QUICK START GUIDE
VIA IVT01
Android 10.0 EVK
1.00-30052022
Copyright
Copyright © 2022 VIA Technologies Incorporated. All rights reserved.
No part of this document may be reproduced, transmied, transcribed, stored in a retrieval system, or translated into any language, in any
form or by any means, electronic, mechanical, magnec, opcal, chemical, manual or otherwise without the prior wrien permission of
VIA Technologies, Incorporated.
Trademarks
All brands, product names, company names, trademarks and service marks are the property of their respecve holders.
Disclaimer
VIA Technologies makes no warranes, implied or otherwise, in regard to this document and to the products described in this document.
The informaon provided in this document is believed to be accurate and reliable as of the publicaon date of this document. However,
VIA Technologies assumes no responsibility for the use or misuse of the informaon (including use or connecon of extra device/
equipment/add-on card) in this document and for any patent infringements that may arise from the use of this document. The informaon
and product specicaons within this document are subject to change at any me, without noce and without obligaon to nofy any
person of such change.
VIA Technologies, Inc. reserves the right the make changes to the products described in this manual at any me without prior noce.
ii
iii
VIA IVT01 Android 10.0 EVK Quick Start Guide
Revision History
Version Date Remarks
1.00 30/05/2022 Inial release
iv
VIA IVT01 Android 10.0 EVK Quick Start Guide
Table of Contents
1. Introducon.................................................................................................................................................... 1
1.1 EVK Package Contents........................................................................................................................... 1
1.1.1 Firmware Folder Contents ............................................................................................................. 1
1.1.2 Document Folder Contents............................................................................................................ 1
1.1.3 Tool Folder Contents...................................................................................................................... 1
1.2 Version Informaon and Supported Features....................................................................................... 2
2. Image Installaon .......................................................................................................................................... 3
2.1 Installing with the Fastboot Mode........................................................................................................ 3
3. Hardware Funcons ....................................................................................................................................... 7
3.1 Using the Debug Console...................................................................................................................... 7
3.2 Changing the Kernel Debug Level ......................................................................................................... 7
3.3 Checking the BSP Version...................................................................................................................... 8
3.4 DVFS...................................................................................................................................................... 8
3.5 Camera.................................................................................................................................................. 8
3.6 MTK NeuroPilot AI APU Hardware Acceleraon................................................................................... 9
1
VIA IVT01 Android 10.0 EVK Quick Start Guide
1. Introducon
This Quick Start Guide provides an overview of how to boot the Android image for the VIA IVT01 and congure
the supported hardware funcons in the build.
The VIA IVT01 Android 10.0 EVK is developed based on the MediaTek Android 10.0 BSP, and enables the
hardware features of the VIA IVT01.
1.1 EVK Package Contents
There are three folders in the package listed as below.
Firmware folder Descripon
VIA_IVT01_Android_10.0_EVK.zip Android image
Document folder Descripon
VIA_IVT01_Android_10.0_EVK_Quick_Start_Guide.pdf Quick Start Guide
Tool folder Descripon
VIA_Android_USB_Driver.zip VIA USB driver
1.1.1 Firmware Folder Contents
VIA_IVT01_Android_10.0_EVK.zip: Contains the precompiled Android image for evaluang the VIA IVT01.
1.1.2 Document Folder Contents
VIA_IVT01_Android_10.0_EVK_Quick_Start_Guide.pdf: This Quick Start Guide provides an overview on how
to boot the Android image for the VIA IVT01 and congure the supported hardware funcons in the build.
1.1.3 Tool Folder Contents
VIA_Android_USB_Driver.zip: VIA USB driver.
