Volvo V60 Manuel utilisateur

QUICK GUIDE

WEB EDITION

Remote control key

Keyless* lock system

Starting and switching off the engine

Parking brake

Wipers

Climate system controls

Headlamp control

Combined instrument panel

Infotainment system

Phone*

Internet*

External audio device

Buttons in the centre console

Settings in the menu system

Workshop/booking service*

02 Starting and driving

Adjusting the steering wheel

Adjusting the seat

Drive mode

Charging

Preconditioning

Mobile application

01 Your hybrid car

04 Your driving environment

Refuelling

Car care

Storage spaces

AUX/USB* and 12 V sockets

05 Functions in your car

06 Tips

Pedestrian protection*

03 Driver support in your car

WELCOME TO YOUR NEW VOLVO!

This folder contains a selection of the most common functions in your particular car. The owner's manual and

other manuals contain safety instructions and all warning, important and note texts.

The following symbols mean:

Different parts are pointed out in the overview images.

Step–by–step instructions.

It is particularly important to read the owner's manual.

Warning, important and note texts, that must be read, are included on the last page.

Options are marked with an asterisk *.

The owner's manual is available as a printed manual and digitally in the car's screen, on the Web and as a

mobile app. The mobile app contains the whole owner's manual as well as instruction films and has several

search paths with text and illustrations. The mobile app can be downloaded to mobile devices from App Store or

Google play.

In addition, learn more about your car at www.volvocars.com.

Which drive modes can I select?

The car is powered by two motors - an electric motor and

a diesel engine. Different drive modes can be selected. It

is not possible to select the "wrong" drive mode - the car

returns to the HYBRID mode if certain conditions are not

met. The lamp in the hybrid button will then illuminate.

HYBRID

This is the car's preset drive mode. Both the motor

and the engine are used - individually or in parallel.

A computer determines what is most appropriate in

each case.

PURE

The car is powered by the electric motor. Air

conditioning is switched off in order to obtain the

longest possible driving distance. The diesel engine

starts automatically when the battery needs to be

charged or when the driver requests more power

than the electric motor can supply. The diesel engine

is also used to provide all-wheel drive if required, e.g.

when starting and on slippery surfaces.

POWER

Provides the best response and performance by me-

ans of both the electric motor and the diesel engine

being activated the whole time. Driving in a lower

gear is prioritised for active driving, which results in

delayed upshifting.

AWD

All-wheel drive is activated. Primarily intended for low

speed in slippery driving conditions when better grip

and traction are required. The drive mode also has a

stabilising effect at higher speeds.

SAVE

Maintains current energy level in the battery for later

needs. In the event of low charge level the battery

will also be charged to a level equivalent to approx.

20 km electric operation. Select PURE when electric

operation is required.

How do I open and close the hatch for the

charging input socket?

The charging cable is located in the storage compartment

under the cargo area's floor hatch.

Press in the rear section of the hatch and release.

Fold out the flap.

Pull away the cover for the charging input socket and

secure it to the inside of the hatch.

Close the hatch for the charging input socket in reverse

order.

Where is the charging cable located?

Illuminated symbol: Shows selected charging current.

Lit symbol: Cable connected to 230V.

Increases the charging current.

Decreases the charging current.

Lit symbol: Cable connected to the car.

How does the control unit for the charging

cable work*? 01

How do I stop charging?

Unlock the car with the remote control key's unlock

button

Detach the charging cable from the car.

Detach the charging cable from the 230 V electrical

socket.

Refit the charging cable in the storage space under

the cargo area's floor hatch.

The charging cable locks automatically into the charging

input socket a little while after unlocking if it was not

removed. Open the lock/inhibitor with the remote control

key's unlock button.

What do the lamps for the charging input

socket show? 01

White constant: Guide light

Yellow constant: Waiting mode

Green short flashes: Charging of low charge battery

Green long flashes: Charging of well-charged battery

Green constant or off: Charging complete

Blue: Timer switched on

Red: Error

How do I start charging?

Connect the charging cable to the 230 V electrical

socket.

Increase/decrease the charging current on the con-

trol unit*. Affects charging time and preconditioning.

Connect the charging cable to the car - the cable

locks automatically into the charging input socket.

