Benefits

802.11g Wireless

Hot Spot Gateway

g-4100 v2

High-Speed Bandwidth Sharing and

Complete Firewall in a Box

Integrated Hotspot service

Scalable User Authentication and

Accounting

Rich Networking Functions

Customized Login Page,

Advertisement URL Link and Walled

Garden Features

All-in-One Hotspot Gateway

ZyXEL G-4100 v2 is an all-in-one hotspot gateway that provides secure free or charged Internet access

according to business policies.It provides authentication and accounting function for both wireless and

wired clients, and supports up to 100 concurrent users.The G-4100 v2 work with SP-200E statement printer

to generate and print tickets with account, password,and pre-configured time for Internet access hours

automatically through a few button clicks on SP-200E. All functions required for hotspot services are self-

contained in the G-4100 v2.

Scalable, Easy-to-Manage User Authentication and Accounting

With an easy-configuration authentication server embedded in the G-4100 v2, no additional hardware or

software are required for hotspot operators such as coffee shops, book stores, hotels or resorts to offer

Internet services.The G-4100 v2 also supports RADIUS server for large-scale hotspot service deployments

in chain stores or airport terminals to provide roaming service from one spot to another through

centralized authentication and accounting features.

Best Hotspot User Experience with Security and Privacy

To provide the best hotspot user experience, the G-4100 v2 features rich networking functions such as IP

PnP, DHCP server, NAT, MAC address and IP address filtering.The IP PnP technology enables the ultimate

“zero configuration”user experience by taking care of the IP networking transparently, which dramatically

improves user satisfaction and reduces technical support needs. User no longer needs to change the IP

address, subnet mask, default gateway,Web proxy and even SMTP server settings.Moreover,V-LAN security

for wired and wireless client,NAT, Layer 2 isolation, as well as MAC and IP address filtering technologies also

work behind the scene to ensure protected user privacy,keeping sensitive personal data from being

exposed to the public.

Tailor-Made Hotspot Gateway

With powerful marketing features built into the G-4100 v2, operators can customize the login page, redirect

user to advertisement links, or provide limited Internet access to the designated home page.Additionally,

powerful management features such as SSL login page, secure remote function, LAN and WLAN device

management are all specifically designed for hotspot offerings. For easy deployment, the G-4100 v2

support PoE and the PoE-capable SP-200E statement printer, so the hotspot solution can be freely placed

regardless of the power outlet location.The G-4100 v2 is not only a gateway tailor-made for hotspot

deployments, but also customizable to fit business and service needs.

Specifications

IP Plug and Play (iPnP technology)

• Easy-to-Use,Zero Configuration IP Plug and

Play Internet Access

Rich Networking Functions

• NAT

• Outgoing SMTP Server Redirection

• DNS Redirection

• Various WAN connections

(Static IP/DHCP Client/PPPoE/PPTP)

• DHCP Server

• Transparent HTTP Proxy

• NTP (Network Time Protocol) support

User Authentication and

Accounting

• Supports up to 100 concurrent users

• Web-based Authentication

• Idle-timeout Control

Security and Firewall

• Layer 2 Isolation Security

• SSL Login Page and Administration

• VPN (IPSec/PPTP/L2TP) Pass through

• Pass through IP and MAC Address

• Custom SSL Certificate

• Administration Access Control

Management

• Web-based management tool

• TFTP/HTTP firmware upgrade

• Central scheduled firmware upgrade

• Backup/Restore Configuration file

• WLAN/LAN devices Management

• Devices Status Monitor

• Session List

• Syslog Messaging System

• Default printer (SP-200E) support

Marketing Cooperation

• Passthrough IP/MAC/URL

• Custom Login Page

• Login Page Redirect

• Advertisement URL link

• Walled garden

• Portal page redirection

Hardware Specifications

Network Specification

• IEE802.3 10BaseT Ethernet

• IEE802.3u 100BaseTX Fast Ethernet

• IEE802.11g Wireless LAN

Compatibility

• Communicate with Wi-Fi certificated

wireless adapters

Connectors

• 4 LAN Ports and One WAN Port

• 10/100BaseTX with auto MDI/MDI-X

• RS-232 port (For debugging and testing

purpose only)

