Vauxhall Vectra Mode d’emploi

VAUXHALL Vectra

Operation, Safety, Maintenance

-2

Data specific to your vehicle

Please enter your vehicle’s data here to keep it easily accessible.

This information is available under the section "Technical data" as well as on the identification plate.

Fuel

Designation

Engine oil

Grade

Viscosity

Tyre inflation pressure

Tyre size with up to 4 persons with full load

Summer tyres Front Rear Front Rear

Winter tyres Front Rear front Rear

Weights

Permissible Gross Vehicle Weight

– ECkerbweight

=Loading

-1

Your Vectra

Your vehicle represents an intelligent

synthesis of advanced technology,

outstanding safety, environmental

compatibility and economy.

It now lies with you to drive your vehicle

safely and to see it performs perfectly. This

Owner's Manual provides you with all the

necessary information to that end.

Make sure your passengers are aware of

the possible risk of accident and injury

which may result from improper use of the

vehicle.

You must always comply with the laws of

the country in which you are travelling.

These could differ from the information in

this Owner’s Manual.

The Owner's Manual should always be kept

in the vehicle: ready to hand in the glove

compartment.

Make use of the Owner's Manual:

zIts "In Brief" section will give you an initial

overview.

zThe table of contents at the start of the

Owner’s Manual and in each individual

chapter will help you find your way.

zIts index will help you find what you

want.

zIt will familiarise you with the

sophisticated technology.

zIt will increase your pleasure in your

vehicle.

zIt will help you to handle your vehicle

expertly.

The Owner’s Manual is designed to be

clearly laid-out and easily understood.

This symbol signifies:

6Continue reading on next page.

3The asterisk signifies equipment not

fitted to all vehicles (model variants,

engine options, models specific to one

country, optional equipment, Genuine

Vauxhall Parts and Accessories).

Yellow arrows in the illustrations serve as

points of reference or indicate some action

to be performed.

Black arrows in the illustrations indicate a

reaction or a second action to be

performed.

Thank you for choosing a Vauxhall. We

wish you many hours of pleasurable

driving.

Your Vauxhall Team

9Warning

9Warning is used to mark text

regarding possible risks of accident or

injury. Failure to follow the instructions

could lead to injury or loss of life. Inform

vehicle passengers accordingly.

Contents Commitment to customer

satisfaction:

Our aim: to keep you happy with your

vehicle. All Vauxhall Authorised Repairers

offer first-class service at competitive

prices. Experienced, factory-trained

technicians work according to factory

instructions. Your Authorised Repairer can

supply you with GENUINE VAUXHALL-

APPROVED PARTS, which have undergone

stringent quality and precision checks, and

of course useful and attractive

VAUXHALL-APPROVED ACCESSORIES.

Our name is your guarantee!

For details of the

Vauxhall Authorised Repairer Network,

please ring this number; 0845 090 2044

In Brief ....................................................... 2

Instruments ............................................. 34

Keys, doors,

bonnet ................................................ 62

Seats, Interior .......................................... 81

Safety systems ..................................... 106

Lighting ................................................. 128

Windows, Sun Roof ............................. 136

Climate control .................................... 142

Easytronic ............................................ 170

Automatic transmission ...................... 178

Driving hints ......................................... 186

Saving fuel,

Protecting the environment ............ 188

Fuel consumption,

fuel, refuelling .................................. 190

Catalytic converter, exhaust gases .... 193

Drive Control Systems ......................... 198

Brakes .................................................... 210

Wheels, tyres ......................................... 214

Roof Racks,

Caravan and Trailer Towing .......... 220

Self-help ................................................ 229

If you have a problem ......................... 264

Maintenance,

Inspection System ............................ 266

Vehicle care .......................................... 278

Technical Data .................................... 282

Index ...................................................... 314

2InBrief

In Brief

Key numbers,

code numbers

Remove key number from keys.

The key number is specified in the vehicle

documents and in the Car Pass 3.

Alloy wheels 3, towing equipment 3: make

a note of the key identifier codes.

Electronic immobiliser, infotainment

system 3: The code numbers are specified

in the Car Pass.

Do not keep the Car Pass in the vehicle.

For key with retractable key blade 3, press

button to extend.

6Further information – see pages 62, 63,

vehicle recommissioning – see page 277.

To unlock and open

the doors:

Press button q,

pull door handle

6Door locks, child safety locks

– see page 77,

Electronic immobiliser – see page 63,

Keys – see page 62,

Radio remote control – see page 64,

programming unlocking mode

– see page 67,

Central locking system – see page 66,

Anti-theft locking system 3– see page 66,

Vauxhall alarm system 3– see page 74.

3In Brief

Unlock luggage compartment

and open:

Press button qon the

remote control,

press button and

with the estate pull button

beneath the handle

6Radio remote control – see page 64,

central locking – see page 66,

programming unlocking mode

– see page 67,

vauxhall alarm system 3– see page 74,

electrically operated tailgate 3

– see page 71.

To adjust front seats:

Pull handle,

slide seat,

release handle

Never adjust the seat while driving. It could

move in an uncontrolled manner when the

handle is pulled.

6Seat position – see page 81,

electrically adjustable front seats

– see page 84.

Adjust front seat backrests:

Turn handwheel

Move backrest to suit seating position.

Do not lean on seat backrest whilst

adjusting it.

6Seat position – see page 81,

fold front passenger seat backrest

– see page 95,

electrically adjustable front seats

– see page 84.

9Warning

Important: Do not sit nearer than 10

inches (25 cm) from the steering wheel, to

permit safe airbag deployment.

4InBrief

To adjust front seat lumbar

support 3at front seats:

Operate lever

Adjust lumbar support to suit personal

requirements.

Do not lean on seat backrest whilst

adjusting it.

