for complete Viper Pro system electrical,

mechanical, environmental, and network requirements.

™

What’s Inside? 3

New Features 7

Hazard Messages 9

Other Useful Documents

Here you’ll find a listing of other documents that may be helpful to you as you use the Viper Pro.

Quick System Overview

This section gives you a quick look at everything on the Viper Pro.

Operator Interface

This section describes xx

quick start guide what’s inside?

RDM Installation and Removal

This section describes how to install and remove the Resin Delivery Module (RDM). It also

provides blade removal and off-line temperature information.

Software Overview

This section gives an overview of how to use the software that is connected to the Viper Pro. It

includes the pictures of software screens, as well as information on how to open, start, complete,

and remove a build.

Debris Filtering

This section tells you how to filter debris from the Viper Pro.

Image Projection Module

This section gives information on geometric calibrations and laser calibrations, xx (et al.)

Safety

Read this section before you start a Viper Pro build. It tells you how to handle resin properly and

how to avoid damage and injury when running the Viper Pro.

quick start guide what’s inside?

For more detailed material safety information, see (xx: other manuals to consult? and their part

number). To verify that your facility was properly prepared for the Viper Pro, see Facility

Requirements Guide: Viper Pro SLA System. Your 3D Systems Viper Pro accessory kit includes

both guides. They are also available in the /Docs folder on your Viper Pro software CD-ROM.

See Other Useful Documents on page 10.

Maintenance

This section lists Viper Pro maintenance procedures that must be performed to ensure high part

yield and low Viper Pro down time. You can perform some maintenance procedures. Semi-annual

preventive maintenance requires a certified 3D Systems Customer Support Representative. xx:

Brian Ward to give important information?

Glossary

Are you wondering what stereolithography is all about? Do you have questions about the

SmartSweep Recoating Process? In this section, we’ve covered the definitions that you need to

operate the Viper Pro.

Troubleshooting

If you run into difficulty with your Viper Pro system, look for solutions in this section first. You’ll

find descriptions of some common problems that can occur and suggestions of corrective actions.

This section also defines error messages that you might see on the computer display and tells you

what to do if you see a message.

quick start guide what’s inside?

Customer Support

Have you read everything and you still can’t figure it out? Give us a call! This section tells you

how. We’re glad to help!

Legal Notices

This section explains our legal stance; please read it!

quick start guide new features

New Features

The Viper Pro has the following features that are improvements over SLA models:

Resin Delivery Module

Single Resin Delivery Module

The Viper Pro is capable of building with only one resin delivery module while the second

delivery module is inactive. As mentioned in the previous paragraph, the second module can be

warmed up offline while the first is building. A single resin delivery module can upgrade to a dual

resin delivery module in less than two days.

Dual Resin Delivery Module

The Viper Pro can also build parts in two separate build zones. Each zone is independently

capable of supporting its own active resin delivery module and motion axis control, allowing

controlled builds in both zones simultaneously and allowing those builds to use different resins.

Extra Large Resin Delivery Module

The Viper Pro can operate so that two build zones combine into a single larger build zone to create

larger parts that figure into a single contiguous envelope. The extra large resin delivery module

allows for a build zone of 1500mm x 750mm x 500mm.

quick start guide new features

Intelligent Resin Container

Each container holds an electronic storage device that has information about the resin that is in the

bottle. This information allows the Viper Pro to make sure that the user does not use the wrong

material, use the material incorrectly, use an empty container, or use an expired container.

Resin Change Time Reduction

Not only can you now change resin time in less than ten minutes, you can also swap the resin

delivery module easily without coming into contact with resin. All components that come in

contact with resin in the resin delivery module are removed with the module itself. You can

remove the resin delivery module easily and quickly and replace it with another active resin

delivery module, without having to clean any wet resin surface. This new feature significantly

reduces resin swap time. In addition, you may warm up a resin delivery module offline, allowing

you to swap one resin delivery module for another that is ready to use.

Recoating Module

Scanning System

The scanning system makes the laser draw.

quick start guide hazard messages

Hazard Messages

You will find four types of safety hazard message in this Viper Pro Quick Start Guide:

Also see the Safety section for descriptions of safety labels on your Viper Pro.

Damage Hazard

Machine damage, part damage, and/or data loss can result if you ignore this type of

hazard message.

Electric Shock Hazard

Injury or death from electric shock can result if you ignore this type of hazard

message.

UV Radiation Hazard

Eye injury or blindness can result if you ignore this type of hazard message.

Irritant Hazard

Bodily irritation or allergic reaction can result if you ignore this type of hazard

message.

quick start guide Other Useful Documents

Other Useful Documents

The following documents will help your Viper Pro system to achieve its maximum proficiency.

You can find them in the \Documentation folder of your Viper Pro Software CD.

Viper Pro Client Online Help

Run the Viper Pro software, then select Help > Help Topics in the software window or the 3-D

Print Preview window to launch Viper Pro Client online Help. The online Help provides detailed

instructions on how to use the Viper Pro software to set up, run, and manage print jobs.

Viper Pro Material Handling Guide

This multi-language document has everything that you need to know in order to handle and

dispose of Viper Pro material safely. It also includes relevant regulatory guidelines for material

disposal worldwide.

Viper Pro Facility Requirements Guide

To see what preparation you must do for your site prior to installing the Viper Pro, read Facility

Requirements Guide: Viper Pro SLA System. A pdf copy is installed on your system for reference.

Viper Pro Material Safety Data Sheets (MSDSs)

These online copies of the printed Viper Pro model material MSDS ship with Viper Pro materials.

Make sure that everyone in your facility who handles Viper Pro materials reads these MSDS and

follows the safety guidelines in them. To order extra copies of these MSDS, request them from 3D

Systems.
