YASKAWA FM 050 Manuel utilisateur

FM | 050-1BA10 | Manual

HB300 | FM | 050-1BA10 | en | 19-35

VIPA System SLIO

Counter module 5V differential 1x32Bit - FM 050

www.vipa.com/en/service-support/manuals

VIPA GmbH

Ohmstr. 4

91074 Herzogenaurach

Telephone: 09132-744-0

Fax: 09132-744-1864

Email: [email protected]

Internet: www.vipa.com

Table of contents

1 General.................................................................................................................... 4

1.2 Über dieses Handbuch..................................................................................... 5

1.3 Safety information............................................................................................. 6

2 Basics and mounting............................................................................................. 7

2.1 Safety information for users.............................................................................. 7

2.2 System conception........................................................................................... 8

2.2.1 Overview........................................................................................................ 8

2.2.2 Components.................................................................................................. 9

2.2.3 Accessories................................................................................................. 11

2.2.4 Hardware revision........................................................................................ 12

2.3 Dimensions..................................................................................................... 12

2.4 Mounting periphery modules.......................................................................... 15

2.5 Wiring periphery modules............................................................................... 18

2.6 Wiring power modules.................................................................................... 20

2.7 Demounting periphery modules...................................................................... 24

2.7.1 Easy Maintenance....................................................................................... 27

2.8 Trouble shooting - LEDs................................................................................. 28

2.9 Installation guidelines..................................................................................... 29

2.10 General data................................................................................................. 31

3 Hardware description........................................................................................... 33

3.1 Properties....................................................................................................... 33

3.2 Structure......................................................................................................... 33

3.3 Technical data................................................................................................. 36

4 Deployment........................................................................................................... 39

4.1 Fast introduction............................................................................................. 39

4.2 In-/Output area............................................................................................... 41

4.2.1 Input area 8byte .......................................................................................... 41

4.2.2 Output area 10byte ..................................................................................... 43

4.3 Parameter data............................................................................................... 44

4.4 Counter - Functions........................................................................................ 47

4.5 Counter additional functions........................................................................... 52

4.6 Diagnostic and interrupt.................................................................................. 55

VIPA System SLIO Table of contents

HB300 | FM | 050-1BA10 | en | 19-35 3

1 General

This document contains proprietary information of VIPA and is not to be disclosed or used

except in accordance with applicable agreements.

This material is protected by the copyright laws. It may not be reproduced, distributed, or

altered in any fashion by any entity (either internal or external to VIPA), except in accord-

ance with applicable agreements, contracts or licensing, without the express written con-

sent of VIPA and the business management owner of the material.

For permission to reproduce or distribute, please contact: VIPA, Gesellschaft für Visuali-

sierung und Prozessautomatisierung mbH Ohmstraße 4, D-91074 Herzogenaurach, Ger-

many

Tel.: +49 9132 744 -0

Fax.: +49 9132 744-1864

EMail: [email protected]

http://www.vipa.com

Every effort has been made to ensure that the information contained in

this document was complete and accurate at the time of publishing. Nev-

ertheless, the authors retain the right to modify the information.

This customer document describes all the hardware units and functions

known at the present time. Descriptions may be included for units which

are not present at the customer site. The exact scope of delivery is

described in the respective purchase contract.

Hereby, VIPA GmbH declares that the products and systems are in compliance with the

essential requirements and other relevant provisions. Conformity is indicated by the CE

marking affixed to the product.

For more information regarding CE marking and Declaration of Conformity (DoC), please

contact your local VIPA customer service organization.

VIPA, SLIO, System 100V, System 200V, System 300V, System 300S, System 400V,

System 500S and Commander Compact are registered trademarks of VIPA Gesellschaft

für Visualisierung und Prozessautomatisierung mbH.

SPEED7 is a registered trademark of profichip GmbH.

SIMATIC, STEP, SINEC, TIA Portal, S7-300, S7-400 and S7-1500 are registered trade-

marks of Siemens AG.

Microsoft and Windows are registered trademarks of Microsoft Inc., USA.

Portable Document Format (PDF) and Postscript are registered trademarks of Adobe

Systems, Inc.

All other trademarks, logos and service or product marks specified herein are owned by

their respective companies.