Press the button for approach lighting on the remote

control key the combined instrument panel then shows

the remaining charging time. Charge status indicated via

the charging input socket's lamps and the Volvo On Call*

mobile app.

Approach lighting must be activated in MY CAR -

see the owner's manual.

What can I do with the Volvo On Call* app?

The Volvo On Call mobile application can be used anytime

and anywhere. With a single touch of a button on the

mobile phone, the car can be located and locked remotely,

amongst other things, the combined instrument panel and

charge status can be checked, and preconditioning can

be set.

The mobile application is updated continuously. For more

information – see Volvo On Call* in the owner's manual.

How do I activate preconditoning?

Preconditioning is mainly used to optimise the car's elec-

tric drive system prior to a planned departure. The function

heats/cools the passenger compartment and is activated

via direct start in the combined instrument panel, the

remote control key* or Volvo On Call* mobile app.

Activate via the combined instrument panel:

Press OK on the left-hand stalk switch.

Turn the thumbwheel* to Preconditioning and press

OK.

Select between Direct start,Timer,Outdoor

parking or Indoor parking (can only be activated

if the car is being charged with the charging cable).

Confirm with OK.

Activating via the remote control key*:

– Press the approach lighting button for approx. 2

seconds. The car's direction indicators emit 5 short

flashes, followed by a constant glow when preconditio-

ning has been activated.

Check status via remote control key*: (see illustra-

tion)

– Press the information button for approx. 2 seconds.

The red indicator lamp emits 5 short flashes, followed

by a constant glow when preconditioning is activate.

For more information on activation via mobile

phone – see Volvo On Call* in the owner's manual.

How does the remote control key work? 02

Unlocks doors and tailgate and disarms the alarm.

The function can be set in MY CAR.

Locks doors and tailgate and arms the alarm.

Approach light duration.

Unlocks and disarms the alarm for the tailgate only.

Information*.

Panic function.

The remote control key can store settings for,

amongst other things, door mirrors and power

driver's seat* – see owner's manual.

How does the Keyless* lock system work?

The remote control key can remain in a pocket, for example,

the whole time.

Lock and arm the alarm

– Touch the rear section of one of the outer door handles

or press lightly on the smaller of the tailgate's two rub-

berised buttons.

Unlock and disarm the alarm

– Grip a door handle and open the door in the usual way

or press lightly on the larger of the tailgate's two rub-

berised buttons.

What do the remote control key indicator

lamps* show? 02

Green constant light: The car is locked.

Yellow constant light: The car is unlocked.

Red continuous light: the alarm has been triggered

since the car was locked.

Red light flashing alternately in both indicator lamps:

The alarm was triggered less than 5 minutes ago.

How do I use the parking brake? 02

To apply

– Press the control PUSH LOCK/PULL RELEASE – the

symbol starts to flash. Once there is a constant glow

the parking brake is applied.

To disengage

Depress the foot brake pedal.

Pull the control PUSH LOCK/PULL RELEASE.

Disengage automatically

– Drive away (for cars with automatic gearbox, the seat-

belt must be buckled).

How do I switch off the engine? 02

Briefly press the START/STOP ENGINE button -

the engine stops. The electric motor is switched off

when the digits in the speedometer or tachometer

and side gauge have extinguished.

Take the remote control key out from the ignition

switch.

How do I start the engine?

Ensure that the charging cable has been removed before

starting the car.

Push the remote control key into the ignition switch

(does not apply to Keyless drive*).

Fully depress the brake pedal.

Briefly press the START/STOP ENGINE button and

release. The electric motor is running when the digits

in the speedometer or tachometer and side gauge

are illuminated.

It is important to understand this function – see

owner's manual.

Collision Warning with Auto Brake and Cyclist and Pede-

strian Detection, which can warn, brake and/or stop for

vehicles, cyclists and pedestrians.

The function is only an aid and does not work in all situa-

tions – for example, it does not see cyclists from the side

and pedestrians who are shorter than 80 cm or who are

partially obscured.

How does the pedestrian protection work*? 03

How do I start the windscreen wipers and rain

sensor*?

Move the lever downward to start the windscreen wipers

and upward for a single sweep.

Rain sensor On/Off.

