WELCOME TO YOUR NEW VOLVO!

Getting to know your car is an exciting experience.

After looking through this Quick Guide you'll like your new Volvo even

more. You can find detailed information in the Owner's Manual.

Warning texts and other important information are only available in the

Owner's Manual, not in this folder. The Owner's Manual contains the

most up-to-date information.

Options are marked with an asterisk (*).

There is further information on your car at www.volvocars.com

VOLVO C70

QUICK GUIDE WEB EDITION

AUTOSTART (APPLIES TO 2.4i, T5 AND D5)

Depress the clutch and/or brake pedal. Turn the

remote control/ignition dial to end position III

and release it straight away – the engine starts

automatically.

Diesel engines must always be preheated in

key position II before the engine is started.

KEY BLADE

Used to lock/unlock the glovebox or the driver's

door/cargo area, e.g. if car is without electrical

power.

COLD START

NOTE

After a cold start the idling speed is higher

irrespective of the outside temperature.

Raised idling speed is part of Volvo's efficient

emissions system.

KEY & REMOTE CONTROL

Locks doors, storage compartment in

doors*, the boot lid and the ski hatch,

and arms the alarm. After 30 seconds

the doors are double-locked and cannot

be opened from inside.

Unlocks doors, storage compartment

in doors*, the boot lid, the ski hatch and

steering lock, and disarms the alarmA.

Unlocks the boot lid – it does not open.

Switches on lighting for 30 secondsB

in the side mirrors*, in the passenger

compartment, at the floor and on the

number plate. Indicators and parking

lamps illuminate.

"Panic" button. Press and hold for

approx. 3 seconds in an emergency to

trigger the alarm. Switch off the panic

alarm with one long press on the same

button or the unlock button.

AAutomatic relocking takes place if a door/boot lid

is not opened within 2 minutes after unlocking.

BThe time is adjustable to 30, 60 or 90 seconds, see

the Owner's Manual.

DIRECTION INDICATORS

A. Short sequence, three flashes.

B. Continuous flash sequence.

WARNING! Adjust the steering wheel before

setting off – never while driving.

ADJUSTINGTHE STEERING WHEEL

Lock for emergency opening of the boot lid.

LIGHT SWITCHES

Headlamp levelling. Automatic for Bi-

Xenon lights®*

Automatic dipped beam and main

beam flash. Main beam cannot be

activated.

Parking lamps

Dipped beam – Switches off when the

ignition is switched off. Main beam can

be activated.

Display and instrument lighting

Fog lamps (front*)

Fog lamp (rear, only driver's side)

Main beam flash

BMain/dipped beam switching and

Home safe lighting.

REFUELLING

Washing by hand is gentler to the paintwork

than an automatic car wash. The paintwork

is also more sensitive when it is new. For

this reason, handwashing is recommended

during the first few months with a new car.

Leather upholstery requires regular clea-

ning. Treat with leather care products,

1–4 times per year or as necessary. Leather

care products are available at your Volvo

dealer.

CAR CARE

Open the fuel filler flap, hang up the fuel

cap during refuelling.

BLIS – BLIND SPOT INFORMATION

SYSTEM*

If the BLIS’ indicator lamp illuminates despite

there being no vehicle within the blind spot,

the cause could be for example, reflection

from shiny wet road surface, own shadow on

light road surface or low sun in the camera.

In the event of a direct fault in the system the

display shows the text Blis Service Re-

quired

AUTOMATIC CAR WASHES

Remove the antenna before using an auto-

matic car wash. Turn the antenna anticlock-

wise to remove it.

WINDSCREEN WIPERS AND RAIN SENSOR*

Single sweep

0Off

Intermittent wiping. Turn (B) to adjust.

Normal speed

High speed

Windscreen and headlamp washing

AUDIO SYSTEM

ARain sensor On/Off. Position D–F

deactivates.

BAdjust sensitivity using the thumb-

wheel.

Display symbol for rain sensor On.

1On/Off and audio volume. Press for

On/Off. Turn to adjust the volume. Radio,

TP, handsfree* and RTI* volume are stored

individually.

2Radio FM1,FM2 or AM.

4Display

5MODE – CD or AUXA

6Sound pattern –Press to select Sound

pattern e.g. BASS, Dolby Pro Logic II* or

SUBWOOFER*. Turn to adjust.

