Dear Parent,

At VTech®, we know that every year, children are asking to play video games

at younger and younger ages. At the same time, we understand the hesitation

of most parents to expose their children to the inappropriate content of many

popular video gamtyou feel confident in allowing your childen to play these

games, and still educate and entertain them in a healthy, age-appropriate

manner?

Our solution to this on-going debate is the V.SMILE™ TV Learning System

– a unique video game system created especially for children aged 3 to 7.

The V.SMILE™ TV Learning System combines a kid-friendly design,

age-appropriate curriculum, entertaining graphics, and fun game play into

a unique experience that your child will love and you can support. The

V.SMILE™ TV Learning System engages your child with two modes of play:

the Learning Adventure - an exciting exploratory journey in which learning

concepts are seamlessly integrated, and the Learning Zone - a series of games

designed to focus on specific school skills in a fun, engaging way. Both of these

educational modes offer your child hours of learning fun.

As part of the V.SMILE™ TV Learning System, VTech® offers a library of

game Smartridges™ based on popular children’s characters that engage and

encourage your child to play while learning. The library is organized into

three levels of educational play – Early Learners (ages 3-5), Junior Thinkers

(ages 4-6) and Master Minds (ages 6-8) – so that the educational content of

the system grows with your child.

At VTech®, we are proud to provide you with a much-needed solution to the

video game dilemma, as well as another innovative way for your child to learn

while having fun. We thank you for trusting VTech®‚ with the important job

of helping your child explore a new world of learning!

Sincerely,

Your Friends at VTech®

To learn more about the V.SMILE™ TV Learning System and other VTech®

toys, visit www.vtechkids.com

INTRODUCTION

Thank you for purchasing the V.SMILE Art Studio™!

With the help of the V.SMILE™ TV Learning System, this art studio will

help your child become the next budding Picasso! This interactive, creative

studio provides opportunities to unleash your child’s imagination! With an

interactive pen, touch-sensitive drawing pad, and over twelve activities,

including drawing lessons and games, kids can tap into their creativity by

creating their own, unique masterpieces!

This creative studio connects directly to the V.SMILE™ TV Learning

System (sold separately) for fun, creative game play on your home TV!

INSTRUCTIONS

INCLUDED IN THIS PACKAGE

• One VTech® V.SMILE Art Studio™

• One VTech® V.SMILE Art Studio Smartridge™

• One User’s Manual

WARNING: All packing materials such as tape, plastic sheets, wire ties

and tags are not part of this toy and should be discarded for

your child’s safety.

INTRODUCTION / INSTRUCTIONS

V.SMILE Art Studio™

V.SMILE Art

Studio

Smartridge™

Touch-sensitive Drawing Pad

User’s

Manual

PRODUCT FEATURES

FREE DRAW Button The FREE DRAW button is a shortcut that takes

you to the Free Draw mode. When you press the

FREE DRAW button, the game will pause. An EXIT

message will pop up to make sure you want to quit.

Move the pen or arrow buttons left to “Yes ” to

leave the game and go directly to the Free Draw

mode or right to “No ” to keep playing. Hold down

the pen or press the ENTER button to confirm.

HELP Button When you press the HELP button , you will hear

some helpful hints, or the instructions to the current

game you are playing will be repeated for you.

EXIT Button When you press the EXIT button , the game will

pause and an EXIT message will pop up to make

sure you want to quit. Move the pen or arrow buttons

left to “Yes ” to leave the game or to the right to

“No ” to keep playing. Hold down the pen or press

the ENTER button to confirm.

Arrow Buttons You can use the four-directional arrow buttons to

choose selections on screen by moving up, down,

left and right.

ENTER Button When you press the ENTER button , it will

select your current game choice. You can also use

this to confirm answers within a given game.

Cable Connect the V.SMILE Art Studio™ cable to the

PLAYER 1 slot on your V.SMILE™.

Touch-sensitive Use the pen on the pad to choose your play

mode.

Interactive Pen Select the activity with the pen and hold it down

when you are finished.

PRODUCT FEATURES

Cable

Interactive Pen

FREE DRAW Button

EXIT Button

Arrow Buttons

ENTER Button

Touch-sensitive

Drawing Pad

HELP Button

Drawing Pad

GETTING STARTED

BATTERY PACK INSTALLATION

1. Locate the battery cover on the bottom of the main

unit.

2. Remove the battery cover.

3. Insert 4”AA”size batteries as illustrated.

4. Replace the battery cover.

BATTERY NOTICE

• Do not try to recharge non-rechargeable batteries.

• Rechargeable batteries are only to be charged under adult

supervision.

• Do not mix different types of batteries.

• Do not mix new and used batteries.

• Only use batteries of the recommended or equivalent type.

• Always insert batteries properly matching the plus (+) and minus (-)

signs.

• Batteries that have run out of energy must be removed from the toy.

• Do not short-circuit the supply terminals.

• Do not use more batteries than recommended.

• Do not dispose of batteries in fire, as batteries may explode or leak.

• Remove batteries from the toy if it will not be used for an extended period

of time.