6Seat position – see page 81,

electrically adjustable front seats

– see page 84.

To adjust front seat height 3:

Operate lever on

outboard side of seat

Pump direction of the lever

Up: Raises seat

Down: Lowers seat

Do not adjust driver’s seat whilst driving.

6Seat position – see page 81,

electrically adjustable front seats

– see page 84.

To adjust front seat inclination 3:

Operate front lever on

outboard side of seat

Pump direction of the handle

Up: Inclines seat

Down: Levels seat

Do not adjust driver’s seat whilst driving.

6Seat position – see page 81,

electrically adjustable front seats

– see page 84.

5In Brief

Electric seat adjustment 3:

Operate switch on outboard side

of seat

1Adjusting the longitudinal position

2Adjusting the inclination

3Height adjustment

4Backrest adjustment

5 Lumbar support 3

Do not adjust driver’s seat whilst driving.

6Seat position – see page 81,

electrically adjustable front seats

– see page 84.

To adjust thigh support 3

of the front sport seat 3:

Press button in recessed handle

centred in the lower half of the

adjustment cushion and

adjust the thigh support

Adjust thigh support to suit personal

requirements.

Do not adjust the thigh support whilst

driving.

To adjust head restraint height of

front and rear outboard seats 3:

Press button to release,

adjust height,

engage in position

6Adjusting rear centre

head restraint – see page 82,

head restraint position – see page 82,

head restraint removal – see page 82.

6InBrief

To adjust 3head restraint

angle of front and rear outboard

seats 3:

Swivel bottom edge of head

restraint forward or rearward

6Head restraint position – see page 82,

rear head restraints – see page 82.

Adjusting interior mirror:

Swivel mirror housing

Swivel lever on underside of mirror housing

to reduce dazzle at night.

6Automatic anti-dazzle interior mirror

– see page 126.

To adjust exterior mirrors:

Four-way switch in driver’s door

If the outer mirror switch is pressed 1the

four-way switch operates the driver and

front passenger mirrors 3, and if the inner

mirror switch is pressed 2it only operates

the front passenger mirror.

With electric seat adjustment with memory

function 3:

If the interior mirror switch 2is pressed the

exterior passenger mirror automatically

points at the rear tyres as a parking aid

when reverse gear is selected (not with

trailer attached) 3.

6Further information, aspherical exterior

mirrors 3– see page 126,

automatic anti-dazzle exterior mirrors

– see page 126,

heated exterior mirrors – see page 18,

electric seat adjustment 3– see page 85.

Autres manuels pour Vectra

Table des matières

Autres manuels Vauxhall Automobile

Vauxhall

Vauxhall 2010 Astra Manuel utilisateur

Vauxhall

Vauxhall INSIGNIA 2017 Manuel utilisateur

Vauxhall

Vauxhall New Crossland Manuel utilisateur

Vauxhall

Vauxhall 2013 Adam Manuel utilisateur

Vauxhall

Vauxhall VIVARO Manuel utilisateur

Vauxhall

Vauxhall MY15 INSIGNIA Manuel utilisateur

Vauxhall

Vauxhall Zafira Manuel utilisateur

Vauxhall

Vauxhall 2013 Corsa Infotainment system Manuel utilisateur

Vauxhall

Vauxhall VIVARO Manuel utilisateur

Vauxhall

Vauxhall NEW INSIGNIA Manuel utilisateur

Vauxhall

Vauxhall 2013 Meriva Manuel utilisateur

Vauxhall

Vauxhall 2013 Corsa Infotainment system Manuel utilisateur

Vauxhall

Vauxhall Astra Sport Hatch Edition 2 2011 Manuel utilisateur

Vauxhall

Vauxhall Antara 2014 Manuel utilisateur

Vauxhall

Vauxhall Corsa 2014 Manuel utilisateur

Vauxhall

Vauxhall Crossland X 2017 Manuel utilisateur

Vauxhall

Vauxhall Vectra Manuel utilisateur

Vauxhall

Vauxhall 2011 Meriva Manuel utilisateur

Vauxhall

Vauxhall VIVARO Manuel utilisateur

Vauxhall

Vauxhall Corsa 2010.5 Manuel utilisateur

Vauxhall

Vauxhall Meriva Manuel utilisateur

Vauxhall

Vauxhall 2013 Combo Manuel utilisateur

Vauxhall

Vauxhall 2013 Combo Manuel utilisateur

Vauxhall

Vauxhall Ampera Manuel utilisateur

Manuels Automobile populaires d'autres marques

Toyota

Toyota 2000 Tundra Manuel utilisateur

CITROËN

CITROËN DS4 DSign Manuel utilisateur

Lexus

Lexus 2015 CT 200h Manuel utilisateur

Cadillac

Cadillac CTS 2008 Manuel utilisateur

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuel utilisateur

Porsche

Porsche Boxster S Manuel utilisateur

GMC

GMC 2010 Savana 1500 Cargo Manuel utilisateur

KIAM

KIAM SPORTAGE 2014 Manuel de la liste des pièces

GMC

GMC 2013 Terrain Instructions de montage

GMC

GMC T-Series 1999 Manuel utilisateur

Mercury

Mercury 1998 Mystique Manuel utilisateur

Mercury

Mercury 2007 Mariner Manuel utilisateur

Mazda

Mazda 2007 Mazdaspeed 3 Mode d’emploi

Mazda

Mazda 2014 CX-5 Manuel utilisateur

GMC

GMC Chevrolet Express 2022 Manuel utilisateur

GMC

GMC 1997 Jimmy Manuel utilisateur

Chevrolet

Chevrolet 2012 Malibu Manuel utilisateur

Cadillac

Cadillac 2010 Escalade Manuel utilisateur
