Vaxcel T0521 Manuel d'instructions

ASSEMBLY AND INSTALLATION

INSTRUCTIONS

190611

1. Unscrew the four set screws (C) from the cover.

2. Install a bulb (not included).

See relamping label at socket area or packaging

for maximum allowed wattage.

3. Alight the holes on the lamp frame to the fixture’s,

secure them by threading the set screws (C) going

through the holes one by one.

4. Pull out the wires and grounding wire from the post.

Make wire connections using the wire connectors (B):

---The hot wire (usually black insulation) from the

fixture to the black wire from the post.

---The neutral wire (usually white insulation) from

the fixture to the white wire from the post.

---The grounding wire (usually green insulation or

bare wire from the fixture to the grounding wire

from the post.

Carefully put the wires back into the post.

5. Place the fitter on the top of the post, and then

secure it with three fitter screws (A).

NOTE: With silicone caulking compound,

caulk completely around where the fitter

meets with the post surface to prevent water

from seeping into the post.

NOTES: 1. Before installing, consult local electrical codes for wiring and grounding requirements.

2. READ AND SAVE THESE INSTRUCTIONS.

T0521 T0526

Hardware Package (included):

Fitter Screw (A) Wire Connector (B)

Turn off the power at fuse or circuit box

Installation Steps

WARNING:

TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF

POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE.

Turn on the power at fuse or circuit box

Cover

Set Screw

Lamp Frame

Fitter

Fitter Screw (A)

Wire Connector (B)

Grounding Wire

Post

Bulb Type A MAX 60W

(not included)

190611

Assembly Kit

6132MM (1SET) for T0521

6133MM (1SET) for T0526

The following parts are available for re-order if damaged or missing.

Spare Parts List:

Glass

10106CS

A: 8-1/2"

B: 19-3/4"

Fitter Screw (A) Wire Connector (B)