2
VIA IVT01 Android 10.0 EVK Quick Start Guide
1.2 Version Informaon and Supported Features
• Kernel version: 4.14.141
• Evaluaon image: Android 10.0
• Development based on MediaTek Android 10.0 BSP
• Supports eMMC boot
• Supports MIPI DSI capacive touch panel
−AUO 8" G080UAN02.2 (1200×1920)
−ILITEK I2C touch
• Supports 2 COM ports as RS-232 mode (TX/RX/CTS/RTS)
• Supports MediaTek MT6358 Headphone and Mic-in
• Supports MediaTek MT7668 Wi-Fi 802.11ac and Bluetooth 5.0
• Supports VIA EMIO-2574 (SIM7600JC-H) 4G LTE mobile broadband miniPCIe module
• Supports LOCOSYS MC-1612-DG mulple GNSS module with DR funcon
• Supports TDK InvenSense ICM-20948 MEMS MoonTracking device
• Supports MIPI CSI OV5648 camera module
• Supports MediaTek NeuroPilot AI APU hardware acceleraon
3
VIA IVT01 Android 10.0 EVK Quick Start Guide
2. Image Installaon
This secon explains the setup requirements for boong from the eMMC.
The precompiled images are provided in the "Firmware" folder.
2.1 Installing with the Fastboot Mode
The rst step is to prepare the "fastboot tool" and install the "VIA USB driver" into your Windows 10 host
machine.
To get the "fastboot tool" for Windows, please refer to the "SDK Plaorm Tools release notes" chapter on the
Android developer website (hps://developer.android.com/studio/releases/plaorm-tools).
To install the "VIA USB driver", right-click on the mouse buon to install the "android_winusb". When nished,
it will show "The operaon completed successfully".
Then connect the Windows 10 host machine and the VIA IVT01 through the USB 2.0 Type-A port using the
Male USB Type-A to Male USB Type-A cable.
USB 2.0 Type-A port diagram
Plug in the AC-to-DC power adapter to power on the VIA IVT01.
The VIA IVT01 will stop at "fastboot: processing commands" as shown in the debug console below.
Fastboot Mode
Note:
Make sure the Windows 10 host machine detects the VIA IVT01 as an Android device.
4
VIA IVT01 Android 10.0 EVK Quick Start Guide
Extract the VIA_IVT01_Android_10.0_EVK.zip le on your Windows 10 host machine.
To install the image, use the following command:
D:\VIA_IVT01_Android_10.0_EVK>set PATH=D:\platform-tools;%PATH%
D:\VIA_IVT01_Android_10.0_EVK>viaash.exe
++++++++++++++++++++++++++++++++++++++++++++++++++++
VIAFlash version v1.0.0
(built: Mar 16 2022 18:03:28 UTC)
++++++++++++++++++++++++++++++++++++++++++++++++++++
To let this tool work well, please
ensure the system is at fastboot mode!
If yes, please press any key to continue.
++++++++++++++++++++++++++++++++++++++++++++++++++++
>> The image OS should be "Android"
++++++++++++++++++++++++++++++++++++++++++++++++++++
MBR : OK
preloader_ivt01_sp.bin : OK
logo.bin : OK
vbmeta.img : OK
vbmeta_system.img : OK
vbmeta_vendor.img : OK
md1img.img : OK
spmfw.img : OK
scp.img : OK
sspm.img : OK
cam_vpu1.img : OK
cam_vpu2.img : OK
cam_vpu3.img : OK
lk.img : OK
boot.img : OK
dtbo.img : OK
tee.img : OK
super.img : OK
userdata.img : OK
++++++++++++++++++++++++++++++++++++++++++++++++++++
=============================================
Start to ash images --> Android
=============================================
Sending 'preloader_a' (255 KB) OKAY [ 0.032s]
Writing 'preloader_a' OKAY [ 0.018s]
Finished. Total time: 0.081s
Erasing 'pgpt' OKAY [ 0.022s]
Finished. Total time: 0.033s
Sending 'pgpt' (32 KB) OKAY [ 0.028s]
Writing 'pgpt' OKAY [ 0.008s]
Finished. Total time: 0.061s
Sending 'logo' (3409 KB) OKAY [ 0.104s]
