Viessmann Vitorond 100 Mode d'emploi
Service instructions
for contractors
VIESMANN
Vitorond 100
Type VR2B, 40 to 100 kW
Oil/gas boiler
For applicability, see the last page
VITOROND 100
5692 659 GB 2/2013 Please keep safe.
2
Please follow these safety instructions closely to prevent accidents and mate-
rial losses.
Safety instructions explained
Danger
This symbol warns against the
risk of injury.
!Please note
This symbol warns against the
risk of material losses and envi-
ronmental pollution.
Note
Details identified by the word "Note" con-
tain additional information.
Target group
These instructions are exclusively inten-
ded for qualified contractors.
■ Work on gas installations must only be
carried out by a registered gas fitter.
■ Work on electrical equipment must
only be carried out by a qualified elec-
trician.
■ The system must be commissioned by
the system installer or a qualified per-
son authorised by the installer.
Regulations
Observe the following when working on
this system:
■ Statutory regulations regarding the
prevention of accidents
■ Statutory regulations regarding envi-
ronmental protection
■ Codes of practice of the relevant trade
associations
■ All current safety regulations as
defined by DIN, EN, DVGW, TRGI,
TRF, VDE and all locally applicable
standards
aÖNORM, EN, ÖVGW-TR Gas,
ÖVGW-TRF and ÖVE
cSEV, SUVA, SVGW, SVTI,
SWKI, VKF and EKAS guideline
1942: LPG, part 2
If you smell gas
Danger
Escaping gas can lead to explo-
sions which may result in serious
injury.
■ Do not smoke. Prevent naked
flames and sparks. Do not
switch lights or electrical appli-
ances on or off.
■ Close the gas shut-off valve.
■ Open windows and doors.
■ Evacuate any people from the
danger zone.
■ Notify your gas or electricity
supply utility from outside the
building.
■ Shut off the electricity supply to
the building from a safe place
(outside the building).
Safety instructions
Safety instructions
5692 659 GB
3
If you smell flue gas
Danger
Flue gas can lead to life-threat-
ening poisoning.
■ Shut down the heating system.
■ Ventilate the installation site.
■ Close all doors in the living
space.
Flue systems and combustion air
Ensure that flue systems are clear and
cannot be sealed, for instance due to
accumulation of condensate or other
causes. Ensure a sufficient supply of
combustion air.
Instruct system users that subsequent
modifications to the building characteris-
tics are not permissible (e.g. cable/pipe-
work routing, cladding or partitions).
Danger
Life-threatening poisoning
caused by carbon monoxide in
the flue gas occurs as a result of
leaking or blocked flue systems
or an insufficient supply of com-
bustion air.
Ensure the flue system is in
proper working order. It must not
be possible to close apertures for
interconnected combustion air
supply.
Extractors
Operating appliances that extract air to
the outside (cooker hoods, extractors, air
conditioning units, etc.) can create neg-
ative pressure. If the boiler is operated at
the same time, this can lead to reverse
flow of the flue gas.
Danger
The simultaneous operation of
the boiler and appliances that
extract air to the outside can
result in life threatening poison-
ing due to reverse flow of the flue
gas.
Fit an interlock circuit or take suit-
able steps to ensure a sufficient
supply of combustion air.
Working on the system
■ Where gas is used as the fuel, close
the main gas shut-off valve and safe-
guard it against unintentional reopen-
ing.
■ Isolate the system from the power sup-
ply (e.g. by removing the separate fuse
or by means of a mains isolator) and
check that it is no longer 'live'.
■ Safeguard the system against recon-
nection.
!Please note
Electronic assemblies can be
damaged by electrostatic dis-
charge.
Prior to commencing any work,
touch earthed objects, such as
heating or water pipes to dis-
charge static loads.
Repair work
!Please note
Repairing components that fulfil a
safety function can compromise
the safe operation of your sys-
tem.
Defective components must be
replaced with genuine
Viessmann spare parts.
Safety instructions
Safety instructions (cont.)
