TITAN 12 User’s Manual

TITAN 12_Manual RevC.indd 1 8/31/06 4:30:49 PM

USER'S MANUAL

Titan 12 is the latest innovation from

Wharfedale Pro. A high performance passive

speaker system designed around your needs.

High output, punchy low end and extended

high frequency response that’s equally at

home with music and speech. An ultra-light-

weight composite enclosure that’s designed

to be stand mounted, arrayed or even used

as a ﬂoor monitor. Compact, lightweight and

affordable, the Titan 12 still packs professional

drivers that deliver unmatched performance.

TITAN 12_Manual RevC.indd 2 8/31/06 4:30:49 PM



TITAN 12 • 2-way Passive Loudspeaker

Warnings & Safety Instructions

1. READ ALL INSTRUCTIONS carefully and become familiar with the features and

functions of this product before operating it.

2. RETAIN THESE INSTRUCTIONS for future reference.

3. COMPLY WITH ALL WARNINGS – All warnings and instructions for this product

should be adhered to.

4. USE WITH AMPLIFIERS – In order to avoid damage to drivers and other equipment,

it is advisable to establish and follow a routine for powering up and powering down a

sound system. With all system components connected, turn on source equipment (mixers,

signal processors, record and playback units, etc.) BEFORE powering up ampliﬁers. Tran-

sient voltages from powering up source equipment can damage speakers if ampliﬁers are

turned on when these sources are powered up. Make sure that ampliﬁer volumes are set

to their minimum settings and power up any system ampliﬁers LAST. It is recommended

that all system components be allowed to stabilize for several seconds before any source

signals are introduced or level setting adjustments are made.

Similarly, when shutting systems down, turn all ampliﬁers off ﬁrst, before

powering down any other system components.

5. CABLES – Do not use shielded or microphone cables for connection between

ampliﬁers and speakers. Use only approved speaker cables with proper

connectors.

6. RIGGING – SUSPENDING – MOUNTING – Rigging, suspending and mounting of this

speaker system can expose members of the public to serious health and risks and even

death. UNDER NO CIRCUMSTANCES ATTEMPT TO RIG, SUSPEND OR OTHERWISE MOUNT

THIS SYSTEM UNLESS YOU ARE FULLY QUALIFIED AND CERTIFIED TO DO SO BY REL-

EVANT LOCAL, STATE AND NATIONAL AUTHORITIES. ALL RELEVANT SAFETY REGULA-

TIONS MUST BE FOLLOWED. IF YOU ARE NOT PROPERLY QUALIFIED OR DO NOT KNOW OF

PERTINENT REGULATIONS, CONSULT QUALIFIED PERSONNEL FOR ADVICE.

7. CAUTION – These professional loudspeaker systems are capable of generating very

high sound pressure levels. Use care with placement and operation to avoid exposure to

excessive volume levels that can cause permanent hearing damage if operated to ex-

tremes.

8. SERVICE – There are no user serviceable parts inside this product. Users should not

attempt to service this product. Warranty nulliﬁcation could result if this is attempted.

TITAN 12_Manual RevC.indd 3 8/31/06 4:30:49 PM



Thank you for purchasing the Wharfedale Pro TITAN 12!

The TITAN 12 offers acoustical voicing and drivers that provide a smooth high end re-

sponse and a punchy, tight low end bass response in a surprisingly small and portable

composite enclosure.

Features:

+Custom designed, heavy duty 12” low frequency driver

+1.75" titanium high frequency compression driver

+90 x 60 degree integral Elliptical Wave Guide for even high frequency dispersion

+Built in 18dB per octave Linkwitz-Riley crossover

+DTF™ Dynamic Thermal Filament – Integral High-Frequency Driver

Overload protection

+High frequency EQ switch (boost/ﬂat)

+Design for a wide variety of sound reinforcement applications

+Built in, rubberized easy-grip handles for convenient transportation

+Integral pole mount adapter for stand mounting

+Trapezoidal shape for vertical arrays and horizontal stage monitor use

+Top stacking feature for easy integration of multiple enclosures

+Ten M8 threaded rigging inserts for several hang-mount options

+Bottom mounted M8 threaded inserts that ﬁt OmniMount® 60.0 footprint

+Injection molded enclosure construction

+Integral cord wrap and cable anchor molded into the enclosure

+Dual ¼" and NL4 input connectors

TITAN 12_Manual RevC.indd 4 8/31/06 4:30:49 PM



Operation

The TITAN 12 is a passive, two-way, speaker system that provides an 8 ohm impedance

load, per enclosure, to each output channel of the system power ampliﬁer. Multiple

TITAN 12 enclosures can be “daisy-chained”, in parallel, with the impedance load

dropping in half with each additional enclosure. In other words, two TITAN 12 enclosures,

connected in parallel, will provide a 4 Ohm impedance load. Like wise, three TITAN 12

enclosures connected in parallel will provide a 2 ohm impedance load to the ampliﬁer. Be

aware that some ampliﬁers are not designed to accept loads as low as 2 ohms and loads

this low can result in decreased performance and overheating of the ampliﬁer and can

cause damage to ampliﬁer electronics. Consult the manufacturers operating manual for

the ampliﬁer before connecting multiple speakers together.

