VISU 200

Surgical Microscope

Instructions for use

G30-1298-en

Issue 2.0

Printed on 09. 11. 2006

G30-1298-en VISU 200 Surgical Microscope Issue 2.0

Printed on 09. 11. 2006

Key to symbols

Warning!

The warning triangle indicates potential sources of danger which

may constitute a risk of injury for the user or a health hazard.

Caution:

The square indicates situations which may lead to malfunction, de-

fects, collision or damage of the instrument.

Note:

The hand indicates hints on the use of the instrument or other tips for

the user.

OPMI®is a registered trademark of Carl Zeiss.

G30-1298-en VISU 200 Surgical Microscope Issue 2.0

Printed on 09. 11. 2006

Contents

Functions at a glance 5

Safety 7

Description 17

VISU 200 Surgical Microscope 18

Attaching the equipment 43

Operation 47

Preparations for use 48

Procedure 53

What to do in an emergency 55

Maintenance / Further information 57

Index 71

G30-1298-en VISU 200 Surgical Microscope Issue 2.0

Printed on 09. 11. 2006

G30-1298-en VISU 200 Surgical Microscope Issue 2.0

Printed on 09. 11. 2006

Functions at a glance 5

Functions at a glance

VISU 200 Surgical Microscope 6

6Functions at a glance

G30-1298-en VISU 200 Surgical Microscope Issue 2.0

Printed on 09. 11. 2006

VISU 200 Surgical Microscope

1Resetting the X-Y coupling, focus and zoom to their initial positions

2Locking the front-to-back tilt of the surgical microscope

3Adjusting the PD

4Adjustable eyecup

5Diopter setting

6Display of magnification factor of zoom system

7Adjusting the red reflex illumination (+ 2° and - 2°)

8Releasing the magnetic clutches of the stand

9Changing the magnification of the assistant's microscope

10 Focusing the assistant's microscope

11 Adjusting the 6° illumination

12 Focusing range markings

13 Locking the assistant's microscope vertically

14 Light stop knob

15 Light guide socket

16 Locking the assistant's microscope horizontally

67 9 10 5 4 11 12 9 13 14 15 16108 8

G30-1298-en VISU 200 Surgical Microscope Issue 2.0

Printed on 09. 11. 2006

Safety 7

Safety

Directives and standards 8

Notes on installation and use 9

When using a fundus imaging system (e.g. BIOM II) 12

Phototoxic retinal injury in eye surgery 12

Warning labels and notes 15

8Safety

G30-1298-en VISU 200 Surgical Microscope Issue 2.0

Printed on 09. 11. 2006

The instrument described in this manual has been developed and tested

in accordance with Carl Zeiss safety standards and with national and in-

ternational regulations. A high degree of instrument safety is thus en-

sured.

We would like to inform you on the safety aspects involved in operating

the instrument. This chapter contains a summary of the most important

precautions to be observed.

Further safety notes are also contained in other parts of this user's

manual; they are marked with a warning triangle containing an exclama-

tion mark as shown here. Please pay special attention to these safety

notes.

Safety is only ensured when this instrument is operated properly. Please

read through this manual carefully before turning the instrument on. Also

read through the user's manuals of the other equipment used with this in-

strument. You may obtain further information from our service organiza-

tion or authorized representatives.

Directives and standards

The instrument described in this manual has been designed in compli-

ance with the following standards:

–EN

–IEC

–UL

–CSA

In accordance with Directive 93/42/EEC, Annex II, Article 3, the quality-

management system of Carl Zeiss has been approved by TÜV Rheinland,

which is a notified body. The registration number is: 95 102 7601.

• The instrument must be connected to a special emergency backup

line supply in accordance with the regulations or directives which ap-

ply in your country.

• This is a class I instrument as defined by Directive 93/42 /EEC.

• Please observe all applicable accident prevention regulations.

G30-1298-en VISU 200 Surgical Microscope Issue 2.0

Printed on 09. 11. 2006

Safety 9

Notes on installation and use

Safe working order

• Do not operate the equipment contained in the delivery package in

– explosion-risk areas,

– the presence of inflammable anesthetics or volatile solvents such

as alcohol, benzine or similar chemicals.

• Do not station or use the instrument in damp rooms. Do not expose

the instrument to water splashes, dripping water or sprayed water.

• Immediately unplug any equipment that gives off smoke, sparks or

strange noises. Do not use the instrument until our service represent-

ative has repaired it.

• Do not place any fluid-filled containers on top of the instrument. Make

sure that no fluids can seep into the instrument.

• Do not force cable connections. If the male and female parts do not

readily connect, make sure that they are appropriate for one another.

If any of the connectors are damaged, have our service representative

repair them.

• Potential equalization: The instrument can be incorporated into poten-

tial equalization measures. For this purpose, contact our service de-

partment.

• Do not use a mobile phone in the vicinity of the equipment because

the radio interference can cause the equipment to malfunction. The ef-

fects of radio interference on medical equipment depend on a number

of various factors and are therefore entirely unforeseeable.

• Modifications and repairs on these instruments or instruments used

with them may only be performed by our service representative or by

other authorized persons.

• The manufacturer will not accept any liability for damage caused by

unauthorized persons tampering with the instrument; this will also for-

feit any rights to claim under warranty.

• Use this instrument only for the applications described.

• Only use the instrument with the accessories supplied. Should you

wish to use other accessory equipment, make sure that Carl Zeiss or

the equipment manufacturer has certified that its use will not impair

the safety of instrument.

10 Safety

G30-1298-en VISU 200 Surgical Microscope Issue 2.0

Printed on 09. 11. 2006

• Only personnel who have undergone training and instruction are al-

lowed to use this instrument. It is the responsibility of the customer or

institution operating the equipment to train and instruct all staff using

the equipment.

• Keep the user's manuals where they are easily accessible at all times

for the persons operating the instrument.

• Never look at the sun through the binocular tube, the objective lens or

an eyepiece.

• Do not pull at the light guide cable, at the power cord or at other cable

connections.

• This instrument is a high-grade technological product. To ensure opti-

mum performance and safe working order of the instrument, its safety

must be checked once every 12 months. We recommend having this

check performed by our service representative as part of regular main-

tenance work.

If a failure occurs which you cannot correct using the trouble-shooting

table, attach a sign to the instrument stating it is out of order and con-

tact our service representative.

Requirements for operation

Our service representative or a specialist authorized by us will install the

instrument. Please make sure that the following requirements for opera-

tion remain fulfilled in the future:

– All mechanical connections (details in the user's manual) which are

relevant to safety are properly connected and screw connections tight-

ened.

– All cables and plugs are in good working condition.

– The voltage setting on the instrument conforms to the rated voltage of

the line supply on site.

– The instrument is plugged into a power outlet which has a properly

connected protective ground contact.

– The power cord being used is the one designed for use with this in-

strument.

Before every use and after re-equipping the instrument

• Make sure that all ”Requirements for operation” are fulfilled.

• Go through the checklist.

• Re-attach or close any covers, panels or caps which have been re-

moved or opened.
