Vantrue Element 2 Manuel utilisateur

Element 2

User Manual

122mmX130mm

70g

Voice-Controlled Dual Dash Cam

Hey, find us here:

www.vantrue.net/contact facebook.com/vantrue.live

CONTENTS

VERZEICHNIS

CONTENU

ÍNDICE

SPIS TREŚCI

106

151

196

240

281

Basic Operation

Grundlegende Bedienung

Opérationdebase

Operación básica

Podstawowe funkcje

基本操作

功能亮点

Installation

Instalación

Instalacja

取り付け方法

安装及使用说明

139

184

228

270

Camera Overview

Die Übersicht über Kamera

Vue d'ensemble de la caméra

Descripción de la cámara

Budowa kamery

ドラレコの概要

机身部件说明

134

180

224

267

133

179

223

266

What’s in the box?

Was ist in der Box？

Qu'ya-t-ildanslaboîte？

¿Qué hay en la caja？

Co znajdziemy w pudełku？

同梱内容

盒内物品清单

CONTENTS

VERZEICHNIS

CONTENU

ÍNDICE

SPIS TREŚCI

131

177

220

263

302

Specifications

Spezifikation

Speciﬁcation

Especificaciones

Dane techniczne

製品仕様

产品规格参数

132

178

221

264

303

Warranty & Support

Garantie und Support

Garantie & Support

Garantía y Soporte

Gwarancja & wsparcie

保証とアフターサービス

售后服务

1. What’s in the Box?

3M Adhesive

Stickers

Wireless Remote

Control L.

CPL Fliter

- 1 -

A. Vantrue E2

Dash Cam

GPS Adhesive

Mount

B. R03 Rear Camera

User Manual K.

Crowbar

Type C Data Cable

(3.3ft, for transferring

files only)

F. Car Charger with

Built-in Type C

Cable(11.5ft)

Cable for Rear

Camera(20ft)

Warning Stickers

Electrostatic

stickers

Optional Accessories

Element 2

User Manual

Voice-Controlled Dual Dash Cam

2. Camera Overview

- 2 -

NO. DescriptionName

During video recording, you can long press to turn

off the screen, and short press to stop recording

and enter standby mode; you can confirm the

selected option in the menu; when playing back

a file, press the button to play/pause the file

1 Button

VTE1E0001

1 2 3 4

10 13 1412

17 18 19

2 During video recording and standby, short press

to switch the video window; in menu setting and

file browsing, short press to display the previous

option, long press to scroll up to display options;

in playback mode, short press to fast forward; in

WiFi mode, press any key to exit WiFi

During video recording and standby, long press

to quickly enter parking mode, and short press to

turn on/off the microphone; in menu settings,

long press to scroll through menu options, and

short press to display the next menu option;

during file browsing, long press to scroll to display

file, short press to display the next file; in playback

mode, short press to pop up the delete file menu;

in WiFi mode, press any key to exit WiFi

During video recording, long press to turn on/off

WiFi; In standby state, short press to enter the

menu or return, and long press to turn on or off

WiFi; in WiFi mode, press any key to exit WiFi

Button

3 Button

Button

Serial Number Serial number for warranty registration

7 Speaker Delivers sound during video playback

- 3 -

Microphone Records clear audio with the video footage

10 Screen 2.45” LCD Screen

11 REC Green light means the camera is powered on

8Front Camera Front facing camera for video recording road

events.

9Power Port Connects to Type C cable or car charger for

external power supply

LED Indicator

- 4 -

12 Mount interface Location of the installing mount

13 Type C Port for

Rear Camera

Connects the rear camera into this Port; connects

the data cable for data transfer

14 Button

16 Reset Button Short press to restart the camera

17 Rear Camera Records road events behind the car

18 Indicators for

Rear Camera

A green light indicates that the rear camera is

connected to power

19 Rear Camera

connector

Connection port for rear camera cable

15 SD Card Slot Supports Micro SD Card up to 512GB in FAT32,

Class 10

DescriptionLED

Steady green light

Blinking green light

Instandbystatus, or the REC light is set to off

Camera is recording

During the video recording, short press will lock

the current video and take a picture, long press

to shut down; in standby mode, short press will

capture the picture, long press will shut down; in

WiFi state, short press to exit WiFi, long press to

shut down

LED Status

REC

- 5 -

Screen Overview

14:39:07 06-20-2022

00:00:37 MP/H

1440P+1440P 30FPS

Loop recording off

Loop recording for 1 min

Loop recording for 3 mins

Loop recording for 5 mins

Mic is ON

Mic is OFF

No memory card or the

card is not recognized

G-Sensor ON

G-Sensor OFF

Recorded Driving Speed

(KMH or MPH)

Parking Mode Recording

Time(Current Clip)

Video

Resolution

Snapshot

Remote control is connected

Time Lapse On

Collision Detection ON

Motion Detection ON

1080P Low Bitrate Recording ON 15FPS

720P Low Bitrate Recording ON 15FPS

Low Framerate Parking Mode

GPS Signal Connecting

GPS Signal Locked

Voice control is off

Voice control is on

MP/H

Current Date and Time

Memory card is working

properly
