Wali M001LP Manuel utilisateur
M001LP
WARNING
！
！
USE OF TIPOVER RESTRAINTS MAY ONLY REDUCE, BUT NOT ELIMINATE RISK OF TIP OVER.
SMALL PARTS- NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a
qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may
cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
Do not exceed weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect
assembly or inappropriate use.
SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM TIPOVER. TO HELP PREVENT TIPOVER:
Single Mount With Laptop Tray
75x75\100x100
INSTALLATION MANUAL
1-844-SATTLER (18447288537)
www.walielectric.com
(10kg/22lbs)x2
RATED
TIPOVER WARNING
● NEVER ALLOW CHILDREN TO CLIMB, STAND, HANG, OR PLAY ON ANY PART OF MONITOR OR STAND.
● USE TIPOVER RESTRAINT OR ANCHOR STAND TO WALL.
Supplied Parts List
Pole
a (x1)
C-Clamp Brace
c (x1)
C-Clamp
b (x1)
VESA Plate
e (x2)
M8x12 Bolt
g (x2)
Nut
h (x2)
M5x14 Bolt
f (x3)
Support Plate
j (x1)
Spring Washer
l (x1)
M10 Washer
k (x1)
M10 Bolt
i (x1)
Grommet Base Plate
m (x1)
Wire Clip
n1 (x2)
Allen Key
o (x1)
Wire Clip
n2 (x3)
M4 Spacer
s (x8)
M4x30 Bolt
r (x8)
Wrench
p (x1)
M4x12 Bolt
q (x8)
Swivel Arms
d (x1)
Laptop Tray
t (x1)
M4 Nut
v (x4)
M4x10 Bolt
u (x4)
Option A : Clamp Installation
1. Connect Pole a and C-Clamp Brace c from the bottom using M5x14 Bolt f and
tighten with Allen Key 3mm o .
1
2. Select the preferred height according to your desk thickness. Connect C-Clamp b to C-Clamp
Brace c using M8x12 Bolt g and tighten with Allen Key 5mm o . Rotate the hand knob
clockwise to fasten for stability.
Hand Knob
a
c
c
c
f
o
o
o
g
g
b
b
a c f
o
Option B : Grommet Base Installation
1. Place Pole a onto Grommet Base Plate m . Connect them from the bottom using
M5x14 Bolt and tighten with Allen Key 3mm .
o
o
a
a
m
m
f
f
Laptop : 17” Max
Monitor: 27” Max
Washer
w (x4)
Anti-skid Pad
x (x4)
Option A : Laptop Tray Installation Option B : Monitor Mount Installation
Laptop Tray Holder
For safety, please remove your laptop when making adjustments.
6Manually swivel, tilt, and rotate the monitor laptop tray for the best viewing angle.
5Guide the cable through the Wire Clips ( n1, n2 ) and store the Allen Keys o in the Wire Clip n1 .
Adjust the tilt angle using Allen Key 5mm n .
n1 n1
o
o
n2
n2 15°
15°
j
a
j
k
lp
i
2b. Self-drilled Grommet Hole Installation
ø 10mm
(ø ")3/8
o
Step 1
Select Monitor Screws
Step 3a
Flat Back Monitor
Step 3b
Curved or Recessed Back Monitor
e
e
r
s
q
M4x12 M4x30
3
Only one screw size fits your Monitor
Step 2
Select Spacers ( if needed )
Hand thread screws into the
threaded inserts on the back
of your Monitor to determine
which screw (M4x12 or M4x30)
to use.
4Put the assembled laptop tray and TV/Monitor onto the Swivel Arms d . Tighten the VESA
Plate e with Nut h for stability.
e
d
h
o
n1
e
d
h
Mark the position of the hole on your mounting surface. Drill a 3/8"(10mm) diameter hole at the
marked position through the mounting surface. Position the Pole a on the mounting surface and
secure using the Support Plate j , M10 Washer k , Spring Washer l , and M10 Bolt i . Fasten the
Bolt using the provided Wrench p .
a
jkl
p
i
2Put the Wire Clip n1 and Swivel Arms d through the Pole a , adjust the preferred height
and tighten using Allen Key 6mm o . Attach the Wire Clips n1 to the Swivel Arms d .
d
d
d
n2
n2
n1
n1
a
a
o
o
j
j
k
l
i
p
a
2a. Existing Grommet Hole Installation
If the existing grommet hole comes with a plastic protector, remove it to ensure a flat surface before
installing the desk mount. Position the Pole a on the mounting surface and secure using the
Support Plate j , M10 Washer k , Spring Washer l , and M10 Bolt i . Fasten the Bolt using
the provided Wrench p .
p
jkli
a
Select bolts and spacers (if needed) according to your TV/Monitor. Attach the VESA Plate to the Monitor and tighten with a screwdriver. (Screwdriver not included)
t
w
xu
e
xu
t
w
w
v
v
e
Notice: Please make sure the security nut is installed before you rotate the monitor.
h
h
Using M4 X 10 Bolt u , M4 Nut v , and Washer to attach the VESA
Plate e to the laptop tray t and tighten with a screwdriver. Put the Anti-skid
Pad on the designated position on the tray. (Screwdriver not included)
e
x
t
vu w
