Uponor Climate Control Manuel utilisateur

RADIANT HEATING SYSTEMS

UPONOR CLIMATE

C O

˘NTROL™ NETWORK

SYSTEM THERMOSTAT

Uponor Climate Co

˘ntrol™ Network System

Thermostat User Manual

USER MANUAL

www.uponor-usa.com • www.uponor.ca

Uponor Climate Co˘ntrol™ Network System

Thermostat User Manual

Published by Uponor

5925 148th Street West

Apple Valley, MN 55124 USA

Phone: (800) 321-4739

Fax: (952) 891-2008

Uponor, Ltd.

655 Park Street

Regina, SK S4N 5N1 CANADA

Phone: (888) 994-7726

Fax: (800) 638-9517

www.uponor-usa.com

www.uponor.ca

First Edition

First Printing, April 2008

Printed in the United States of America

Uponor Climate Co˘ntrol™ Network System Thermostat User Manual i

Table of Contents

Section 1 — Uponor Climate Co˘ntrol™

Network System Thermostat . . . . . . . . . . . . . . . . . . . . . 3

Section 2 — Button Function and Operation . . . . . . . . 5

Thermostat Display . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Section 3 — Using the Thermostat . . . . . . . . . . . . . . . 7

Outdoor Temperature . . . . . . . . . . . . . . . . . . . . . . . . . 7

Viewing the Room Temperature Setpoint . . . . . . . . . . . . . . . . . 7

Changing the Room Temperature Setpoint . . . . . . . . . . . . . . . . . 7

Viewing the Slab Temperature Setpoint . . . . . . . . . . . . . . . . . .7

Changing the Slab Temperature Setpoint . . . . . . . . . . . . . . . . .7

Section 4 — Selecting the Operating Mode . . . . . . . . . 9

Selecting modes . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Section 5 — Changing the Fan Speed . . . . . . . . . . . . 11

Section 6 — Using the Ventilation Mode . . . . . . . . . . 13

Turning Ventilation Mode On and Off. . . . . . . . . . . . . . . . . . 13

Section 7 — Changing Ventilation Fan Speed . . . . . . 15

For two-speed equipment . . . . . . . . . . . . . . . . . . . . . . 15

For three-speed equipment . . . . . . . . . . . . . . . . . . . . . 15

Section 8 — Viewing the Relative Humidity Reading . . . 17

Section 9 — Changing the Relative Humidity Setpoint . . 19

Section 10 — Changing the Units of Temperature . . . 21

Section 11 — Setting the Backlighting Time . . . . . . . 23

www.uponor-usa.com • www.uponor.ca

Uponor Climate Co˘ntrol™ Network System Thermostat User Manual 3

The Uponor Climate Co˘ntrol™ Network is an integrated

system built to accommodate the vast majority of a

home’s heating, ventilation and air conditioning (HVAC)

applications. It uses a modular design to scale the system

to t any HVAC mechanical system.

This user manual provides standard operating procedures for

use with the Uponor Climate Co˘ntrol Network Thermostat.

Section 1 –

Uponor Climate Co˘ntrol™ Network System Thermostat

Following is a list of common terms used in this manual

and how they are dened for this product:

Term Denition

CO2 Sensor A carbon dioxide readings in a room.

HRV Heating-recovery ventilator

Slab This refers to a concrete slab under which radiant heating

has been installed

Setpoint This refers to the desired thermostat setting. The room

setpoint temperature is the target temperature for the room.

Zone An area of a radiant panel served by one or more loops

and individually controlled through a thermostat

Table 1-1: Terms Used in this Manual

www.uponor-usa.com • www.uponor.ca

Uponor Climate Co˘ntrol™ Network System Thermostat User Manual 5

Section 2 –

Button Function and Operation

The Climate Co˘ntrol Network thermostats come with

simple, easy-to-use push-buttons that allow the user to

access a variety of information and setting.

The basic button types on the thermostat are:

• Cycle button — Press the cycle button to scroll

through user settings (between setpoints and readings).

• Mode button — Press the mode button to scroll

through setup options (heat and cool mode,

schedules, etc.).

• (+) and (–) buttons — Press the + and – buttons

to change settings (setpoints, fan speeds, etc.).

Thermostat Display

The Thermostat Display consists of four elds:

• Reading — This eld displays current room temperature.

• Status — This eld shows which parts of the heating

and cooling system are currently in operation.

• System Mode — This eld displays whether the

thermostat is set to run heating, cooling, ventilation

or any combination.

