Vivo MOUNT-VW11 Manuel utilisateur

TV Wall Mount and Entertainment Shelf

Scan the QR code with your mobile device or follow the link

for helpful videos and specifications related to this product.

Instruction Manual

https://vivo-us.com/products/mount-vw11

SKU: MOUNT-VW11

[email protected]om www.vivo-us.com 309-278-5303

Chat live with an agent!

GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

PACKAGE CONTENTS

TOOLS NEEDED

100lbs

(45.34kg)

DO NOT EXCEED WEIGHT CAPACITY.

Failure to do so may result in serious injury.

WARNING!

Phillips

Screwdriver

A (x1)

TV Plate

B(x2)

TV Bracket

C(x2)

Hanger

P (x2)

M6x25

Q x4)

M6 Nut

R(x1)

Bracket

U(x1)

4mm Allen

Wrench

O(x4)

12x6.5x1.5

K (x4)

18x6.5x1.5

Washer

L (x6)

Washer

M (x6)

M8x60

N (x6)

M10x50

If you do not understand these directions, or if you have any doubts about the safety of the installation,

please call a qualified technician. Check carefully to make sure there are no missing or defective parts.

Improper installation may cause damage or serious injury. Do not use this product for any purpose that is

not explicitly specified in this manual. Do not exceed weight capacity. We cannot be liable for damage or

injury caused by improper mounting, incorrect assembly or inappropriate use.

NOTE: NOT ALL HARDWARE INCLUDED WILL BE USED

W(x1)

2.5mm Allen Wrench

V (x4)

Support

Pad

Drill

CAUTION!

DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR WALL CONSTRUCTION. USE WOOD STUDS TO

MOUNT. We include mounting for brick and concrete walls. If unsure, please contact us at vivo-us.

com, email at [email protected], or call us at 309-278-5303.

D(x1)

Mounting Bracket

E(x1)

Glass Shelf

F (x1)

Shelf Support

G(x4)

M4x12

H(x4)

M5x12

I(x4)

M6x12

J(x4)

M8x16

S(x3)

M5x12

T(x2)

M6x35

WARNING: CHOKING HAZARD

SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.

ASSEMBLY STEPS

STEP 1

OPTION A: Wood Wall

Use TV plate (A) to mark mounting locations on wall for drilling. Use of a stud finder is highly

recommended. Drill 1.2” deep holes with a 3mm or 1/8” drill bit, and anchor TV mounting plate (A) to

wall using screws (M) and washers (L).

OPTION B: Concrete Ceiling

Use TV plate (A) to mark mounting locations on wall for drilling. Drill 2.4” deep holes using 10mm or

13/32” drill bit. Press anchors (N) into wall, and anchor TV mounting plate (A) to wall using screws (M)

and washers (L).

STEP 2

STEP 3

Assemble shelf support (F) and L bracket (R) to shelf mounting bracket with screws (S).

Assemble mounting bracket (D) to hangers (C) at

desired height using nuts (Q) and washers (O).

Screw plastic thumb screws (P) through front of

hangers (C) and thumb screws (T) through back

of shelf mounting bracket.

STEP 4

Slip shelf support pads (V) onto shelf support, and secure with 2.5mm Allen key (W). Rest glass shelf

(E) on shelf support with pads, and secure with screw (S). DO NOT OVERTIGHTEN, as this could

damage the glass.

STEP 5

Hang shelf assembly onto TV plate (A), and secure with previously installed thumbscrews. Turn lower

thumbscrews to adjust the angle of the shelf.

STEP 6

Assemble TV brackets (B) to TV using appropriate mounting screws (G, H, I, J) and washers (K). Ensure

that VESA brackets are positioned with slots on top and holes on bottom, and with the tilt adjustment

knobs facing away from each other.

STEP 7

Hang TV on TV plate (A) and secure with safety bolts underneath TV brackets (B).

LAST UPDATED: 03/05/2020

Open Monday - Friday 7:00am - 7:00pm CST,

our dedicated support team can oer immediate assistance with rapid response times. If any

parts are received damaged or defective, please contact us. We are happy to replace parts to

ensure you have a fully functioning product.

FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com

[email protected] AVG. RESPONSE TIME (within oice hrs): 1HR 8M

- 23% within < 15m

- 38% within < 30m

- 61% within < 1hr

- 83% within < 2hr

- 92% within < 3hr

Love your new VIVO setup and want to share?

Tag us in your photo! @vivo_us

AVG. RESOLUTION TIME (within oice hrs): < 15 M

www.vivo-us.com

Chat live with an agent!

AVG. RESOLUTION TIME (within oice hrs): 5M 4S

309-278-5303
