weBoost eqo Manuel utilisateur
Cell Phone Signal Booster
Installation Guide
NEED HELP? 866.294.1660support.weboost.com
MON - FRI: 6AM to 7PM MST
SAT - SUN: 8AM to 5PM MST
Troubleshooting
Safety Guidelines
Frequently Asked Questions
Package Content 1
2
18
16
14
12
11
8
4
Find Strongest Signal
Quick Installation
Antenna Expansion Kit
Signal Booster Specifications
Warranty
Index
6
Light Patterns
eqo Booster eqo Antenna
+ 15’ Cable
(303020) (859948)
Power Supply
Package
Content
IMPORTANT NOTICE: Connect your eqo Booster
AC Power Supply to a surge protected AC power
strip with at least a 1000 Joule rating. Failure to do
this will void your warranty in the event of a power
surge or lightning strike.
This device may be operated ONLY in a fixed location for in-building
use. The signal booster unit is designed for use in an indoor,
temperature controlled environment ( > 150 degrees Fahrenheit)
!
!
CELL PHONE SIGNAL BOOSTER 1
Installation Instructions for the Following weBoost Signal Booster:
eqo™ 700 MHz Band 12 & 17
800 / 1900 (Excluding B25) AWS (1700 / 2100)
Find the
Strongest
Cellular Signal
CELL PHONE SIGNAL BOOSTER
2
Before you install your eqo signal booster, you must determine
the location of the best available cellular signal. This will help
you maximize performance from your eqo booster.
Use any of the following methods to find the strongest signal in
the room where the booster will be installed.
(FIND THE STRONGEST CELLULAR SIGNAL cont.)
weboost.com/us/test-mode-instructions/
WITH 2 PEOPLE - one inside and one outside. The
person inside should have the phone in test mode so
the numerical signal strength can be read. This is
more accurate than the bar indicator. For help in
finding the test mode for your phone please go to:
Place calls from several locations outside your
building. As you move to dierent locations, note
where you get the best reception.
Check the bar indicator on your cell phone display and
note where the signal appears the strongest. Repeat
your signal check several times, moving each time to a
dierent location. Remember each time you move to a
new location, your phone may require up to 30
seconds to reset and display the new reading.
For additional instructions on finding the strongest cellular
signal, watch the installation video at: weboost.com/us/eqovideo.
How to Find
Your Strongest Signal.
CELL PHONE SIGNAL BOOSTER 3
(Note: cell phone bars are only an approximation of signal strength
and vary from phone to phone.)
-80dB
-100dB
-95dB
-90dB
-90dB
Quick
Installation
1
3
To view an installation video for this booster please visit the
following link:
weboost.com/us/eqovideo/
Place the Antenna where you need to
boost your signal, at least 6 feet away
from the Booster. The Antenna can be
mounted on the wall.
Place your Booster in the area with the
strongest cell phone signal, as identified
on the previous page. The LED light
should be facing into the room.
6 ft.
2
Connect the supplied Coax Cable and
Power Supply on the side of the Booster.
Power Cable
Coax
Cable
CELL PHONE SIGNAL BOOSTER
4
IMPORTANT NOTICE: Connect your eqo Booster AC Power Supply to a
surge protected AC power strip with at least a 1000 Joule rating.
Failure to do this will void your warranty in the event of a power
surge or lightning strike.
!
4
5
CELL PHONE SIGNAL BOOSTER 5
Connect the Power Supply to a surge
protected AC power strip with at
least 1000 Joule rating*.
Connect the other end of the Coax Cable
to the Antenna.
Coax
Cable
A
A A A
BA
The booster and antenna
should face the same
direction.
The booster and antenna should never
face each other, or be placed back to
back. They should be at least 6 feet
away from each other.
