This manual describes the Analog Input Module 750-477

2 AI AC/DC 0-10 V, Differential Inputs of the modular WAGO-I/O-SYSTEM

750.

Handling, assembly and start-up are described in the manual of the Fieldbus

Coupler. Therefore this documentation is valid only in the connection with the

appropriate manual.

750-477 [2 AI AC/DC 0-10 V, Differential Inputs] • 7

View

WAGO-I/O-SYSTEM 750

I/O Modules

2 I/O Modules

2.1 Analog Input Modules

2.1.1 750-477 [2 AI AC/DC 0-10 V, Differential Inputs]

2-Channel Analog Input Module (AC/DC 0-10 V, differential inputs)

2.1.1.1 View

+E1 +E2

13 14

750-477

-E1 -E2

+AI 2

Power jumper contacts

Data contacts

Function AI 2

Function AI 1

+AI 1

Error AI 2

Error AI 1

Shield

(screen)

Shield

(screen)

-AI 1 -AI 2

Fig. 2.1.1-1: View g047700e

2.1.1.2 Description

The analog input module receives AC and DC voltages of values 0-10 Vrms.

The module has two differential input channels and can receive differential

signals via the connections +AI 1 and -AI 1 or +AI 2 and -AI 2.

The Shield (screen) is directly connected to the DIN rail. A capacitive

connection is made automatically when snapped onto the DIN rail.

The input signal is measured for each channel galvanically separated to the

system level as rms value of the voltage and displayed with a resolution of

1 mV.

The maximum value of the voltage must not exceed 20 V.

The operational readiness and trouble-free internal data bus communication of

the channels are indicated via a green Function LED. Overrange of the

measuring range or input open is indicated via a red error LED.

Any configuration of the input modules is possible when designing the

fieldbus node. Grouping of module types is not necessary.

8 • 750-477 [2 AI AC/DC 0-10 V, Differential Inputs]

Display Elements

WAGO-I/O-SYSTEM 750

I/O Modules

The voltage supply is done via system voltage.

The field side supply voltage of 24 V and 0 V for the input module is derived

from adjacent I/O modules or from a supply module.The field supply voltage

is passed on separately galvanically to following modules without own use.

The supply voltage for the field side is made automatically through the

individual I/O modules by means of power jumper contacts.

Warning

The maximum current of the internal power jumper contacts is 10 A. When

configuring the system it is important not to exceed the maximum/sum

current. However, if such a case should occur, another supply module must be

added.

The analog input module 750-477 can be used with all couplers/controllers of

the WAGO-I/O-SYSTEM 750 (except for the economy types 750-320, -323, -

324 and -327).

2.1.1.3 Display Elements

LED Channel Meaning State Function

off

No operational readiness or the

internal data bus communication is

interrupted

green

Function

AI 1

Operational readiness and trouble-

free internal data bus

communication

off Normal operation

red

Error

AI 1 on Overrange of the admissible

measuring range

off

No operational readiness or the

internal data bus communication is

interrupted

green

Function

AI 2

Operational readiness and trouble-

free internal data bus

communication

off Normal operation

13 14

Fig. 2.1.1-2: Display

Elements g041802x

red

Error

AI 2 on Overrange of the admissible

measuring range

750-477 [2 AI AC/DC 0-10 V, Differential Inputs] • 9

Schematic Diagram

WAGO-I/O-SYSTEM 750

I/O Modules

2.1.1.4 Schematic Diagram

750-477

Shield

(screen)

Logic

Function

Error

Shield

(screen)

+Al

10nF

270

10nF

-Al

120 k

+AI 1 +AI 2

24V

-AI 2

-AI 1

Fig. 2.1.1-3: Schematic diagram g047701e

10 • 750-477 [2 AI AC/DC 0-10 V, Differential Inputs]

Technical Data

WAGO-I/O-SYSTEM 750

I/O Modules

2.1.1.5 Technical Data

Module Specific Data

Number of inputs 2

Voltage supply via system voltage DC /DC

Current consumption typ. (internal) 80 mA

Signal voltage 0 V... 10 V r.m.s. (peak value 20 V)

Internal resistance 120 kΩ

Resolution 16 bits internal (1 LSB = 1mV)

Conversion time typ. 200 ms

Measuring error 25°C <±0.1 % of full scale value

Temperature coefficient <±110 ppm /K of full scale value

Measuring error over whole temp.

range

<±0.6 % of full scale value

Voltage resistance DC 500V (channel/channel or channel/system)

Voltage via power jumper contacts DC 24 V

Bit width 2 x 16 bits data

2 x 8 bits control/status (option)

Process data 0,0 V corresponds to 0x0000

20 V DC corresponds to 0x4E20

Dimensions W x H* x L

* from upper edge of 35 DIN rail

12 mm x 64 mm x 100 mm

Weight ca. 80 g

Standards and Regulations (cf. Chapter 2.2 of the Coupler/Controller Manual)

EMC-Immunity to interference (CE) acc. to EN 50082-2 (96)

EMC-Emission of interference (CE) acc. to EN 50081-1 (93)

Approvals (cf. Chapter 2.2 of the Coupler/Controller Manual)

CULUS (UL508)

Conformity Marking

More Information

Detailed references to the approvals are listed in the document "Overview

Approvals WAGO-I/O-SYSTEM 750", which you can find on the CD ROM

ELECTRONICC Tools and Docs (Item-No.: 0888-0412)

or in the internet under:

www.wago.com !Documentation !WAGO-I/O-SYSTEM 750 !

System Description

Table des matières

Autres manuels WAGO Unité de contrôle

WAGO

WAGO 750-616/040-000 Manuel utilisateur

WAGO

WAGO 751-3502 Manuel utilisateur

WAGO

WAGO I/O-SYSTEM 750 Manuel utilisateur

WAGO

WAGO 751-5201 Manuel utilisateur

WAGO

WAGO I/O-SYSTEM 750 Manuel utilisateur

WAGO

WAGO 750-8212/040-010 Manuel utilisateur

WAGO

WAGO SPEEDWAY 767 Series Manuel utilisateur

WAGO

WAGO 750-1416/040-000 Manuel utilisateur

WAGO

WAGO I/O-SYSTEM 751-3002 Manuel utilisateur

WAGO

WAGO 750-645 Manuel utilisateur

WAGO

WAGO 750-624/040-00 Series Manuel utilisateur

WAGO

WAGO 750-430/040-000 Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

WAGO

WAGO 767-1501 Manuel utilisateur

WAGO

WAGO SPEEDWAY 767 Series Manuel utilisateur

WAGO

WAGO 750-535/040-000 Manuel utilisateur

WAGO

WAGO 750-527 Manuel utilisateur

WAGO

WAGO 750-536 Manuel utilisateur

WAGO

WAGO 750-1415/040-000 Manuel utilisateur

WAGO

WAGO I/O-SYSTEM 751-4001 Manuel utilisateur

WAGO

WAGO 750-606 Manuel utilisateur

WAGO

WAGO WAGO-I/O-SYSTEM 750-506 Manuel utilisateur

WAGO

WAGO 750-564 Manuel utilisateur

WAGO

WAGO 750-606/040-000 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur

Flyron

Flyron FN-BC04 Manuel utilisateur