• Schedule and Master — Whether the thermostat

is running a setback schedule or vacation calendar

and indicates if it is the controlling thermostat for

a given air zone.

Refer to Figures 2-2 and 2-3 to view how the elds display

on the vertical and horizontal thermostat respectively. Figure 2-1: Thermostat

Reading Field

Status Field

System Mode Field

Schedule and Master Field

Reading Field

Status Field System and

Mode Field

Schedule and Master Field

Cycle button

Mode button

Figure 2-2: Vertical Thermostat Icon Display Figure 2-3: Horizontal Thermostat Icon Display

www.uponor-usa.com • www.uponor.ca

Table 2-1:

Thermostat Display

Icon Descriptions

Note: All of the above icons may

not always be viewable or

displayed, depending on

how the Climate Co˘ntrol

Network-system is set up.

No. Name Description

1 Air Circulation Icon Indicates a stale air call

2 Relative Humidity Icon Indicates a humidity call

3 Forced-air Heating Icon Indicates the furnace is delivering air heat

4 Forced-air Cooling Icon Indicates the air conditioner is delivering air cooling

5 Ventilation Icon Indicates the ventilation system is running

6 Fan Icon Indicates the fan is running

7 Fan Speed Indication Icon Indicates fan speed(if multiple speed is available)

8 Ventilation Mode/

Outdoor Temperature Icon

Indicates the ventilation mode is turned on (when available);

also appears when the outdoor temperature is viewed

9 Vacation Schedule Icon Indicates that the vacation schedule is enabled

10 Character Display Displays numeric settings

Note: When temperatures are displayed in °F, only full

degree increments are available.

11 Unit Icons Displays the current units (°C or °F)

12 Slab Icon Indicates when the slab settings are viewed or modied

13 Radiant Heating Icon Indicates the radiant heating system is running

14 Supplemental Heat Icon Indicates when supplemental heating is running

(e.g., baseboard heating)

Cooling Mode Icon

Heating Mode Icon

Indicates the system is in cooling mode

Indicates the system is in heating mode

17 Master Thermostat Icon Indicates that the thermostat is designated as an air zone’s

master thermostat

18 Schedule Enabled Icon Indicates that a schedule is enabled

Figure 2-4: Thermostat Display

Each of the elds display specic

icons to show the modes and

functions of the thermostat. Refer

to Figure 2-4 and Table 2-5 for

detailed information about each icon.

Uponor Climate Co˘ntrol™ Network System Thermostat User Manual 7

Outdoor Temperature

Press the cycle button once to view the outdoor

temperature. The LCD shows both the outside temperature

and the outdoor temperature icon as shown in Figure 3-1.

Figure 3-1: Outdoor Temperature Icon

Viewing the Room

Temperature Setpoint

The thermostat displays the current room temperature

while static or while no button is pressed. The display

returns to the current room temperature after ve seconds

of the last button press.

Changing the Room

Temperature Setpoint

The room temperature setpoint is the target temperature

for the room that the thermostat controls. When viewing

the room temperature on the display, use the (+) or (–)

buttons to change the room temperature setpoint.

• Press the (+) button to increase the room temperature

setpoint by 1.0°F or 0.5°C degree increments

depending on the temperature units displayed.

• Press the (–) button to decrease the room temperature

setpoint by 1.0°F or 0.5°C degree increments

depending on the temperature units displayed.

Viewing the Slab Temperature

Note: The slab temperature readings and settings are only

available if the slab sensor is installed.

The slab temperature is the current temperature of the

radiant panel. This temperature is viewable for radiant

heating and/or radiant cooling.

To view the slab temperature, press the cycle button three

times or until the display shows the slab icon blinking.

The display now shows the temperature of the slab.

Figure 3-2: Slab Temperature Icon

Changing the Slab

Temperature Setpoint

Note: Slab temperature readings and settings are only

available if the slab sensor is installed.

The slab temperature setpoint is the target temperature

of the radiant panel. To change the slab temperature

setpoint, use the following procedure:

• Press the cycle button three times or until the

blinking slab icon appears.

• Press the (+) button to increase the slab temperature

setpoint by 1°F or 0.5°C degree increments depending

on the temperature units displayed. Press the (–)

button to decrease the slab temperature setpoint by

1°F or 0.5°C degree increments depending on the

temperature units displayed.

Section 3 –

Using the Thermostat

www.uponor-usa.com • www.uponor.ca
