X-Vision XC960DA Manuel utilisateur
Professional HD 960H Low Light
Varifocal Discreet Dome Camera
User Manual
Version 1
Thank you for purchasing the XC960DA camera from Xvision.
Please ensure that you read and understand this User Guide before operating the camera.
Please store this User Guide in an easily accessible location.
HD 960H
XC960DA
HD 960H
2
www.xvision.com
Contents
1. Product Overview .................................................................................. 4
1.2 Package Contents .......................................................................... 4
2. Installaon ............................................................................................ 5
3. How to Operate the Camera .................................................................. 7
4. Camera Menu ........................................................................................ 7
4.1 Lens ............................................................................................... 8
4.2 Exposure ....................................................................................... 8
4.3 White Balance ............................................................................... 8
4.4 Backlight ........................................................................................ 9
4.5 Day/Night ...................................................................................... 9
4.6 DPC ................................................................................................ 10
4.7 Special ........................................................................................... 10
5. Specicaons ........................................................................................ 12
XC960DA
HD 960H
3
www.xvision.com
Safety Precauons
1. Do not install the equipment in an environment with too much moisture, dust or smoke dust as this
may result in re or electric shock.
2. In the unlikely event that the equipment should malfuncon and emit an abnormal smell or smoke,
please immediately stop it, shut o the power and contact your supplier.
3. Please do not place this equipment near a heat source to avoid risk of re.
4. Please do not store, install and use this product in danger areas with inammable or explosive
substances.
5. Please make sure the power is turned o when installing the product.
6. Please ensure that you install the camera in an area with good venlaon.
7. When installing the camera, please make sure that it does not face any objects giving out strong lights
as this will damage the CCD of the camera.
8. Please do not use the camera in an environment where temperatures exceed either -20°C to +55°C.
XC960DA
HD 960H
4
www.xvision.com
Thank you for purchasing the HD 960H XC960DA from Xvision. Please read through this manual carefully
and make sure you understand before operang the camera.
1.1 Features
• Sony 960H CCD Sensor
• Xvision X3K DSP
• Xvision 2.8 to 12mm HD Megapixel Lens for a viewing angle between 23 and 92°
• Advanced Wide Dynamic Range
• High Speed Digital Slow Shuer
• 3D Digital Noise Reducon
• Programmable High Light Suppression
• Tamper Resistant
• Designed for Wall or Ceiling Mount
1.2 Package Contents
The packaged box for the XC960DA comes with the following items:
• XC960DA Camera
• Screws
• Allen Key
• DC Plug with screw terminals
• Ceiling Mount Stencil
• User Manual
Should any of these items be missing, please contact your local distributor.
1. Product Overview
1. Product Overview
XC960DA
HD 960H
5
www.xvision.com
1. Product Overview
2. Installaon
The XC960DA camera can be wall or ceiling mounted, so to install the camera, you will need to adjust the
lens to the desired angle.
1. To do this, twist the main camera to remove
from the camera base.
2. Li the main camera housing away frim the
camera base. Then, unscrew the camera housing
3. Press the clip and twist the base an-clockwise
to remove.
4. Use the installaon stencil or the base, to mark
out the holes in the wall/ceiling for drilling. When
placed, drill the holes.
6. Then, re-aach the main camera bracket to the
base. To do this, twist the camera bracket
clockwise unl you hear a click sound.
5. At this point, you can either feed the wires
through the side of the dome (as it comes in the
box) or feed them through the wall or ceiling. To
do this, you will need to break the middle of the
base (shown below) and then drill through the
wall/ceiling to put the wires through.
XC960DA
HD 960H
6
www.xvision.com
7. Then, you can adjust the camera angle to
get the desired view. To do this, you will need
to loosen the screw located on the side of the
camera bracket (shown below). This will
enable you to adjust the camera angle 180°.
8. Lastly, re-aach the dome cover by twisng
clockwise onto the camera bracket.
XC960DA
HD 960H
7
www.xvision.com
1. Product Overview
3. How to Operate the Camera
To operate the camera, rstly you will need to connect the BNC and DC sockets to the BNC and DC sockets
of a power supply and DVR or Monitor. If you wish to extend the cables, you can connect the DC and BNC
Sockets to the BNC/DC of a PNP cable/RG59 cable.
You can then connect the DC socket to a 12V DC Power Supply and the BNC socket to back of your
compable DVR or monitor.
BNC Socket for
video
DC Socket for
power
Joysck for entering camera
menu and navigang opons
1. Product Overview
4. Camera Menu
To access the camera menu, when the camera is on press the joysck buon. When the menu has
appeared, you will be presented with the following opons:
• Lens
• Exposure
• White Balance
• Backlight
• D/N (Day/Night)
• DPC
• Special
Up
Le
Down
Right
XC960DA
HD 960H
8
www.xvision.com
4.1 Lens Opon: DC / Manual
Select the lens type from either DC or Manual. Use the joysck to navigate between the opons and
when on the desired opon, press the joysck in to select. Both opons have a sub-menu as follows:
DC: Brightness - adjust the brightness of the image between
0-255. Iris Speed - adjust the iris speed between 0-255.
