WIKA 32 Manuel utilisateur

Operating instructions

Betriebsanleitung

Mode d'emploi

Manual de instrucciones

Machine glass thermometer, model 32

Maschinen-Glasthermometer, Typ 32

Thermomètre industriel en verre, type 32

Termómetro de capilla, modelo 32

11603445.02 03/2017 EN/DE/FR/ES

WIKA operating instructions model 32

Operating instructions model 32 Page 3 - 26

Betriebsanleitung Typ 32 Seite 27 - 50

Mode d'emploi type 32 Page 51 - 74

Manual de instrucciones modelo 32 Página 75 - 98

WIKA®is a registered trademark in various countries.

WIKA®ist eine geschützte Marke in verschiedenen Ländern.

Prior to starting any work, read the operating instructions!

Keep for later use!

Vor Beginn aller Arbeiten Betriebsanleitung lesen!

Zum späteren Gebrauch aufbewahren!

Lire le mode d‘emploi avant de commencer toute opération !

A conserver pour une utilisation ultérieure !

¡Leer el manual de instrucciones antes de comenzar cualquier trabajo!

¡Guardar el manual para una eventual consulta!

11603445.02 03/2017 EN/DE/FR/ES

WIKA operating instructions model 32

Contents

1. General information 4

2. Design and function 5

3. Safety 6

4. Transport, packaging and storage 9

5. Commissioning, operation 10

6. Faults 19

7. Maintenance and cleaning 21

8. Dismounting, return and disposal 22

9. Specifications 25

10. Thermowells as accessories 26

11603445.02 03/2017 EN/DE/FR/ES

WIKA operating instructions model 32

1. General information

■

The machine glass thermometer described in the operating

instructions has been manufactured using state-of-the-art

technology. All components are subject to stringent quality and

environmental criteria during production. Our management

systems are certified to ISO 9001 and ISO 14001.

■

These operating instructions contain important information on

handling the instrument.Working safely requires that all safety

instructions and work instructions are observed.

■

Observe the relevant local accident prevention regulations and

general safety regulations for the instrument's range of use.

■

The operating instructions are part of the product and must

be kept in the immediate vicinity of the instrument and readily

accessible to skilled personnel at any time. Pass the operating

instructions onto the next operator or owner of the instrument.

■

Skilled personnel must have carefully read and understood the

operating instructions prior to beginning any work.

■

The general terms and conditions contained in the sales

documentation shall apply.

■

Subject to technical modifications.

■

Further information:

- Internet address: www.wika.de / www.wika.com

- Relevant data sheet: TM 32.02

1. General information

11603445.02 03/2017 EN/DE/FR/ES

WIKA operating instructions model 32

2. Design and function

2.1 Overview

Case with measuring range

Glass insert with temperature scale and indicator liquid

Stem

2.2 Description

The model 32 machine glass thermometer is mainly used in

industrial applications such as machine building and also in

heating, air-conditioning and refrigeration technology.



see chapter

6.1





Straight 90° angle 135° angle













2. Design and function

11603445.02 03/2017 EN/DE/FR/ES

WIKA operating instructions model 32

It is notable for its high accuracy and very long service life (since

there is no mechanical wear).

The model 32 machine glass thermometer is available in three

sizes (200, 150 and 110 mm) and three versions (straight,

135° angle and 90° angle).

2.3 Scope of delivery

Cross-check scope of delivery with delivery note.

3. Safety

3.1 Explanation of symbols

WARNING!

... indicates a potentially dangerous situation that can

result in serious injury or death, if not avoided.

CAUTION!

... indicates a potentially dangerous situation that can

result in light injuries or damage to equipment or the

environment, if not avoided.

WARNING!

... indicates a potentially dangerous situation that can

result in burns, caused by hot surfaces or liquids, if not

avoided.

Information

... points out useful tips, recommendations and

information for efficient and trouble-free operation.

2. Design and function / 3. Safety

11603445.02 03/2017 EN/DE/FR/ES

WIKA operating instructions model 32

3.2 Intended use

The model 32 machine glass thermometer is used for measuring

the temperature in plant or machinery in closed rooms. Do not

exceed the specified limit values (see chapter 9 “Specifications”).

