Volvo C70 Manuel utilisateur

welcome to the global FamIly oF volvo

owners!

Getting to know your new vehicle is an exciting experience.

This Quick Guide provides a brief overview of the most common

features and functions in your Volvo.

However, for the most up-to-date and detailed descriptions and

instructions, as well as important warnings and other information not

included in this folder, please refer to your Owner’s Manual.

An asterisk (*) indicates optional equipment.

For additional information, contact Customer Service:

U.S.A.: 1-800-458-1552 www.volvocars.us

Canada: 1-800-663-8255 www.volvocanada.com

VOLVO C70

quick guide

Insert the key blade to mechanically open the

trunk.

KEY BLADE

Used to lock/unlock the glove compartment or

the driver’s door if the vehicle has no electrical

current.

AUTOSTART

Depress the clutch and/or brake pedal. Turn

the key/keyless drive start control to position

III and release it. The engine will start automati-

cally.

REMOTE KEY & KEY BLADE

NOTE

After cold starts, your engine will idle at a

higher speed for a short time.

TURN SIGNALS STEERING WHEEL ADJUSTMENT

Lane-change sequence, three flashes.

Full turn sequence. WARNING

Never adjust the steering wheel while

driving.

SETTING THE CLOCK

Press the MENU button on the center console control panel.

Select Clock adjust.

Press ENTER

Use the left/right arrow keys on the navigation control to highlight a number in the clock.

Set the time by using the number keys or with the up/down arrow keys.

Press ENTER to save the change and exit the menu.

Locks the doors and trunk and arms

the alarm. If the car is locked with the

remote key while the power retractable

hard top is down, the double locking

feature activates after approximately

30 seconds. The doors can then not be

opened from inside the car.

Unlocks the doors and trunk, and dis-

arms the alarmA.

Unlocks (but does not open ) the trunk.

Approach lighting illuminates lights in

door mirrors, cabin, footwells, license

plates. Turn signals and parking lights

illuminate.

“Panic” alarm.

– Press and hold to sound the alarm.

Turn off alarm with unlock button.

A. Automatic relock occurs if no door/trunk is opened within

2 minutes after unlock.

LIGHTING PANEL

STORAGE SPACES, 12-VOLT SOCKET & AUX/USB* CONNECTOR

The 12-volt sockets in the cabin function in

ignition positions Ior II.

The 12-volt socket* in the trunk always func-

tions.

AUX/USB* can be used to connect e.g., an

mp3 player to the vehicle’s audio system.

CAUTION

Using the optional 12-volt socket in the trunk

with the engine switched off will drain the

battery.

CAR CARE

Hand washing is gentler on the paint than an

automatic car wash. Since the paint on a new

vehicle may take several months to harden

completely, we recommend washing the vehi-

cle by hand during this period. Use clean water,

a suitable car washing detergent and a sponge.

Keep in mind that dirt or grit on the sponge can

scratch the paint.

Automatic headlights. High beam flash

only.

Parking lights.

Headlights: turn off when ignition is

switched off, high/low beams.

Active Bending Lights*, headlight

beams follow movements of the steer-

ing wheel.

Display & instrument panel lighting.

Front fog lights*.

Open the fuel filler door.

Rear fog light (driver’s side only).

High beam flash.

Toggle between high/low beams, home

safe lighting.

AUDIO SYSTEM

The deep center storage compartment has

room for 10 CD jewel cases. These cases must

be inserted with their spines upward in order

to allow room for 10 CDs.

CD STORAGE

RADIO

Turn to select a radio station.

Search for the next strong station.

Search for stations with left/right arrows.

Store up to 20 stations by pressing and

holding one of the preset buttons 0–9in

FM1 and 0–9in FM2, until the stored sta-

tion is confirmed in the display.

Autostore stations by pressing for 2 sec-

onds. AUTOSTORE is displayed during

the search. The 10 strongest stations are

stored. Press 0–9to select a station.

CD PLAYER

Press to eject a CD.

Turn to change tracks.

Change tracks with left/right arrows.

BLUETOOTH®

Make the cell phone searchable/visible.

Press the PHONE button on the audio sys-

tem control panel briefly.

Select ”Add phone” in the audio system

display.

Select the cell phone to be connected.

Enter the numbers shown in the audio sys-

tem display using the cell phone’s keypad.

Press to turn on/off.

Turn to adjust volume.

FM1, FM2 or AM radio.

Display

MODE, CD, Sirius satellite radio*, AUX/

USBA

Sound settings. Press to select e.g.,

BASS, TREBLE, etc.

Turn to adjust.