Wireless Operation Range

• Open Space: 100~300m

• Indoors: 35~100m

Wireless Data Rate

• Up to 54 Mbps with auto fallback with 802.11b

Encryption

• WEP 64/128, WPA/WPA2-PSK, WPA/WPA2

Enterprise,WPA/WPA2 Mixed Mode

Physical Specifications

External Antenna Type

• 2dBi (Max) Dual detachable diversity antenna

with reverse SMA connector

Power Requirement

• External Power Adapter

- Input: 100-240 VAC, 50/60 Hz, 0.35 A

- Output: 5V, 2A

• POE

•Dimensions: 212.5 (W) x 138.5 (D) x 52.0 (H) mm

•Weight: 508 g

LED Indicators

• One POWER LED

• One WAN Link/Activity LED

• Four LAN Link/Activity LEDs

• One Sys LED

• One Blue Wireless Link/Activity LED

Environmental Specifications

Environment Conditions

•Operating Temperature: 0˚C ~50˚C

•Storage Temperature: -30˚C ~60˚C

• Humidity: Max. 90% non-condensing

brands, product names,or trademarks mentioned are the property of their respective owners. All specifications are subject to change without notice.

For more product information, visit us on the web www.ZyXEL.com

Corporate Headquarters

ZyXEL Communications Corp.

Tel: +886-3-578-3942

Fax: +886-3-578-2439

Email: [email protected]

http://www.zyxel.com

http://www.zyxel.com.tw

ZyXEL Denmark A/S

Tel: +45 39 55 07 00

Fax:+45 39 55 07 07

Email: [email protected]

http://www.zyxel.dk

ZyXEL France SARL

Tel: +33 (0)4 72 52 97 97

Fax:+33 (0)4 72 52 19 20

Email: [email protected]

http://www.zyxel.fr

ZyXEL Hungary

Tel: +36-1-336-1646

Fax: +36-1-325-9100

Email: [email protected]

http://www.zyxel.hu

ZyXEL North America

Tel: +1-714-632-0882

Fax: +1-714-632-0858

Email: [email protected]

http://www.us.zyxel.com

ZyXEL Poland

Tel: +48 (22) 333 8250

Fax:+48 (22) 333 8251

Email: [email protected]

http://www.pl.zyxel.com

ZyXEL Spain

Tel: +34 902 195 420

Fax:+34 913 005 345

Email: [email protected]

http://www.zyxel.es

ZyXEL UK Ltd.

Tel: +44 (0) 1344 303044

Fax:+44 (0) 1344 303034

Email: [email protected]

http://www.zyxel.co.uk

ZyXEL Finland Oy

Tel: +358-9-4780 8400

Fax: +358-9-4780 8448

Email: [email protected]

http://www.zyxel.fi

ZyXEL Czech s.r.o.

Tel: +420 241 091 350

Fax:+420 241 091 359

Email: [email protected]

http://www.zyxel.cz

ZyXEL Germany GmbH.

Tel: +49 (0) 2405-6909 0

Fax:+49 (0) 2405-6909 99

Email: [email protected]

http://www.zyxel.de

ZyXEL Kazakhstan

Tel: +7-327-2-590-699

Fax: +7-327-2-590-689

Email: [email protected]

http://www.zyxel.kz

ZyXEL Norway A/S

Tel: +47 22 80 61 80

Fax:+47 22 80 61 81

Email: [email protected]

http://www.zyxel.no

ZyXEL Russia

Tel: +7 (095) 542-8920

Fax:+7 (095) 542-8925

Email: [email protected]

http://www.zyxel.ru

ZyXEL Sweden A/S

Tel: +46 (0) 31 744 77 00

Fax:+46 (0) 31 744 77 01

Email: [email protected]

http://www.zyxel.se

ZyXEL Ukraine

Tel: +380 44 494 49 31

Fax:+380 44 494 49 32

Email: [email protected]

http://www.ua.zyxel.com

65-100-410002G 08/06

Application

Diagram

WEP Encryption

WPA

Web-based Authentication

VPN Pass Through

Internet

G-4100 v2

xDSL/Cable

Modem Local User Authentication

Local Billing System