Writing 'logo' OKAY [ 0.081s]
Finished. Total time: 0.211s
Sending 'vbmeta_a' (4 KB) OKAY [ 0.026s]
Writing 'vbmeta_a' OKAY [ 0.008s]
Finished. Total time: 0.064s
Sending 'vbmeta_system_a' (4 KB) OKAY [ 0.026s]
Writing 'vbmeta_system_a' OKAY [ 0.007s]
Finished. Total time: 0.059s
Sending 'vbmeta_vendor_a' (4 KB) OKAY [ 0.027s]
Writing 'vbmeta_vendor_a' OKAY [ 0.007s]
Finished. Total time: 0.058s
Sending 'md1img_a' (0 KB) OKAY [ 0.027s]
Writing 'md1img_a' OKAY [ 0.007s]
Finished. Total time: 0.060s
5
VIA IVT01 Android 10.0 EVK Quick Start Guide
Sending 'spmfw_a' (47 KB) OKAY [ 0.027s]
Writing 'spmfw_a' OKAY [ 0.008s]
Finished. Total time: 0.061s
Sending 'scp_a' (608 KB) OKAY [ 0.039s]
Writing 'scp_a' OKAY [ 0.021s]
Finished. Total time: 0.085s
Sending 'sspm_a' (480 KB) OKAY [ 0.036s]
Writing 'sspm_a' OKAY [ 0.021s]
Finished. Total time: 0.083s
Sending 'cam_vpu1_a' (1610 KB) OKAY [ 0.063s]
Writing 'cam_vpu1_a' OKAY [ 0.043s]
Finished. Total time: 0.133s
Sending 'cam_vpu2_a' (9887 KB) OKAY [ 0.244s]
Writing 'cam_vpu2_a' OKAY [ 0.221s]
Finished. Total time: 0.492s
Sending 'cam_vpu3_a' (135 KB) OKAY [ 0.029s]
Writing 'cam_vpu3_a' OKAY [ 0.013s]
Finished. Total time: 0.071s
Sending 'lk_a' (782 KB) OKAY [ 0.042s]
Writing 'lk_a' OKAY [ 0.033s]
Finished. Total time: 0.105s
Sending 'dtbo_a' (8192 KB) OKAY [ 0.202s]
Writing 'dtbo_a' OKAY [ 0.180s]
Finished. Total time: 0.413s
Sending 'tee_a' (139 KB) OKAY [ 0.030s]
Writing 'tee_a' OKAY [ 0.011s]
Finished. Total time: 0.072s
Sending 'userdata' (860 KB) OKAY [ 0.044s]
Writing 'userdata' OKAY [ 0.154s]
Finished. Total time: 0.227s
------------------------------------------------
Platform will be rebooted and continue soon,
please wait for ash completed
------------------------------------------------
Rebooting into bootloader OKAY [ 0.004s]
Finished. Total time: 0.007s
< waiting for any device >
Sending 'boot_a' (32768 KB) OKAY [ 0.886s]
Writing 'boot_a' OKAY [ 0.710s]
Finished. Total time: 1.649s
------------------------------------------------
Platform will be rebooted and continue soon,
please wait for ash completed
------------------------------------------------
Rebooting into bootloader OKAY [ 0.003s]
Finished. Total time: 0.006s
< waiting for any device >
Sending sparse 'super' 1/12 (131068 KB) OKAY [ 3.203s]
Writing 'super' OKAY [ 2.997s]
Sending sparse 'super' 2/12 (128054 KB) OKAY [ 2.979s]
Writing 'super' OKAY [ 4.433s]
Sending sparse 'super' 3/12 (127565 KB) OKAY [ 2.979s]
Writing 'super' OKAY [ 3.585s]
Sending sparse 'super' 4/12 (131068 KB) OKAY [ 3.083s]
Writing 'super' OKAY [ 3.064s]
Sending sparse 'super' 5/12 (131068 KB) OKAY [ 3.023s]
Writing 'super' OKAY [ 2.889s]
6
VIA IVT01 Android 10.0 EVK Quick Start Guide
Sending sparse 'super' 6/12 (131071 KB) OKAY [ 3.266s]
Writing 'super' OKAY [ 11.001s]
Sending sparse 'super' 7/12 (115560 KB) OKAY [ 2.645s]
Writing 'super' OKAY [ 2.802s]
Sending sparse 'super' 8/12 (115736 KB) OKAY [ 2.689s]
Writing 'super' OKAY [ 2.634s]
Sending sparse 'super' 9/12 (131068 KB) OKAY [ 3.089s]
Writing 'super' OKAY [ 3.010s]
Sending sparse 'super' 10/12 (131069 KB) OKAY [ 3.023s]
Writing 'super' OKAY [ 3.681s]
Sending sparse 'super' 11/12 (131068 KB) OKAY [ 3.073s]
Writing 'super' OKAY [ 3.138s]
Sending sparse 'super' 12/12 (78604 KB) OKAY [ 1.838s]
Writing 'super' OKAY [ 1.868s]
Finished. Total time: 80.410s
=============================================
Finished. Re-Starting system ...
