YDG313

The functions and design of this product can be changed without

prior notice for quality improvement.

x

Dry

Cloth

Do not attempt to

disassemble the unit

by yourself. That can

cause an electronic shock

and product damage.

Do not install the product in

the outdoor environment.

Be careful not to let any

unauthorized users discover

your PIN Code.

Please keep your PIN Code safe.

Make sure the door is securely

locked whenever you leave

your house, especially in the

manual lock mode.

Do not force with a tool.

Keep foreign materials away

from the Card Key Sensor to

maintain it cleanly and do not

use it with wet ngers.

If the sheet is already papered,

the product's adhesive strength

lessens Please remove the sheet

completely before installing.

When a double-opening door

ock is installed, one of the doors

must be closed.

Do not spray water directly to

the product or wipe it with

chemical substances such as

benzene, thinner, or alcohol

when cleanig the product.

Safety Feature

Product Features

Advance Mode

Advance Mode can be used for professional and high secure

management.

Magic Mirror

A magic Mirror function is applied, which the keypad number appears on the

Mirror as soon as a user touches the product. The user can chech the rear

through the Magic Mirror, so that security can be enhanced.

Safe Thumb-turn

Only if a user pushes the two safe buttons simultaneously axed to the thumb-turn

knob, the user can turn the thumb-turn knob. Its security is improved compared to

normal knob.

Modern & Thin design

It is the Solid and thin design using digital keypad on a solid base.

High Temperature Alarm

When there’s re, it detects the temperature of the inside.

It not only goes o an alarm but also releases the lock status automatically.

Remote Control

(Option)

You can use the Remote Control by installing the applicable remote control

module.

This option may not available depending on your country or local dealer.

The durability depends on the battery life and the frequency of use.

The color of the product may change if it is under the direct light for a long time, and it is not a defect.

Optional Accessory (purchase separately)

Speciﬁcations

Remote Control

Remote Control Module

Strike for a double side door

Parts

Front Body 14(D) x 72.8(W) x 186(H)

48.8(D) x 77.5(W) x 190.5(H)

4EA 1.5 AA alkaline batteries

(Operating voltage: 4.5 ~ 6V)

Operating temperature :

Last up to 1 year

(10 times used a day)

Back Body

Battery

Speciﬁcations Remarks

Basic Contents

Magnet for

a single door

Extension

type deadbolt

10mm door

thickness gasket

Front Body Back Body

Screws

Card Keys (4EA)

User Guide

Installation Template

Components Overview

Speciﬁcations

Front Body Back Body

Keypad

Lowbatt.

Card key

Reader

Emergency Power

Supply Terminal

Battery

Cover

Slot for Remote

Control module

(optional extra)

Manual

Thumb Turn

Safe Knob

Open/Close

Button

Registration

button

Dead Bolt

Registering User PIN Code

Registering Card Keys

Open Door with User PIN Code

Open Door with Card key

To Use Card Key

Contact Card Key

To Use User PIN Code

Caution

How to Use

Press

(Registration) button

Press

(Registration) button

Enter User PIN Code

(4 to 12 digits)

Press

(Registration) button

Press

(Registration) button

Contact all the keys

you wish to register

on one by one

User PIN Code should be set Within 4 to 12 digits. [ ] and [ ] are not allowed.

Touch with palm

Enter User PIN Code

(4 to 12 digits)

Touch with palm or

Press button to end

Keep the door open while you register Card Key to prevent yourself from accidentally getting locked out.

The previously registered Card Key will automatically be deleted when the new Card Key is registered.

Please use the only provided RF Cards in the package for security.

To Close Door from Outside 

To Close Door from Inside

Lock Door

Step Icon Description

Auto Lock status

Touch the keypad in the front body gently with your

palm to lock a door.

Manual Lock status

- Please check the deadbolt as it turns to standby mode and stop when closing a door.

- If the door is twisted, the auto-lock feature will not function properly. Please check before use.

The built-in Auto Lock sensor automatically locks

a door within 5 seconds after closing the door.

Turn the manual thumb turn to

unlock pressing buttons together.

Press open / Close button.

The built-in Auto Lock sensor automatically locks

a door within 5 seconds after closing the door.

(If an auto-lock magnetic is not installed, you cannot

enable the auto-lock feature.)

Manual Lock status

(The default setting)

Auto Lock status

How to Use

Set

Release

Outside Forced Lock Setting - PIN Code

Forced Lock

Inside Forced Lock Setting

Outside Forced Lock Setting - Card Key

- If compulsory external lock is setup, the door open/close button will not function. The alarm will go o if one tries to open the door through

the manual opening/closing unit.

- To open the door with the manual opening/closing unit under compulsory external lock setting, one must completely turn the know within

one second. Or else, the door will lock itself again.

Set

Press the Registration button or,

Turn the manual thumb turn to pressing

buttons together.

Release

Press the Open / Close button

for 5 seconds.

Touch with palm

Enter User PIN Code

Enter button

for 3 sconds

Contact Card Key for 3 seconds until you hear 3 beeps.

How to Use

To Set Auto Locking Mode

To Set Manual Locking Mode * The default setting

Auto / Manual Locking Mode

Auto lock setting locks a door in 5 second after the door was closed.

Even after a door was locked by the Auto Lock function, please check again

if the door was completely locked.

Press

(Registration) button

Press

(Registration) button

Enter button Enter number and

on the keypad

Be careful not to leave the door open at manual lock mode.

Press

(Registration) button

Press

(Registration) button

Enter button Enter number and

on the keypad

MUTE

* The default setting : High

Volume Setting Feature

It enables you adjust the sound volume.

Press

(Registration) button

Press

(Registration) button

Enter button

LOW

HIGH

How to Use

Open / Close Button Setting Feature

It enable you set the Open / Close button .

* The on/o of the function changes every time one sets the setting.

* When the system is set to o, the open/close button does not function.

Press

(Registration) button

Press

(Registration) button

Enter button Enter number and

on the keypad

How to Use
