Zonestar P802CR2 Manuel utilisateur
Model:P802CR2/P802CU2
Installation Guide
Ver 3.0
www.zonestar3d.com Youtube Channle Facebook Group
Version
Date
Author
Check
Remark
V1.0
2016-10-20
Tony
Hally
First Version
V2.0
2017-1-12
Tony
Hally
Add Power Supply and Hotbed
V3.0
2017-4-27
Sea
Hally
Upgraded Package etc.
2
Version history
Video Tutorial
Caution: Hot!
Extruder has high temperature even the printer stop working.
Caution: Hot!
Bed has high temperature even the printer stop working.
Please put it away from the reach of kids.
Must be guided by adults when children are installed or used.
Take care when wiring, to avoid electrical shock hazards.
Please strictly follow the standard operation when assembling.
Be careful not to cut yourself while installing.
Please keep well-ventilated condition! May produce
toxic gases when printer working.
ATTENTION
Acrylic is brittle, please be careful not to damage when assemble.
3
Parts Picture
A1 A2 A3 A4 A5 A6
B1 B2
B3 B4 B5
B2
C1 C2 C3
C4
C4 C5 C6
D1 D2 D3
D4 D5
FIG
Name
FIG
Name
FIG
Name
FIG
Name
FIG
A1
Base Frame Left
B1
Hotend Frame Front
C1
Z Right Support
D1
Pulley gaskets
P1
Ball Bearing bracket
Bottom
A2
Base Frame Right
B2
Hotend Frame Side
C2
Z Right Frame
D2
Feeder piece
A3
Base Frame Top
B3
Hotend Frame Top
C3
Z Motor Support
D3
Y Endstop support
P2
Ball Bearing bracket
Top
A4
Base Frame Bottom
B4
Hotend Frame
Bearing Cover
C4
Heatbed Bearing
Cover
D4
lead rod restriction
A5
Base Frame Back
C5
Y Motor Support
D5
M5 nut Wrench (tools)
A6
Base Frame Front
B5
Hotend Frame Back
C6
Feeder Support
E1
Heatbed bracket
E1
P1 P2 P2
Screws and nuts
M8 nut (x12)
M8 shim (x12)
M3x30 Screw (x7)
M2.5x15 Screw (x2)
M2.5 Nut (x2)
M3 Hand Nute (x4)
Φ4.5*22 Springs (x4)
M3x6 Screw (x8)
5x10 Shim (x4)
5x7 E-Washer (x2)
M3x12 pole (x12)
M3 Nut (x60 )
M3X20 Screw (x45)
M3x10 Screw (x45)
5x6x7 Pole (x2)
M3x16 Screw (x12)
M5x35 Screw (x1)
M5 Nut (x5)
M3X45 pole (x1)
Assemble the ball bearing to Y-axis belt pulley holder, lock with screw
and nut.
Notice:smooth surface of shim towards ball bearing.
Assemble Y-axis belt pulley
6
M5 nut
Y-axis belt pulley
holder *2
ball bearing 625zz
M5x35
shim 5x10x0.8 *2
Shim 6x20x1.2 *2
Pre-Assembled
1. Push bearings into slot, and then through the two bearings by sliding rod and test if it
can move smoothly.
2. Install the M5 copper nut to the red part.
3. Insert the nylon pole to the red part, and mount a screw and spring and lock it.
Assemble slider module(left) Pre-Assembled
LM8UU *2
M5 copper
nut
M3x8 pole
Spring
M3x30
1. Push bearings into slot, and then through the two bearings by sliding rod and test if
it can move smoothly.
2. Mount the ball bearing to the part, use screw and nut to lock.
3. Install the M5 copper nut to the red part
Assemble slider module(right)
M5 Nut
shim 5x10x0.8*2
M5x20
ball bearing 625zz
LM8UU linear bearing *2
8
Pre-Assembled
1. Install a stepper motor (23mm shaft lenght) to the left silder, lock with 3 pcs
M3x6 screws.
2. Mount one pulley to the stepper motor, lock the jbckscrew on the pulley.
Install X-axis Motor
9
Note: Please pay attention to
the installation direction of the
pulley and the position on the
motor shaft.
M3*6 x3
clamp mechanism
shim M4
U-bearing
M4x10
1 2
3
jbckscrew
M3x3 *2
M3x6
motor holder
Adapter
•Assemble Extruder Engine(EM4)
10