Rebooting OKAY [ 0.003s]
Finished. Total time: 0.007s
D:\VIA_IVT01_Android_10.0_EVK>
If you have already installed the image, use the following command to enter the Fastboot Mode on your
Windows 10 host machine.
D:\platform-tools>adb reboot bootloader
Unplug the AC-to-DC power adapter to power o the VIA IVT01.
Unplug the Male USB Type-A to Male USB Type-A cable, then power on the VIA IVT01.
When the boot process has completed, you will see the Android 10.0 desktop.
Autres manuels pour IVT01
1
Table des matières
Autres manuels VIA Technologies Matériel informatique
VIA Technologies
VIA Technologies SOM-7000 Manuel utilisateur
VIA Technologies
VIA Technologies AMOS-820 SKU Manuel utilisateur
VIA Technologies
VIA Technologies SOM-6X50 Manuel utilisateur
VIA Technologies
VIA Technologies ARTiGO-A1200 Manuel utilisateur
VIA Technologies
VIA Technologies QSM-8Q60 Manuel utilisateur
VIA Technologies
VIA Technologies VAB-820 Manuel utilisateur
VIA Technologies
VIA Technologies VAB-820 Manuel utilisateur
VIA Technologies
VIA Technologies SOM-9X50-STK Manuel utilisateur
VIA Technologies
VIA Technologies AMOS-820 SKU Manuel utilisateur
VIA Technologies
VIA Technologies LPC-01 Manuel utilisateur
VIA Technologies
VIA Technologies ARTiGO A820 Manuel utilisateur
VIA Technologies
VIA Technologies VAB-600 SmartETK SDK Manuel utilisateur
VIA Technologies
VIA Technologies ARTiGO A950 Manuel utilisateur
VIA Technologies
VIA Technologies VNT6656AU Manuel utilisateur
VIA Technologies
VIA Technologies VT82C693A Manuel utilisateur
VIA Technologies
VIA Technologies SOM-9X50-STK Manuel utilisateur
VIA Technologies
VIA Technologies VAB-600 SmartETK SDK Manuel utilisateur
VIA Technologies
VIA Technologies VAB-3000 Manuel utilisateur
VIA Technologies
VIA Technologies SOM-9X35 Manuel utilisateur
VIA Technologies
VIA Technologies SOM-9X35 Manuel utilisateur
Manuels Matériel informatique populaires d'autres marques
EMC2
EMC2 VNX Series Manuel du propriétaire
Panasonic
Panasonic DV0PM20105 Manuel utilisateur
Mitsubishi Electric
Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur
Gigabyte
Gigabyte B660M DS3H AX DDR4 Manuel utilisateur
Raidon
Raidon iT2300 Manuel utilisateur
National Instruments
National Instruments PXI-8186 Manuel utilisateur