5692 659 GB
4
Auxiliary components, spare and
wearing parts
!Please note
Spare and wearing parts that
have not been tested together
with the system can compromise
its function. Installing non-author-
ised components and making
non-approved modifications or
conversions can compromise
safety and may invalidate our
warranty.
For replacements, use only orig-
inal spare parts supplied or
approved by Viessmann.
Safety instructions
Safety instructions (cont.)
5692 659 GB
5
Product information
Intended use......................................................................................................... 6
Commissioning, inspection, maintenance
Steps - commissioning, inspection and maintenance.......................................... 7
Further details regarding the individual steps....................................................... 8
Parts lists............................................................................................................ 16
Commissioning/service reports........................................................................ 19
Specification....................................................................................................... 20
Certificates
Declaration of conformity...................................................................................... 21
Manufacturer's certificate according to the 1st BImSchV [Germany]................... 22
Keyword index.................................................................................................... 23
Index
Index
5692 659 GB
6
The appliance is only intended to be
installed and operated in sealed unven-
ted heating systems that comply with
EN 12828, with due attention paid to the
associated installation, service and
operating instructions. It is only designed
for the heating of water that is of potable
water quality.
Intended usage presupposes that a fixed
installation in conjunction with permissi-
ble, system-specific components has
been carried out.
Commercial or industrial usage for a pur-
pose other than heating the building or
DHW does not comply with regulations.
Any usage beyond this must be
approved by the manufacturer for the
individual case.
Incorrect usage or operation of the appli-
ance (e.g. the appliance being opened
by the system user) is prohibited and
results in an exclusion of liability. Incor-
rect usage also occurs if the components
in the heating system are modified from
their intended function (e.g. if the flue
gas and ventilation air paths are
sealed).
Product information
Intended use
5692 659 GB
7
For further information regarding the individual steps, see the page indicated
Commissioning steps
Inspection steps
Maintenance steps Page
•1. Filling the system........................................................... 8
••• 2. Commissioning the system........................................... 9
• • 3. Shutting down the system
• • 4. Closing the Vitoair draught stabiliser (if installed)...... 10
•5. Opening the boiler door, extracting and cleaning the
turbulators....................................................................... 10
•6. Cleaning the heating surface, flue outlet and flue....... 12
• • 7. Checking all gaskets and packing cords on the flue
gas side
• • 8. Checking gaskets and thermal insulation sections.... 12
•9. Inserting the turbulators and fitting the boiler door.... 12
• • 10. Checking the firm seating of electrical plug-in
connections and cable grommets
• • 11. Checking the thermal insulation
••• 12. Checking connections on the heating water and DHW
side and the sensor well for leaks
••• 13. Checking the function of the safety equipment
••• 14. Checking the expansion vessel and system pressure 13
• • 15. Checking the mixer for ease of operation and
tightness.......................................................................... 14
••• 16. Checking the Vitoair draught stabiliser (if installed)... 14
• • 17. Adjusting the burner...................................................... 14
•18. Operating and service documents................................ 15
Commissioning, inspection, maintenance
Steps - commissioning, inspection and maintenance
5692 659 GB
8
Filling the system
Fill water
!Please note
Unsuitable fill water increases
the level of deposits and corro-
sion and may lead to boiler dam-
age.
■ Flush the heating system thor-
oughly before filling.
■ Only use fill water of potable
quality.
■ An antifreeze additive suitable
for heating systems can be
added to the fill water. The anti-
freeze manufacturer must ver-
ify its suitability.
■ Fill and top-up water with a
water hardness in excess of
the following values must be
softened, e.g. with a small soft-
ening system for heating water.
