Whirlpool AKG668 Manuel d'utilisation

Instructions for Use

and Installation

for the

AKG668

Double Electric Oven & Grill

AKG668 EF720 DO 08 17485 00

17485 00 AKG668 Inst. Book 7/10/05 11:25 am Page 1

17485 00 AKG668 Inst. Book 7/10/05 11:25 am Page 2

AKG668 Installation & Instructions for Use

CONTENTS

SUBJECT PAGE No.

INSTALLATION 3

CLEANING 4

HOW TO USE THE PROGRAMMER / CLOCK 6

AUTOMATIC COOKING 9

USING THE FAN ASSISTED MAIN OVEN 11

MAIN OVEN BAKING GUIDE 14

SLOW COOKING, DEFROSTING AND COOLING 15

ROASTING GUIDE 16

USING THE GRILL 17

USING THE TOP OVEN 18

TOP OVEN BAKING GUIDE 20

TECHNICAL INFORMATION 21

BEFORE YOU START INSTALLATION 22

INSTALLATION METHODS 1, 2 AND 3 23

17485 00 AKG668 Inst. Book 7/10/05 11:25 am Page 3

AKG668 Installation & Instructions for Use

Congratulations on the purchase of your new Whirlpool Built-ln

double oven and grill, from the World’s Largest Major Appliance

Manufacturer.

This appliance represents the latest in design and function. For this

reason it is suggested that this instruction book is read thoroughly

before attempting to use the oven for the first time, and then kept in

a safe place for future reference.

17485 00 AKG668 Inst. Book 7/10/05 11:25 am Page 4

AKG668 Installation & Instructions for Use

INSTALLATION

SITING THE OVEN

The AKG668 is designed to be

installed either into a housing unit,

or between base units.

ELECTRICAL CONNECTION

The appliance must be installed

by a competent electrician and

connected to l.E.E. wiring

regulations, to a cooker control

unit of 30 amp minimum capacity,

incorporating a double pole switch

having contact separation of at

least 3mm at all poles. It is wired

for single phase operation and

must be earthed. Access to the

mains terminal connections is

gained by removing the panel at

the left hand rear of the appliance.

Connect the cable to the terminal

block, then position the cover

plate in the rear panel, and tighten

the cable clamp screw before

securing the cover.

IMPORTANT

The wires of the mains lead for

this appliance must be connected

in accordance with the following

code:

As the colours of the wires in the

mains lead you may use to

connect this appliance may not

correspond with the markings on

the terminals, please proceed as

follows.

Brown (or Red) = Live

Blue (or Black) = Neutral

Green/Yellow (or Green) = Earth

If you are in any doubt as to the

correct connections, consult a

qualified electrician.

Before using the oven remove

any protective polythene film and

wash the oven shelves and

furniture in hot soapy water to

remove their protective covering,

of oil.

IN THE EVENT OF A POWER

CUT

1. SWITCH OFF the electricity

supply to the appliance.

2. When the power returns you

MUST reset the-programmer to

show the time of day, see page 7,

until this is done the oven and the

grill CANNOT be used.

17485 00 AKG668 Inst. Book 7/10/05 11:25 am Page 5

AKG668 Installation & Instructions for Use

CLEANING

ALL parts of the oven can be

safely cleaned with a clean cloth

wrung out in hot soapy water but

let the oven cool before cleaning.

To avoid damaging the surfaces

when removing stubborn marks,

we recommend the following:

GLASS PARTS (Facia control

panel, Door panel)

DO NOT use abrasive cleaners or

polishes. Use a mild cream

cleaner rinse thoroughly and dry

with a soft cloth.

CAUSTIC PASTE, ABRASIVE

POWDERS, COARSE WIRE

WOOL AND HARD TOOLS;

WILL DAMAGE THE SURFACE.

IMPORTANT:

The inner oven door glass panel

can be removed for cleaning.

To remove the glass panel, open

the door wide, hold the top and

bottom edges and slide out.

When refitting, take care that the

glass is held level and straight

with the grooves in the door trims

before sliding back.

PAINTED PARTS (Door frame,

Door handle, Outer frame trim)

ONLY use a clean cloth wrung

out in hot soapy water.