Regulates the sensor sensitivity or the intermittent

delay.

Wiper, rear window - intermittent/normal.

How do I adjust the steering wheel?

Release the catch.

Adjust the steering wheel forward/backward and up/

down.

Activate the catch.

To lift up the wiper blades they must be in service

position – see owner's manual.

How do I regulate the temperature?

Turn for individual temperature in the left/right-hand

area of the passenger compartment. The screen

shows the selected temperature.

Press AUTO for automatic control of air distribu-

tion and other functions. The screen shows AUTO

CLIMATE.

How do I adjust the seat?

Raise/lower the front of the seat cushion.

Raise/lower the seat.

Move the seat forward/backward.

Tilt the backrest.

Lumbar support* adjustment.

Storing settings for power seat*.

Memory buttons for power seat*.

Store setting:

Hold the button depressed to store settings while

depressing one of the memory buttons. Hold the buttons

depressed until a signal is heard and text is shown in the

combined instrument panel. This stores the position of the

seat as well as the door mirrors. The position of the lumbar

support is not stored.

The position for the door mirrors, and memory

settings (not lumbar support) for the power seat,

can also be stored in the remote control key* – see

owner's manual.

Autres manuels pour V60

Table des matières

Autres manuels Volvo Automobile

Volvo

Volvo S80 - Manuel utilisateur

Volvo

Volvo V 90 Manuel utilisateur

Volvo

Volvo 1992 240 Manuel utilisateur

Volvo

Volvo XC90 - ANNEXE 951 Guide de démarrage rapide

Volvo

Volvo S90 TWIN ENGINE 2018 Manuel utilisateur

Volvo

Volvo V60 Manuel utilisateur

Volvo

Volvo 164 1971 Manuel utilisateur

Volvo

Volvo STD 101-0001 Manuel utilisateur

Volvo

Volvo XC70 - ANNEXE 808 Manuel utilisateur

Volvo

Volvo S90 2020 Manuel utilisateur

Volvo

Volvo 2003 V70 Guide de démarrage rapide

Volvo

Volvo XC40 2018 Manuel utilisateur

Volvo

Volvo V70 SPORT Manuel utilisateur

Volvo

Volvo S80 - Manuel utilisateur

Volvo

Volvo S60 - ANNEXE 931 Manuel utilisateur

Volvo

Volvo V90 TWIN ENGINE 2017 Manuel utilisateur

Volvo

Volvo C30 2007 Manuel utilisateur

Volvo

Volvo S60 - ANNEXE 931 Manuel utilisateur

Volvo

Volvo S90 2019 Manuel utilisateur

Volvo

Volvo 120 Manuel d'instructions et de sécurité

Volvo

Volvo XC70 - ANNEXE 808 Manuel utilisateur

Volvo

Volvo XC60 Twin Engine 2020 Manuel utilisateur

Volvo

Volvo S40 - ANNEXE 244 Manuel utilisateur

Volvo

Volvo 120 Manuel du propriétaire

Manuels Automobile populaires d'autres marques

Toyota

Toyota 2000 Tundra Manuel utilisateur

CITROËN

CITROËN DS4 DSign Manuel utilisateur

Lexus

Lexus 2015 CT 200h Manuel utilisateur

Cadillac

Cadillac CTS 2008 Manuel utilisateur

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuel utilisateur

Porsche

Porsche Boxster S Manuel utilisateur

GMC

GMC 2010 Savana 1500 Cargo Manuel utilisateur

KIAM

KIAM SPORTAGE 2014 Manuel de la liste des pièces

GMC

GMC 2013 Terrain Instructions de montage

GMC

GMC T-Series 1999 Manuel utilisateur

Mercury

Mercury 1998 Mystique Manuel utilisateur

Mercury

Mercury 2007 Mariner Manuel utilisateur

Mazda

Mazda 2007 Mazdaspeed 3 Mode d’emploi

Mazda

Mazda 2014 CX-5 Manuel utilisateur

GMC

GMC Chevrolet Express 2022 Manuel utilisateur

GMC

GMC 1997 Jimmy Manuel utilisateur

Chevrolet

Chevrolet 2012 Malibu Manuel utilisateur

Cadillac

Cadillac 2010 Escalade Manuel utilisateur
