In order to continue serving our customers and providing the best products, our product information
including our user manuals may receive updates from time to time. Please check our website for the latest
user manuals and product materials. ver.1.0 5/20/19
GNV30CB
3
Table of Contents
Section 1: Safety Precautions.....................................................4
Section 2: Box Contents.............................................................. 5
Section 3: Product Overview.......................................................6
3.1 – Monitor Buttons...............................................................6
3.2 – Monitor Ports...................................................................6
Section 4: Stand Installation.......................................................7
Section 5: Mount Installation ...................................................... 8
Section 6: Connectivity Options................................................. 9
6.1 – Connecting Your Earphones............................................9
6.2 – DP Connectivity ..............................................................9
6.3 – Connecting the Power Cable ..........................................10
6.4 – HDMI Connectivity..........................................................10
Section 7: Basic Operation.......................................................... 11
Section 8: Indicator Light ............................................................11
Section 9: OSD.............................................................................. 12
9.1 – OSD Menu Functions......................................................13
Section 10: RGB, LED Effects and Gameplus........................... 14
Section 11: Troubleshooting........................................................ 15
Section 12: Specifications........................................................... 16
Section 13: 1 Year Limited Hardware Warranty......................... 17
4
Section 1: Safety Precautions
Read and observe the following warnings and information below.
1. Before cleaning, always unplug your monitor. It is recommended that you use
dry cloth or lightly damp cloth to clean your monitor. Dry cloth is, however,
the safest. If using damp cloth, wait for your monitor to completely dry before
plugging it in again.
2. Do not use alcohol or ammonia-based cleaner and/or liquids to clean your
monitor.
3. This monitor features ventilation openings on the back of the unit. Avoid blocking
these openings to prevent the monitor from overheating.
4. Avoid placing this monitor near any heat sources e.g: portable heaters or heating
vents, as this may cause damage to your monitor.
5. Do not spray cleaner and or any kind of liquid directly onto the monitor’s screen
or any part of the monitor.
6. Do not insert anything into any part of the monitor especially the ventilation
openings.
7. Always make sure your monitor is placed on a secure, level surface to prevent it
from falling and sustaining damage.
8. Unplug your monitor during any extended periods of non-use.
9. Do not place heavy items on the monitor or monitor cables.
10. Do not attempt to disassemble or remove parts from the monitor. Any
disassembly or modication etc. not performed by an authorized technician
can result in damage to the monitor and/or possible exposure to high voltage
electricity which may lead to serious injury or death.
VIOTEK®shall not be held responsible for injury or damage of products or persons
due to failure to adhere to the aforementioned precautions or any others noted
hereafter.
5
Section 2: Box Contents
Monitor x 1 Stand Stem x 1 Stand Base x 1
Power Adapter x 1
(DC 12V, 4.0A)
Cable Clip VESA Adapter x 1
Screws x 4
(for Stand Installation) DP Cable x 1
Screwdriver x 1 User Manual x 1
Extra screws may be included as backup.
6
Section 3: Product Overview
3.1 – Monitor Buttons
7 Audio Output: Insert one end of the audio cable into an external audio
source, e.g., speakers or headphones, to pass audio signals through the
monitor.
8 DP Connector: Insert one end of the DP cable into the computer’s DP output
and connect the other end to the monitor’s DP port.
9 HDMI Connectors: Insert one end of the HDMI cable into the computer’s
HDMI output and connect the other end to the monitor’s HDMI port.
10 Power Connector: Insert the power cable to supply power to the monitor.
7 9 10
8
2 3 4 5 61
1 M Menu Button: Press to display the OSD menu or enter sub-menus.
2 Down Button: Press to move down in the menus.
3 Up Button: Press to move up in the menus.
4 E Exit Button:Press to exit.
5 Power Button: Press to turn the monitor on/off.
6 LED Indicator: Changes colors to indicate status. Refer to Section 8.
3.2 – Monitor Ports
7
Section 4: Stand Installation
Keep the foam underneath the monitor before attaching the stand.
1. Open the package, take out the product with foam still attached, and gently place
it on a desktop or table. Next, take out the stem, cable clip, and base, use the
included screwdriver and two screws to fasten base to the stem.
Screws x 2
Stand Stem
Cable Clip
Base
2. Remove the foam covering the bottom of the monitor, and remove the rubber post
attached on stem. Use a screw to fasten the stem onto the monitor, then reinstall
the rubber post on the stem.
Rubber Post
Screw x 1
Make sure the monitor is laid on a at surface before removing the stand.
8
Section 5: Mount Installation
1. Open the package, take out the product with foam still attached, and gently
place it on a desktop or table. Remove the extra parts and the foam covering the
bottom of the monitor. If the monitor is already attached to the stand, remove it.
3. Use a screw to attach the included 75x75mm VESA adapter to the back of
monitor, then install the monitor on the wall, mount, or xture as desired.
Screw x 1
Mount
(not included)
9
Section 6: Connectivity Options
6.1 – Connecting Your Earphones
Plug in your earphones to receive audio signals from your monitor. If your earphones
are connected to the monitor and audio devices are connected to your computer
at the same time, the audio devices will not produce sound. Earphones and other
audio devices not included.
Earphones (not included)
Listening to loud audio for prolonged periods of time may permanently
damage your hearing.
6.2 – DP Connectivity
In order for the monitor to receive DP signals from the computer, use the DP cable
to connect the monitor to the computer.
DP
DP OUTPUT
DP Cable (Included)
10
6.3 – Connecting the Power Cable
Connect the included power cable to the power connector, and then plug the other
end into an wall outlet.
Power Cable
6.4 – HDMI Connectivity
In order for the monitor to receive HDMI signals from the computer, use an HDMI
cable to connect the monitor to the computer.
HDMI OUTPUT
PC
HDMI Cable (Not included)