VITREOUS ENAMEL PARTS

(Grill pan / Grill compartment)

Use a mild cream cleaner. Look

for one which has the VITREOUS

ENAMEL COUNCIL’S seal of

approval.

17485 00 AKG668 Inst. Book 7/10/05 11:25 am Page 6

AKG668 Installation & Instructions for Use

SELF CLEAN SURFACES (Oven

compartment)

MOST TYPES OF CLEANING

AGENT WILL DAMAGE THESE

S U R F A C E S . Only use a few

drops of washing up liquid in hot

water. Wipe the surfaces with a

clean cloth wrung out in the hot

soapy water, or when large

splashes of fat do not readily

disappear scrub the area with a

nylon brush or nylon pan scourer,

rinse well and heat the oven to dry

the linings.

NOTE:

If you do a lot of open roasting

you may feel these surfaces need

and occasional wipe.

CHROME PLATED PARTS

(Oven shelves, Oven shelf

runners)

DO NOT use abrasives or

polishes. Use a moist soap pad

eg: Brillo. Oven shelf runners can

be removed for cleaning.

1. Lift the bottom edge away from

the oven side.

2. Ease the runners from the

hanging holes.

17485 00 AKG668 Inst. Book 7/10/05 11:25 am Page 7

AKG668 Installation & Instructions for Use

HOW TO USE THE PROGRAMMER / CLOCK

FUNCTIONS

Cooking duration, cooking end

time, time of day, minute minder

up to 23 hours 59 minutes.

DISPLAYS

A= Automatic programme

Cookpot symbol = Duration and

manual mode

Bell symbol = Minute minder

THE PROGRAMMER ENABLES

YOU TO:

1. Set the time of day.

2. Set the minute minder for an

alarm tone to sound.

3. Set the main oven to SWITCH

OFF when the meal or dish is

ready ie. semi automatic.

4. Cancel the automatic operation

(at anytime) by selecting the

manual function. After a

programme which has been set

comes to an end, it is

automatically cancelled.

5. Set the main oven to SWITCH

ON and OFF for delayed cooking.

ie. fully automatic.

SETTING

After pressing a function button

the time required can be set with

the plus (+) and minus (-) buttons.

The counting up and down speed

increases when the buttons are

held down. If a function button is

just briefly touched and released,

the selected function is displayed

for 5 seconds. Within this time

setting may be commenced (one

hand setting). Five seconds after

releasing the function button or

after setting is completed, the

display reverts to the time of day.

When programme has been set, it

automatically starts immediately.

Selection of a function is

accompanied by an audible

signal.

Timer Display and Control Panel

17485 00 AKG668 Inst. Book 7/10/05 11:25 am Page 8

AKG668 Installation & Instructions for Use

1. SET THE TIME OF DAY

Select time of day function by

pressing duration and end time

button simultaneously and set

time of day with the plus (+) and

minus (-) buttons. Any programme

which has been set is cancelled.

2. MINUTE MINDER

Press the minute minder button

and set required time with the plus

(+) and minus (-) buttons.

As the time set elapses the

symbol is illuminated.

After the time set has elapsed, the

audible signal sounds.

The audible signal sounds at the

end of minute minder cycle or of a

cooking programme for a period

of 7 minutes. The signal can be

cancelled by pressing any

function button.

3. SEMI AUTOMATIC WITH

COOKING DURATION

Press cooking duration button and

set required duration with the plus

(+) and minus (-) buttons. The ”A”

and “Cookpot” symbols appear.

If time of day is equal to the

cooking end time, the “Cookpot”

symbol is switched off, the audible

signal sounds and “A” blinks.

4. SEMI AUTOMATIC WITH

COOKING END TIME

Press cooking end time button

and set required end time with the

plus (+) and minus (-) buttons.

The “A” and “Cookpot” symbols

are illuminated.

If the cooking end time is equal to

the time of day the cookpot

symbol is switched off, the audible

signal sounds and “A” blinks.

5. FULLY AUTOMATIC

Press the cooking duration button

and set required duration with the

plus (+) and minus (-) buttons.

The “A” symbol and the cookpot

symbol appear.

Select cooking end time function

and the earliest possible end time

are displayed.