The HIGH FREQUENCY EQ switch provides a 3dB boost to the high frequency driver for

long throw applications. Switch selections are “BOOST” (3dB increase) and “FLAT”

(no increase).

Connections

The TITAN 12 input connections from the output of the ampliﬁer will be via ¼” phone

jacks or Speakon® NL4 connectors that are located on the rear mounted input plate. NL4

connector pin wiring is conﬁgured as follows:

+1 = Positive

–1 = Negative

Optional Accessories

+ Wall mount bracket – Enables surface mounting with pan and tilt positioning for

ﬁxed installations

+ Titan Tour Bag – Ballistic nylon zippered carrying bag with storage pocket

for cables

TITAN 12_Manual RevC.indd 5 8/31/06 4:30:49 PM



TITAN 12 Speciﬁcations

Loudspeaker Type: 12" 2-way

Frequency Response (+/–3dB): 55—20kHz

Sensitivity (1W@1M): 98dB

HF Coverage (H x V): 90˚ x 60˚

Peak SPL: 128dB

System Impedance: 8 ohm

POWER HANDLING CAPABILITY (WATTS)

Continuous: 250W

Music: 500W

Peak: 1000W

LOW FREQUENCY DRIVER

Size: 305mm/12"

Coil Size:

HIGH FREQUENCY DRIVER

Type: Compression Driver

Coil Size: 44mm/1.75"

Exit Size: 25mm/1"

Diaphragm Material: Titanium

HF Driver Protection: DTF™ Dynamic Thermal Filament

HF Long-Throw EQ Compensation: 3dB boost (long-throw) / Flat (near-ﬁeld)

HIGH FREQUENCY HORN

Type: EWG™ - Elliptical Waveguide

Throat Size: 25mm/1"

CROSSOVER

Type: 2-way

Frequency/Filter:

ENCLOSURE

Shape: Trapezoidal for vertical array and horizontal stage

monitor applications

Material: Polypropylene

Rigging: + (10) M8 threaded rigging points for safe ﬂown applications

+ (4) M8 threaded rigging points on bottom in

Omnimount®6.0-type footprint

+ Speaker pole-mount receptacle with lock screw

+ Optional wall-mount bracket

+ Optional dual-unit array speaker stand hardware

IN/OUT PANEL

Input Connectors: (2) 1/4" jacks '+ (2) NL4 connectors

DIMENSIONS/WEIGHTS

Net Weight: 12kg / 26.4lbs

Gross Weight: 14kg / 30.8lbs

Dimensions (H x W x D): 556 x 384 x 312mm / 21.88" x 15.1" x 12.3"

*Features, details and specifications subject to change without notice

TITAN 12_Manual RevC.indd 6 8/31/06 4:30:49 PM

64.26mm / 2.5"

2.2KHz / Linkwitz-Riley

THE WHARFEDALE PRO ADVANTAGE

While other companies increasingly out-

source manufacturing, we continue to add

to our factory; already at 1.5 million square

feet in size. That’s because at Wharfedale

Pro we design, engineer, tool and manufac-

ture each and every component that goes into

our speaker systems. All of which helps ex-

plain how we can pack so much technology,

performance and quality into our products

at an incredibly low cost. Recognized since

1932 as a pioneering brand, Wharfedale Pro

is now part of the International Audio Group

with operations and distributionworldwide.

Our mission remains to design and build

the very best Pro Audio gear possible, with

great technologies, abundant features and

unmatched quality at the very lowest possible

cost. That’s the Wharfedale Pro advantage!

TITAN 12_Manual RevC.indd 7 8/31/06 4:30:50 PM

* Details and speciﬁcations subject to change without notice.

IAG House, Sovereign Court, Ermine Business Park, Huntingdon, Cambridgeshire, PE29 6XU

WHARFEDALE PRO [USA] WHARFEDALE PRO [UK] WHARFEDALE PRO [GERMANY] WHARFEDALE PRO [INT.]

ph: +1.877.440.0888 ph: +44 (0) 845 4580011 ph: +49 (0) 2161-61783-0 ph: +86 (0) 755 8209 6639

ph: +1.425.861.3909 ph: +44 (0) 1480 447700 fx: +49 (0) 2161-6178350 fx: +86 (0) 755 8209 0203

fx: +1.425.861.3906 fx: +44 (0) 1480 431767

UNPACKING

All Wharfedale Pro products are fully checked before leaving the factory.

After unpacking please inspect cabinets for any physical damage. Please

retain the shipping carton if possible and internal packing material in

case the unit needs to be returned. Please check as soon as possible that

the unit is functioning. In the event of any damage, please contact your

dealer immediately.

WHARFEDALE PRO LIMITED WARRANTY *

Wharfedale Titan loudspeaker systems are warranted to be clear of man-

ufacturing or materials defects for a period of one year from the original

date of purchase. In the event of malfunction, contact your authorized

Wharfedale Professional dealer or distributor for information.

* Be aware that warranty details may differ from country to country.

Contact your dealer or distributor for information. These terms do not

infringe your statutory rights.

www.wharfedalepro.com

TITAN 12_Manual RevC.indd 8 8/31/06 4:30:50 PM

INTERNATIONAL PATENT PROTECTION ZL 200530151345.9
