Viessmann VITOGAS 100 Manuel d'instructions

S 1

Cast iron hot water heating boiler

300 to 380 MBH/88 to 111 kW

Vitogas 100

GS10 Series – commercial, assembled cast iron block

with separate enclosure panels

Natural Gas-/Propane-Fired, wo-Stage Boiler

cast iron sectional construction

with atmospheric, fully premi burner

Heating input: 300 to 380 MBH

88 to 111 kW

Technical Data Manual

Model Nos. and pricing: see Price List

5167 466 v1.3 02/2011

Product Information

2VITOGAS 100, GS10

S 1

With a rated input of 300 to 380 MBH/

88 to 111 kW, the Vitogas 100 makes a

grand entry into the heating technology

industry.

The new Vitotronic control generation,

minimum noise levels and economical

operation, make the Vitogas 100, GS10 the

choice for single- as well as multiple-boiler

applications.

he benefits at a glance:

HHigh operational reliability and a long

service life due to special high-grade gray

cast iron with lamellar graphite and a low

thermal load on the heat e changer

surface.

HClean combustion due to atmospheric

premi burner with super-stoichiometric

premi ing: NO < 27.9 ppm (air-free),

CO < 9.2 ppm (air-free). The Vitogas 100

therefore satisfies the requirements of the

German environmental emblem “Blue

Angel”, Swiss Clean Air Regulations and

California Regulations.

HEconomical and environmentally friendly

operation via modulating boiler water

temperatures.

Combustion efficiency of up to 85.6%.

HEven during partial-load operation, the entire

combustion chamber is used allowing for

balanced usage of burner and boiler.

HIntermittent pilot ignition system provides

soft, quiet and extremely reliable ignition.

Heat exchanger surfaces of special

high-grade gray cast iron for high

operational reliability and a long

service life

Product Information

Cross-Section

Product may not be e actly as illustrated.

VITOGAS 100, GS10 3

Extremely effective insulation

Heat exchanger surface Vitotronic 300 –

of high-grade gray cast iron the new control generation:

with lamellar graphite Intelligent, easy to install, operate

and service

Stainless steel

atmospheric premix

burners for low emission

combustion

Technical Data

4VITOGAS 100, GS10

echnical Data

Boiler Model Model No. GS10-72 GS10-84 GS10-96

CSA input full load

partial load

MBH

300

210

340

100

238

380

111

266

CSA output full load

partial load

MBH

257

180

291

204

325

228

Net I=B=R rating*1 MBH

224

253

283

Heat exchanger surface area ft.2

6.23

7.25

8.26

Max. operating pressure psig

bar

Min. gas supply pressure

Natural Gas

Liquid Propane

”w.c.

Max. gas supply pressure*2 ”w.c. 14 14 14

Combustion efficiency % 85.6 85.6 85.6

Dimensions boiler shell

Length boiler shell*3

as delivered

Overall length

Overall width

Overall height

– with Vitotronic 100,

200 or 300

inches

912

1007

1010

1088

1227

912

1007

1120

1088

1227

912

1057

1220

1088

1227

Dimensions of cast iron

sections

Side section W × H × T*4

Mid section W× H × T

inches

22 29 4.7

557 × 734 ×120

22 23 4.1

557 × 585 ×105

Number of cast iron sections 7 8 9

Number of burner tubes 6 7 8

Weight boiler shell lbs

(as delivered incl. burner) kg

Overall weight lbs

(boiler with insul., burner, kg

boiler control, install. fittings and draft hood)

714

324

927

420

805

365

1036

470

895

406

1194

542

Boiler water content USG

ltr

9.9

37.6

11.4

43.0

12.8

48.3

Boiler connections

Boiler supply and return

Safety supply

Drain valve

Ø” (NPTM) 2

Ø” (straight male thread) 1½

Ø” (NPTM) 1

1½

*1Net I=B=R rating based on piping and pick-up allowance of 1.15.

*2If t e gas supply pressure is ig er t an t e maximum permissible value, a separate gas regulator must be installed upstream of t e

boiler system.

