WELCOME TO YOUR NEW VOLVO!

Getting to know your new car is an exciting experience.

Look through this Quick Guide so that you learn some of the most

common functions quickly and easily.

All warning texts, and other important and detailed information, are

only available in the owner's manual – this folder only contains a small

selection.

In addition, the owner's manual contains the latest and most current

information

Options are marked with an asterisk (*).

There is further information concerning your car at www.volvocars.com.

VOLVO S80

Quick Guide WEB EDITION

Locks doors and boot lid and arms the

alarm*.

UnlocksAthe doors and boot lid, and

disarms the alarm.

Unlocks the boot lid – this does not

open.

Approach light duration. Switches on

the lamps in the side mirrors*, the direc-

tion indicators and parking lamps, at the

number plate, passenger compartment

and floor.

"Panic" button. Held down for approx.

3 seconds in an emergency to trigger

the alarm.

AAutomatic relocking takes place if a door/boot

lid has not been opened within 2 minutes after

unlocking.

REMOTE CONTROL KEY WITH PCC* – PERSONAL CAR COMMUNICATOR

KEY POSITIONS

In order to reach the following key positions

without the engine starting: Do not depress the

brake/clutch pedal!

Position Active functions

Remote control key not inserted

– Audio system and passenger

compartment lighting.

Remote control key inserted

– Instrument/clock lighting, steering

lock off.

Inserted key and short press on

START – Sunroof*, power windows,

fan, ECC, windscreen wipers, 12 V

socket, RTI*.

To exit key position 0/Iand switch off all con-

sumers: Press the key – it is ejected.

PCC*

Information on the car can be obtained

within a radius of 20 metres.

– Press the button and wait 7 seconds.

Pressing the button out of range shows

the last status stored in the memory.

1Green light: The car is locked.

2Yellow light: The car is unlocked.

3Flashing alternating red light: Someone

may be inside the car.

4Red light: The alarm has been triggered.

STARTTHE ENGINE

BLIS – BLIND SPOT INFORMATION

SYSTEM*

If the BLIS’ indication lamp illuminates despite

no vehicle being in the blind spot, the cause

could be reflection from wet road surface or

low sun shining into the camera for example.

In the event of a direct fault in the system

the display shows the text Blind spot syst.

Service required.

– Insert the remote control key in the ignition

switch and press gently on it – the key is

drawn in.

– Depress the clutch or brake pedal

COLD START

After a cold start the idling speed is high irre-

spective of outside temperature. A period of

raised idling speed is part of Volvo's efficient

emissions system.

SWITCH OFFTHE ENGINE AND

REMOVETHE REMOTE CONTROL KEY

Briefly press the button – the engine

stops.

Briefly press the key – it can now be

removed from the ignition switch (auto-

matic transmission must be in Pposition).

– Briefly press the button to start the engine.

Setting the door mirrors

– Select L(left) or R(right), adjust with

the lever.

Retracting/extending the door mirrors*

–Press Land Rsimultaneously.

1Manual windows.

2Automatic windows.

Child safety locks*. Windows and rear

doors cannot be opened from the rear

seat.

CONTROL PANEL DRIVER'S DOOR

157

AUDIO SYSTEM

RADIO

3Turn to select station.

4Search station with left/right arrow.

Store up to 20 stations by holding in 0–9

on FM1 or FM2 at the desired station until

the display confirms the selection.

5Press for about 2 seconds to autostore

the 10 strongest stations. The display

shows Autostoring during the search.

Select stored station with 0–9.

CD PLAYER

3Turn to change track.

4Change CD tracks with left/right arrow.

Select CDBwith up/down arrow.

6One short press ejects the current disc.

One long press ejects all discsB.

7Select CDBwith 1–6.

BOnly CD changer.

1Press for On/Off. Turn to adjust the vol-

ume.

2Select AM,FM1/FM2, CD or MODE.Use

MODE to activate AUXAand to adjust the

AUX audio source volume.

3Press to select sound pattern e.g. BASS,

Dolby Pro Logic II* or SUBWOOFER*

– turn to adjust.

AAUX input for e.g. MP3 player (set volume at medium

for optimum audio reproduction).

LOWERINGTHE REAR SEAT BACKREST

Pull the required handle in order to lower

the left/right-hand backrest.

1. Make sure that the rear head restraints are

raised.

Lower the backrests.

ELECTRONIC CLIMATE CONTROL – ECC*

MANUAL CONTROL

2Ventilation left/right-hand seat.

3Turn to change the fan speed.

4Heating, left/right-hand seat.

5Air distribution.

