Ubiquiti EdgeRouter ER-12P Manuel utilisateur

EdgeRouter ER-12P Wall Mount Screws (Qty. 2) Wall Mount Anchors (Qty. 2)

Ground Screw Power Adapter (24V, 2.5A) Power Cord

Package Contents

Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Cable Clip

Installation Requirements

Wall mounting (optional)

Drill with 6 mm drill bit

Phillips screwdriver

For indoor applications, use Category 5 (or above) UTP cabling approved for indoor

use.

For outdoor applications, shielded Category 5 (or above) cabling should be used for

all wired Ethernet connections and should be grounded through the AC ground of the

power supply.

We recommend that you protect your networks from harmful outdoor environments

and destructive ESD events with industrial-grade, shielded Ethernet cable from

Ubiquiti. For more details, visit: ui.com/toughcable

Hardware Overview

Note: Although the cabling can be located outdoors, the EdgeRouter itself

should be housed inside a protective enclosure.

Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

System LED

Flashing White Bootup in progress.

White

Ready for use, not connected to Ubiquiti® Network

Management System (UNMS™). See “UNMS

Management”.

Blue Ready for use, connected to UNMS.

Steady Blue with

Occasional Flashing

Ready for use, unable to connect to UNMS, check

connection to UNMS server.

Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

RJ45 PoE LED (Ports 0 - 9)

RJ45 Speed/Link/Activity LED (Ports 0 - 9)

SFP Link/Activity LED (Ports 10 - 11)

Quickly Flashing Blue Used to locate a device in UNMS.

Alternating

Blue/White Firmware upgrade in progress.

Off No PoE

Green 24V Passive PoE Output

Off No Link

Amber Link Established at 10/100 Mbps

Amber Flashing Link Activity at 10/100 Mbps

Green Link Established at 1000 Mbps (1 Gbps)

Green Flashing Link Activity at 1000 Mbps (1 Gbps)

Off No Link

Green Link Established at 1 Gbps

Green Flashing Link Activity at 1 Gbps

Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Console

USB

RJ45 (Ports 0 - 9)

SFP (Ports 10 - 11)

Reset Button

Power

Grounding Point

RJ45 serial console port for Command Line Interface (CLI) management.

Reserved for future use.

All RJ45 ports can be used for routing. They support 10/100/1000 Mbps Ethernet

connections and 24V Passive PoE output. Ports 0 - 7 can be configured for

switching functions using the EdgeOS® Configuration Interface.

SFP routing ports are hot-swappable and support Gigabit fiber SFP modules.

Click here to learn how to reset an EdgeRouter to factory defaults.

Connect the included Power Adapter to the Power port.

Ground bonding point for an optional ground wire.

Hardware Installation

Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Wall Mounting

1.

2.

Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

3.

Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

4.

Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Grounding the EdgeRouter (Recommended)

The Power Adapter grounds the device; however, you can add optional ESD grounding

for enhanced ESD protection (ground wire not included).

Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Optional

Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD
