Ubiquiti AirMax AC Manuel utilisateur

UbiquitiNetworksSupportandHelpCenter /airMAX /ConfigurationGuides

airMAX-ConfigureaWi-FiaccesspointclusterinAPWDSrepeater

mode

August13,201513:44

Overview

ReaderswilllearnhowtoconfigureradiosinaPtP"repeater"modetopology.Thisgoesby

manydifferentnameslikeWDSRepeater,RepeaterSetup,RepeaterBridge,etc.Basically,

twoormoreAccessPointsworktogethertoextenda wirelessnetwork.Thecaveattothis

repeatermodeisanaddeddegreeofinstability(especiallyasthenumberofRepeaterAPs

increases)andadecreaseinthroughputby50%perhop.

UBNT Support

Pagina

airMAX

Configure a Wi

Fi access point cluster in AP WDS repeater mode

–

Ubiq

...

21/

04/

2016

https://help.ubnt.com/hc/en

us/articles/205197620

airMAX

Configure

access

...

TwoormoreairMAXradioscanbeconnectedinaWDSrepeatertopologytoextenda

wirelessnetworkandallowclient-hotspotaccessateachAP.

Steps

1. The instructions assume that your radio is set toFACTORYDEFAULTvalues.

Please restore to factory defaults before proceeding. This is critical, especially if you are

troubleshootingaproblem.

2. With yourWindows7PC orMaccomputer configured to the 192.168.1.x subnet,

connect it to the radio using an Ethernet cable. The Ethernet port is auto-sensing. You

arenotrequiredtouse acrossovercable.

3. Usingawebbrowser,enter192.168.1.20asthe"URL"togainaccesstotheradio's

managementconsole.

4. Enter"ubnt"astheadministrationaccountand"ubnt"asthepassword.

ConfigurationInstructions(changeONLYtheitemsshown,leavingothersat defaultvalues):

AccessingtheairMAXradio:

1. RestoreyourradiotoFACTORYDEFAULTvalues.Thisiscritical,especiallyifyou

aretroubleshootingaproblem.

2. ConnecttheradiotoyourcomputerusinganEthernetcable.TheEthernetportis

auto-sensing.Youarenotrequiredtouseacrossovercable.

3. Usingawebbrowser,enter192.168.1.20asthe"URL"togainaccesstotheradio's

managementconsole.

4. Enter"ubnt"astheadministrationaccountand"ubnt"asthepassword.

ConfiguretheradiolabeledasIP=192.168.1.2above:

A.Choosethe|Wireless|tab,andchangeonly:

Pagina

airMAX

Configure a Wi

Fi access point cluster in AP WDS repeater mode

–

Ubiq

...

21/

04/

2016

https://help.ubnt.com/hc/en

us/articles/205197620

airMAX

Configure

access

...

• WirelessMode:AP-Repeater

•WDS Peers: AA:BB:CC:00:00:03 (Example only. Use the actual MAC address of the

OTHERradio)

• ChannelWidth:20 MHz

•Frequency: Choose one from the list. NOTE: "Channel 1" = 2412, "Channel 6" =

2437,"Channel11"=2462

• Press[Change]button

B.Choosethe|Network|tab,andchangeonly:

• IPAddress:192.168.1.2

• Press[Change]Button

C.Choose|UbiquitiLogo|tab

• AirMax:[]enable(UN-check)

• Press[Change]Button,Press[Apply]Button

DONE with this radio. Repeat 1-4 with the second radio, then continue below.

'''ConfiguretheradiolabeledasIP=192.168.1.2above:'''

D.Choosethe|Wireless|tab,andchangeonly:

• WirelessMode:AP-Repeater

• WDSPeers:AA:BB:CC:00:00:02(Exampleonly.UsetheactualMACaddressofthe

OTHERradio)

• ChannelWidth:20MHz

• Frequency:ChooseTHESAMEfrequencythatyouchoseabove.

• Press[Change]button

Pagina

airMAX

Configure a Wi

Fi access point cluster in AP WDS repeater mode

–

Ubiq

...

21/

04/

2016

https://help.ubnt.com/hc/en

us/articles/205197620

airMAX

Configure

access

...

E.Choosethe|Network|tab,andchangeonly:

• IPAddress:192.168.1.3

• Press[Change]Button

F.Choose|UbiquitiLogo|tab

• airMAX:[]enable(UN-check)

• Press[Change]Button,Press[Apply]Button

DONE

'''IfusingaCable/DSLModem:'''

G.RebootorpowercycletheCable/DSLmodemoffandonbeforeusingthislink.

'''DONE'''

Notes

1-Secureyourinstallation-modifythedefaultadministrationaccount

• Select|System|tab> SystemAccounts

• AdministrativeUsername[changeitfrom'ubnt']

• Hoverovericontotheright,"ChangePassword"andchangeit

• Press[Change]button,press[Apply]button

2-SecureyourWi-Fifromunauthorizeduse(unlessyouintendtorunanopenAP/HotSpot)

Pagina

airMAX

Configure a Wi

Fi access point cluster in AP WDS repeater mode

–

Ubiq

...

21/

04/

2016

https://help.ubnt.com/hc/en

us/articles/205197620

airMAX

Configure

access

...

• Select|Wireless|Tab>WirelessSecurity

• Security>WEP(thisistheONLYencryptionavailableinthismode)

• PresharedKey:[entersomethinglong,butmemorabletoyou]

•Press [Change] button. Press [Apply] button.

Variations

ThefigurebelowshowsfiveconnectedaccesspointswithonecentralAPperformingthe

repeatingfunction.

Wasthisarticlehelpful? 1outof1 foundthishelpful

 