This instrument is not permitted to be used in hazardous areas!

The instrument has been designed and built solely for the

intended use described here, and may only be used accordingly.

The technical specifications contained in these operating

instructions must be observed. Improper handling or operation of

the instrument outside of its technical specifications requires the

instrument to be taken out of service immediately and inspected

by an authorised WIKA service engineer.

The manufacturer shall not be liable for claims of any type based

on operation contrary to the intended use.

3.3 Improper use

WARNING!

Injuries through improper use

Improper use of the instrument can lead to hazardous

situations and injuries.

▶

Refrain from unauthorised modifications to the

instrument.

▶

Do not use the instrument within hazardous areas.

▶

Do not use the instrument with abrasive or viscous

media.

3. Safety

11603445.02 03/2017 EN/DE/FR/ES

WIKA operating instructions model 32

Any use beyond or different to the intended use is considered as

improper use.

Do not use this instrument in safety or emergency stop devices.

3.4 Responsibility of the operator

The instrument is used in the industrial sector.The operator is

therefore responsible for legal obligations regarding safety at work.

The safety instructions within these operating instructions, as well

as the safety, accident prevention and environmental protection

regulations for the application area must be maintained.

To ensure safe working on the instrument, the operating company

must ensure

■

that suitable first-aid equipment is available and aid is provided

whenever required.

■

that the operating personnel are regularly instructed in all

topics regarding work safety, first aid and environmental

protection and know the operating instructions and in

particular, the safety instructions contained therein.

■

that the instrument is suitable for the particular application in

accordance with its intended use.

■

that personal protective equipment is available.

3.5 Personnel qualification

WARNING!

Risk of injury should qualification be insufficient!

Improper handling can result in considerable injury and

damage to equipment.

▶

The activities described in these operating instructions

may only be carried out by skilled personnel who have

the qualifications described below.

3. Safety

11603445.02 03/2017 EN/DE/FR/ES

WIKA operating instructions model 32

Skilled personnel

Skilled personnel, authorised by the operator, are understood to

be personnel who, based on their technical training, knowledge

of measurement and control technology and on their experience

and knowledge of country-specific regulations, current standards

and directives, are capable of carrying out the work described and

independently recognising potential hazards.

Special operating conditions require further appropriate

knowledge, e.g. of aggressive media.

4. Transport, packaging and storage

4.1 Transport

Check the instrument for any damage that may have been caused

by transport. Obvious damage must be reported immediately.

CAUTION!

Damage through improper transport

With improper transport, a high level of damage to

property can occur.

▶

When unloading packed goods upon delivery as well

as during internal transport, proceed carefully and

observe the symbols on the packaging.

▶

With internal transport, observe the instructions in

chapter 4.2 “Packaging and storage”.

4.2 Packaging and storage

Do not remove packaging until just before mounting.

Keep the packaging as it will provide optimum protection during

transport (e.g. change in installation site, sending for repair).

3. Safety / 4. Transport, packaging, storage

11603445.02 03/2017 EN/DE/FR/ES

WIKA operating instructions model 32

Permissible conditions at the place of storage:

■

Storage temperature: 0 ... 70 °C

■

Humidity: 35 ... 85 % relative humidity (no condensation)

Avoid exposure to the following factors:

■

Direct sunlight or proximity to hot objects

■

Mechanical vibration, mechanical shock (putting it down hard)

■

Soot, vapour, dust and corrosive gases

■

Hazardous environments, flammable atmospheres

Store the instrument in its original packaging in a location that

fulfils the conditions listed above. If the original packaging is not

available, pack and store the instrument as described below:

1. Wrap the instrument in a plastic film.

2. Place the instrument, along with shock-absorbent material and

the stem protector (if accompanying), in the packaging.

3. If stored for a prolonged period of time (more than 30 days),

place a bag containing a desiccant inside the packaging.

5. Commissioning, operation

Personnel: Skilled personnel

Tools:

■

Open-ended spanner for counter nut: SW 22

■

Open-ended spanner for immersion stem/thermowell:

SW 27 and SW 32

■

Allen key (for 90° version): size 3

4. Transport ... / 5. Commissioning, operation