MENU. AUX, volume and advanced sound

settings.

HD RADIO

HD radio reception is subject to coverage limita-

tions. See your Owner’s Manual for details.

A. AUX/USB sockets for e.g., an mp3 player. Set the device’s

volume to medium for best sound quality. An iPod® con-

nected to the USB socket will also be charged.

WIPERS AND RAIN SENSOR*

Rain sensor On/Off with the lever in the

0position.

Turn to adjust intermittent wiper speed or

rain sensor sensitivity where applicable.

Single wiper sweep.

Off

Intermittent wipers. Turn (2) to adjust

interval.

Normal wiper speed.

High wiper speed.

Windshield and headlight washer.

Displayed when the rain sensor is

active.

AUTOMATIC CONTROL

In AUTO mode, ECC controls all functions

automatically and makes driving more pleasant

with optimal air quality.

Press AUTO to maintain automatic cabin

temperature, balanced airflow and other

settings.

Press to individually adjust the left (L) or

right (R) side.

Turn the dial to the desired temperature,

which is shown in the display.

ELECTRONIC CLIMATE CONTROL (ECC)

MANUAL CONTROL

Blower speed.

Max. defroster. Directs maximum air flow

to the windshield and front side windows.

Recirculation

Heated rear window and door mirrors.

Air distribution.

Air conditioning Off/On to cool the cabin

and defog the windows.

Low fuel level indicator

When the symbol illuminates, refuel as

soon as possible.

Fuel gauge.

The fuel filler door is on the right, as indi-

cated by the arrow.

Information display (trip computer in-

formation, messages, clock and ambient

temperature).

The trip odometer display shows two

separate trip odometers, T1 & T2.

A short press toggles between T1 &T2.

Along press resets the displayed odom-

eter.

TRIP COMPUTER AND ODOMETER

Press to display or erase a message.

Turn to show trip computer information

alternatives.

A short press resets current function.

Along press resets all functions.

NOTE

The display text MILES TO EMPTY TANK is

an approximation, based on recent average

fuel consumption.

BLIND SPOT INFORMATION SYS-

TEM (BLIS)*

If the BLIS indicator lights illuminate occasion-

ally even when there are no other vehicles in

the blind area, this may be caused by light re-

flected from a wet road surface, the vehicle’s

own shadow against a large, light, smooth

surface, or sunlight directly in the camera

when the sun is low on the horizon.

In the event of a fault, BLIND SPOT SYST.

SERVICE REQUIRED will be displayed. See

the Owner’s Manual for other BLIS-related

messages.

REFUELING

1. Press this button to open the fuel filler door.

2. Hang the fuel filler cap on the hook while

refueling.

OPERATING THE POWER RETRACT-

ABLE HARD TOP

PREPARATION

There should be no objects on the parcel

shelf, roof, or trunk lid.

6.5 ft (2 m) free height above the car, and

8 in. (0.2 m) behind.

Flat ground.

Ambient temperature above 14 ˚F (-10 ˚C).

Trunk lid and trunk divider closed.

The car must be at a standstill.

Due to the low roofline, the front seat head

restraints must be in the lowest position.

Always have an unobstructed view of the

power retractable hard top when it is in

motion.

The windows open automatically approxi-

mately 1 in. (2 cm) when the power retractable

hard top is operated. They close automati-

cally.

•

TRUNK DIVIDER

The trunk divider limits the amount of cargo

in the trunk to leave space for the power

retractable hard top.

Raise the divider when loading the trunk.

Close the divider completely (3) before

operating the hard top. See the decal on

the trunk divider.

Raise or lower the folded power retractable

hard top to facilitate loading.

Press the button and wait several sec-

onds for the hard top to rise slightly.

Open the trunk divider, load the cargo,

and close the trunk divider again.

Press the button again to lower the folded

power retractable hard top.

LOAD ASSISTANCE

OPERATION

Engine idling (car parked outdoors).

Press the brake pedal.

Hold down the button (see inset illustra-

tion above) to open or pull up to close

the convertible hard top. Hold until a tone

is audible and the message TOP FULLY

UP/TOP FULLY DOWN is displayed.

Release the button.

AUTOMATIC CAR WASH

Remove the antenna by turning it coun-

terclockwise before washing the car in an

automatic car wash.

ENTERING THE REAR SEAT

MANUAL SEAT

Moving the seat forward

Remove the seat belt from the guide (A).

Pull up the handle (B) and fold the backrest

forward until it locks in position.

Move the seat forward (C).

Moving the seat rearward

Move the seat rearward until it reaches the

desired position (D).