7Air quality system. OFF/AUT/Recirculation.

8Defroster. Quickly removes mist on the

windscreen and side windows.

9Rear window and side mirror defrosters.

AC – Air conditioning On/Off. Cools the

passenger compartment and demists the

windows.

AUTOMATIC CONTROL

In AUTO mode the ECC system controls all

functions automatically, making driving simpler

with optimum air quality.

1Turn for the desired individual tempera-

ture, left/right-hand side of the passenger

compartment. The display shows the

selected temperature.

6Press for automatic control of selected

temperature and other functions.

STORAGE SPACES, 12 V SOCKET & AUX/USB*

IMPORTANT

Using the 12 V socket in the cargo area when

the engine is switched off could discharge

the battery.

The 12 V sockets in the passenger compartment

work in key position Ior II. The 12 V socket* in

the cargo area is always active.

The car's audio system can playback music from

an MP3 player etc. using the AUX/USB* output.

8 9

1Low fuel level. When the lamp is illumi-

nated, fill with fuel as soon as possible.

2T1 & T2 – independent trip meters, which

are always active.

3Fuel gauge. The symbol's arrow points

out the side on which the fuel cap is

located.

4Display, trip computer. Select function

with (8).

5Clock. Adjust with (6).

6Turn to end position and hold to set the

clock.

One short press switches between T1

&T2. One long press resets the current

meter.

TRIP COMPUTER ANDTRIP METERS

7Press to show/clear message.

8Turn to see the trip computer's options.

9One short press resets the trip compu-

ter's current function.

One long press resets all trip computer

functions.

ADJUSTINGTHE STEERING WHEEL REFUELLING

WARNING

Adjust the steering wheel before starting to

drive – never do this while driving.

– Press to open the tank cover.

Display text Kilometres to empty tank is an

estimate of the possible distance left to drive,

based on earlier driving conditions.

HEADLAMP CONTROL

Display and instrument lighting.

Front fog lamps.

Fog lamps rear (driver's side only).

Automatic dipped beam. Main beam

flash works but not fixed main beam.

Parking lamps.

Dipped beam. Switches off when the

engine is switched off. Main beam can

be activated.

Manual headlamp levelling (automatic

for Dual Xenon lights*).

Single sweep.

Off.

BIntermittent wiper, see also (2).

Normal sweep speed.

High sweep speed.

Washer, windscreen and headlamps.

Illuminates when the rain sensor is

active.

WINDSCREEN WIPERS AND RAIN SENSOR*

1Rain sensor On/Off, with the lever in posi-

tion 0.

2Regulates the sensor sensitivity or the

intermittent delay.

DRIVER SUPPORT SYSTEM* BLUETOOTH*

To help the driver to brake in time, for exam-

ple, keep a safe distance from other vehicles

or maintain a good road position, the car may

be fitted with a number of systems:

Adaptive cruise control*

Distance control*

Collision warning with auto brake*

Driver Alert System*

•

Makes mobile phone searchable/visible.

Hold in the audio system's PHONE button.

Select Add phone from the audio system

display.

Select the phone to be connected.

Input the digits shown in the audio system

display using the mobile phone's keypad.

Main beam flash.

BMain/dipped beam switching and Home

safe light duration.

ADJUSTINGTHE FRONT SEAT

1Lumbar support

2Backrest rake.

3Raise/lower seat.

4Raise/lower the front of the seat cush-

ion.

5Forwards/backwards.

6Lowering the passenger seat backrest.

TP 11110 (En glish). AT 0 920. Printed in Swed en, Götebo rg 2009. C opyright © 20 00 -200 9 Volvo Car C orpo ration.

Handwashing is gentler on the paintwork than

an automatic car wash. The paintwork is also

more sensitive when it is new. For this reason,

handwashing is recommended during the first

few months with a new car. Use clean water

and a washing sponge. Remember that dirt ad

grit can scratch the paintwork.

To apply

– Press the button. The warning lamp flashes

until the parking brake is fully applied – after

which the lamp stays on.

To disengage

Key position 0or I.

Depress the brake pedal and pull the button

gently.

Disengage automatically

– Drive away. (For cars with automatic trans-

mission, the seatbelt must be buckled).

PARKING BRAKE

EBA – EMERGENCY BRAKE ASSIST

Emergency Brake Assistance helps to

increase brake force and so reduce braking

distance. EBA is activated when the driver

brakes suddenly. When EBA is activated the

brake pedal depresses a little further than

usual.

– Press (hold) down the brake pedal for as

long as necessary – all braking ceases if the

pedal is released.

CAR CARE