9MENU – AUX, volume and advanced

audio settings. Activate/deactivate SUB-

WOOFER*.

RADIO

6Select radio station by turning.

8SCAN – automatic tuning.

Search for station using Left/Right ar-

row. Store up to 20 stations by holding

in 0–9 on FM1 and 0–9 on FM2. When a

station has been stored it is confirmed in

the display.

Autostore stations – Press AUTO for ap-

prox. 2 seconds. Autostoring is shown in

the display. The 10 strongest stations are

stored. Then press 0–9 to select a station.

CD PLAYER

3Ejecting a CD disc. One short press

ejects the current disc. One long press

ejects allB.

6Turn – change CD track.

7Direct selection CD discB– Press 1–6.

Change CD track using Left/Right arrow

or turn (6).

Select CD discBusing Up/Down arrow.

AAUX input for e.g. MP3 player (set volume at

medium for optimum audio reproduction).

BOnly CD changer*.

AUTOMATIC CONTROL

In AUTO mode the ECC system controls all

functions automatically making driving simpler

with optimum air quality.

1Automatic

Press AUTO for automatic control of set

temperature and other functions.

2Temperature

Press for individual adjustment of left L

or right-hand Rside. Turn to required

temperature. The set temperature is shown

in the display.

ELECTRONIC CLIMATE CONTROL, ECC*

WARNING

Incorrect use could endanger life. Consult

the Owner's Manual if you have the slightest

doubt about its use.

MANUAL CONTROL

Fan speed

Air distribution

Defroster to quickly remove misting

from the windscreen and side windows.

A – Air quality system* On.

M – Recirculation On.

Air conditioning On/Off. Cools the

passenger compartment and demists

the windows.

Rear window and door mirror defros-

ters. Automatic deactivationA.

ARear window 12 minutes. Mirrors 6 minutes.

PACOS*, DEACTIVATINGTHE AIRBAG

PACOS (Passenger Airbag Cut Off Switch)

Use the ignition key to switch ON/OFF.

OFF: The airbag is deactivated.

PASSENGERAIRBAGOFFis shown in the

warning lamp above the interior rearview mirror.

A child can sit on a booster cushion or child

seat in the front seat but never passengers

taller than 140 cm.

ON: The airbag is activated.

Passengers taller than 140 cm can sit in the

front seat but never a child on a booster

cushion or child seat.

FUEL

1Low fuel level

When the symbol illuminates - refuel as

soon as possible.

2Fuel gauge.

The arrow indicates that the fuel filler flap

is on the right-hand side.

TRIP METERS

3Switch between T1 & T2 with one short

press. Reset the current meter with one

long press.

5Display shows two independent trip

meters, T1 & T2.

DISPLAY

4Shows trip computer, messages, clock

and outside temperature.

TRIP COMPUTER ANDTRIP METERS

TRIP COMPUTER

6Press to clear a message.

7Turn to show e.g. KILOMETRES TO

EMPTY TANK in the display (4).

8Reset the current function. One long

press resets all functions.

IMPORTANT

"Kilometres to empty tank" is an estimate of

possible distance based on earlier driving

conditions.

CONTROL PANEL IN DRIVER'S DOOR

LRAdjusting the door mirrors, –

Select Lor R. Set with the lever.

Retracting the door mirrors*

– Press Land Rsimultaneously. Press

again to extend.

1Manual windows

2Automatic windows

All windows open simultaneously with

one press on the right-hand side of

the button. Hold down the left-hand

side to close.

WINDOW AUTOMATION

The windows are automatically opened approx.

2 cm when doors are opened/roof is operated.

The windows are closed automatically.

2,0m

0,2m

LOADING ASSISTANCE

OPERATION

OPERATING THE ROOF "TOP DOWN &TOP UP"

PREPARATIONS

No objects on parcel shelf, roof or boot lid.

2 m clearance and 0.2 m behind.

Level ground.

Outside temperature above -10 ˚C.

Closed cargo separator and boot lid.

The car must be stationary.

Pay attention that no individual is close to

the roof's moving parts during its opera-

tion.

The side windows lower several centimetres

when the roof is operated. They then return

automatically.

•

CARGO SEPARATOR

Engine at idling speed.

Depress the brake pedal.

Press and hold button (A) or (B) until a

signal sounds and the message ROOF

CLOSED/ROOF OPEN is shown in the

display.