*3In case of difficulties w en transporting or installing, boiler supply and return pipes can be removed temporarily, reducing t e lengt of

t e boiler s ell to 27.5 inc es/700 mm.

*4W=widt , H= eig t, T=t ickness

Technical Data

VITOGAS 100, GS10 5

echnical Data (continued)

Safety header pressure relief

valve connection

Ø” (NPTF) ¾ ¾ ¾

Gas supply connection Ø” (NPTM) ¾ ¾ ¾

Flue gas (NG)*5

Temperature (at boiler water

supply temp. of 180 ºF/82 ºC)

– at rated full load

– at rated partial load

Mass flow rates

– full load

– partial load

ºF

ºC

ºF

ºC

lbs/h

237

114

195

375

328

226

108

196

411

364

231

111

201

498

430

Vent pipe collar nominal ∅inches 8 9 10

Combustion and dilution air (appro . CFM) 100 115 125

Standby losses %

at boiler water temperature of 140 ºF/60 ºC

0.72 0.69 0.67

*5Measured flue gas temperature after dilution air wit combustion air temperature of 68 °F/20 °C.

Partial load values are based on an input of 70% of t e rated full load input.

"For information regarding ot er Viessmann System Tec nology componentry, please reference documentation of respective product.

Technical Data

Legend

BD Boiler Drain

BR Boiler Return

BS Boiler Supply

DH Draft Hood

GC Gas Connection

SS Safety Supply

6.53”/166 mm

30”/767 mm

41”/104.2 mm

Overall height

Overall width 30”/770 mm

57”/1442 mm

Height with flue gas pipe elbow

37.6”/957 mm

Overall length

Flue gas pipe elbow

6.5”/165 mm

18.2”/462 mm

29”/749 mm

12.4”/316 mm

VITOGAS 100

VIEßMANN

48”/1220 mm

2.9”/74 mm

11.3”/282 mm

6VITOGAS 100, GS10

Dimensions

Boiler shell (delivered as cast iron block)

*1For ease of transportation and/or installation,

boiler supply and return pipes can be

removed temporarily, reducing t e lengt of

t e boiler s ell to 27.5 inc es/700 mm.

Dimensions

Boiler Model Model No. GS10-72 GS10-84 GS10-96

a inches/mm 37/950 42/1060 46/1160

Hot water heating boiler with insulation and boiler control

Dimensions

Boiler Model Model No. GS10-72 GS10-84 GS10-96

inches/mm

19/484

21/526

21/542

23/578

23/589

25/631

*2Control in operating position

*3Control in service position

27.5”/700 mm

32.4”/823 mm

36”/912 mm

Technical Data

VITOGAS 100, GS10 7

Recommended Minimum Service Clearances Minimum Clearances to Combustibles

Top

panel

Front

panel

Rear

panel

Left

panel

Right

panel

Floor Flue

6 6 AL,

600

Combustible

2” CT

0” CI

AL = Alcove

CL = Closet

CT = Single-wall stainless steel vent

CI = Double-wall insulated stainless steel vent

Diagram is not to scale.

Waterside Flow (primary circuit)

The Vitogas 100 is designed only for closed loop, forced circulation

hot water heating systems.

ypical flow rates

Model GS10- 72 84 96

Btu/h output 257 000 291 000 325 000

20 ºF rise (GPM) 25.7 29.1 32.5

30 ºF rise (GPM) 17.1 19.4 21.7

Use standard friction loss met od for pipe sizing.

min.

9.8”/250 mm

min.

9.8”/250 mm

min. 33.5”/850 mm

min 18”/

450 mm

top min.

24”/ 600 mm

Water flow

200

Pressure drop

100

1000

2000

3000

4000

5000

6000

8000

10000

20000

4.4

0.4

0.8

1.2

1.6

2.0

2.4

3.2

ltr/h

GPM

“ w.c.

mbar

Standard and Optional Equipment/

Boiler Control Alternatives

8VITOGAS 100, GS10

Standard Equipment Optional Equipment

Note:

Boiler controls and burners are purc ased

separately. Please see Price List for details.