CONNECTING THE V.SMILE ART STUDIO™ TO V.SMILE™

NOTE: Before you connect the V.SMILE Art Studio™ to V.SMILE™,

check to make sure that the V.SMILE™ is working. Once you

have turned the unit ON, the power indicator light (ON Button)

should glow. If the ON Button does not glow, check to see the

adaptor is connected, or that the batteries are installed correctly.

If the batteries are not installed correctly, the V.SMILE™ TV

Learning System will not function and damage to the unit could

result. Make sure that the TV and the unit are turned OFF before

you begin making connections.

GETTING STARTED

Connect the V.SMILE Art Studio™ cable to the PLAYER 1 slot on your

V.SMILE™ as illustrated.

NOTE: If you connect the cable to the PLAYER 2 slot, there will be

no responses when pressing the HELP button or EXIT button.

Therefore, please be sure to plug the cable into the PLAYER 1 slot.

CONNECTING TO A TELEVISION

Connect the V.SMILE™ TV Learning System to your TV or monitor by

plugging the colored cables on the unit into the matching color video and

audio input jacks on your TV set.

For TVs with stereo audio inputs:

- Connect the yellow plug on the V.SMILE™ cable to

the yellow video input terminal on your TV.

- Connect the white and red plugs on the V.SMILE™

cable to the white and red audio input terminals on

your TV.

For TVs with a mono audio input:

- Connect the yellow plug on the V.SMILE™ cable to

the yellow video input terminal on your TV.

- Connect the white or red plug on the V.SMILE™ cable

to the white or red audio input terminal on your TV.

CONNECTING TO A VCR

GETTING STARTED

If there is no video IN and audio IN terminal on your TV set, you can

connect V.SMILE™ to a VCR.

- Connect the yellow plug on the V.SMILE™ cable to

the yellow video input terminal on your VCR.

- Connect the white and red plugs on the V.SMILE™

cable to the white and red audio input terminals on

your VCR.

TO BEGIN PLAY

STEP 1: CHOOSE YOUR PLAY MODE

Touch your pen on the touch-sensitive drawing pad to choose the activity

mode, or press the arrow buttons up and down to play. Hold down the pen

or press the ENTER button when you are ﬁnished.

1. Free Draw

This mode allows you to draw anything you wish! You can use the user-

friendly art functions such as choosing colors, adding stamp images,

choosing an animation, and more to create your own masterpiece!

2. Art Lesson

This mode provides seven different drawing lessons that help you learn

about the elements of art and using these elements to create your own

drawing. In the Art Lesson menu, choose any of the seven lessons you

like.

Hold down the pen or press the ENTER button to make your choice. Use

the pen or arrow buttons to move the cursor to the lesson you want and

hold down the pen or press the ENTER button to play.

Note: For the details of the ‘Art Lesson’ games, please refer to the

“Activities – Art Lesson” section.

GETTING STARTED

3. Creative Play

In this mode, you can play two learning games that focus on speciﬁc

gaming skills.

Note: For the details of the ‘Creative Play’ games, please refer to the

“Activities – Creative Play” section.

4. Practice Time

This mode provides two activities to encourage your creativity.

Note: For the details of the ‘Practice Time’ games, please refer to the

“Activities – Practice Time” section.

5. Options

In this screen, you can move the pen or arrow buttons up and down to

move the cursor between Chances and Music options.

Chances: Normal/Unlimited Selection

To choose between Normal and Unlimited chances of play, move the pen

or arrow buttons left or right to either “Normal” or “Unlimited” . Hold

down the pen or press the ENTER button to make your choice.

Music: On/ Off Selection

To turn the background music and sounds On or Off, move the pen or

arrow buttons left or right to either “On” or “Off” . Hold down the

pen or press the ENTER button to make your choice.

Level of Difﬁculty: Easy/Hard Levels

To change the level of difﬁculty, move the pen or arrow buttons to the left to

choose the Easy level or to the right to choose the Hard level .

STEP 2: CHOOSE YOUR GAME SETTINGS

The Art Lesson, Creative Play and Practice Time modes each have their

own game settings on their activity selection screens. Please refer to each

section for details.

STEP 3: START YOUR GAME

For Free Draw, please go to the “Activities – Free Draw” section.

For Art Lesson, please go to the “Activities – Art Lesson” section.

For Creative Play, please go to the “Activities – Creative Play” section.

For Practice Time, please go to the “Activities – Practice Time” section.

GETTING STARTED

ACTIVITIES

EDUCATIONAL CURRICULUM

Free Draw: Independent Creativity & Imaginative Skills

Art Lessons

Lesson 1 Line Drawing Basic Drawing Skills

Lesson 2 Shape Drawing Advanced Shape Drawing

Lesson 3 Shape Combination Shape Matching

Lesson 4 Color Filling Colors

Lesson 5 Color Mixing Primary & Secondary Colors

Lesson 6 Object Drawing Advanced Drawing Skills

Lesson 7 Animation Sequencing

Creative Play

Game 1 Rainbow Chase Colors, Problem Solving

Game 2 Toy Maker Logic Skills, Color Matching

Practice Time

Activity 1 Animation Maker Drawing, Sequencing, Creativity

Activity 2 Coloring Fun Colors, Creativity

FREE DRAW MODE

BASIC OPERATIONS

Move the pen upward Cursor moves upwards.

