ViewSonic IFP62 Series Manuel utilisateur

IFP62 Series

Commercial Touch Display

User Guide

Model No. VS18622 | VS18623 | VS18624

P/N: IFP6562 | IFP7562 | IFP8662

IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in

a safe manner, as well as registering your product for future service. Warranty information contained in this User

Guide will describe your limited coverage from ViewSonic®Corporation, which is also found on our web site at

http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right

corner of our website. “Antes de operar su equipo lea cu idadosamente las instrucciones en este manual”

Thank you for choosing ViewSonic®

As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding

the world’s expectations for technological evolution, innovation, and simplicity.

At ViewSonic®, we believe that our products have the potential to make a positive

impact in the world, and we are confident that the ViewSonic® product you have

chosen will serve you well.

Once again, thank you for choosing ViewSonic®!

Safety Precauons

Please read the following Safety Precauons before you start using the device.

• Keep this user guide in a safe place for later reference.

• Read all warnings and follow all instructions.

• Do not use the device near water. To reduce the risk of fire or electric shock, do

not expose the device to moisture.

• Never remove the rear cover. This display contains high-voltage parts. You may

be seriously injured if you touch them.

• Avoid exposing the device to direct sunlight or other sources of sustained heat.

• Do not install near any heat sources such as radiators, heat registers, stoves, or

other devices (including amplifiers) that may increase the temperature of the

device to dangerous levels.

• Use a soft, dry cloth to clean the external housing. For more information, refer

to the "Maintenance" section.

• When moving the device, be careful not to drop or bump the device on

anything.

• Do not place the device on an uneven or unstable surface. The device may fall

over resulting in an injury or a malfunction.

• Do not place any heavy objects on the device or connection cables.

• If smoke, an abnormal noise, or a strange odor is present, immediately turn the

device off and call your dealer or ViewSonic®. It is dangerous to continue using

the device.

• The device is a monitor with an LED backlight intended for general office use.

• Do not attempt to circumvent the safety provisions of the polarized or

grounding-type plug. A polarized plug has two blades with one wider than the

other. A grounding-type plug has two blades and a third grounding prong. The

wide blade and the third prong are provided for your safety. If the plug does not

fit into your outlet, obtain an adapter and do not attempt to force the plug into

the outlet.

• When connecting to a power outlet, DO NOT remove the grounding

prong. Please ensure grounding prongs are NEVER REMOVED.

• Protect the power cord from being treaded upon or pinched,

particularly at the plug, and at the point where it emerges from

the equipment. Ensure that the power outlet is located near the

equipment so that it is easily accessible.

• Only use attachments/accessories specified by the manufacturer.

• When a cart is used, use with caution when moving the cart/equipment

combination to avoid injury from tipping over.

• Disconnect the power plug from the AC outlet if the device is not being used for

a long period of time.

• Place the device in a well-ventilated area. Do not place anything on the device

that prevents heat dissipation.

• Refer all servicing to qualified service personnel. Service will be

required when the unit has been damaged in any way, such as:

if the power supply cord or plug is damaged

if liquid is spilled onto or objects fall in the unit

if the unit is exposed to moisture

if the unit does not operate normally or has been dropped

Introducon

Package Contents

•HDMI cable

•Power cable(by region)