Pull up the handle (E) and return the back-

rest to the upright position.

Put the seat belt back into the guide (F).

POWER SEAT*

Moving the seat forward

Remove the seat belt from the guide (A).

Pull up the handle (B) and fold the backrest

forward until it locks in position.

Press and hold in the front section of the

button (G).

Moving the seat rearward

Press and hold in the rear section of the

button (G).

Pull up the handle (E) and return the back-

rest to the upright position.

Put the seat belt back into the guide (F).

NOTE

When putting on the seat belt, it is easiest

to reach for the lower section of the belt,

near the guide, instead of reaching over

your shoulder.

ADJUSTING THE FRONT SEAT

TIRE PRESSURE MONITORING

SYSTEM (TPMS)

When a low tire pressure warning message

(LOW TIRE PRESS. CHECK TIRES or VERY

LOW TIRE PRESSURE) has been displayed

and the tire pressure warning light ( ) has

illuminated, one or more tires has low inflation

pressure.

Check the inflation pressure of all four tires

with a tire pressure gauge as soon as possible

and pump the tire(s) with low pressure to the

recommended inflation pressure.

Refer to the inflation pressure tables in the

chapter “Wheels and tires” in the Owner’s

Manual.

Lumbar support.

Head restraint height adjustment.

Access to rear seat.

Backrest tilt.

Raise/lower the seat.

Raise/lower the front edge of the seat

cushion.

Forward/rearward.

Autres manuels pour C70

Table des matières

Autres manuels Volvo Automobile

Volvo

Volvo XC90 - ANNEXE 951 Manuel utilisateur

Volvo

Volvo 2010 C70 Manuel utilisateur

Volvo

Volvo S60 2013 Guide de démarrage rapide

Volvo

Volvo XC90 Twin Engine 2019 Manuel utilisateur

Volvo

Volvo S40 - ANNEXE 244 Manuel utilisateur

Volvo

Volvo XC90 - ANNEXE 951 Manuel utilisateur

Volvo

Volvo S60 - ANNEXE 931 Manuel utilisateur

Volvo

Volvo XC90 2020 Manuel utilisateur

Volvo

Volvo V70 SPORT Manuel utilisateur

Volvo

Volvo 2003 S60 Manuel utilisateur

Volvo

Volvo XC60 - ANNEXE 541 Manuel utilisateur

Volvo

Volvo C70 Manuel utilisateur

Volvo

Volvo S60 2018 Manuel utilisateur

Volvo

Volvo XC90 - ANNEXE 951 Manuel utilisateur

Volvo

Volvo XC60 - ANNEXE 541 Manuel utilisateur

Volvo

Volvo 760 GLE Turbo 1986 Manuel utilisateur

Volvo

Volvo S80 - Manuel utilisateur

Volvo

Volvo V90 Cross country 2020 Manuel utilisateur

Volvo

Volvo C30 - ANNEXE 798 Manuel utilisateur

Volvo

Volvo C30 2012 Manuel utilisateur

Volvo

Volvo S60 - ANNEXE 931 Manuel utilisateur

Volvo

Volvo XC90 - ANNEXE 951 Manuel utilisateur

Volvo

Volvo TURBO R SPORT Manuel utilisateur

Volvo

Volvo 2004 V70R Manuel utilisateur

Manuels Automobile populaires d'autres marques

Toyota

Toyota 2000 Tundra Manuel utilisateur

CITROËN

CITROËN DS4 DSign Manuel utilisateur

Lexus

Lexus 2015 CT 200h Manuel utilisateur

Cadillac

Cadillac CTS 2008 Manuel utilisateur

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuel utilisateur

Porsche

Porsche Boxster S Manuel utilisateur

GMC

GMC 2010 Savana 1500 Cargo Manuel utilisateur

KIAM

KIAM SPORTAGE 2014 Manuel de la liste des pièces

GMC

GMC 2013 Terrain Instructions de montage

GMC

GMC T-Series 1999 Manuel utilisateur

Mercury

Mercury 1998 Mystique Manuel utilisateur

Mercury

Mercury 2007 Mariner Manuel utilisateur

Mazda

Mazda 2007 Mazdaspeed 3 Mode d’emploi

Mazda

Mazda 2014 CX-5 Manuel utilisateur

GMC

GMC Chevrolet Express 2022 Manuel utilisateur

GMC

GMC 1997 Jimmy Manuel utilisateur

Chevrolet

Chevrolet 2012 Malibu Manuel utilisateur

Cadillac

Cadillac 2010 Escalade Manuel utilisateur