Manual: Brightness - adjust the brightness of the image
between 0-255.
Return: Save / End and return to the previous menu.
4.2 Exposure Opon: Shuer / AGC / DWDR
The exposure menu allows you to adjust the shuer speed, Automac Gain Control (AGC) and the Digital
Wide Dynamic Range (DWDR) on the camera.
Shuer: Adjust the shuer speed to auto or choose from
the following shuer speeds (1/25, FLK, 1/50, 1/100, 1/2000,
1/5000, 1/10000).
AGC: Adjust the AGC to either Auto, Low, Middle or High.
DWDR: Turn the DWDR on or o. If you choose to turn it on,
you can adjust the sensivity level (0-63).
Return: Save / End and return to the previous menu.
4.3 White Balance Opon: AWB / ATW / An CRL / Manual
Adjust the White Balance and set the Automac White Balance (AWB), ATW, An Colour Rolling (An CRL)
and choose to set the white balance manually.
AWB: Set the white balance to Automac
ATW: Turns this funcon on so the camera will detect
the colour temperature automacally.
An CRL: Turn on the an colour rolling funcon
Manual: Set the white balance to manual. If this opon is
chosen, you will need to adjust the colour temperature.
To do this, adjust the colour temperature from Manual, Indoor
or Outdoor. In each of these opons you will need to
set the blue and red gain.
Return: Save / End and return to the previous menu.
XC960DA
HD 960H
9
www.xvision.com
4.5 Day/Night Opon: D&N Auto / B&W / EXT / Colour
Day/Night: Set the camera to Day/Night mode. When selected, you can set the Day/Night mode to Auto,
Black and White, EXT or Colour.
D/N Auto: When choosing Auto you can adjust the lux
level from which the camera will switch from day to
night mode (0-255) and the delay from when the
camera reaches that lux level to turn to night mode
(0-30). You can also do this from night to day.
B/W: When choosing B/W you will put the cameras
image to black and white. You can also choose to turn
on the burst funcon, turn on the IR Smart and set
the IR level.
EXT: Choose the EXT funcon to set the day to night
funcon to be decided by external signals, for example
IR LEDs. Set the delay to (0-30 seconds) and night to
day funcon delay (0-30 secs).
Colour: Set the camera’s image to colour.
Return: Save / End and return to the previous menu.
4.4 Backlight Opon: O / BLC / HLC
This opon allows you adjust the advance backlight sengs, giving the following opons; Backlight
Compensaon (BLC), Highlight Compensaon (HLC), Day/Night, Black & White mode, EXT and Colour
Mode.
BLC: Select this opon to allow objects in front of
bright lights to be seen clearer, by making the background
darker. Once selected, you will be presented with a
further 2 opons; area select and state. Select the area gain
control (30-255), Height, Width (both 0-13), Le/Right
and Top/Boom (Both 0-5). You can also turn the state
on or o.
HLC: Select this opon to mask bright areas in an image,
for example, car headlights. Once selected, you can set the
sensivity level (0-240), set HLC to All Day or Mask Skip.
If you select Mask Skip, you can set the height, width,
le/right and top/boom of the masked areas between
0-15 values.
XC960DA
HD 960H
10
www.xvision.com
4.6 DPC Opon: Start / DPC View / LS Value / Di / Area
Start: Once selected, you will be asked to cover the lens
and press the joysck in. Please note that this is for
factory use only, if iniated power the camera down
and then power the camera to back up.
DPC View: Turn the DPC View on or o.
LS Value: Set the shuer value for searching dead pixels
Di: Set the di. value for searching dead pixels
Area: Set the area of the DPC. There are areas to
adjust; HS, HE, VS and VE (0-255).
Return: Save / End and return to the previous menu.
4.7 Special Opon: Camera Title / Moon / Privacy / Park Line / Image Adjust
Cam Adjust / Display ID / Language / Version
The special opon allows you to adjust various sengs on the camera from camera tle, privacy masking,
moon detecon and language etc.
Camera Title: Turn the camera tle on or o. When choosing on,
you will be presented with an on screen keyboard to set the
camera tle. Move the joysck to navigate between the
leers/numbers and then press the joysck in to conrm
selecon.
Moon: Turn the moon detecon funcon on or o.
If set to on, you will be presented with the following opons:
Area Select: Select 1-4 areas
Area State: Turns the selected moon zone on or o
Height: 0-50
Width: 0-50
Top: 0-50
Boom: 0-50
Degree: 0-255
View: On or o
Privacy: Turn the privacy funcon on or o. If set to on, you
will be presented with the following opons:
Area Select: Select 1-8 areas
Area State: Turns the selected privacy zone on or o
Height: 0-255
Width: 0-255
Le/Right: 0-255
Top/Boom: 0-255
Colour: 0-15 - choose between 15 colour opons to show the masked areas.