Vitogas 100, GS10 boilers are shipped

unassembled with the boiler enclosure

panels, insulation, draft hood, and control

packaged separately from the sectional cast

iron block.

Standard shipment is composed of:

1 skid with cast iron block and prewired

gas train

1 carton with draft hood and vent pipe

adaptor

1 carton with insulation blankets and panels

1 carton with safety header

1 carton with boiler installation fittings

(c/w 30 psig pressure relief valve)

1 carton containing either a stainless steel

vent damper or a Tjernlund power venter

(please specify at time of order).

Boiler Control Alternatives

Vitotronic 100, KK10

standard boiler control for high temperature

heating systems

Vitotronic 100, KW10

standard boiler control for high temperature

heating systems with indoor/outdoor system

control

Vitotronic 100, KW10A / KW10B

standard boiler control for high temperature

heating systems with indoor/outdoor system

control

With or without DHW

Vitotronic 200, KW2

for multiple temperature heating systems

with or without a mi ing valve,

with indoor/outdoor digital boiler and

heating system control

Vitotronic 300, KW3

for multiple temperature heating systems

with up to two mi ing valves,

with indoor/outdoor digital boiler and

heating system control

For multiple-boiler installations:

Multimatik

for multiple-boiler installations. The

Multimatik digital heating system control

acts as the master control and

communicates digitally with the base

control on each Vitogas 100, GS10 boiler.

The Multimatik can control up to 6

single-stage boilers or 3 two-stage boilers.

A wide range of sophisticated standard and

optional features makes the Multimatik a

suitable solution for almost any demanding

application. For assistance in selecting the

appropriate Multimatik control, please

contact your regional Viessmann Sales

Representative.

Custom control panels

In addition, custom control panels for

residential or commercial applications are

designed and manufactured by Viessmann

to suit any customer’s specific

requirements. Both Multimatik and custom

control panels can have features such as

pool heating, hot tub heating, snow melting,

telephone tie-in and/or several other

functions. Please inquire.

Installation E amples

VITOGAS 100, GS10 9

Installation Examples

hese examples depict possible piping

layouts for Viessmann product equipped

with Viessmann System echnology. For

boiler and tank combinations, please install

only the feasible combinations listed in the

Price List.

hese are simplified conceptual drawings

only!

Piping and necessary componentry must be

field verified.

Proper installation and functionality in the

field is the responsibility of the heating

contractor.

Single-stage operation can only occur when

the boiler water temperature is above the

minimum temperature and a demand for

heat is present. When the water

temperature is above the minimum, the

boiler control will determine full input

operation or partial load operation based on

the demand for heat. Refer to boiler control

instructions.

Install LWCO where required by local codes.

IMPOR AN

Vitotronic boiler controls are factory

set for single-stage operation. he

Vitogas 100, GS10 boiler control must

be programmed on-site for two-stage

operation.

Without mixing valve

e.g. with Vitotronic 100

The installation of a flow check valve in the

heating supply pipe prevents uncontrolled

heat flow to the heating system by gravity

during priority switching of domestic hot

water heating or during summer operation.

Heating circuit

Spring-loaded flow check valve

Circulation pump

Safety header

with automatic air vent,

pressure relief valve, and

pressure gage

E pansion tank

Domestic hot water storage tank

(indirect-fired)

DHW pump module

Bypass pipe (highly recommended)

c/w two regulating valves (V1, V2).

See Installation Instructions for

details.

IMPOR AN

Installation E amples

10 VITOGAS 100, GS10

Installation Examples (continued)

With 4-way mixing valve for heating circuit control

e.g. with Vitotronic 200, KW2 and mi ing valve actuator accessory kit

Heating circuit

Spring-loaded flow check valve

Circuit pump

Safety header with air vent, pressure

relief valve and pressure gage

E pansion tank

Vitocell-V or -H DHW storage tank

(indirect-fired)

Drain valve

4-Way mi ing valve

Bypass pipe with flow regulating valve,

for systems with large water content

(>1 USG/13 000 Btu/h / 15 ltr/kW/h of

boiler input).