•Remote control

•AAA battery x 2

•USB cable Type C

•USB touch cable

•Passive Stylus x 2

•Quick start guide

•RS232 adapter

•Clamp x 5

•Plate

•Screw x 8

Aspect

Compliance Statement

적합성 선언

Declaration de conformite

Hinweise

Declaración de conformidad

Dichiarazione di conformita

Declaração de compatibilidade

Vyhlásenie o zhode vydané

Federálnou komisiou pre

rádiové a televízne vysielanie

Izjava o skladnosti

Prohlášení o souladu se

Izjava o sukladnosti

IFP62 Series

VS18697

ViewBoard series

Aspect

Compliance Statement

적합성 선언

Declarationde conformite

Hinweise

Declaraciónde conformidad

Dichiarazionedi conformita

Declaraçãode compatibilidade

Vyhlásenieo zhode vydané

Federálnoukomisiou pre

rádiovéa televízne vysielanie

Izjavao skladnosti

Prohlášenío souladu se

Izjavao sukladnosti

IFP9850-4

VS18697

CommercialTouch Display

QuickStart Guide

Aspect

IFP9850-4

VS18697

CommercialTouchDisplay

QuickStartGuide

PackageContents

Aspect

IFP6532/IFP7VS18471/VS1CommercialTQuickStartG

PackageCon

ComplianceStatement

적합성 선언

Declarationdeconformite

Hinweise

Declaracióndeconformidad

Dichiarazionediconformita

Declaraçãodecompatibilidade

Vyhlásenieozhodevydané

Federálnoukomisioupre

rádiovéatelevíznevysielanie

Izjavaoskladnosti

Prohlášeníosouladuse

Izjavaosukladnosti

NOTE: The power cord and video cables included in your package may vary

depending on your country. Please contact your local reseller for more

informaon.

Wall Mount Kit Specicaons (VESA)

NOTE: Please follow the instrucons in the wall mount installaon guide to

install your wall mount or mobile mount bracket. If aaching to other

building materials, please contact your nearest dealer.

Model VESA Spec. (A x B) Standard Screw (C x D) Quanty

IFP6562 - 65” 600 x 400 mm M8 x 25 mm 4

IFP7562 - 75” 800 x 400 mm M8 x 25 mm 4

IFP8662 - 86” 800 x 600 mm M8 x 25 mm 4

NOTE: Do not use screws that are longer than the standard dimension, as they

may cause damage to the inside of the display.

Product Overview

Control Panel

Number Item /

Port

Descripon

• Power indicator light

• Press the key to turn on the device

• Press the key to turn off/on the display backlight only

• Press and hold to turn off the device

2Remote control receiver

3Ambient Light Sensor to monitor the ambient light

4USB Type-C input; connect to PC with USB Type-C

output.

High definition input; connect to PC with HDMI

output, set-top box, or other video device.

HDMI IN does not support HDMI CEC.

6Touch signal output to external PC

Connect USB devices such as hard disks, keyboard,

mouse, etc. Automatically switches between PC and

external PC.

USB

Type-C

HDMI IN

TOUCH

USB 2.0

I/O Panel

Number Port Descripon

1HDMI OUT Extend content out to another display device

2USB 3.0 Connect USB devices such as hard disks, keyboard,

mouse, etc. Automatically switches between PC and

external PC.

3HDMI 1/2/3

High definition input; connect to PC with HDMI

output, set-top box, or other video device.

HDMI 1/2/3: supports HDMI CEC (One Touch Play,

System Standby, partial Remote Control Pass

Through)

4TOUCH

5USB 2.0

Touch signal output to external PC

For ViewBoard firmware upgrade

External computer audio input

VGA External computer image input

AUDIO OUT Audio out to an external speaker

SPDIF SPDIF output

RS232 Serial interface; used for mutual transfer of data

between devices

LAN

Standard RJ45 (10M/100M/1G) Internet

connection interface.

Used for the ViewBoard and Slot-in PC

AUDIO IN

Remote Control

Inserng Remote Control Baeries

To insert baeries into the remote control:

1. Remove the cover on the rear of the remote control.

2. Insert two “AAA” baeries, ensuring the “+” symbol on the baery matches the

“+” on the baery post.

3. Replace the cover by aligning it with the slot on the remote control and snapping

the latch shut.

WARNING: There is a risk of explosion if baeries are replaced with the incorrect

type.

NOTE:

•It is recommended that you do not mix battery types.

•Always dispose of old batteries in an environmentally friendly way. Contact

your local government for more information on how to dispose of batteries

safely.