Placement Instructions
eqo Booster
Product Number U473020
460032
PWO460032
4726A-460032
Connectors SMA-Female
Antenna Impedance 50 Ohms
Frequency
Model Number
FCC ID:
IC:
698-716 MHz, 729-756 MHz, 777-787 MHz, 824-894 MHz, 1850-1990 MHz, 1710-1755/2110-2155 MHz
Passband Gain (nominal)
700 MHz
Band 12/17
61
700 MHz
Band 13
62
800 MHz
Band 5
62
1700/2100 MHz
Band 4
68
1900 MHz
Band 2
70
20 dB Bandwidth (MHz) 700 MHz
Band 12/17
700 MHz
Band13
800 MHz
Band 5
1700/2100 MHz
Band 4
1900 MHz
Band 2
Typical
Maximum
31.8
35.4
32.1
35.6
37.9
39.0
79.9
83.0
81.9
85.1
Power output for single cell
phone (Uplink) dBm
700 MHz
Band 12/17
700 MHz
Band 13
800 MHz
Band 5
1700 MHz
Band 4
1900 MHz
Band 2
23.94 24.19 23.49 24.55 23.61
Power output for single cell
phone (Downlink) dBm
700 MHz
Band 12/17
700 MHz
Band 13
800 MHz
Band 5
2100 MHz
Band 4
1900 MHz
Band 2
11.64 11.92 12.1 11.9 9.5
Power output for multiple
received channels (Uplink) dBm
No. Tones
Maximum Power
Maximum Power
700 MHz
Band 12/17
700 MHz
Band 13
800 MHz
Band 5
1700 MHz
Band 4
1900 MHz
Band 2
2 20.7 19.9 23.4 21.2 19.1
3 17.1 16.3 19.9 17.7 15.5
4 14.6 13.8 17.4 15.2 13.0
5 12.7 11.9 15.4 13.3 11.1
611.1 10.3 13.9 11.7 9.5
Power output for multiple
received channels
(Downlinklink) dBm
Maximum Power
No. Tones
700 MHz
Band 12/17
700 MHz
Band 13
800 MHz
Band 5
2100 MHz
Band 4
1900 MHz
Band 2
2 12.7 13.3 11.8 11.9 12.6
3 9.2 9.8 8.2 8.4 9.1
4 6.7 7.3 5.7 5.9 6.6
5 4.8 5.4 3.8 4.0 4.7
6 3.2 3.8 2.2 2.4 3.1
Noise Figure 5 dB nominal
Isolation > 110 dB
5V/2.5A
Power Requirements
IC Note #1: The term “IC” before the radio certification number only signifies that Industry Canada technical specifications were met.
Specifications
CELL PHONE SIGNAL BOOSTER
6
CELL PHONE SIGNAL BOOSTER 7
Each Signal Booster is individually tested and factory set to ensure FCC compliance. The Signal Booster
cannot be adjusted without factory reprogramming or disabling the hardware. The Signal Booster will
amplify, but not alter incoming and outgoing signals in order to increase coverage of authorized
frequency bands only. If the Signal Booster is not in use for five minutes, it will reduce gain until a signal
is detected.
If a detected signal is too high in a frequency band, or if the Signal Booster detects an oscillation, the
Signal Booser will automatically reduce the gain on that specific band.
The Manufacturer’s rated output power of this equipment is for single carrier operation. For situations
when multiple carrier signals are present, the rating would have to be reduced by 3.5 dB, especially
where the output signal is re-radiated and can cause interference to adjacent band users. This power
reduction is to be by means of input power or gain reduction and not by an attenuator at the output of
the device.
(SPECIFICATIONS cont.)
Antenna Expansion Kit
Outside Fixed
CELL PHONE SIGNAL BOOSTER
8
50 Ohm Outside Antenna Kits
Mini Mag
75 Ohm Outside Antenna Kits
Kit 314453-5825
50 Ohm Pole Mount Panel Antenna
25’ RG58 Cable
Kit 314411-5825
50 Ohm Wide Band Directional
25’ RG58 Cable
Kit 301111-5850
Yagi Directional Antenna
50’ RG58 Cable
Kit 311129-5840
800 MHz Yagi Directional
40’ RG58 Cable
Kit 311203-5820
Omni-Directional Antenna
20’ RG58 Cable
Kit 311203-40020
Omni-Directional Antenna
20’ LMR400 Cable
Kit 301111-400170
Yagi Directional w/ N-Female
170’ LMR400
Kit 311124-400100
1900 MHz Yagi Directional
100’ LMR400 Cab;e
Kit 311129-400100
800 MHz Yagi Antenna
100’ LMR400 Cable
Kit 314453-40075
50 Ohm Pole Mount Panel Antenna
75’ LMR400 Cable
Kit 311201-0620
Omni Directional w/F-Female
20’ Rg6 Cable
Kit 311129-0660
800 MHz Yagi Directional
60’ RG6 Cable
N-Male to F-Female adapter
Kit 311124-0650
1900 MHz Yagi Directional
50’ RG6 Cable
N-Male to F-Female adapter
Kit 301111-0675
Yagi Directional Antenna
75’ RG6 Cable
N-Male to F-Female adapter
301126 w/ 12.5 RG174 cable- SMA
Kit 311124-5830
1900 MHz Yagi Antenna
30’ RG58 Cable
Kit 314411-40075
50 Ohm Wide Band Directional
75’ LMR400 Cable
