ASTRA
©Copyright by Vauxhall Motors Ltd., England.
Reproduction or translation, in whole or in parts, is not
permitted without prior written consent from Vauxhall Motors
Ltd.
All rights as understood under the copyright laws are explicitly
reserved by Vauxhall Motors Ltd.
All information, illustrations and specifications contained in this
manual are based on the latest production information
available at the time of publication.
The right is reserved to make changes at any time without
notice.
Edition: January 2006.
TS 1612-B-06
ASTRA
Operation, Safety and Maintenance
Owner’s Manual
VAUXHALL Astra
Owner’s Manual
Seite -2, , Bearbeitung 19.12.05
Data specific to your vehicle
Please enter your vehicle’s data here to keep it easily accessible.
This information is available under the section "Technical data" as well as on the identification plate.
Fuel
Designation
Engine oil
Grade
Viscosity
Tyre inflation pressure
Tyre size with up to 3 persons with full load
Summer tyres front rear front rear
Winter tyres front rear front rear
Weights
Permissible Gross Vehicle Weight
– ECkerbweight
=Loading
Seite -1, , Bearbeitung 19.12.05
Your Astra
Developed according to the latest findings of vehicle research, it offers technical sophistication and exceptional comfort.
Your Astra represents an intelligent synthesis of advanced technology, outstanding safety, environmental compatibility and economy.
It now lies with you to drive your Astra safely and to see it performs perfectly.
This Owner’s Manual provides you with all the necessary information to that end.
Make sure your passengers are aware of the possible risk of accident and injury which may result from improper use of the vehicle.
The Owner’s Manual should always be kept in the vehicle: ready to hand in the glove compartment.
Make use of the Owner’s Manual:
zIts "In brief" section will give you an initial overview.
zThe table of contents at the beginning of the owner’s manual
and within the individual chapters will show you where everything is.
zIts index will help you find what you want.
zIt will familiarise you with the sophisticated technology.
zIt will increase your pleasure in your vehicle.
zIt will help you to handle your vehicle expertly.
The Owner’s Manual is designed to be clearly laid-out and easily understood.
This symbol signifies:
6Continue reading on next page.
3The asterisk signifies: equipment not fitted to all vehicles
(model variants, engine options, models specific to one country, optional equipment, Genuine Vauxhall Parts and Accessories).
Yellow arrows in the illustrations serve as points of reference or indicate some action to be performed.
Black arrows in the illustrations indicate a reaction or a second action to be performed.
We wish you many hours of pleasurable driving
Your Vauxhall Team
9Warning
Text marked 9Warning provides information on risk of accident or injury.
Disregard of the instructions may lead to injuries or endanger life.
Inform your passengers accordingly.
Seite 0, , Bearbeitung 20.12.05
Contents Commitment to customer
satisfaction:
Our aim: to keep you happy with your
vehicle. All Vauxhall Authorised Repairers
offer first class service at competitive
prices. Experienced, factory-trained
technicians work according to factory
instructions. Your Authorised Repairer can
supply you with GENUINE VAUXHALL-
APPROVED PARTS, which have undergone
stringent quality and precision checks, and
of course useful and attractive
VAUXHALL-APPROVED ACCESSORIES.
Our name is your guarantee!
For details of the
Vauxhall Authorised Repairer Network
please ring this number; 01582 - 427200
In brief ....................................................... 2
Instruments ............................................. 36
Keys, doors, bonnet .............................. 66
Seats, Interior .......................................... 87
Safety systems ..................................... 109
Lighting ................................................. 134
Windows, sunroof ................................ 141
TwinTop ................................................ 146
Climate control .................................... 153
Easytronic ............................................. 174
Automatic transmission ...................... 182
Automatic transmission
with ActiveSelect .............................. 188
Driving hints ......................................... 196
Saving fuel,
protecting the environment ............ 198
Fuel consumption,
fuel, refuelling .................................. 200
Catalytic converter, exhaust gases .... 203
Drive control systems .......................... 208
Brakes .................................................... 222
Wheels, tyres ......................................... 226
Roof racks,
caravan and trailer towing ............. 234
Self-help ................................................ 243
If you have a problem ......................... 288
Maintenance, inspection system ........ 290
Vehicle care .......................................... 302
Technical data .................................... 306
Index ...................................................... 342
2 In brief
In brief
Picture no: 17027t.tif
Key numbers,
code numbers
Remove key number from keys.
