ESKY005437 Transimtter User Manual
1. Transimtter
Throttle & Rudder
Stick (Mode2)
Throttle Trim
Lever (Mode 2)
Rudder Trim
Lever (Mode 2)
Elevator & Aileron
Stick (Mode2)
Elevator Trim
Lever (Mode 2)
Aileron Trim
Lever (Mode 2)
Power Switch
Antenna Charging Slot for
Esky150 LiPo
Battery
LED Indicator
1) Switch onthe helicopter powersupply (switch towardto the helicoptertail), the statusindicator on
helicopter flashes rapidly.
2) Press andhold the rightbutton of therudder trim lever, and switch on the transimtter simultaneously.
3) When thestatus indicator isoff on the helicopter,release the rightbutton of therudder trim lever.
Then the status indicator issolid light onthe helicopter againwhich indicates the binding successfully.
2.Binding
1) Place fourAAbatteries inside thetransmitter correctly.
2) For safety, switch off the helicopter and transmitter.
3) Plug thecharging cable intothe charging portunder the helicopterbattery and plugthe other end
into the chargingslot behind thetransmitter. Then, there isa solid greenlight on thetransmitter's LED
indicator.
4) When theLiPo battery insidethe helicopter isfully charged, thegreen light willgo out.
Diagram for thecharging process
3.How to charge Esky150
4.Transimtter Control
Mode 2
Mode 1
Mode 2
Mode 1
When pushing theELEVATOR stick upor down, thehelicopter moves forwardor backward accordingly.
When moving theRUDDER stick left or right, thehead of the helicopter moves left or right accordingly.
When pushing theTHROTTLE stick upor down, the helicopter lifts up or descends accordingly.
When moving theAILERON stick left or right,the helicopter slides left or right accordingly.
ESKY005437 Transimtter User Manual
Warning: Changes or modifications tothis unit not expressly approved by theparty responsible for compliance could void
the user sauthority to operate the equipment.
NOTE: This equipmenthas been testedand found to comply with the limits for aClass B digital device, pursuant toPart 15
of the FCCRules. These limitsare designed to provide reasonable protection against harmful interferencein a residential
installation. This equipmentgenerates, uses andcan radiate radiofrequency energy and, if not installed andused in
accordance with theinstructions,may cause harmful interference to radiocommunications.
However, thereis no guarantee that interference will not occur in a particular installation. If this equipmentdoes
cause harmful interferenceto radio or television reception, whichcan be determined by turning the equipment
off and on,the user isencouraged to try to correct the interference by oneor more of the following measures:
Reorient or relocatethe receiving antenna.
Increase the separationbetween the equipment and receiver.
Connect the equipmentinto an outlet on a circuit different from that to which thereceiver is connected.
Consult the dealeror an experienced radio/TV technician for help.
This device complieswith Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may notcause harmful interference, and (2) thisdevice must accept any interference received, including
interference that maycause undesired operation.
Tocomply with FCC s RF radiationexposure limits for general population/uncontrolled exposure,this device
must be operatedonly in hands with a separation distance of at least 20 cm from its antennato the body. In add-
ition it mustnot be collocated or operating in conjunction with any other antenna or transmitter.
FCC ID: 2AAB6-HK0002
Item Number:ESKY005437
Zonda Hobby Technologies Electronic Ltd
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
Correct Disposal ofthis product. Thismarking indicates that this product should not be disposed with
other household wastesthroughout the EU. Toprevent possible harm to the environmentor human health from
uncontrolled waste disposal,recycle it responsibly to promote thesustainable reuse of material resources. To
return your useddevice, please use the return and collection systems or contact the retailerwhere the product
was purchased. Theycan take thisproduct for environmental safe recycling.
Hereby, ZONDAHOBBY TECHNOLOGIES ELECTRONIC LIMITED, declaresthat this is in compliance
with the essentialrequirements and other relevant provisions ofDirective 1999/5/EC
ESKY005437