EC Conformity Declaration

Conformity Information

Trademarks

VIPA System SLIO

General

HB300 | FM | 050-1BA10 | en | 19-35 4

Contact your local VIPA Customer Service Organization representative if you wish to

report errors or questions regarding the contents of this document. If you are unable to

locate a customer service centre, contact VIPA as follows:

VIPA GmbH, Ohmstraße 4, 91074 Herzogenaurach, Germany

Telefax: +49 9132 744-1204

EMail: [email protected]

Contact your local VIPA Customer Service Organization representative if you encounter

problems with the product or have questions regarding the product. If you are unable to

locate a customer service centre, contact VIPA as follows:

VIPA GmbH, Ohmstraße 4, 91074 Herzogenaurach, Germany

Tel.: +49 9132 744-1150 (Hotline)

EMail: [email protected]

1.2 Über dieses Handbuch

This manual describes the FM 050-1BA10 of the System SLIO from VIPA. It contains a

description of the construction, project implementation and usage.

Product Order number as of state:

FM 050 050-1BA10 01

The manual is targeted at users who have a background in automation technology.

The manual consists of chapters. Every chapter provides a self-contained description of a

specific topic.

The following guides are available in the manual:

nAn overall table of contents at the beginning of the manual

nReferences with page numbers

The manual is available in:

nprinted form, on paper

nin electronic form as PDF-file (Adobe Acrobat Reader)

Important passages in the text are highlighted by following icons and headings:

DANGER!

Immediate or likely danger. Personal injury is possible.

Information product sup-

port

Technical support

Objective and contents

Target audience

Structure of the manual

Guide to the document

Availability

Icons Headings

VIPA System SLIO General

Über dieses Handbuch

HB300 | FM | 050-1BA10 | en | 19-35 5

CAUTION!

Damages to property is likely if these warnings are not heeded.

Supplementary information and useful tips.

1.3 Safety information

The system is constructed and produced for:

ncommunication and process control

ngeneral control and automation tasks

nindustrial applications

noperation within the environmental conditions specified in the technical data

ninstallation into a cubicle

DANGER!

This device is not certified for applications in

– in explosive environments (EX-zone)

The manual must be available to all personnel in the

nproject design department

ninstallation department

ncommissioning

noperation

CAUTION!

The following conditions must be met before using or commis-

sioning the components described in this manual:

– Hardware modifications to the process control system should only be

carried out when the system has been disconnected from power!

– Installation and hardware modifications only by properly trained per-

sonnel.

– The national rules and regulations of the respective country must be

satisfied (installation, safety, EMC ...)

National rules and regulations apply to the disposal of the unit!

Applications conforming

with specifications

Documentation

Disposal

VIPA System SLIO

General

Safety information

HB300 | FM | 050-1BA10 | en | 19-35 6

2 Basics and mounting

2.1 Safety information for users

VIPA modules make use of highly integrated components in MOS-Technology. These

components are extremely sensitive to over-voltages that can occur during electrostatic

discharges. The following symbol is attached to modules that can be destroyed by elec-

trostatic discharges.

The Symbol is located on the module, the module rack or on packing material and it indi-

cates the presence of electrostatic sensitive equipment. It is possible that electrostatic

sensitive equipment is destroyed by energies and voltages that are far less than the

human threshold of perception. These voltages can occur where persons do not dis-

charge themselves before handling electrostatic sensitive modules and they can damage

components thereby, causing the module to become inoperable or unusable. Modules

that have been damaged by electrostatic discharges can fail after a temperature change,

mechanical shock or changes in the electrical load. Only the consequent implementation

of protection devices and meticulous attention to the applicable rules and regulations for

handling the respective equipment can prevent failures of electrostatic sensitive modules.

Modules must be shipped in the original packing material.

When you are conducting measurements on electrostatic sensitive modules you should

take the following precautions:

nFloating instruments must be discharged before use.

nInstruments must be grounded.

Modifying electrostatic sensitive modules you should only use soldering irons with

grounded tips.

CAUTION!

Personnel and instruments should be grounded when working on electro-

static sensitive modules.