The key number is specified in the vehicle
documents and in the Car Pass.
Alloy wheels 3, towing equipment 3: make
a note of the key identifier codes.
Electronic immobiliser, Infotainment
system 3: the code numbers are specified
in the Car Pass.
Do not keep the Car Pass in the vehicle.
For key with retractable key blade 3,
press button to extend.
6Further information – see pages 66, 67,
vehicle recommissioning – see page 301.
Picture no: 16968t.tif
To unlock and open the vehicle:
Press button q,
pull door handle
In vehicles with an Open&Start system 3,
the vehicle is unlocked automatically by
pulling a door handle or by operating the
button beneath the tailgate handle, if the
electronic key is in the external reception
range of the vehicle.
6Door locks, child safety locks –
see page 86,
electronic immobiliser – see page 67,
keys – see page 66,
Open&Start system 3– see page 70,
radio frequency remote control –
see page 68,
central locking system – see page 76,
anti-theft locking system – see page 76,
Vauxhall alarm system 3– see page 83,
TwinTop roof operation 3– see page 146.
3In brief
Picture no: 16969t.tif
To unlock and
open the luggage compartment:
Press button qon
remote control and
operate button beneath handle
In vehicles with Open&Start system 3the
tailgate is unlocked automatically by
operating the button beneath the handle if
the electronic key is within the external
reception range of the vehicle. The doors
are also unlocked.
6Open&Start-System 3– see page 70,
radio frequency remote control –
see page 68,
central locking system – see page 76,
Vauxhall alarm system 3– see page 83.
Picture no: 16970t.tif
To adjust front seat:
Pull handle,
slide seat,
release handle
Never adjust the front seat while driving. It
could move in an uncontrolled manner
when the handle is pulled.
6Seating position – see page 87.
Picture no: 16971t.tif
To adjust front seat backrest:
Turn handwheel
Move backrest to suit seating position.
Do not lean on seat backrest whilst
adjusting it.
6Seating position – see page 87.
9Warning
Important: Do not sit nearer than
10 inches (25 cm) from the steering
wheel, to permit safe airbag deployment.
4 In brief
Picture no: 16972t.tif
To adjust front seat lumbar
support 3:
Turn handwheel
Adjust lumbar support to suit personal
requirements.
Do not lean on seat backrest whilst
adjusting it.
6Seating position – see page 87.
Picture no: 16973t.tif
To adjust front seat height 3:
Operate lever on outboard side
of seat
Lever pumping action
upward: seat higher
downward: seat lower
6Seating position – see page 87.
Picture no: 16974t.tif
To adjust front seat inclination 3:
Pull inner lever on front of seat,
adjust inclination,
release lever,
engage seat in position
Adjust the inclination by distributing body
weight.
6Seating position – see page 87.
5In brief
Picture no: 16975t.tif
To fold the front seat backrest
forward 3:
Lift release lever,
fold backrest forward and lock,
slide seat forward
To raise seat, slide back to stop, lift release
lever and raise backrest.
In front seats with memory-function 3, the
seat engages in its original position when
pushed back.
In front seats without memory function 3,
engage seat in required position when
pushing backwards.
Panoramic windscreen 3: before folding
the seat, push the head restraints down
and close the sunvisors.
6Seating position – see page 87.
Picture no: 17959t.tif
To adjust thigh support 3
of the front sport seat 3:
Press button in recessed handle
centred in the lower half of the
adjustment cushion and
adjust the thigh support
Adjust thigh support to suit personal
requirements.
Picture no: 16976t.tif
To adjust head restraint height of
front and rear outboard seats:
Press button to release,
adjust height,
engage in position
6Adjusting centre rear head restraint –
see page 88,
head restraint position – see page 88,
head restraint removal – see page 88.