See Installation Instructions for details.

Underfloor heating with system isolation

Underfloor heating circuit

Spring-loaded flow check valve

Circuit pump for underfloor heating

Safety header with air vent, pressure

relief valve and pressure gage

E pansion tank

3-Way mi ing valve

Circuit pump for heat e changer

Heat e changer

Supply temperature sensor

Drain valve

Autres manuels pour VITOGAS 100

Ce manuel convient aux modèles suivants

Autres manuels Viessmann Chaudière

Viessmann

Viessmann VITOLIGNO 200-S Guide de démarrage rapide

Viessmann

Viessmann Vitocrossal 100 Manuel utilisateur

Viessmann

Viessmann VITODENS 200 Mode d'emploi

Viessmann

Viessmann Vitodens 100-W Guide rapide

Viessmann

Viessmann Vitodens 100-W Manuel d'instructions

Viessmann

Viessmann VITOCROSSAL 300 Mode d'emploi

Viessmann

Viessmann Vitodens 222-F Manuel d'instructions

Viessmann

Viessmann VITOMAX 200-HW Manuel de formation

Viessmann

Viessmann Vitocrossal 300 CU3A 35 Manuel utilisateur

Viessmann

Viessmann Vitocrossal 200 CM2 246 Manuel utilisateur

Viessmann

Viessmann Vitocrossal Manuel utilisateur

Viessmann

Viessmann VITOCELL 100-U Mode d'emploi

Viessmann

Viessmann Vitodens 200-W WB2B Series Manuel utilisateur

Viessmann

Viessmann Vitodens 100-W Guide rapide

Viessmann

Viessmann Vitodens 300 Manuel utilisateur

Viessmann

Viessmann Vitodens 100-W WB1B Series Manuel utilisateur

Viessmann

Viessmann Vitodens 300 Mode d'emploi

Viessmann

Viessmann VITOCROSSAL 200 Manuel utilisateur

Viessmann

Viessmann VITOCROSSAL 300 Mode d'emploi

Viessmann

Viessmann Vitodens 100-W Manuel utilisateur

Viessmann

Viessmann VITODENS 200 Mode d'emploi

Viessmann

Viessmann VITODENS 100-W P25 Manuel utilisateur

Viessmann

Viessmann Vitorond 200 Type VR2 Mode d'emploi

Viessmann

Viessmann Vitodens 200-W B2HA series Guide de l'utilisateur

Manuels Chaudière populaires d'autres marques

Vaillant

Vaillant uniSTOR VIH SW GB 500 BES Manuel utilisateur

Radijator

Radijator BIO max 23.1 Manuel utilisateur

Brunner

Brunner BSV 20 Manuel utilisateur

Buderus

Buderus Logamax GB062-24 KDE H V2 Manuel utilisateur

Potterton

Potterton 50e Fiche technique

UTICA BOILERS

UTICA BOILERS TriFire Manuel utilisateur

Joannes

Joannes LADY Series Manuel

ECR International

ECR International UB90-125 Manuel d'instructions

Froling

Froling FHG Turbo 3000 Manuel utilisateur

Froling

Froling P4 Pellet 8 - 105 Manuel utilisateur

U.S. Boiler Company

U.S. Boiler Company K2 Manuel utilisateur

Henrad

Henrad C95 FF Manuel utilisateur

NeOvo

NeOvo EcoNox EF 36 Manuel utilisateur

Potterton

Potterton PROMAX SL 12 Manuel utilisateur

Eco Hometec

Eco Hometec EC 25 COMPACT Manuel utilisateur

Baxi

Baxi Prime 1.24 Manuel utilisateur

REXNOVA

REXNOVA ISA 20 BITHERMAL Manuel utilisateur

Radiant

Radiant R2K 55 Manuel