Handling of electrostatic

sensitive modules

Shipping of modules

Measurements and altera-

tions on electrostatic sen-

sitive modules

VIPA System SLIO Basics and mounting

Safety information for users

HB300 | FM | 050-1BA10 | en | 19-35 7

2.2 System conception

2.2.1 Overview

System SLIO is a modular automation system for assembly on a 35mm mounting rail. By

means of the peripheral modules with 2, 4 or 8 channels this system may properly be

adapted matching to your automation tasks. The wiring complexity is low, because the

supply of the DC 24V power section is integrated to the backplane bus and defective

modules may be replaced with standing wiring. By deployment of the power modules in

contrasting colors within the system, further isolated areas may be defined for the DC

24V power section supply, respectively the electronic power supply may be extended with

2A.

VIPA System SLIO

Basics and mounting

System conception > Overview

HB300 | FM | 050-1BA10 | en | 19-35 8

2.2.2 Components

nCPU (head module)

nBus coupler (head module)

nLine extension

nPeriphery modules

nAccessories

CAUTION!

Only modules of VIPA may be combined. A mixed operation with third-

party modules is not allowed!

With this CPU 01xC, the CPU electronic, input/output components and power supply are

integrated to one casing. In addition, up to 64 periphery modules of the System SLIO can

be connected to the backplane bus. As head module via the integrated power supply

CPU electronic and the I/O components are power supplied as well as the electronic of

the connected periphery modules. To connect the power supply of the I/O components

and for DC 24V power supply of via backplane bus connected peripheral modules, the

CPU has removable connectors. By installing of up to 64 periphery modules at the back-

plane bus, these are electrically connected, this means these are assigned to the back-

plane bus, the electronic modules are power supplied and each periphery module is con-

nected to the DC 24V power section supply.

With this CPU 01x, the CPU electronic and power supply are integrated to one casing. As

head module, via the integrated power module for power supply, CPU electronic and the

electronic of the connected periphery modules are supplied. The DC 24 power section

supply for the linked periphery modules is established via a further connection of the

power module. By installing of up to 64 periphery modules at the backplane bus, these

are electrically connected, this means these are assigned to the backplane bus, the elec-

tronic modules are power supplied and each periphery module is connected to the DC

24V power section supply.

CAUTION!

CPU part and power module may not be separated!

Here you may only exchange the electronic module!

With a bus coupler bus interface and power module is integrated to one casing. With the

bus interface you get access to a subordinated bus system. As head module, via the inte-

grated power module for power supply, bus interface and the electronic of the connected

periphery modules are supplied. The DC 24 power section supply for the linked periphery

modules is established via a further connection of the power module. By installing of up to

64 periphery modules at the bus coupler, these are electrically connected, this means

these are assigned to the backplane bus, the electronic modules are power supplied and

each periphery module is connected to the DC 24V power section supply.

CAUTION!

Bus interface and power module may not be separated!

Here you may only exchange the electronic module!

CPU 01xC

CPU 01x

Bus coupler

VIPA System SLIO Basics and mounting

System conception > Components

HB300 | FM | 050-1BA10 | en | 19-35 9

In the System SLIO there is the possibility to place up to 64 modules in on line. By means

of the line extension you can divide this line into several lines. Here you have to place a

line extension master at each end of a line and the subsequent line has to start with a line

extension slave. Master and slave are to be connected via a special connecting cable. In

this way, you can divide a line on up to 5 lines. For each line extension the maximum

number of pluggable modules at the System SLIO bus is decreased by 1. To use the line

extension no special configuration is required.

Each periphery module consists of a terminal and an electronic module.

1 Terminal module

2 Electronic module

The terminal module serves to carry the electronic module, contains the backplane bus

with power supply for the electronic, the DC 24V power section supply and the staircase-

shaped terminal for wiring. Additionally the terminal module has a locking system for

fixing at a mounting rail. By means of this locking system your SLIO system may be

assembled outside of your switchgear cabinet to be later mounted there as whole system.

The functionality of a SLIO periphery module is defined by the electronic module, which is

mounted to the terminal module by a sliding mechanism. With an error the defective

module may be exchanged for a functional module with standing installation. At the front

side there are LEDs for status indication. For simple wiring each module shows a corre-

sponding connection diagram at the front and at the side.

Line extension

Periphery modules

Terminal module

Electronic module

VIPA System SLIO

Basics and mounting

System conception > Components

HB300 | FM | 050-1BA10 | en | 19-35 10