Release the button.

The cargo separator limits the cargo area to

make space for the folding roof.

Raise the cargo separator during loading.

Lower the cargo separator fully into the

catches (3) before lowering the roof. See

decal on the cargo separator.

Raise/lower the lowered roof to facilitate

Press the button and wait several se-

conds until the roof is raised. Raise the

cargo separator, load, and then fold it

down fully.

Press the button again to lower.

ADJUSTINGTHE FRONT SEAT

STORAGE SPACES, 12 V SOCKET & AUX

12 V socket in centre console front/rear

works in ignition position Ior II.12 V socket on

right-hand side in cargo area is always active.

The car's audio system can playback music

from an MP3 player etc. using the AUX output.

6Easy entry & belt guide

Manual seat

A. Always remove the seatbelt from the belt

guide.

B. Pull the handle and move the seat forwards.

Power seat*

A. Always remove the seatbelt from the belt

guide.

B. Pull the handle and fold up the backrest.

C. Hold the button in while the seat moves

forwards.

Hold the button in again to move the seat

back.

1Lumbar support

2Backrest rake

3Raise/lower seat

4Seat cushion front edge raise/lower

5Forwards/backwards

IMPORTANT

Using the 12 V socket in the cargo area when

the engine is switched off could discharge

the battery.

Autres manuels pour C70

Table des matières

Autres manuels Volvo Automobile

Volvo

Volvo XC60 - ANNEXE 541 Manuel utilisateur

Volvo

Volvo XC40 2020 Manuel utilisateur

Volvo

Volvo 2010 XC60 Manuel utilisateur

Volvo

Volvo S80 PREMIER Guide de démarrage rapide

Volvo

Volvo 164 Manuel utilisateur

Volvo

Volvo V50 Manuel utilisateur

Volvo

Volvo 2009 V70 R-DESIGN Guide de démarrage rapide

Volvo

Volvo 2011 C70 Manuel utilisateur

Volvo

Volvo S90 2018 Manuel utilisateur

Volvo

Volvo 2009 S60 Manuel utilisateur

Volvo

Volvo XC60 2011 Guide de démarrage rapide

Volvo

Volvo C30 - ANNEXE 798 Guide de démarrage rapide

Volvo

Volvo 2011 C30 Manuel utilisateur

Volvo

Volvo S60 2018 Manuel utilisateur

Volvo

Volvo 2004 V70 Guide de démarrage rapide

Volvo

Volvo XC90 Twin Engine 2019 Manuel utilisateur

Volvo

Volvo S80 - Manuel utilisateur

Volvo

Volvo V60 Manuel utilisateur

Volvo

Volvo XC70 2013 D5 AWD Guide de démarrage rapide

Volvo

Volvo V60 2018 Manuel utilisateur

Volvo

Volvo 2016 XC 90 Twin Engine Manuel utilisateur

Volvo

Volvo S40 - ANNEXE 244 Manuel utilisateur

Volvo

Volvo V60 Manuel utilisateur

Volvo

Volvo XC60 - ANNEXE 541 Manuel utilisateur

Manuels Automobile populaires d'autres marques

Toyota

Toyota 2000 Tundra Manuel utilisateur

CITROËN

CITROËN DS4 DSign Manuel utilisateur

Lexus

Lexus 2015 CT 200h Manuel utilisateur

Cadillac

Cadillac CTS 2008 Manuel utilisateur

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuel utilisateur

Porsche

Porsche Boxster S Manuel utilisateur

GMC

GMC 2010 Savana 1500 Cargo Manuel utilisateur

KIAM

KIAM SPORTAGE 2014 Manuel de la liste des pièces

GMC

GMC 2013 Terrain Instructions de montage

GMC

GMC T-Series 1999 Manuel utilisateur

Mercury

Mercury 1998 Mystique Manuel utilisateur

Mercury

Mercury 2007 Mariner Manuel utilisateur

Mazda

Mazda 2007 Mazdaspeed 3 Mode d’emploi

Mazda

Mazda 2014 CX-5 Manuel utilisateur

GMC

GMC Chevrolet Express 2022 Manuel utilisateur

GMC

GMC 1997 Jimmy Manuel utilisateur

Chevrolet

Chevrolet 2012 Malibu Manuel utilisateur

Cadillac

Cadillac 2010 Escalade Manuel utilisateur
