Viessmann Vitocell 340-M Mode d'emploi

Service instructions

for contractors

VIESMANN

Vitocell 340-M/360-M

Type SVKA

Type SVSA

Combi cylinder

750 and 950 litre capacity

For applicability, see the last page

VITOCELL 340-M/360-M

5608 688 UAE 1/2012 Please keep safe.

Please follow these safety instructions closely to prevent accidents and mate-

rial losses.

Safety instructions explained

Danger

This symbol warns against the

risk of injury.

!Please note

This symbol warns against the

risk of material losses and envi-

ronmental pollution.

Note

Details identified by the word "Note" con-

tain additional information.

Target group

These instructions are exclusively inten-

ded for qualified contractors.

■ Work on electrical equipment must

only be carried out by a qualified elec-

trician.

■ The system must be commissioned by

the system installer or a qualified per-

son authorised by the installer.

Regulations

Observe the following when working on

this system:

■ National installation requirements

■ Legal instructions regarding the pre-

vention of accidents

■ Legal instructions regarding environ-

mental protection

■ The Code of Practice of relevant trade

associations

■ All current safety regulations as

defined by DIN, EN, DVGW, VDE and

all locally applicable standards

aÖNORM, EN and ÖVE

cSEV, SUVA, SVTI and SWKI

Working on the system

■ Isolate the system from the power sup-

ply (e.g. by removing the separate fuse

or by means of a mains isolator) and

check that it is no longer 'live'.

■ Safeguard the system against unau-

thorised reconnection.

!Please note

Electronic assemblies can be

damaged by electrostatic dis-

charge.

Before beginning work, touch

earthed objects, such as heating

or water pipes, to discharge static

loads.

Repair work

!Please note

Repairing components that fulfil a

safety function can compromise

the safe operation of your sys-

tem.

Replace faulty components only

with original Viessmann spare

parts.

Safety instructions

5608 688 UAE

Auxiliary components, spare and

wearing parts

!Please note

Spare and wearing parts that

have not been tested together

with the system can compromise

its function. Installing non-author-

ised components and making

non-approved modifications or

conversions can compromise

safety and may invalidate our

warranty.

For replacements, use only orig-

inal spare parts supplied or

approved by Viessmann.

Safety instructions

Safety instructions (cont.)

5608 688 UAE

Commissioning, inspection, maintenance

Steps - commissioning, inspection and maintenance.......................................... 5

Further details regarding the individual steps....................................................... 6

Parts lists

Ordering parts...................................................................................................... 8

Overview of the assemblies................................................................................. 8

Cylinder assembly................................................................................................ 9

Thermal insulation assembly................................................................................ 10

Commissioning/service reports........................................................................ 11

Product characteristics..................................................................................... 12

Accessories

Specification for immersion heater....................................................................... 13

Certificates

Declaration of conformity...................................................................................... 14

Index

5608 688 UAE

For further information regarding the individual steps, see the page indicated

Commissioning steps

Inspection steps

Maintenance steps Page

•1. Filling the DHW cylinder.................................................. 6

• • 2. Inspection and maintenance........................................... 6

• • 3. Shutting down the system

• • 4. Cleaning the inside of the DHW cylinder........................ 7

• • 5. Checking connections on the water side for tightness

•6. Instructing the system user............................................. 7

Commissioning, inspection, maintenance

Steps - commissioning, inspection and maintenance

5608 688 UAE

Filling the DHW cylinder

1. Fill the DHW cylinder from the DHW

side.

Note

Initially fill the cylinder from the DHW

side, then from the heating water

side. If the DHW side of your cylinder

cannot be filled yet, but you want to

commission your heating system,

then you can operate your cylinder

with a pressure of 2.5 bar on the heat-

ing water side.

Operation without DHW heating:

Operating instructions for the

heating system

Note

The ventilation of the solar coils

occurs via the solar flow. Collect

excess solar medium with a flexible

hose above the air vent plug and

restart the system.

Alternatively:

Service instructions for the

solar thermal system

2. Check the fittings on the heating

water and DHW sides for leaks and

retighten if required.

3. Check the function of the safety

valves according to manufacturer's

instructions.

Inspection and maintenance

DIN 1988 requires a visual inspection

and (if required) cleaning no later than

two years after the cylinder has been

commissioned and thereafter according

to requirements.

Commissioning, inspection, maintenance

Further details regarding the individual steps

5608 688 UAE

Cleaning the inside of the DHW cylinder

1. Drain the cylinder from the DHW

side.

2. Disconnect the cylinder from the

pipework to prevent cleaning agents

and contaminants entering the pipe-

work.

3. You can also carry out cleaning on

the DHW side with a chemical clean-

ing agent.

!Please note

Never use cleaning agents

containing hydrochloric acid,

to prevent material losses.

Danger

Cleaning agent residues can

lead to poisoning.

Always observe the details

provided by the manufacturer

of the cleaning agent.

4. Fully drain any cleaning agent.

5. Thoroughly flush the indirect coil on

the DHW side after cleaning.

6. Reconnect the cylinder to the pipe-

work.

7. Fill the cylinder on the DHW side.

Instructing the system user

The installer should instruct the user in

the operation of the system.

Commissioning, inspection, maintenance

Further details regarding the individual steps (cont.)

5608 688 UAE

The following information is required:

■Serial No. (see Vitocell A type plate)

■ Assembly (from this parts list)

■ Position number of the individual part

within the assembly (from this parts

list)

Standard parts are available from your

local supplier.

Overview of the assemblies

AType plate

BCylinder assembly

CThermal insulation assembly

Parts lists

Ordering parts

5608 688 UAE

0001 Adjustable foot

0002 Sensor retainer

0003 Vitocell type plate

0004 Drain R ½

0005 Plug

0006 Elbow G1 - R ½

0007 Clamping bracket

0008 Air vent hose

0009 Service instructions

0010 Installation instructions

0006

0008

0004

0007

0010

0009

0005

0007

0002

0001

0003

Parts lists

Cylinder assembly

5608 688 UAE

0001 Clip closure (6 pce)

0002 Thermal insulation jacket, right

0003 Thermal insulation jacket, left

0004 Upper thermal insulation mat

0005 Lower thermal insulation mat

0006 Cover

0007 Cover strip

0008 Thermometer cover

0009 Thermometer 30 - 120 °C

0010 Viessmann logo

0011 Cover strip

0012 Pipe collar (3 pce) Sensor well

0013 Pipe collar (2 pce) Solar coil

0013

0010

0004

0011

0005

0002

0003

0001

0008

0009

0012

0007

0006

0010

0012

0006

Parts lists

Thermal insulation assembly

5608 688 UAE