Total permissible hardness of the fill and top-up water
Total heating
output
Specific system volume (Conversion rate 1 mol/m3 = 100
ppm)
kW < 20 l/kW ≥ 20 l/kW to
< 50 l/kW
≥ 50 l/kW
≤ 50 ≤ 3.0 mol/m3 ≤ 2.0 mol/m3 < 0.02 mol/m3
> 50 to ≤ 200 ≤ 2.0 mol/m3 ≤ 1.5 mol/m3 < 0.02 mol/m3
> 200 to ≤ 600 ≤ 1.5 mol/m3 ≤ 0.02 mol/m3 < 0.02 mol/m3
> 600 < 0.02 mol/m3 < 0.02 mol/m3 < 0.02 mol/m3
Commissioning, inspection, maintenance
Further details regarding the individual steps
5692 659 GB
9
1. Check the pre-charge pressure of the
expansion vessel.
If the pre-charge pressure is lower
than the static system pressure, top
up with nitrogen until the pre-charge
pressure is 0.1 to 0.2 bar (10 to
20 kPa) higher.
2. Close the oil or gas shut-off valves.
3. Open the check valve.
4. Top up the heating system with water
and vent until the charge pressure is
0.1 to 0.2 bar (10 to 20 kPa) higher
than the pre-charge pressure of the
expansion vessel.
Permiss. operating pressure: 3 bar
(0.3 MPa)
Test pressure: 4 bar (0.4 MPa)
5. Mark the charge pressure at pressure
gauge A.
6. Return the check valves to their oper-
ating position.
Commissioning the system
Operating and service instruc-
tions for the control unit and the
burner
1. Check that the installation room vent
is open.
2. Open the oil or gas shut-off valves.
Commissioning, inspection, maintenance
Further details regarding the individual steps (cont.)
5692 659 GB
10
Closing the Vitoair draught stabiliser (if installed)
1. Press rotary selector A on the
Vitoair motor and turn to position 5.
2. Lock the control disc with latch B.
Opening the boiler door, extracting and cleaning the turbulators
Note
Remove the gas supply pipe on gas
burners.
Commissioning, inspection, maintenance
Further details regarding the individual steps (cont.)
5692 659 GB
Autres manuels pour Vitorond 100
10
Table des matières
Autres manuels Viessmann Chaudière
Viessmann
Viessmann Vitocrossal 200 CM2 Series Manuel utilisateur
Viessmann
Viessmann VITOCROSSAL 300 Manuel utilisateur
Viessmann
Viessmann Vitocrossal CRU Series Manuel utilisateur
Viessmann
Viessmann VITOCROSSAL 200 Manuel d'instructions
Viessmann
Viessmann VITORADIAL 300-T Manuel utilisateur
Viessmann
Viessmann VITOCELL 100-V Manuel utilisateur
Viessmann
Viessmann EVO-COOL Series Manuel utilisateur
Viessmann
Viessmann VITODENS 050-W Guide rapide
Viessmann
Viessmann Vitodens 100-W Manuel utilisateur
Viessmann
Viessmann Vitodens 100-W Manuel d'instructions
Viessmann
Viessmann VITOCELL 100-U Mode d'emploi
Viessmann
Viessmann Vitoplex 100-LS SXD Manuel utilisateur
Viessmann
Viessmann Vitogas 050 ECD Series Supplément
Viessmann
Viessmann VITOCELL 100-V Guide rapide
Viessmann
Viessmann Vitorond 200 Series Manuel utilisateur
Viessmann
Viessmann Vitocrossal 300 CU3A Guide de l'utilisateur
Viessmann
Viessmann Vitorondens 200-T Series Manuel utilisateur
Viessmann
Viessmann VITOCROSSAL 300 Mode d'emploi
Viessmann
Viessmann Vitodens 200-W System Manuel utilisateur
Viessmann
Viessmann Vitodens 200-W System Mode d'emploi
Manuels Chaudière populaires d'autres marques
Vaillant
Vaillant uniSTOR VIH SW GB 500 BES Manuel utilisateur
Radijator
Radijator BIO max 23.1 Manuel utilisateur
Brunner
Brunner BSV 20 Manuel utilisateur
Buderus
Buderus Logamax GB062-24 KDE H V2 Manuel utilisateur
Potterton
Potterton 50e Fiche technique
UTICA BOILERS
UTICA BOILERS TriFire Manuel utilisateur