Set the required end time with the

plus (+) and minus (-) buttons.

The “ C o o k p o t ” symbol is

switched off.

The “Cookpot” symbol appears

again when the time of day is

equal to the calculated start time.

After the automatic programme is

ended, the symbol “A” blinks.

The audible signal is on, and the

“Cookpot” symbol is switched off.

17485 00 AKG668 Inst. Book 7/10/05 11:25 am Page 9

AKG668 Installation & Instructions for Use

SETTING ERROR

The setting is incorrect if the time

of day is in between the

calculated cooking time and end

times.

This will be indicated by an

audible signal and by the flashing

“A” symbol. The faulty setting can

be corrected by re-setting either

cook time or end time.

RETURN DISPLAY TO TIME OF

DAY

To return the display to show the

time of day, press the duration

and the end time buttons

simultaneously

IMPORTANT

The programmer must be set to

the time of day before the oven

or grill can be used.

17485 00 AKG668 Inst. Book 7/10/05 11:25 am Page 10

Table des matières

Autres manuels Whirlpool Four

Whirlpool

Whirlpool RM980PXY Manuel utilisateur

Whirlpool

Whirlpool 102.259.14 Instructions d'utilisation et d'installation

Whirlpool

Whirlpool AMW 582 Manuel d'utilisation et d'entretien

Whirlpool

Whirlpool RB770PXT1 Manuel utilisateur

Whirlpool

Whirlpool RBS275PRB00 Manuel utilisateur

Whirlpool

Whirlpool W9 OP2S2HBLAUS Manuel utilisateur

Whirlpool

Whirlpool MBI 500 Manuel utilisateur

Whirlpool

Whirlpool AKZM 656 Manuel utilisateur

Whirlpool

Whirlpool RBS245PR Manuel utilisateur

Whirlpool

Whirlpool WOS51E Manuel utilisateur

Whirlpool

Whirlpool RS610PXGN3 Manuel utilisateur

Whirlpool

Whirlpool AKP 755 IX Manuel utilisateur

Whirlpool

Whirlpool AMW 882 Mode d'emploi

Whirlpool

Whirlpool BUILT-IN MICROWAVE OVEN Manuel utilisateur

Whirlpool

Whirlpool G2P 61F Manuel utilisateur

Whirlpool

Whirlpool RBS305PV Series Manuel utilisateur

Whirlpool

Whirlpool RM255PXP Manuel utilisateur

Whirlpool

Whirlpool AKZ 319/01 Manuel utilisateur

Whirlpool

Whirlpool AKP3840PIXAUS Guide de configuration

Whirlpool

Whirlpool 1319999/868842 Manuel utilisateur

Whirlpool

Whirlpool RBS240PD Manuel utilisateur

Whirlpool

Whirlpool AKPM 759 Mode d'emploi

Whirlpool

Whirlpool AKP 7460 IX Mode d'emploi

Whirlpool

Whirlpool AKP 236 Mode d'emploi

Manuels Four populaires d'autres marques

Bosch

Bosch HVA531NS0 Manuel utilisateur

Electrolux

Electrolux EOF6P46X Manuel utilisateur

NEFF

NEFF B44S32 5GB Series Manuel utilisateur

Combi

Combi BLODGETT BC142GDS Manuel utilisateur

AEG

AEG COMPETENCE 311704300 Manuel utilisateur

Falcon

Falcon DOMINATOR PLUS G3106 Series Guide de l'utilisateur

Rational

Rational SCC WE 61G Manuel utilisateur

Smeg

Smeg DOSPA38X Manuel d'installation et d'exploitation

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manuel utilisateur

Miele

Miele HR 1954-2 Manuel utilisateur

KHIND

KHIND OT50 Manuel utilisateur

Henny Penny

Henny Penny Smoker Box Manuel utilisateur

Lang

Lang ECOD-AP Manuel utilisateur

AEG

AEG BEK455310M Manuel utilisateur

Frigidaire

Frigidaire FNGE90JGR Manuel utilisateur

Hotpoint

Hotpoint FE9 S831 JSH IX Manuel utilisateur

GE Advantium SCB2000 Manuel utilisateur

AEG

AEG DE401301DM Manuel utilisateur