Move the pen downward Cursor moves downwards.

Move the pen to the left Cursor moves to the left.

Move the pen to the right Cursor moves to the right.

Hold down the pen Confirm your choice / use the current

function.

Cursor moves upwards.

Cursor moves downwards.

Cursor moves to the left.

Cursor moves to the right.

ENTER button Confirm your choice / use the current

function.

ACTIVITIES

Color Icons

Function Icons

Quit Icon

Cursor This is the cursor you control on the screen.

Color Icons Select it to choose a color. There are 15 colors you can

use in this activity.

Clear Icon Use it to clear all the drawings on your current

picture.

Undo Icon Use it to undo the last action you took.

Pencil Icon Use it to draw lines – the default color is black. To

select the size of the pencil line, select one of the three

different-sized lines in the pop-up menu.

Eraser Icon Use it to erase lines on your drawing. To select the size

of the eraser, select one of the three different-sized

circles in the pop-up menu.

Color Filling Icon

Use it to fill an area of your drawing with a solid color-

the default color is black.

Line and Shape Use it to draw solid or dotted lines and outlined or filled

shapes. Click in the drawing area and hold down the

pen to adjust the size of the shape. Then release the

pen to see the size. The thickness of the line and shape

depends on the current size of the pencil selected.

Stamp Icon

Select it to open a submenu. You will see a variety of

stamps. Select your favorite one and it will be added

to your picture.

Copy Icon

Use it to copy sections of your artwork to another

location.

Cut Icon

Use it to cut sections of your artwork to another

location.

Advanced Art Tools

Select it to open a pop-up menu of advanced art

tools.

ACTIVITIES

Drawing Icon

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels V-tech Jouet

V-tech

V-tech Pull & Play Kitten Manuel utilisateur

V-tech

V-tech Alphabet Apple Instructions de montage

V-tech

V-tech Soar & Learn Plane Manuel utilisateur

V-tech

V-tech My Busy Workbench Manuel utilisateur

V-tech

V-tech Switch & Go Dinos RESCUE RAIDERS 3-IN-1 Manuel utilisateur

V-tech

V-tech Count & Wobble Cody Manuel utilisateur

V-tech

V-tech Pop & Spin Mower Manuel utilisateur

V-tech

V-tech InnoTab 3 The Learning App Tablet Manuel utilisateur

V-tech

V-tech Farm & Learn Animal Wagon Manuel utilisateur

V-tech

V-tech Alphabet Classroom Manuel utilisateur

V-tech

V-tech 80-190300 Manuel utilisateur

V-tech

V-tech KidiCom Advance Instructions de montage

V-tech

V-tech Lightning McQueen Learning Laptop Manuel utilisateur

V-tech

V-tech SWITCH&GO WOLF FIRE CHIEF Manuel utilisateur

V-tech

V-tech Pull & Learn Lion Manuel utilisateur

V-tech

V-tech CoComelon Toot-Toot Drivers JJ's House Track... Manuel utilisateur

V-tech

V-tech Thomas & Friends Sodor Fun Time Station Manuel utilisateur

V-tech

V-tech Starshine the Bright Lights Unicorn Instructions de montage

V-tech

V-tech Teletubbies Press & Play Po Manuel utilisateur

V-tech

V-tech Kidizoom camera Connect Manuel utilisateur

V-tech

V-tech Dora Alphabet Journey Manuel utilisateur

V-tech

V-tech Go! Go! SmartWheels Revved Up Stunt Spiral Instructions de montage

V-tech

V-tech Ready to Race LightningMcQueen Instructions de montage

V-tech

V-tech CYBER SPY Manuel utilisateur

Manuels Jouet populaires d'autres marques

marklin

marklin 37321 Manuel utilisateur

Canon

Canon PAPER CRAFT Manuel utilisateur

GREAT PLANES

GREAT PLANES Pitts M-12S Manuel utilisateur

NOCH

NOCH 14261 Manuel utilisateur

Hausler

Hausler 450 SE V2 Manuel utilisateur

Dynaflite

Dynaflite Daydream Manuel utilisateur

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Manuel

Kenner

Kenner Batman 63651 Manuel utilisateur

LEGO

LEGO 8527 Manuel utilisateur

iKarus

iKarus ECO 8 Manuel utilisateur

Multiplex

Multiplex EasyStar II Mode d’emploi

Walkera

Walkera 38 Mode d’emploi

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE Manuel utilisateur

MD MXION SWD Manuel utilisateur

Mattel

Mattel Disney Pixar Cars Cozy Cone Spiral Rampway Manuel utilisateur

marklin

marklin 39671 Manuel utilisateur

Meccano

Meccano 15103 Manuel utilisateur

LEGO

LEGO TECHNIC 8735 Manuel utilisateur
